Mi P1 User manual
12
34
USB 2.0
USB 2.0
TunerSatellite
Android TV
3840×2160 (4K)
100-240V~ 50/60Hz
60Hz
Quad-core CA55
2GB DDR
16GB eMMC
Mali G52 MP
2.4GHz/5GHz
BT4.2/5.0
FLAC; AAC; OGG;Dolby Audio; DTS-HD
Model
Power Consumption
Screen size
Screen resolution
Voltage
Refresh rate
CPU
RAM
Flash Storage
Graphics processor
Wi-Fi
Bluetooth
Audio formats
Video formats
Specs 55"50"43"
L43M6-6AEU
105W
108cm
L50M6-6AEU
125W
125.7cm
L55M6-6AEU
150W
138.8cm
Dolby Vision, MPEG 1/2/4;
H.263; H.264; H.265; VP8; VP9
Dolby Vision, HDR10+,
MPEG 1/2/4; H.263; H.264; H.265; VP8; VP9
CI CARD
AV composite cable Blu-ray/DVD
HD player
Computer Game console
Blu-ray/DVD Digital set-top box
Ethernet port
English
Power:
Audio Track:
Number Buons:
INFO:
TTX:
Input:
Seings:
CH List:
Google Assistant:
Netflix:
Prime Video:
OK:
Direction:
Back:
Patchwall Home:
Android TV Home:
Exit:
Volume:
Channel:
Mute:
Color Buons:
Turn On and Off the TV.
Select audio track from multiple audio tracks.
Gives direct access to channels.
Short press to launch info bar.
Select or exit Teletext mode.
Press to select available video sources.
Displays the main on-screen menu.
Press to show channel list or to switch to watch TV when current watching is not on
Live TV.
Press the Assistant button on your remote to use your Google Assistant*.
Gives direct access to Netflix application.
Gives direct access to Prime Video application.
Press to confirm current selection during navigation. You can pause/play the current
video during playback, except Live Channels (Set-Top Box or RF).
Navigate up/down or left/right through content. During playback use left/right
buttons to rewind/fast-forward.
To go back to the last channel, or to close a menu or a application, or to go back to the
previous menu.
Short press to quickly return to the PatchWall Home screen.
Short press to quickly return to the Android TV Home screen. Long press to open App
drawer.
Quit the menu.
To adjust the volume level. Long press Volume “-” button will mute immediately.
On live TV mode, Move the button up or down to select the channel.
Short press to mute/un-mute the volume.
Select options directly.
• Using the remote control
Input
INFO
CH List
Netflix
Google Assistant
Color Buttons
TTX
Settings
Prime Video
AAA Batteries × 2
Direction
Back
Android TV Home
Channel
OK
PatchWall Home
Volume
Power
Number Buttons
Audio Track
Exit
Mute
Press and buttons simultaneously,
while pointing the remote at the center of your TV.
Long press Volume “-” buon
will mute immediately
* The Google Assistant is not available in certain languages and countries.
English
Installation
• The TV should be installed near an AC power outlet that can be
easily plugged and unplugged.
• Place the TV on a smooth, flat surface to avoid the TV falling and
causing injury, or damaging the TV.
• If you intend to install a TV wall mount, we recommend that you use
an authorized TV wall mount.
• The diameter and length of the screws will vary depending on the
wall mount model. Failure to use the correct screws may cause the
TV to fall or lead to internal damage.
Moving
• Disconnect all cables before moving the TV.
• Large TV need 2 or more people to move safely. Avoid applying
pressure to the LED panel when moving the TV. Avoid shaking the
TV or exposing it to excessive vibrations.
• When moving the TV to a new location or to carry out repairs,
package the TV using the original box and packaging materials.
Ventilation
• Do not cover the ventilation holes or insert any objects into the
case.
• Keep a space for ventilation around the TV.
Wall mounting
In order to ensure proper ventilation and prevent the buildup of dust
or dirt:
• Do not mount the TV flat, upside-down, or backwards, or side
mount the TV.
• Do not place the TV on a shelf, carpet, bed, or closet.
• Do not cover the TV with fabric (such as curtains) or other
materials (such as newspapers).
