Microtek FunView S350 User manual

User's Manual
Portable DVD Player

All Rights Reserved
This user manual contains proprietary information,
which is protected by copyrights. All rights are reserved.
No part of this manual may be photocopied, reproduced
or translated to another language without prior written
permission of Microtek International.
Microtek International Inc.
No. 6, Industrial East Road 3, SBIP
Hsinchu, Taiwan

Important Notice
This device complies with FCC Rules Part 15.
Operation is subject to the following two
conditions: (1) This device may not cause harmful
interference and (2) this device must accept any
interference that may be received, including
interference that may cause undesired operation.
Safety Instructions
(1) This DVD player is a portable, class I-laser
product. It uses a visible/invisible laser beam
which could cause hazardous radiation exposure
if beamed or directed incorrectly. Should you
open the upper cover of the DVD player, make
sure you do not place your eyes too close to the
opening or peer into the inside of the player, as
this may be harmful to your sight and health.
(2) To reduce the risk of fire or electric shock,
follow these instructions carefully:
!Confirm the voltage available at each
country location before using this product. The
provided AC/DC adapter operates on
100~240VAC.
!For connection to a power supply not
compatible with the power used in the United
States or Canada, use an adapter with the
proper power configuration.
!For assistance in selecting an alternate
plug adapter, contact your local electrical
parts distributor .
-1-

tBuilt-in Charging Circuit
tOSD(On Screen Display) Control
tMP3 playback with folder management
tJPEG picture playback
tAnti-shock memory
DVD: 3 seconds
MP3: 35 seconds
VCD: 20 seconds@128K bps
tAC/ DC Adapter for Indoor use
tDoor Locker
tStand
tBuilt-in Lithium -Ion Polymer Battery
Protection Circuit
Product Features
t3.5 inch TFT-LCD Panel with 4:3 aspect ratio
tBuilt-in top-loading DVD player
t36-key Infrared Remote Control
t11 Control Buttons on the Front Panel:
PLAY, STOP, NEXT, PREV, MENU, SELECT,
PIX, UP/DOWN, RIGHT/LEFT
tA/V Output Jacks
t
t
t
t
t
t
t
Stereo Headphone Jack
DC Power Input Jack
Volume Control with Rotary Potentiometer
Battery LED Indicator
RED: Battery Charging
GREEN: Battery Full
Power LED Indicator:
RED: Power On
Blinking: Battery Low
Hold Switch
Lock/Unlock the function of control buttons
Standby Switch
Turn on/off the backlight of the LCD panel
-2-

Table of Contents
01. Control Buttons on Front Panel .............................. 04
02. IO/Ports on the Sides ...................................... 07
03. Remote Control Operations ................................... 11
04. General Operating Instructions ............................. 15
05. DVD Basics ................................................. 18
06. Playing Audio CDs ........................................... 24
07. Playing MP3 CDs ............................................. 25
08. Warnings/Troubleshooting ................................... 27
09. Specifications ............................................. 28
-3-

Control Buttons on Front Panel
-4-
7
2
6
3
5
9
4
10
8
1

Description of Functions
1. PLAY
Press this button to play or pause DVD
playing.
2. STOP
Press this button to stop DVD playing.
STOP -> STOP -> PLAY: Play disc from the
beginning
STOP -> PLAY: Resume from the point where
playing stopped.
3. NEXT
Play next chapter or track.
4. PREV
Play previous chapter or track.
5. MENU
Show the Root Menu in the DVD for users to
navigate.
6. SELECT
Press this button to make a selection or to
play the disc.
7. UP/DOWN/RIGHT/LEFT
(1) Direction use: Navigate the OSD
(2) Adjustment use: Increase/decrease the
quality of video in BRIGHTNESS, TINT,
COLOR, and CONTRAST.
8. PIX (Picture Selection)
Each time this button is pressed, the picture
adjustment OSD cycles through selections for
BRIGHTNESS, CONTRAST, COLOR, and
TINT. Once the desired adjustment bar is
displayed, use the RIGHT/ LEFT button to
adjust the setting. The bar display will
automatically disappear if no adjustments are
made within 6 seconds or if any other button
is pressed.
-5-

9. IR Sensor - Forward Sensor Eye
Allow remote controller to navigate the OSD
(On Screen Display) on this unit and to
control other accessories.
10. LCD Panel
-6-

