MicroSurvey DC5 User manual

MicroSurvey
DC5 USER MANUAL
（V1.0）
2014.06.27

Table of Contents
Preface .............................................................................................................................................. 1
Chapter 1 Product Introduction ..................................................................................................... 2
1.1 Front Components .............................................................................................................. 3
1.1.1 Keypad ...................................................................................................................... 5
1.2 Back Components ............................................................................................................... 6
1.3 Bottom Components ........................................................................................................... 7
Chapter 2 Basic peration ............................................................................................................. 8
2.1 Turning on、Suspending、Turning ff、Resetting ............................................................ 8
2.1.1 Turning on ................................................................................................................ 8
2.1.2 Suspending ............................................................................................................... 8
2.1.3 Turning off ................................................................................................................ 9
2.1.4 Resetting................................................................................................................... 9
2.1.4.1 Performing a Hard Reset ............................................................................. 10
2.1.4.2. Performing a Factory Reset ........................................................................ 10
2.2 Pull the Stylus out and in ................................................................................................... 10
2.3 Installing、Uninstalling the SIM、TF Card and Battery .................................................... 10
2.4 Charging the Battery ......................................................................................................... 11
2.5 Fitting the Hand Strap ....................................................................................................... 12
Chapter 3 Connecting and Synchronizing with Your Computer ................................................... 13
3.1 Installing Connection Management Software ................................................................... 13
3.1.1 Installing Windows Mobile Device Center ............................................................. 14
3.1.2 Installing ActiveSync ............................................................................................... 14
3.2 Connecting and Synchronizing With Your Computer ........................................................ 15
3.2.1 Managing the Connection and Synchronization Using the Windows Mobile Device
Center .............................................................................................................................. 15
3.2.2 Managing the Connection and Synchronization Using MicroSurvey Transfer ....... 19
3.2.3 Connecting with U Disk Mode ................................................................................ 28
3.2.4 TG Connection ..................................................................................................... 29
Chapter 4 Brief Description of the perating System .................................................................. 30
4.1 System Main Interface and the Start Menu ...................................................................... 30
4.2 Status Indicators ................................................................................................................ 32
4.2.1 Battery Status Indicators ........................................................................................ 32
4.2.2 Speaker Status Indicators ....................................................................................... 32
4.2.3 Network and Modem Status Indicators ................................................................. 33
4.3 Pre-installed Programs ...................................................................................................... 33
4.4 Interacting With the Device .............................................................................................. 34
4.5 Entering Information ......................................................................................................... 35
4.5.1 Using the n-screen Keyboard ............................................................................... 35
4.5.2 Drawing and Writing on the Screen Directly .......................................................... 36
4.5.3 Recording a Message.............................................................................................. 37
4.5.4 Camera (Select Models nly) ................................................................................. 38
4.5.4.1 Taking Pictures............................................................................................. 38

