Currys Essentials C7PDVD10 User manual

P O R TA BL E DV D PL AY E R
INSTRUCTION MANUAL
C7PDVD10
C7PDVD10_IB_110218.indd 1 2/18/11 3:35 PM

C7PDVD10_IB_110218.indd 2 2/18/11 3:35 PM

Contents
Unpacking.....................................................................................................................5
Product Overview.........................................................................................................6
DVD Player ......................................................................................................................................................6
Remote Control.............................................................................................................................................7
Battery Installation for the Remote Control........................................................................................8
Remote Control Operation Range..........................................................................................................8
Power Supply ................................................................................................................9
Using the Mains Adapter (for indoor use) ...........................................................................................9
Using the Car Power Adapter (for in-car use).....................................................................................9
Connections ............................................................................................................... 10
Connecting a TV......................................................................................................................................... 10
Watching a DVD on your TV .................................................................................................................. 10
Using Earphones........................................................................................................................................ 10
Compatible Disc Types .............................................................................................. 11
Supported Formats................................................................................................................................... 11
Region Code................................................................................................................................................ 11
Turning On the DVD Player....................................................................................... 12
Basic Playback............................................................................................................ 12
Playing a Disc.............................................................................................................................................. 12
Using the Disc Menu................................................................................................................................ 12
Pausing Playback....................................................................................................................................... 12
Selecting Title / Chapter / Track (for DVD)........................................................................................ 13
Selecting Track / Time / Disc Time (for CD)....................................................................................... 13
Stopping Playback.................................................................................................................................... 13
Skip (Forward / Reverse)......................................................................................................................... 13
Fast Forward / Fast Reverse ................................................................................................................... 13
Repeat Play Mode ..................................................................................................................................... 14
Slow................................................................................................................................................................ 14
Angle Selection.......................................................................................................................................... 14
Audio Selection.......................................................................................................................................... 15
Subtitle Selection...................................................................................................................................... 15
Viewing the Disc Playback Information ............................................................................................ 15
Programmable Memory.......................................................................................................................... 15
Zoom Selection.......................................................................................................................................... 16
Adjusting the LCD Screen....................................................................................................................... 16
Repeat a Specic Section ....................................................................................................................... 16
TITLE............................................................................................................................................................... 16
C7PDVD10_IB_110218.indd 3 2/18/11 3:35 PM

Using a USB Flash Drive or and SD/MMC/MS Card.................................................. 17
General Operation .................................................................................................................................... 17
Using the Language Setup Menu............................................................................. 18
OSD Language ........................................................................................................................................... 18
Subtitle / MPEG4 Subtitle / Audio / DVD Menu.............................................................................. 18
Using the Video Setup Menu .................................................................................... 18
Aspect Ratio ................................................................................................................................................ 19
View Mode................................................................................................................................................... 19
TV System..................................................................................................................................................... 19
Using the Audio Setup Menu.................................................................................... 19
Using the Rating Setup Menu................................................................................... 20
Parental Control Settings........................................................................................................................ 20
Set Password............................................................................................................................................... 21
Using the Misc Menu ................................................................................................. 21
Maintenance .............................................................................................................. 22
Hints and Tips ............................................................................................................ 23
Specications............................................................................................................. 25
Safety Warnings......................................................................................................... 26
C7PDVD10_IB_110218.indd 4 2/18/11 3:35 PM

5
DVD Player Remote Control
(P.N.: 1706-054009-08R)
Mains Adapter
(P.N.: 5323-079515-02R)
Instruction Manual
(P.N.: 1600-196H53-01R)
Car Power Adapter
(P.N.: 5338-081330-20R)
Quick Start Guide
(P.N.: 1601-196H53-02R)
If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose it please do so
according to local regulations.
The following items are included:
SD/MS/MMC IR
Thank you for purchasing your new Currys Essentials Portable DVD
Player.
These operating instructions will help you use it properly and safely.
We recommend that you spend some time reading this instruction manual in
order that you fully understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this instruction
manual for future reference.
C7PDVD10_IB_110218.indd 5 2/18/11 3:35 PM

