Chapter 1 Introduction
Thank-you for purchasing our latest state-of-the-art Multimedia notebook computer!
Whether you are a no-nonsense traveling business executive, who are occasionally tied
down by your company’s local area network, or a die-hard multiMedia fan who spends
elaborated hours on the internet; you will find your investment on this notebook worth
the money you have paid for a long time to come.
You are holding one of the most powerful, feature-rich and expandable notebook ever
made. We encourage you to read over this manual to familiarize yourself with all the
capabilities that your machine has to offer. For those of you who just cannot wait to get
start, please take time to read the Safety Instructions at the very beginning of this manual,
the Overview in this chapter, the basic operations in Chapter 2, and Configuring Your
System as explained in Chapter 11. Then you can go ahead and get start with your new
notebook!
Overview
Internally, the notebook uses the Intel’s latest generation of Pentium III SpeedStep
processor, and Intel’s premium North-Bridge/South-Bridge PCI bus architecture. The
ATI’s latest VGA chip-set together ESS’s audio chip-set has made this notebook is an
ideal choice for sober MultiMedia lovers. Externally, the notebook provides a wide
choice of ports and connectivity; such as PCMCIA socket, USB ports, infrared port,
internal fax/modem port (optional), LAN connection port (optional), external CRT,
Television (NTSC/PAL), and many others. This would definitely make the life of a travel
executive a lot easier, off-site, at home, and in the office.
With this notebook, upgrades have never been easier. You can switch CPU processor
among the Intel’s Pentium III 400MHz to 700MHz.Your system memory is easily
upgradeable from 64MB up to 512MB. The hard disk system can handle most of the
9.5mm or 12.7mm IDE industry standard drives, giving you virtually unlimited storage
capability.
Battery life (or more appropriately the duration of which a notebook unit be able to
operate without an AC outlet) is an important issue. Knowing this, we have incorporated

Introduction Model 700A User's Manual
Page 1-2 Information in this document is subject to change without notice!!!
the latest Advanced Power Management (APM) and/or Advanced Configuration
Power Interface (ACPI) for energy saving.
While we hope that this overview has made you aware of some the most exciting features
of your new computer, there is still much more to the notebook. The remainder of this
manual is dedicated to helping you get the most out of your new notebook. Please read
each chapter carefully and we recommend you to explore each of the explained functions.
Now, read on to find out more about what the amazing notebook can do for you!

Model 700A User's Manual Introduction
Information in this document is subject to change without notice!!! Page 1-3
1.1 Standard Features
SYSTEM
■Intel µPGA-II Pentium III 400MHz to 700MHz with 64KB L1 cache and
128KB/256KB L2 cache.
þCore Logic: North Bridge, Intel AGPset FW82443ZXM-100.
South Bridge, Intel PCIset PIIX4 FW82371.
■Two S.O. DIMM memory sockets upgradeable from the basic 32MB to 256MB
memory.
■256Kb Flash ROM contains BIOS and is easily user upgradeable.
■Hard Disk Drive (HDD) is conveniently user changeable.
DISPLAY
■ATI RAGE Mobility-M1/M3 PCI/AGP 1x/2x with MCM memory 8MB, and
16MB.
■LCD only, CRT only, TV only, and LCD/CRT simultaneous.
■Display Panel: TFT 12.1” XGA, 800*600
TFT 13.3” XGA, 1024*768
TFT 14.1” XGA, 1024*768
STORAGE DEVICE
■User changeable industry standard 9.5mm hard disk drive, or latest Ultra DMA 33
hard disk drive.
■Industry standard 3.5inch 1.44MB floppy disk drive.
■32x CD-ROM, or 8x DVD-ROM drive.