4.5.4.2 Recording Video Clips .................................................................................. 40
4.6 Personal Settings ............................................................................................................... 42
4.6.1 Buttons ................................................................................................................... 42
4.6.2 Home ...................................................................................................................... 43
4.6.2.1 Appearance ................................................................................................. 43
4.6.2.2 Items ............................................................................................................ 44
4.6.2.3 Set Date and time ........................................................................................ 45
4.6.3 Screen Lock............................................................................................................. 46
4.6.4 Set Passwords ......................................................................................................... 47
4.6.5 Power ..................................................................................................................... 48
4.6.6 Sounds and Notifications ....................................................................................... 49
4.6.7 Screen ..................................................................................................................... 50
4.6.8 Backlight ................................................................................................................. 51
4.6.9 Align Screen ............................................................................................................ 52
4.7 GPRS Network Setting ....................................................................................................... 53
4.7.1 Add New GPRS Connecting .................................................................................... 53
4.8 Bluetooth Connecting ....................................................................................................... 55
4.9 Phone and Text Messages (Select Models nly) ............................................................... 57
4.9.1 Phone ..................................................................................................................... 57
4.9.1.1 About Your Phone ....................................................................................... 57
4.9.1.2 Making a Call ............................................................................................... 60
4.9.1.3 Responding to a Call .................................................................................... 63
4.9.1.4 perations During a Call ............................................................................. 64
4.9.1.5 Using Call History ........................................................................................ 67
4.9.1.6 Using Speed Dial .......................................................................................... 68
4.9.1.7 Customizing Your Phone .............................................................................. 70
4.9.1.8 Additional Phone perations ...................................................................... 72
4.9.2 Text Messages ........................................................................................................ 73
4.9.2.1 Reading Text Messages................................................................................ 73
4.9.2.2 Composing and Sending a Text Message .................................................... 74
4.10 WIFI Connecting .............................................................................................................. 75
4.10.1 Switching n or ff the Wi-Fi Radio .................................................................... 75
4.10.2 Connecting to a Wireless Network ....................................................................... 75
Chapter 5 Software peration ..................................................................................................... 77
5.1 Installing Programs ............................................................................................................ 77
5.2 Uninstalling Programs ....................................................................................................... 77
Chapter 6 Troubleshooting and Maintenance ............................................................................. 78
6.1 Troubleshooting ................................................................................................................ 78
6.2 Resetting Your Device ........................................................................................................ 79
6.3 Caring for Your Device ....................................................................................................... 80
Chapter 7 Legal Notice ................................................................................................................. 81
Return policy Dead On Arrival instruments ..................................................................................... 82
Over Warranty repair(s) policy ........................................................................................................ 82
Disclaimer and Limitation of Remedy ............................................................................................. 82

Instruments ..................................................................................................................................... 83
Accessories ...................................................................................................................................... 83
7.3 Service Procedure ..................................................................................................................... 83
7.4 Environmental recycling ............................................................................................................ 84
F R C UNTRIES IN THE EUR PEAN UNI N (EU)............................................................................ 84
F R C UNTRIES UTSIDE EUR PEAN UNI N (EU) ........................................................................ 84
Appendix 1：Specifications ............................................................................................................ 84
Chap er 7 Legal No ice ......................... Error! Bookmark not defined.6
7.1 Copyrigh s and rademarks .......... Error! Bookmark not defined.6
7.2 S andard limi ed warran y ........... Error! Bookmark not defined.6
7.3 Service procedure ........................ Error! Bookmark not defined.9
7.4 Enviromen al recycling ............................................................ 80
Appendix 1 Specifica ion …
…………………………………………………………Error! Bookmark not defined.

1
Preface
DC5 is a highly integrated handheld mobile terminal, with an 806MHz
processor, 4G -board FLASH memory, high-capacity battery, integrated
wireless access capability diversification (including GPRS, WIFI and
Bluetooth). For integrating many functions, it can be very convenient to
collect, store and transfer data in the wild using the DC5. With the built-in
high performance GPS Receiver, you can calculate the position, navigate
and get real-time high-quality data. You can use the 5,000,000 pixels
digital camera capture color pictures as well to provide integration
solutions for the natural resource management and assets management.
Modular production process-the product is made up of the standard
modules. Control every aspect during producing to increase the capacity
on the one hand and decrease failure rate, improve the product quality on
the other hand. The advanced production technology and superior
product performance ensure the equipment efficient, table and durable.
It provides every GIS users unprecedented new experience.

2
Chapter 1 Product Introduction
This chapter mainly introduces you to the external components of your
device.

3
1.1 Front Components

4
Ref Componen Descrip ion
① Charge/Power on
Indicator
Flashes in red to indicate that your device
is being turned on.
When battery charging, Flashes in green
to indicate battery charging is in
progress.
Flashes in amber to indicate that the
battery is fully charged.
② GPS Indicator Flashes in green to indicate that the GPS
function is switched on.
③
Wireless
communication
indicator
Flashes in blue to indicate that the
Bluetooth function is on.
Flashes in green to indicate that the
Phone function is on.
④ Earpiece Serves as the phone earpiece during a
call.
⑤ Touch Screen Displays the output of your device and
responds to your tapping.
⑥ Keypad Includes keys for numbers and specific
functions.
⑦ Power Button Turns on or off your device.
⑧ Microphone Records voices.
Serves as the mouthpiece during a call.