6
Product Overview
DVD Player
1. LCD Screen
2. Speaker
3. Disc Door
Push to close the disc door.
4. MENU / PBC Button
PBC on / off switch. Return to DVD root
menu (DVD).
5. SOURCE Button
Select among the different input sources:
DVD / CARD / USB.
6. VOL + / – Button
Adjust the volume.
7. Cursor ( , , , ) Buttons
Move between selections on a menu
screen and adjust certain settings.
Button
Press to perform fast forward / fast reverse
playback.
Button
Move back to the beginning of the
current chapter/tracks / titles or move
forward to next chapters/tracks/titles on
a disc.
OK Button
Confirm selections on a menu screen.
SD/MS/MMC IR
1
2
3
2
4
6
7
1098 11 12
5
13
14
15
16
17
POWER
AV OUT ON OFF DC IN 9-12V
8. Open Button
Press to open the disc door.
9. SD/MS/MMC Port
10. PLAY / PAUSE Button
Press to start playback or pause.
11. STOP Button
Stop playing a disc.
12. SETUP Button
Display the SETUP menu.
13. USB Port
14. Earphone Socket
15. AV OUT Socket
16. POWER ON/OFF Switch
17. DC IN 9-12V Socket
C7PDVD10_IB_110218.indd 6 2/18/11 3:35 PM

7
1. A-B Button
Perform point-to-point repeat playback
on a DVD or CD.
2. SEARCH Button
To search and start playback from a
selected point on the disc.
3. MUTE Button
To mute and restore your DVD sound
output.
4. SOURCE Button
Select among the different input
sources: DVD / CARD / USB.
5. 0 - 9 Number Buttons
Create programs or locate a title/
chapter/track or specific time.
6. 10+ Button
Select and switch to a track that is
higher than 10.
7. DISPLAY Button
To display the playtime and show status
information on the screen.
8. SUBTITLE Button
Select one of the subtitle languages
programmed on a DVD (if available).
Remote Control
1
2
8
9
12
13
17
19
20
22
23
5
4
3
11
10
15
14
16
18
21
24
7
6
9. ANGLE Button
Switch between multiple camera
angles when the DVD you are playing
has been programmed with multiple
camera angle.
Press repeatedly to select the slide
show mode in playing JPEG pictures.
10. AUDIO Button
Select one of the audio sound tracks on
a DVD (if more than one is available) or
select the audio output mode on a CD.
11. MENU / PBC Button
Enter and exit the main DVD menu.
PBC on / off switch. Return to DVD root
menu (DVD).
12. TITLE Button
Return to DVD Title Menu.
13. Cursor ( , , , ) Buttons
Move between selections on a menu
screen and adjust certain settings.
ENTER Button
Confirm selections on a menu screen.
14. STOP Button
Stop playing a disc.
15. PLAY / PAUSE Button
Press to start playback or pause.
16. MODE Button
Adjust Brightness, Contrast, Hue and
Saturation of the LCD screen.
17. SETUP Button
Display the SETUP menu.
18. VOL + / – Button
Adjust the volume.
19. REPEAT Button
Repeat a DVD chapter or title.
Repeat a CD track or the entire disc.
20. SLOW Button
Press repeatedly to enter slow playback,
and cycle between different speeds.
21. Buttons
Press to perform fast forward / fast
reverse playback.
22. PROGRAM Button
Store the favourite tracks from the disc
in DVD / VCD / CD mode.
23. ZOOM Button
To enlarge the picture.
24. / Buttons
Press the skipping back / ahead at
5-level speed (x2, x4, x8, x16).
C7PDVD10_IB_110218.indd 7 2/18/11 3:35 PM