AC power cord
Use the AC power cord and socket according to the instructions
below to avoid fire, electric shock, damage, or personal injury:
• Insert the plug completely into the AC outlet.
• Use the TV with a 100-240V AC power supply.
• When connecting cables, the AC power cord should be unplugged
for safety reasons. Be careful not to trip over cables.
• Before carrying out work or moving the TV, disconnect the AC
power cord from the AC power outlet.
• Keep the AC power cord away from heat.
• Unplug the AC power plug and clean it regularly. If the plug is
covered with dust and has water vapor, its insulation quality may
deteriorate, producing a fire risk.
• Avoid excessive pinching, bending, modifying, or twisting of the AC
power cord, otherwise the wires may become exposed or broken.
• Do not place any heavy objects on the AC power cord.
• Do not pull the AC power cord when disconnecting the power.
• Do not connect too many devices on the same AC power outlet.
• Do not use unsuitable AC power outlets.
Children
• Do not let children climb the TV.
• Place small objects out of the reach of children in order to avoid
swallowing.
Optional items
• Keep optional accessories or any devices that emit
electromagnetic radiation away from the TV in order to avoid image
distortion or noise.
In case of the following problems ...
• The AC power cord is damaged.
• The AC power outlet is not suitable.
• The TV is damaged due to a drop or impact.
• Any liquid or solid object falls into the case through an outlet, turn
off the TV and immediately unplug the AC power cord.
Usage restrictions
Do not install/use the TV in the following places, environments, or
conditions, otherwise the TV may malfunction and cause a fire,
electric shock, damage, or personal injury.
• Places:
Outdoors (in direct sunlight), by the sea, in a ship or other vessel,
inside a car, in a medical institution, at an unstable location, next to
water, or in a place exposed to rain, moisture, or mildew. If the TV is
placed in the dressing room of a public bath or spa, it may be
damaged by the sulfide in the air.
• Environment:
Hot, damp, or dusty places; places where insects may enter; places
that may be exposed to mechanical shock; next to flammable objects
(such as candles). The TV should not be exposed to dripping or
splashing water, and do not place any items containing liquid such as
flower vases on top of the TV. Do not place the TV in a damp or dusty
place, or in a room with steam or fumes (near a stove or humidifier) to
avoid fire, electric shock, or deformation. Do not boil water, heat,
cook noodles, or use mosquito coils near the TV.
• Conditions:
Do not use the TV when your hands are wet, when the case is open,
or with accessories that are not authorized by the manufacturer. In
the case of a lightning storm, disconnect the TV from the AC power
cord and AC outlet. Do not install the TV in an open-air location.
Failure to follow these conditions may result in personal injury or
damage, or cause objects to strike the TV.
• Damage to Mi TV screen
Do not throw any objects toward the TV, otherwise the screen may be
broken due to the impact and cause serious injury. In case of damage
to the surface of the TV, do not touch the TV before the AC power
cord has been unplugged, otherwise electric shock may occur.
• Operating conditions:
Operating temperature: 0°C–40°C; Storage temperature: -15°C–45°C;
Relative humidity: <80%.
Precautions
• Watch TV in appropriate lighting conditions. Watching TV in
insufficient light or for long periods can damage your eyesight.
• The screen and case will get hot when the TV is working. This is
normal.
• Not support the decoding of DTS-CD bitstream coming in from
HDMI IN.
Using and cleaning the screen/case of the Mi TV
Before cleaning the LED TV, ensure that the AC power cord is
disconnected from the AC power outlet. In order to avoid
deterioration of the casing materials or corroding the screen coating,
please observe the following precautions.
• Wipe with a soft cloth to remove any dust on the surface of the
screen/case. If there is still dust, wipe with a soft cloth that has
been moistened with a mild detergent.
• Do not spray water or detergent directly onto the TV. It may drip to
the base of the screen or external parts, causing malfunction.
• Do not use scrub pads, alkaline/acid cleaners, scouring powder, or
volatile liquids, such as alcohol, volatile oils, thinners, or
insecticides. The use of the above materials or prolonged contact
with rubber or vinyl products may cause damage to the screen
surface and casing materials. It is recommended that you regularly
clean the vents to ensure proper ventilation.