11. POWER Slide Switch
ON: System power on
STANDBY: Turn off LCD backlight.
OFF: System power off
12. HOLD Slide Switch
ON: Disable system responses to the control
buttons on the front panel.
OFF: Enable system responses to the control
buttons on the front panel.
13. DC INPUT
Accommodate the AC/DC power adapter.
I/O Ports on the Sides
Right Side:
-7-
11
12
13
POWER
STAND BY
ON OFF
POWER
STAND BY
ON OFF
IUDC NP T
IUDC NP T

14. VOLUME Control
Use rotary potentiometer to adjust audio
volume.
Clockwise: Increase volume
Counterclockwise: Decrease volume
15. Stereo Headphone Jack
Accommodate headphones for monitoring
audio.
16. VIDEO-OUT-AUDIO
(1) Video jack: CVBS signal
(2) Audio jack: Stereo audio signal
Left Side:
-8-
14
15
16
VOLUMEVOLUME

17. OPEN Switch (Door Locker)
Slide towards the right to open the front cover.
18. POWER LED
: Power on
Blinking in RED: Battery low
19. CHARGE LED
: Battery charging
: Battery full
20, 21. VISOR Holes
Slots to accommodate hooks for the sun visor.
RED
RED
GREEN
Front Side:
-9-
CHA ERG
CHA ERG
POWERPOWER
19
17 18
20
21
Rear Side:

Bottom Side:
24
25
24
22
23
22, 23. BATTERY HOLDING Holes
24. 2-pin BATTERY CONTACT
25, 26. BATTERY SLIDING Holes
USE OF ANY CONTROLSOR ADJUSTMENTS OR PROCEDURES
OTHER THAN THOSE SPECIFIED HEREIN MAYRESULT IN HAZARDOUS
RADIATIONEXPOSURE.
DO NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
TO REDUCE THE RISK OF ELECTRIC SHOCK,
THIS PRODUCT COMPLIES WITH FDARADIATION PERFORMANCE STANDARDS,
21CFR SUBCHAPTER J.
No. 6, Industrial East Road 3, SBIP
Hsinchu, Taiwan
Manufactured: April, 2004
Microtek International Inc.
This Class B digital apparatus
complies with Canadian ICES-003
-10-

Remote Control Operations
-11-
BATTERY INSTALLATION
Before attempting to operate your remote
control, install the batteries as described below.
(1) Turn the remote control face down.
Press down on the ridged area of the battery
cover and slide it off.
(2) Slide another battery in.
The remote control will operate the unit.
Please take note that this is not a universal
remote control and will not control equipment
from other manufacturers.
Battery
Battery Housing
Bottom Side
2
6
7
10
3
9
11
1
5
8
12
4

6. UP
While playing the disc, use this button to scroll up the
OSD menu.
While watching TV, use this button to move up to higher
channels.
7. RIGHT
(1) Shift right or go up the OSD menu.
(2) Adjust the voice volume up
8. LEFT
(1) Shift left or go down the OSD menu.
(2) Adjust the voice volume down.
9. DOWN
While playing the disc, use this button to scroll down the
OSD menu.
While watching TV, use this button to move down to lower
channels.
10. Select
Make a selection or begin disc playing.
11. ZOOM
Enlarge the picture in the movie by 1x, 2x and 4x.
12. PBC (Video CD only)
Turn the PBC(Playback Control) on or off.
-12-
1. Setup
Navigate the SETUP MENU. There are 4 pages to
configure the system:
(1) Language Settings
(2) Graphic Settings
(3) Audio Settings
(4) Favorite Settings
2. Menu
Go to the Root Menu included in the disc.
3. Display
Show information on the top left corner on the screen,
including title, chapter/track, time elapsed, and time
remaining, or turn off the display.
4.PIX(Picture Selection)
Each time this button is pressed, the picture adjustment
OSD cycles through selections for BRIGHTNESS,
CONTRAST COLOR, and TINT. Once the desired
adjustment bar is displayed, use the RIGHT/ LEFT
button to adjust the setting. The bar display will
automatically disappear if no adjustments are made
within 6 seconds or if any other button is pressed.
5. Rotate
Press this button to activate up/down and left/right
rotation of image on the LCD panel.
Description of Functions