8
2. Insert two AAA size batteries. Make
sure to match the (+) and (–) ends of
the battery compartment.
Battery Installation for the Remote Control
1. Press and lift the back cover up to
open the battery compartment of the
remote control.
3. Close the battery compartment cover.
Handling the Batteries
• Improper or incorrect use of batteries may cause corrosion or battery leakage, which
could cause fire, personal injury or damage to property.
• Only use the battery type indicated in this manual.
• When the batteries are exhausted, the remote will not function. Replace both batteries
at the same time with new ones.
• Do not install new batteries with used ones and do not mix different types of batteries.
• Do not dispose of used batteries as domestic waste. Dispose of them in accordance
with local regulations.
Handling the Remote Control
• Take care of your fingernails when you press and hold the battery release tab.
• Do not drop or cause impact to the remote control.
• Do not spill water or any liquid on the remote control.
• Do not place the remote control on a wet object.
• Do not place the remote control under direct sunlight or near sources of excessive
heat.
• Remove the battery from the remote control when not in use for a long period of time,
as it could cause corrosion or battery leakage and may result in physical injury and/or
property damage including fire.
Remote Control Operation Range
Point the remote control at the DVD player no more than
2 metres from the remote control sensor and within 40° of
the front of the DVD player. The operating distance may
vary depending on the brightness of the room.
SD/MS/MMC IR
Within about 2 m
20° 20°
C7PDVD10_IB_110218.indd 8 2/18/11 3:35 PM

9
Power Supply
Using the Mains Adapter (for indoor use)
Using the Car Power Adapter (for in-car use)
The 12V car power adapter allows the unit to be used with vehicles that have a 12V,
negative ground electrical system.
• Only use the included mains adapter. Do not use it with any other equipment.
• When the unit is not going to be used for a long period of time, disconnect the
mains adapter from the mains socket.
• When the mains adapter is plugged in, the unit is not completely disconnected
from the main power supply, even when the power is turned off.
• In order to disconnect the unit from the mains completely, the mains adapter
should be disconnected from the mains socket outlet completely.
• Disconnect the car power adapter when not in use. Not for use in 24V vehicles.
• Use the provided 12V car power adapter only. Use with other car pwer adapters
could damage the unit.
• Only use the included 12V car power adapter. Do not use it with any other
equipment.
• In the interest of traffic safety, do not operate this unit or view videos while
driving a vehicle.
• Make sure the unit is securely fastened to prevent it from falling or flying through
the air in the event of an accident.
• When the inside of the cigarette lighter socket is dirty with ash or dust, the plug
section may become hot due to poor contact. Be sure to clean the cigarette
lighter socket before use.
• After use, disconnect the 12V car power adapter from both the unit and the
cigarette lighter socket.
POWER
AV OUT ON OFF DC IN 9-12V
To Mains
Socket
Mains Adapter (included)
Right Side of DVD Player
To DC IN 9V-12V
Socket
POWER
AV OUT ON OFF DC IN 9-12V
Car Power Adapter (included)
To DC IN
9V-12V Socket
Right Side of DVD Player
To Cigarette
Lighter Socket
C7PDVD10_IB_110218.indd 9 2/18/11 3:35 PM

10
Connections
Connecting a TV
If your TV has audio/video inputs, you can connect the unit to your TV using a standard
Audio / Video Cable.
Watching a DVD on your TV
1. Turn on the unit.
2. Turn on the TV and follow the instructions included with it to play the DVD.
Using Earphones
• Turn down the volume before connecting, and then adjust the level.
• When earphones are connected, no sound will be emitted from the unit’s speaker.
POWER
AV OUT ON OFF DC IN 9-12V
Right Side of DVD Player
TV
To AV OUT Sockets
White Red Yellow
Audio / Video Cable (not included)
Everytime you power off the unit you will need to reset the Video Out function.
Avoid listening to sound at levels which may
be harmful to your ears.
POWER
AV OUT ON OFF DC IN 9-12V
Headphones/Earphones
(not included)
Right Side of DVD Player
To Earphone
Socket
C7PDVD10_IB_110218.indd 10 2/18/11 3:35 PM
