Microscan Vision MINI Smart Camera User manual

Vision MINI Smart Camera Guide
84-016300-02 Rev J

Copyright ©2015
Microscan Systems, Inc.
Tel: [phone]
Fax: [phone]
All rights reserved. The information contained herein is proprietary and is provided solely for the purpose of
allowing customers to operate and/or service Microscan manufactured equipment and is not to be released,
reproduced, or used for any other purpose without written permission of Microscan.
Throughout this manual, trademarked names might be used. We state herein that we are using the names to the
benefit of the trademark owner, with no intention of infringement.
Disclaimer
The information and specifications described in this manual are subject to change without notice.
Latest Manual Version
For the latest version of this manual, see the Download Center on our web site at:
www.microscan.com.
Technical Support
For technical support, e-mail: help[email protected].
Warranty
For current warranty information, see: www.microscan.com/warranty.
Microscan Systems, Inc.
United States Corporate Headquarters
+1.425.226.5700 / 800.762.1149
United States Northeast Technology Center
+1.603.598.8400 / 800.468.9503
European Headquarters
+31.172.423360
Asia Pacific Headquarters
+65.6846.1214

Statement of RoHS Compliance
All Microscan readers with a ‘G’ suffix in the FIS number are RoHS-Compliant. All compliant
readers were converted prior to March 1, 2007. All standard accessories in the Microscan Product
Pricing Catalog are RoHS-Compliant except 20-500013-01 and 98-000039-02. These products
meet all the requirements of “Directive 2002/95/EC” European Parliament and the Council of the
European Union for RoHS compliance. In accordance with the latest requirements, our RoHS-Compliant
products and packaging do not contain intentionally added Deca-BDE, Perfluorooctanes (PFOS)
or Perfluorooctanic Acid (PFOA) compounds above the maximum trace levels. To view the document
stating these requirements, please visit:
http://eur-lex.europa.eu/LexUriServ/LexUriServ.do?uri=CELEX:32002L0095:EN:HTML
and
http://eur-lex.europa.eu/LexUriServ/LexUriServ.do?uri=OJ:L:2006:372:0032:0034:EN:PDF
Please contact your sales manager for a complete list of Microscan’s RoHS-Compliant products.
This declaration is based upon information obtained from sources which Microscan believes to be reliable, and from random
sample testing; however, the information is provided without any representation of warranty, expressed or implied,
regarding accuracy or correctness. Microscan does not specifically run any analysis on our raw materials or end product
to measure for these substances.
The information provided in this certification notice is correct to the best of Microscan’s knowledge at the date of publication.
This notice is not to be considered a warranty or quality specification. Users are responsible for determining the applicability
of any RoHS legislation or regulations based on their individual use of the product.
In regards to “RoHS Directive 2011_65_EU” Microscan produces Monitoring and Control Instruments as well as Industrial
Monitoring & Control Instruments as defined within the directive. Microscan has developed and is implementing a
RoHS2 compliance plan with the intention of bringing all active products listed in our current marketing literature within
full compliance as per the directive deadlines.
Key milestones for the transition plan are as follows:
• Complete internal product audit by July 2014.
• Initial “Monitoring and Control Instruments” RoHS2 compliant products available by December 2014
• Initial “Industrial Monitoring & Control Instruments” RoHS2 compliant products available by July 2015
• All new products introduced in 2015 are expected to be WEEE & RoHS2 compliant.
Microscan will mark the products with the ‘CE’ marking that complies with the RoHS2 process to acquire ‘CE’ certification
per the example given: Example >> Machinery directive + EMC directive + RoHS2 = Declaration of Conformity

Vision MINI Smart Camera Guide iv
Contents
PREFACE Welcome vi
Purpose of This Manual vi
Manual Conventions vi
CHAPTER 1 Introduction 1-1
Product Summary 1-2
Features and Benefits 1-2
Applications 1-3
Package Contents 1-3
Vision MINI Smart Camera Models 1-4
Part Number Structure 1-4
CHAPTER 2 System Components 2-1
Hardware Components 2-1
Important Label Information 2-4
Mounting and Wiring the Vision MINI Smart Camera 2-5
Status Indicators 2-10
AutoVISION Button 2-11
Trigger Debounce 2-12
CHAPTER 3 Optics and Lighting 3-1
Optics 3-2
Illumination 3-3