• When adjusting the angle of the TV, slowly move the TV to prevent it
moving or slipping from the base.
RoHS compliance – European Union
Xiaomi products sold in the European Union, meet the requirements
of Directive 2011/65/EU and its subsequent amendments directive
(EU) 2015/863 on the restriction of the use of certain hazardous
substances in electrical and electronic equipment
Simplified EU Declaration of Conformity
Hereby, Beijing Xiaomi Electronics Co.,Ltd declares that the radio
equipment type MI TV is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the
following internet address:
http://www.mi.com/global/service/support/declaration.html
RF Frequency and Power
This device offers the following frequency bands in EU areas only and
maximum radio-frequency power
Bluetooth 2402MHz-2480 MHz:<10dBm
Wi-Fi 2412MHz-2472 MHz:<20dBm
Wi-Fi 5180MHz-5320 MHz :<20dBm
Wi-Fi 5500MHz-5700MHz:<20dBm
Wi-Fi 5745MHz-5825 MHz:<14dBm
This device is restricted to indoor use only when operating in
5150-5350MHz frequency range in following countries:
• Important precautions
AT BE BG HR CY CZ DK EE FI FR DE EL HU IE
IT LV LT LU MT NL PL PT RO SK SI ES SE UK
For the purpose of recycling to facilitate effective
utilization of resources, please return this product to a
nearby authorized Collection Centre, registered
Dismantler or Recycler when disposing of this product.
In accordance with Article 10.2 in Directive 2014/53/EU (RED), this
device can be operated in at least one Member State without
infringing applicable requirements on the use of radio spectrum.
For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS Licensing Limited. DTS, the
Symbol, & DTS and the Symbol together, are registered trademarks,
and DTS-HD is a trademark of DTS, lnc. © DTS, lnc. All Rights
Reserved.
Cast your favorite entertainment apps--
movies & TV shows, music, games, sports and more-- from your
Android or iOS device, Mac or Windows computer, or Chromebook
to Mi TV. Find Chromecast-enabled apps at g.co/castapps.
Google, Android, YouTube, Android TV and other marks are
trademarks of Google LLC.
The terms HDMI and HDMI High-Definition
Multimedia Interface, and the HDMI Logo are trademarks or
registered trademarks of HDMI Licensing Administrator, Inc.
in the United States and other countries.
Dolby, Dolby Vision, Dolby Audio, and the double-D
symbol are trademarks of Dolby Laboratories
Licensing Corporation. Manufactured under license
from Dolby Laboratories. Confidential unpublished works. Copyright ©
1992–2020 Dolby Laboratories. All rights reserved.
What the Wheelie Bin symbol means: The symbol says don’t dispose
your e-waste into the municipal waste collection bins. That’s because
these wastes are hazardous in nature and need to be recycled in a
special way.
How to dispose this product
Carry it to the nearest service center of Xiaomi authorised agency.
Instructions of handling the product during and after its use and Do’s
and Don ’t s with respect to handling the product;
Do’s:
a. Always look for information on the catalogue with your product for
end-of-life equipment handling.
b. Ensure that only Authorized Recyclers repair and handle your
electronic products.
c. Always call Authorized E-waste Recyclers to Dispose products that
have reached end-of life.
d. Always drop your used electronic products, batteries or any
accessories when they reach the end of their life at your nearest
Authorized E-Waste CollectionCenter / Collection Point.
e. Wherever possible or as instructed, separate the packaging
material according to responsible waste disposal options and sorting
for recycling.
Don’ts:
a. Do not dismantle your electronic Products on your own.
b. Do not throw electronics in bins having“Do not Dispose”sign.
c. Do not give e-waste to informal and unorganized sectors like Local
Scrap Dealer/ Rag Pickers.
English
Manufacturer’s Authorized EU Representative
Name: Xiaomi Technology Netherlands B.V
Address: Prinses Beatrixlaan 582, 2595BM, The Hague, The Netherlands
Importer:
Beryko s.r.o.
Na Roudné 1162/76, 301 00 Plzeň
www.beryko.cz
This manual suits for next models
4
Table of contents
Other Mi TV manuals