Introduction Model 700A User's Manual
Page 1-4 Information in this document is subject to change without notice!!!
KEYBOARD
■87 full keys, including 2 Windows keys, and embedded numerical keypad.
■External PS/2 keyboard connector located on the back of notebook.
CONNECTIVITY and EXPANSION
■Built-in TouchPad, IBM PS/2 mouse compatible.
■One Serial D-type 9-pin COM1 connector.
■One 6-pin mini DIN external keyboard, or PS/2 mouse connector.
■One 15-pin D-type connector for external VGA monitor.
■One parallel port 25-pin D-type for printer, or pocket LAN. High-speed bi-
directional port under either hardware or software control (EPP/ECP compliance).
■One type 2 PCMCIA slot.
■Two USB connectors.
■One earphone connector.
■One external microphone-in connector (mono).
■One S-Video jack for television connection.
■One RJ11 Fax/Modem connector.
■One RJ45 LAN connector.
■One IEEE 1394 connector.
■One IrDA port.
POWER
■One battery slot to support 3000mAH Lithium Ion (Li-Ion), or 4500mAH Nickel
Metal Hydride (NiMH) battery pack.
■Offline battery charging time is around two-and-a-half hours.

Model 700A User's Manual Introduction
Information in this document is subject to change without notice!!! Page 1-5
■Full range 100 to 240V auto-switch AC adapter.
PHYSICAL
Weight (TFT color, 14.1”) : 3.2kg
Length/Width/Height : 305.0mm/250.0mm/39.5mm
Note: Weight and height might change due to different configurations and models.
ENVIRONMENT
Operating Temperature : 10ºC to 35ºC
Non-Operating Temperature : -20ºC to 60ºC
Humidity : 20% to 80% non-condensing
Shock : 5G operating, 60G non-operating
Vibration : 3-200Hz @ 1.0G operating
: 3-200Hz @ 1.5G non-operating
Warning: Don't expose your notebook to excessive heat or coldness (frost).
Don't drop, spill fluids or open the exterior of the case. This can
damage the notebook and void the warranty.
POWER MANAGEMENT
Industry standard Advanced Power Management (APM) 1.2, and Advanced
Configuration Power Interface (ACPI) 1.0.
OPERATING SYSTEM
Windows 98 SE (ACPI or APM), Windows 2000, and Widows Millennium.

Introduction Model 700A User's Manual
Page 1-6 Information in this document is subject to change without notice!!!
OPTIONS
■Standard SDRAM S.O. DIMM self-fresh 32MB, 64MB, and 128MB memory
module for expansion from 32MB to 256MB.
■Additional Lithium Ion (Li-Ion), or Nickel Metal Hydride (NiMH) battery pack.
■LAN/Modem Combo Card for Ethernet LAN connection and Fax/Modem
connection.

Model 700A User's Manual Introduction
Information in this document is subject to change without notice!!! Page 1-7
1.2 Special Features
Power Management
Power Saving can be switched to Customized or Disabled in the BIOS Setup.
System will enter Suspend-To-RAM mode (with the LCD panel automatically
turned off), when the cover is closed.
Advanced Power Management (APM), and ACPI supports.
Depending on user’s setup, system enters Suspend Mode (Suspend-To-RAM
or Save-To-File) when no device activity occurs after an user selected time
duration.
In Suspend-To-RAM mode, all major devices and components (including
VGA chip and LCD panel) are shutdown to save energy.
In Save-To-File mode, system is completely shutdown for energy saving. Low
Battery Activity allow system to save memory contents and system activities
into a disk file called Save-To-File (refer to Chapter 10). When you power on
the system again, the system will return to exactly where you left off.
The Hard Disk Drive, HDD, would spin down for power saving if there is no
HDD access for an extended period of time.
Memory Expansion
System Memory, upgradeable from 32MB to 256MB. For more information, refer to
Chapter 7.
Hot Keys
Please see Appendix B for all available Hot Key functions; such as Contrast and
Brightness adjustment, and Suspend-To-RAM and Save-To-File etc.

Introduction Model 700A User's Manual
Page 1-8 Information in this document is subject to change without notice!!!
TouchPad
The TouchPad is conveniently located, making it easily accessible to both left and right
handed people. There are two buttons at the bottom of the TouchPad, emulating the right
and left mouse buttons. Use your finger as a mouse pointer to draw lines or point to an
item as needed. Double click (tap) on the TouchPad to simulate mouse button clicking.
Note: You are advised to clean your TouchPad with a dry cloth in a regular basis.
Grease, dirt, and moisture on the TouchPad can lead to abnormal mouse
operations.
PCMCIA
PCMCIA card provides many powerful features for your notebook. Many cards are
available today such as: Fax/Modems, Network Adapter, and SCSI Adapters. The
PCMCIA unit in your notebook provides connections to one type 2 (5mm height).
SOUND SYSTEM
This internal sound card provides you 16-bit CD-quality stereo sound, and it is Sound
Blaster Pro compatible. The notebook includes built-in stereo speakers, microphone, and
connectors for line-in, line-out, microphone-in, and earphone.

