Meyer Sound Self-Powered Reinforcement Loudspeaker MTS-4 User manual

R
SPL
➪
selection, EMI filtering,
soft current turn-on, surge
suppression, and dual
circuit breakers. Simply
plug in a power source and
an audio signal.
The power system utilizes a
dual fan, forced-air cooling
system which removes the
heat from the heatsink and
exhausts it to the rear. Since
air is not directed over the
electronics themselves, dirt
cannot accumulate on sensitive
components—increasing the
reliability of the amplifiers.
The amplifier unit
is equipped with TruPower™
Limiter technology, which
maximizes speaker protection
reliability and component life.
This breakthrough in speaker
control also results in higher
SPL at all frequencies, and
The MTS-4 is a fully integrated
unit, containing all the drivers
and amplifiers needed to
handle both high frequencies
and lower sub-harmonics.
No extra subwoofers and no
extra amplifiers are needed,
and all of this comes in
only seventeen cubic feet
of cabinet.
Each of the three low
frequency drivers has its own
vented chamber, creating
acoustical addition that gives
the MTS-4 its impressive
output levels. Its high
frequency horn rounds-out the
audio spectrum to produce a
wide, flat frequency response
(±3dB from 30Hz to 16kHz).
The MTS-4 is easy to set up.
The power supply utilizes the
Intelligent AC™system, which
provides for automatic voltage
FEATURES
increased available headroom.
Long term power compression,
typically 3-6 dB in conventional
systems, is less than 1 dB.
Maximum SPL capability
remains constant even during
operation at high levels for
extended periods.
MTS-4 performance can be
supervised using the Remote
Monitoring System™(RMS).
This enables users at a
computer terminal to monitor
such parameters as limiting
activity, power output, voltage,
temperature, fan speed,
and driver status.
Servicing of the MTS-4 is
facilitated by a rear access
panel; the entire power/
amplifier module
can be removed and replaced.
Self-Powered Reinforcement Loudspeaker
MTS-4
Integrated control
electronics and amplifiers
TruPower∆
™
Limiting (TPL)
Intelligent AC™ System
Compatible with the
Remote Monitoring
System™(RMS)
Exceptional
low-frequency
High Peak SPL Capability
Wide audio range
in one unit
4-way active,
corrected x-over
PATENTED
Meyer
Sound
Superior
engineering
for the art
and science
of sound.

Acoustical
(each loudspeaker)
Coverage
Crossover
Transducers
Audio Input
Amplifiers
AC-Power
Physical
Notes
56.75
30.00
7.5°
14.125
28.5
PHYSICALDIMENSIONS
MTS-4 SPECIFICATIONS
Frequency Response1
Phase Response1
Maximum SPL1
Dynamic Range
(-6 dB points)
Sub Frequency
Low Frequency
Middle Frequency
High Frequency
Type
Connector
Nominal Input Level
Type
Burst capability2
THD, IM, TIM
Connector
Automatic voltage selection
Operational Voltage Range
Max Continuous RMS Current (>10 sec)
Burst RMS Current (<1 s)
Max Peak Current During Burst
Soft Start Turn-on
Dimensions
Weight
Enclosure
Finish
Protective Grill
Rigging
±3 dB from 30 Hz to 16 kHz
-6 dB at 26 Hz and 18 kHz
±70°from 90 Hz to 17.2 kHz
140 dB peak@1 meter
>110 dB
70°H; 60°V
40 Hz, 100 Hz, 1 kHz
18” diameter MS-18 cone
15” diameter MS-15 cone
12” diameter MS-12 cone
2” throat (4” diaphragm) MS-2001A compression driver
10kΩimpedance, electronically balanced
XLR (A-3) male and female
+4 dBu
Complementary power MOSFET output stages (audio class AB/H)
2480 watts (620 watts/channel)
<.02 %
250V NEMA L6-20P (twistlock) inlet or IEC 309 male inlet3
95-125 VAC and 208-235 VAC; 50 Hz / 60 Hz4
Turn on: 85 VAC; Turn off 134 VAC; 50/60 Hz
Turn on: 165 VAC; Turn off 264 VAC; 50/60 Hz
@115 V: 14 A @230 V: 7 A @100 V: 16 A
@115 V: 26 A @230 V: 13 A @100 V: 30 A
@115 V: 36 Apk @230 V: 18 Apk @100 V: 42 Apk
Inrush current <12A @ 115V
21 1⁄4” W x 56 3⁄4” H x 30” D
280 lbs (127 kg)
Multi-ply hardwood
Black textured
Perforated metal grill, fiberglass screen
Aircraft pan fittings (3 on top, 2 on bottom).
Working load for each fitting is 600 lbs, which is 1⁄5the
1. Subject to half space loading, measured with one-third
octave frequency resolution in fixed ISO bands.
2. Nominal 8Ωresistive load, pink noise, 100V peak.
3. Other connectors available.
4. The unit is rated at 95-125 VAC and 208-235 VAC, 50/60 Hz, to satisfy EC
standards for –10% to 6% AC line voltage.
ALL UNITS IN INCHES
Meyer Sound Laboratories, Inc.
2832 San Pablo Avenue
Berkeley, CA 94702
tel: [phone]
fax: [phone]
e-mail: [email protected]
http: www.meyersound.com
UL
C
UL
®®
LISTED
3K59
COMMERCIAL
AUDIO SYSTEM
Meyer Sound Laboratories
has devoted itself to
designing, manufacturing,
and refining components
that deliver superb sonic
reproduction. Every part of
every component is
designed and built to
exacting specifications
and undergoes rigorous,
comprehensive testing
in the laboratories.
Research remains an
integral, driving force
behind all production.
Meyer strives for sound
quality that is predictable
and neutral over an
extended lifetime and
across an extended range.
Made by Meyer Sound, Berkeley, CA, USA
European Office:
Meyer Sound Europe
Dalston House
39-49 Hastings Street
Luton Bedfordshire
England, LU1 5BE
© 1998 Meyer Sound Laboratories, Inc.
All rights reserved
30.26
21.97
13.36
13.16
10.63
21.26
30.00
7.5°
14.125
13.00
MTS-4 - 04.029.010.01B