5
1.1.1 Keypad
Ref Componen Descrip ion
①
Numeric Keys Enter numbers（majorly for models with the phone
function）
Alternative
Function Keys
Provide functions as indicated by the red icons when Fn
lock is on.
Moves up, down, left and right within
the screen or menu.
Goes to the next input field.
Increases the brightness level of the
screen. It cycles to the lowest level
after reaching the highest level.
Exit the currently opened menu or
program.
, ,
Performs the program assigned under
Personal settings when you press one
of them.

6
②
Send Key Dials or answers a call.
③
Left/Right Soft
Key
Performs the command shown on the bottom left or
right corner of the screen.
④
Function Key
Switches on or off the alternative functions of the
numeric keys. Fn lock is off by default. When it is
switched on, the icon shows in the navigation bar.
⑤
Camera Key
Starts the Camera program.
Serves as the shutter release button if the Camera
program is currently in use.
⑥
End Key Ends or rejects a call (select models only).
Returns to the Today screen from another program.
⑦
Backspaces over one character when in a text input
field.
⑧
Start Key pens the Start menu.
⑨
Action Key Confirms your selection by pressing, similar to the
Enter key on a keyboard.
1.2 Back Components

7
Ref Componen Descrip ion
①
Camera Lens Takes still pictures or records video
clips.
②
Speaker Plays music, sounds and voices.
③
Hand Strap Holders The hand strap attaches here.
④
Battery Cover Inside is the battery.
1.3 Bottom Components
Ref Componen Descrip ion
①
Serial Connector
Com 5 Provides D-sub 9 pins RS232 function.
②
USB TG (Host &
Client) Connector Connects to the USB cable.

8
③
Power Connector Connects to the AC adapter.
④
Stylus Pinhole
Used to place the stylus that is served
as the input device by tapping on the
touch screen to make selections and
enter information.
⑤
Hand Strap Holders The hand strap attaches here.
Chapter 2 Basic Operation
This chapter mainly introduces you to the basic operations of your device.
2.1 Turning on、Suspending、Turning Off、Resetting
2.1.1 Turning on
Press the Power Button and don not let go until the indicator color turns
to green from red. It’s about 33 seconds to turn on the product. Then the
screen will appear the device information and Windows icon in order.
2.1.2 Suspending
Press the power button one second when the device is on, let go, the
device will be suspended and the first indicator from the left color turns
to amber.
If the device has already in use, the device suspends halfway (black
screen)，to resume operation, press the power button. You will be back
to where you left off.

9
CAUTI N: The mobile phone indicator keeps on flashing when your device
is suspended. Any incoming call will resume your device.
2.1.3 Turning off
If you are not using your device, press and hold the power button for at
least 3 seconds until the device appears a dialog box as shown in figure 1.
Then click “ K”.
Figure 1
2.1.4 Rese ing
If the device stops responding to the stylus or if it does not respond when
you press any of the keypad buttons, you may need to reset it by
performing a hard reset.

10
2.1.4.1 Performing a Hard Reset
Press both and buttons one second at the same time，and
then press the power button to turn on your device.
2.1.4.2. Performing a Factor Reset
Warning: If you perform a factory reset, all installed programs and
information contained in memory will disappear. It is
recommended you backup or copy all data before resetting.
To perform a factory reset, you can do so as follows:
Settings--system--factory reset, then input 1234 and the system will reset
to factory settings.
2.2 Pull the St lus out and in
Use the stylus to navigate and select objects on the screen.
Attach the stylus and your device with the tether. Pull the stylus out of
the slot and extend it for ease of use. Store it in the slot when not in use.
2.3 Installing、Uninstalling the SIM、TF Card and Batter
1. Lift the latch handle of the battery cover and turn it counterclockwise
to the unlocked (vertical) position. Then, detach the cover from the device.