Model 700A User's Manual Before You Begin
Information in this document is subject to change without notice!!! Page 2-1
Chapter 2 Before You Begin
Please read this section before you start using your computer.
2.1 Checking What You Received
Your notebook package should contain the following items:
USER' S MANUAL
b) c) d) e) f)
Note: You should keep the original factory carton and packing materials in case
you need to ship the unit back for servicing.
a) The notebook (without Battery
Pack).
b) Battery Pack
c) AC Adapter
d) AC Power Cable
e) CD-ROM Disc (for Drivers/
Utilities)
f) User’s Manual
a)

Before You Begin Model 500V User's Manual
Page 2-2 Information in this document is subject to change without notice!!!
2.2 Examining Your Computer
Before you start using your computer, you need to get acquainted with your notebook's
main features and interfaces:
A Panoramic View of the notebook
Power Switch
TouchPad
Cover Lock
The Seven System LEDs
LCD Switch
LCD Screen

Model 700A User's Manual Before You Begin
Information in this document is subject to change without notice!!! Page 2-3
View of the Left Panel
DC COM1 USB VGA
Kensington
in Port Ports Port Lock
Rear View
Ventilation PS/2 Replicator Printer S-Video
Hole Port Port Port Port
DVD-ROM/ Emergency
CD-ROM Eject
Drive
E
j
ect Button

Before You Begin Model 500V User's Manual
Page 2-4 Information in this document is subject to change without notice!!!
View of the Right Panel
Two Types of Audio Jet
Stereo Connector: Your
Earphone, Line-In, and
Line-out jets should have
this type of connector as
shown here.
Mono Connector: Your
Microphone jet should
have a connector as
shown here.
Floppy IrDA Microphone Modem Heat
Drive Connector Venting
Grill
LAN IEEE Two PCMCIA
Connector Headphone 1394 Sockets

Model 700A User's Manual Before You Begin
Information in this document is subject to change without notice!!! Page 2-5
View of the Front Panel
The DiscPlay Function
Your notebook supports a state-of-the-art DiscPlay Function, whereby you can playback
audio CD without booting up the system. With a fully charged battery, the system can
continuous play audio CD for several hours. The buttons listed below work only when the
system is in DiscPlay mode:
•Audio CD Play Button
•Audio CD Stop Button
•Audio CD Previous Track Button
•Audio CD Next Track Button
•Volume Up Button
•Volume Down Button
You can switch the DiscPlay Function on/off by pressing the Discplay Switch to the
right. The DiscPlay can be switched ON only when the system is not booted up, or when
the system is in Suspend-To-File (STF) mode.
Audio CD Play Button Cover Latch
Audio CD Stop Button DiscPlay Switch
Left Speaker Right
Speaker
Audio CD Previous Track Button
Audio CD Next Track Button Volume The Two
Up Power
Audio CD Track# Display Volume Button Icons
Down
Button

Before You Begin Model 500V User's Manual
Page 2-6 Information in this document is subject to change without notice!!!
2.3 The Two Power LEDs
The Battery Pack LED
•LED on- The battery pack is being recharged
•LED off- The battery pack is fully recharged
•LED flashes (1/2 second on; ½ second off)- The battery pack is either in
Battery LOW-2 stage, or the battery pack is in pre-charge.
•LED flashes (1 second on; 2 second off)- The battery pack is bad
The Power On LED
•LED on- The system is powered on
•LED off- The system is powered off
•LED flashes- The system is in Suspend-To-RAM (S2R)
Note: For exact location of the Two Power LEDs, please refer to the View of the
Front Panel diagram in Chapter 2.2.
For more information on Battery Low-2 and pre-charge, please refer to
Chapter 6.