Contents
vVision MINI Smart Camera Guide
APPENDIX A Connector Pinouts A-1
Vision MINI Smart Camera Connectors A-2
APPENDIX B Cable Specifications B-1
61-000208-01 USB Type A to USB Type B Plug Cable B-2
61-000105-01 Host Cable, MS-Connect 210 to Host, Stripped to 9-Pin
Socket
B-3
61-000196-02 Vision MINI USB / I/O Cable (Attached) B-4
61-300026-03 Communication Cable, DB25 Plug to DB9 Socket B-6
97-000012-02 Power Supply, 90-254 VAC, 24VDC, USA/Euro Plug B-7
99-000017-01 Photo Sensor, Visible, NPN, Dark On B-8
99-000017-02 Photo Sensor, Visible, NPN, Light On, MS-Connect 210
Configuration B-9
APPENDIX C General Specifications C-1
Vision MINI Smart Camera General Specifications C-2
Dimensions C-7
Field of View and Working Distance C-8
APPENDIX D Serial Commands D-1
APPENDIX E Vision MINI Diagnostic Boot Mode E-1
APPENDIX F USB Power Management F-1

Vision MINI Smart Camera Guide vi
Preface
PREFACE Welcome
Purpose of This Manual
This manual contains detailed information about how to configure and
operate the Vision MINI Smart Camera.
Manual Conventions
The following typographical conventions are used throughout this manual.
• Items emphasizing important information are bolded.
• Menu selections, menu items and entries in screen images are
indicated as: Run (triggered), Modify..., etc.

Vision MINI Smart Camera Guide 1-1
1
Introduction
1
CHAPTER 1 Introduction
FIGURE 1–1. Vision MINI Smart Camera

Chapter 1Introduction
1-2 Vision MINI Smart Camera Guide
Product Summary
The Vision MINI Smart Camera is designed for reliable vision performance
in embedded identification and inspection applications. As the world’s
smallest fully-integrated vision system, the Vision MINI’s compact size
and wide angle optics provide the best performance available for
machine vision tasks at close range.
The Vision MINI allows OEM design engineers to implement inspection,
color matching, symbol decoding, OCR, and more, in a single compact
solution. The camera’s small form factor allows flexible positioning in tight
spaces. The lightweight and durable magnesium alloy case weighs less
than 2 ounces.
Pressing the AutoVISION button at the back of the Vision MINI enables
real time dynamic autofocus. When an object is centered in the field of
view and the AutoVISION button is pressed, the camera automatically
adjusts focal distance and sets internal parameters to optimize image
captures.
AutoVISION software, designed for use with the Vision MINI, provides an
intuitive interface, step-by-step configuration, and a library of presets that
allow easy setup and deployment. For more complex vision applications,
the system can be upgraded from AutoVISION to Visionscape.
Features and Benefits
• World’s smallest fully functional vision system
• Virtual Ethernet over USB
• OEM-ready for easy integration
• Integrated lighting and autofocus lens
• Flexible programming options for custom applications
• AutoVISION button for automatic targeting, calibration, and triggering
• Simplified configuration with AutoVISION software

Applications
Introduction
1
Vision MINI Smart Camera Guide 1-3
Applications
• Part presence/absence
• Color detection and matching
• Medical device inspection
• Fiducial location
• Part location/orientation detection
• Packaging
• Robotics
• Auto ID (Data Matrix and other 2D symbologies, 1D, OCR)
Package Contents
Before you install AutoVISION software and connect your Vision MINI
Smart Camera, please take a moment to confirm that the following items
are available:
• Vision MINI Smart Camera — Your package contains one of the
available models listed in Table 1–1.
• USB Type A to USB Type B Cable
• AutoVISION Software Installation USB Drive