-13-
13. PLAY/PAUSE
Press this button to play or pause a movie while disc is
loaded into the disc compartment. For more information,
consult the DVD Basics section.
14. STOP
Stop playing the movie or songs.
STOP -> PLAY: Resume playing,
STOP -> STOP -> PLAY: Resume from the point where
playing stopped.
15. PREV
Play the previous chapter or track.
16. NEXT
Play the next chapter or track.
17. FF (Fast Forward)
Press this button to search disc forward continuously.
There are 5 speed options to choose from: 2X,4X,
8X,16X, and 32X.
18. FR (Fast Rewind)
Press this button to search disc backward continuously.
There are 5 speed options to choose from, such as
FF(Fast Forward).
19. Slow
Play the disc forward in slow motion.
25
24
27
20
21
16
15
17
18
23
22
26
19
13
14

20. REPEAT (Except VCD with PBC on)
Repeat part or all of a chapter, title, track, or an entire
disc.
21. A- B (Except MP3)
Repeat from point A to point B.
22. Title
Navigate the Title Menu included in the disc.
23. Subtitle
24. Angle
Allow views with a different camera angle. This button
takes effect only on DVDs that support frames with
multiple angles.
25. Audio
Change the audio language to another available
language (only if the disc contains multiple audio
languages).
26. NUMBERS
Decimal number: 0 to 9
27. MUTE
Press this button to shut off the sound at the
headphone station. The screen will display that the
sound has been turned off . Pressing the button again
restores sound to the previously set Level.
Change the subtitle language to another available
language (only if the disc contains multiple subtitle
languages).
-14-

General Operating Instructions
Turning the unit ON or OFF
1. To turn on the system, slide the POWER
switch on the right side of the unit to the
position labeled "ON".
2. To turn off the system, slide the POWER
switch on the right side of the unit to the
position labeled "OFF".
3. To save power, slide the POWER switch to the
position labeled "STANDBY". This can be
done while you are listening to music or
sound on the disc, and will turn off the LCD
backlight to save energy.
Supplying the AC Power to the Unit
1. Insert the DC plug into the "DC INPUT" jack on
the right side of the unit.
2. Attach the AC plug to the AC outlet.
DC Plug
AC Plug
POWER Switch
-15-

Charging the Battery Pack
DC Plug
AC Plug
CHARGE LED
POWER Switch
POWER
POWER
POWER LED
When the "POWER LED" starts to blink in red, the
battery will stop supplying power to the system in
10 minutes. At this time, the user needs to charge
the battery. Please follow the steps below and
refer to the diagram at the right-hand side.
(1) Slide the POWER switch to the "OFF" position in the
direction of arrow as indicated by the diagram on the right.
The "CHARGE LED" will be in GREEN.
(2) Connect the DC plug of the AC/DC adapter to the "DC
INPUT" jack on the right side of the unit.
(3) Connect the AC plug of the AC/DC adapter to the AC outlet.
(4) The "CHARGE LED" will turn to red to indicate that the unit
is charging the attached battery pack.
(5) The "CHARGE LED" will turn green after the battery is full.
DC INPUT
Battery Pack
-16-

Unloading the Battery
Step 1:
Press the points on the battery pack
with your fingers, as indicated by the
diagram above.
Step 2:
Keep pressing and pull the battery pack
out in the direction indicated by the
drawing above.
Step 3:
Slide the battery pack out, as shown in the
diagram above.
-17-

DVD Basics
To get the optimum use out of your DVD player,
make sure you read this section completely.
Regional Coding
Both the DVD player and disc are coded
by regions. These regional codes must match
in order for the disc to play. If the codes don't
match , the disc won't play. This unit's code is
region 1. Other regional codes can't be
played in this unit.
Types of Discs your DVD will play
DVD-Video: DVD contains video.
CD-DA: CD contains musical or sound
content only.
CD-Video: CD contains movie only.
CD-R/RW: A disc that contains audio files
(for example, a CD-R with downloaded MP3
Files), MPEG, or JPEG files.
Loading and Playing Discs
Before you load a disc, make sure that it is
compatible with the player. Note that the
following discs CANNOT be used with this
player：
Optical disc
•CD-1, CD-ROM,DVD-ROM
Mini disc
•CDG(audio only , not graphics).
Loading and Playing a Disc
When you slide the POWER switch to the
"ON" position. Slide the OPEN switch to right
for lifting the front panel and put the disc
printed-side up into the disc area. The disc
will begin to play momentarily when the front
cover is locked into the door locker.
-18-