11
2. We can see two slots then, with the upper side one installing SIM card
and the bottom side one installing TF card. To install the SIM card, push
the SIM card holder right. With the SIM card’s chip side facing down put
the card into the slot. Close the holder then. The TF card installation is
similar to the SIM card installation. To remove the SIM card and TF card,
push the holder and then take out the card.
3. To install the battery, attach the bottom side of the battery to the
compartment at an angle and then lower the upper side to engage the
connector. Attach the bottom side of the battery cover to the device at an
angle, and then with the handle still in the unlocked (vertical) position, fit
the latch handle into place. Secure the latch by turning it clockwise to the
lock (horizontal) position.
CAUTI N: it’s easy to cause damage to the battery during installation. It is
recommended you engage the top of the battery into the connector first
at an angle and then push the bottom of the battery to the compartment.
2.4 Charging the Batter
The battery isn’t charged from the factory. You must charge the battery
completely before using it for the first time. Charging duration is two and
a half hours. The charger has an overcharge protection function.

12
CAUTI N: For optimal performance of the lithium battery, take note of the
following:
Use the included AC adapter and charger only.
There is no need to fully discharge the battery before charging. You
can charge the battery before it is discharged.
Do not charge the battery where the temperature is high (higher than
50℃) or low(less than 0℃).
If you will not use the product for a long period of time, be sure to fully
charge the battery at least once every two weeks, over discharge of
the battery can affect the charging performance.
2.5 Fitting the Hand Strap
Align the upper hand strap bracket with the two mounting holes behind
the device and then use a screwdriver to tighten the screws. The other
side is fixed to the hand strap holders at the bottom of the device. We can
see it after the installation is complete as shown in figure 2.

13
Figure 2
Chapter 3 Connecting and Synchronizing with our Computer
3.1 Installing Connection Management Software
To install software onto a device powered by the Windows Mobile
operating system or to copy files between your device and a PC you must
connect the device to a PC. If the computer is running:

14
• Windows 7 or Windows Vista operating system, use the Windows
Mobile Device Center (WMDC) to manage the connection.
• Windows XP or 2000 operating system, use ActiveSync to manage the
connection.
IMP RTANT N TE: You must install Microsoft’s Windows Mobile Device
Center or ActiveSync onto your PC computer before you connect the
handheld.
3.1.1 Ins alling Windows Mobile Device Cen er
The Windows 7 and the Windows Vista operating system include a basic
connectivity driver for devices powered by a Windows Mobile operating
system. This driver allows you to transfer files from the device to an office
computer.
To install software onto a device powered by a Windows Mobile operating
system, you must install Windows Mobile Device Center 6.5 onto a PC.
3.1.2 Ins alling Ac iveSync
Search the ActiveSync 4.5 version to download. Alternatively, visit
http://www.microsoft.com/en-us/download/details.aspx?id=15 to
download the latest version from the Microsoft website.

15
3.2 Connecting and S nchronizing With Your Computer
To connect the device to a PC:
1. Make sure that the device and the PC are switched on.
2. Make sure you have installed the appropriate connection
management software onto the PC.
3. To form a connection, do one of the following:
① Use the device's integrated Bluetooth radio to establish a wireless
serial link to a Bluetooth-enabled computer.
② Use a USB connecVon: Plug the USB cable into the USB port on the
device. Plug the other end of the USB cable into a USB port on the PC.
3.2.1 Managing he Connec ion and Synchroniza ion Using he
Windows Mobile Device Cen er
Connect the device to the PC. It will appear a dialog box shown as in
figure 3 if the device successfully connects to the PC.

16
Figure 3
CAUTI N: If the device doesn’t establish a connection automatically,
check whether the connection is enabled in the Windows Mobile Device
Center software and on the device.
HELPFUL N TE: if the device doesn’t connect automatically check in
Settings | Connections | USB to PC and uncheck “Enable Advanced
Connectivity”
Click “connect without setting up your device” shown as in figure 4.