Chapter 1Introduction
1-4 Vision MINI Smart Camera Guide
Vision MINI Smart Camera Models
Table 1–1 lists and describes the Vision MINI Smart Camera models,
including acquisition modes and resolutions.
Part Number Structure
TABLE 1–1. Vision MINI Smart Camera Models
Part Number Vision MINI Smart Camera Model
GMV-6300-2100G Vision MINI, USB, STD, WVGA, Built-In Lighting, AutoVISION
GMV-6300-2102G Vision MINI, USB, STD, WVGA, Built-In Lighting, AutoVISION+Visionscape
GMV-6300-2104G Vision MINI, USB, STD, WVGA, Built-In Lighting, AutoVISION+Verification/OCV
GMV-6300-2106G
Vision MINI, USB, STD, WVGA, Built-In Lighting, AutoVISION+Visionscape+Verification/OCV
GMV-6300-2110G Vision MINI, USB, STD, SXGA, Built-In Lighting, AutoVISION
GMV-6300-2112G Vision MINI, USB, STD, SXGA, Built-In Lighting, AutoVISION+Visionscape
GMV-6300-2114G Vision MINI, USB, STD, SXGA, Built-In Lighting, AutoVISION+Verification/OCV
GMV-6300-2116G
Vision MINI, USB, STD, SXGA, Built-In Lighting, AutoVISION+Visionscape+Verification/OCV
GMV-6300-2172G Vision MINI, USB, STD, QXGA Color, Built-In Lighting, Visionscape
GMV-6300-2200G Vision MINI, USB, HD, WVGA, Built-In Lighting, AutoVISION
GMV-6300-2202G Vision MINI, USB, HD, WVGA, Built-In Lighting, AutoVISION+Visionscape
GMV-6300-2204G Vision MINI, USB, HD, WVGA, Built-In Lighting, AutoVISION+ Verification/OCV
GMV-6300-2206G
Vision MINI, USB, HD, WVGA, Built-In Lighting, AutoVISION+Visionscape+Verification/OCV
GMV-6300-2210G Vision MINI, USB, HD, SXGA, Built-In Lighting, AutoVISION
GMV-6300-2212G Vision MINI, USB, HD, SXGA, Built-In Lighting, AutoVISION+Visionscape
GMV-6300-2214G Vision MINI, USB, HD, SXGA, Built-In Lighting, AutoVISION+Verification/OCV
GMV-6300-2216G
Vision MINI, USB, HD, SXGA, Built-In Lighting, AutoVISION+Visionscape+Verification/OCV
GMV-6300-2272G Vision MINI, USB, HD, QXGA Color, Built-In Lighting, Visionscape
GMV 6300
General
Machine
Vision
Vision
MINI
Comm Lens Sensor Options RoHS Custom
2 = USB
1 = Standard
Density
0 =
WVGA 0 = AutoVISION
G = RoHS
compliant 0 to 99
1 =
SXGA
2 =
AutoVISION +
Visionscape
2 = High
Density
7 = Color
QXGA
4 = AutoVISION +
Verification/OCV
6 = AutoVISION +
Visionscape +
Verification/OCV

Vision MINI Smart Camera Guide 2-1
2
System Components
2
CHAPTER 2 System Components
This section contains information about system components as well as
information to help you connect the Vision MINI Smart Camera. Specific
information describes connectors, adapters, cables, pinouts, and signals.
Note: There are no user-serviceable parts inside.
Hardware Components
Table 2-1 lists Vision MINI Smart Camera hardware components.
TABLE 2–1. Vision MINI Smart Camera Hardware Components
Part Number Description
Upgrade to Visionscape
98-000217-01
Upgrade from AutoVISION to full Visionscape functionality
Demo Kit
98-000215-01
Demo Kit (Carrying case, mounting blocks, mounting rods, power supply, IC-332, IB-131,
cables, object detector, test cards, documentation)
Power Supply
97-000012-02 Power Supply, 90-254 VAC, 24VDC, USA/Euro Plug
Communication and I/O Devices and Cables
FIS-0001-0035G IC-332 Adapter
FIS-0210-000XG MS-Connect 210 Connectivity Box
99-000018-01 IB-131 Interface Box
61-000105-01 Host Cable, MS-Connect 210 to Host, stripped-to-9-pin

Chapter 2System Components
2-2 Vision MINI Smart Camera Guide
61-000127-01 Camera Cable, MS-Connect 210 to Camera, 6’
61-000208-01 USB Type A to USB Type B Cable, 6’
61-300026-03 Communication Cable, DB25 Plug to DB9 Socket, 6’
Mounting Options
98-000048-01 Mounting Arm Kit
98-000053-01 (4”)
98-000053-02 (3”) Extension Joint Kit
98-000054-01 Base Plate Kit
98-000057-01 Through-Hole Mount Bracket
98-000060-01 Side Mount Bracket
98-000088-01 Right-Angle Mirror Kit
98-000098-01 Diffuser Accessory Kit
Object Detectors
99-000017-01 Photo Sensor, Visible, NPN, Dark On
99-000017-02 Photo Sensor, Visible, NPN, Light On, MS-Connect 210 Configuration
Documentation
37-000010-01 Microscan Tools Drive (Software, User Manuals, Quick Start Guides, Configuration
Guides, links to other documents on Microscan website
TABLE 2–1. Vision MINI Smart Camera Hardware Components (Continued)
Part Number Description

Hardware Components
System Components
2
Vision MINI Smart Camera Guide 2-3
Front
Figure 2–1 shows the front of the Vision MINI Smart Camera.
FIGURE 2–1. Front
Base
Figure 2–2 shows the base of the Vision MINI Smart Camera.
FIGURE 2–2. Base

Chapter 2System Components
2-4 Vision MINI Smart Camera Guide
Back
Figure 2-3 shows the back of the Vision MINI Smart Camera.
FIGURE 2–3. Back
Important Label Information
Each Vision MINI Smart Camera has its own label, which contains
important information about that camera.
• P/N – The Microscan part number of your Vision MINI Smart Camera.
• S/N — The serial number of your Vision MINI Smart Camera.
• MAC — The MAC address of your Vision MINI Smart Camera.
• Type — The model type of your Vision MINI Smart Camera.
USB / I/O cable
(attached)
AutoVISION
Button
Status Indicators (TRIG, PASS,
FAIL, MODE, LINK/ACT, PWR)

Mounting and Wiring the Vision MINI Smart Camera
System Components
2
Vision MINI Smart Camera Guide 2-5
Mounting and Wiring the Vision MINI Smart Camera
• Mount the camera (1) securely in its camera stand (not supplied).
• Make sure the camera ( 1 ) is mounted at the optimal distance of 2” to 6”.
• Mount the camera (1) as required by the application.
• Connect the USB side of the camera cable ( 2 ) to the USB host cable ( 3 ).
• Connect the IC-332 (4) to the IB-131 (5).
• Connect the D-sub side of the camera cable (2) to the IC-332 (4).
• Connect the trigger (6) to the IB-131 (5).
• Connect the power supply (7) to the IB-131 (5).
• Plug in the power supply (7).
7
1
2
3
6
4
5

Chapter 2System Components
2-6 Vision MINI Smart Camera Guide
Direct Input / Output Diagrams

Mounting and Wiring the Vision MINI Smart Camera
System Components
2
Vision MINI Smart Camera Guide 2-7
Isolated Trigger Input with IC-332

Chapter 2System Components
2-8 Vision MINI Smart Camera Guide
New Master Input with IC-332

Mounting and Wiring the Vision MINI Smart Camera
System Components
2
Vision MINI Smart Camera Guide 2-9
Power Requirements
Refer to Table 2-3 when determining the power supply requirements for
your camera.
TABLE 2–3. Camera Power Requirements
Vision MINI Sensor 5VDC
WVGA 400 mA @ 5 VDC (typ.), 4.0 watts max.
SXGA 465 mA @ 5 VDC (typ.), 4.5 watts max.
QXGA 400 mA @ 5 VDC (typ.), 4.2 watts max.
Optional 10-28 V with IC-332 accessory

Chapter 2System Components
2-10 Vision MINI Smart Camera Guide
Status Indicators
The back of the Vision MINI Smart Camera has multiple LEDs that indicate
different trigger, inspection, camera, communication, and power states.
Additional User Feedback
• Green Flash – A green flash from the front of the unit indicates a Good Read.
• Blue Targeting Pattern – The blue targeting pattern from the front of the
unit allows the user to center an object in the camera’s field of view.
• Beeper – The beeper is an audible verification that either a Pass or a
Fail has occurred.
TRIG
On Steady Continuous Trigger
Off Waiting for Trigger Event
On Flashing Trigger Event
PASS/FAIL On Active State
Off Inactive State
MODE On Steady Unit Ready
Off Unit Not Ready
LINK/ACT
On Steady Link Established
Off No Link/Activity
On Flashing Link Established and Activity on Link
PWR On Power On
Off No Power Applied to Unit
Trigger Status
Inspection Status
Camera Status
Communication Status
Power Status
