MicroVision SHOWWX+ User manual

Contents
4 Important Safety Information
8 Package Contents
9 SHOWWX+™Laser Pico Projector
10 Introduction
10 Getting Started
10 Install Battery
11 Charge Battery
11 Power ON or OFF
12 Connect to a Video Source
12 How To Connect To An iPod, iPhone, or iPad
13 Connecting To Other Composite (TV-Out) VideoSources
14 Usage Guidelines
15 Advanced Controls
15 Menu Controls
15 Onscreen Menu
16 How To Adjust Brightness
16 How To Change Color Mode
16 How To Adjust Aspect Ratio
16 How To Adjust The Image Alignment
17 How To Adjust The Color Alignment
17 How To Reset Default Settings
18 How To Check Remaining Battery Life
18 How to Adjust The Green and Magenta Color
19 Troubleshooting
20 LED Status & Meaning
20 Customer Support
20 Register Your Product Online
20 Care & Maintenance
20 How To Clean The Window
20 How To Store & Transport
20 How To Use The Audio Jack

Intended Use Statement
The SHOWWX+™ laser pico projector is designed to operate with the MicroVision
specified battery and MicroVision battery charger in a normal office and home
environment within the following parameters:
» Operating Temperature: 10° - 30° C, ( 50° - 86° F)
» Storage Temperature: non-operating: - 20° - 60° C, (- 4° - 140° F) with battery
» Humidity: 10 - 85 % relative humidity (without condensation)
» Altitude: - 152 M - 4572 M (- 500 - 15,000 ft.)
AS WITH ANY BRIGHT LIGHT SOURCE, DO NOT STARE INTO THE BEAM.
STARING INTO THE BEAM COULD CAUSE EYE DISCOMFORT AND IMPAIR VISION.
AS WITH ANY PRODUCT CONTAINING LASERS, DO NOT DISASSEMBLE THE PROJECTOR
FOR ANY REASON. DISSASSEMBLING THE PROJECTOR MAY RESULT IN HAZARDOUS LASER
RADIATION EXPOSURE.
EXCEPT FOR OPENING THE BATTERY DOOR AS DIRECTED IN THIS USER GUIDE
TO REPLACE THE BATTERY, THERE ARE NO USER SERVICABLE PARTS INSIDE
THE PROJECTOR.
For service or repair the product must be returned to an authorized repair facility.
See Customer Support section within this User Guide for details.
To avoid risks associated with laser exposure:
» Not recommended for use by children under 14 unless supervised by an adult.
The SHOWWX+ is not a toy.
» Use of controls or adjustments or performance of procedures other than those
specified in this User Guide may result in hazardous laser radiation exposure
To avoid risks associated with hazardous voltage:
» Do not modify this product in any way.
Use only MicroVision approved replacement components.
» Do not use the AC adapter in a wet environment.
» No not use with a damaged AC adapter. Replace damaged AC adapter prior to use.
Important Safety Information
PLEASE READ, UNDERSTAND AND FOLLOW ALL SAFETY INFORMATION IN THIS
USER GUIDE BEFORE YOU USE THIS PROJECTOR. FAILURE TO PROPERLY SET UP, USE,
AND CARE FOR THIS PROJECTOR CAN INCREASE THE RISK OF INJURY, OR DAMAGE
TO THE PROJECTOR. KEEP THIS USER GUIDE FOR FUTURE REFERENCE.
Indicates a potentially hazardous situation, which
if not avoided, may result in death or serious injury
and/or property damage.
4
Warning

To avoid risks associated with fire and explosion:
» Do not immerse the projector or battery in any liquid or allow either to get wet.
» Use only AC adapter and battery provided by MicroVision.
» Do not disassemble the battery or modify it in any way.
» Do not attempt to short out the battery.
» Do not expose the battery to temperatures under -20°C or above 60°C.
» Do not crush the battery.
» Do not overcharge or rapidly discharge the battery.
» Do not dispose of the battery by incineration or fire.
» Do not expose the projector or battery to direct sunlight in a closed space such
as a vehicle.
To avoid risks of other injuries:
» Do not handle a damaged or leaking battery pack.
» Do not handle a battery that has been handled in an inappropriate or dangerous manner.
To avoid risks associated with driver distraction in a moving vehicle:
» Do not use this projector in a moving vehicle in a manner that may distract the driver.
» Do not point the projected image at people, vehicles, or aircraft.
» Risk of explosion if battery is replaced by an incorrect type.
» Dispose of used batteries according to the instructions contained within this guide.
To avoid risks associated with environmental contamination:
» Dispose of all system components in accordance with applicable government regulations.
To avoid risks associated with tripping and falling:
» Position the charging cord and data cables so that they can not be tripped over.
Photosensitive Seizure Warning
A very small percentage of people may experience seizures or blackouts that are triggered
by exposure to light flashes or certain visual images including flashing lights or patterns
that may appear in video games or other video images. Even people who have no history
of seizures or blackouts could experience “photosensitive epileptic seizures” while watching
some video images.
Immediately stop watching projected video images and consult a physician if you experience
symptoms such as lightheadedness, altered vision, eye or face twitching, convulsions,
disorientation, confusion or momentary loss of awareness.
Taking the following precautions while watching video may help reduce
the risk of photosensitive epileptic seizures.
» Avoid use while tired or fatigued.
» Take frequent breaks.
» Look away from the screen from time to time.
» Sit further away from the projected image.
Indicates a potentially hazardous situation,
which if not avoided, may result in minor or moderate
injury and/or property damage.
5
caution

Laser Specifications
The SHOWWX+™ Laser Pico Projector is a CLASS 2 LASER PRODUCT as defined in IEC 60825-1,
2007-03. MicroVision has designed the SHOWWX+ to be safe for general use as a mobile
projector.
IEC and CDRH Statements of Compliance
The SHOWWX+ complies with IEC 60825-1, 2007-03. The device also complies with
21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50
dated June 24, 2007.
The following safety labels are affixed at the factory.
THESE LABELS CONTAIN IMPORTANT SAFETY INFORMATION. DO NOT REMOVE THEM.
Safety Labels
6
Located inside the SHOWWX+.
Do not attempt to disassemble
the SHOWWX+.
Bottom View
Laser
Color Red Green Blue
AlGalnP
laser diode
Frequency doubled
IR laser diode
GaN
laser diode
120 mW 72 mW 50 mW
632 nm 526 nm 440 nm650 nm 537 nm 460 nm
Laser
Type
Max CW
Output
Wave-
length

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference (2) this device must accept any
interference received including interference that may cause undesired operations. This applies
to all product options.
FCC Radio Frequency Interference Statement
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
» Reorient or relocate the receiving antenna.
» Increase the separation between the equipment and receiver.
» Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
» Consult the dealer or an experienced radio/TV technician for help. To comply with FCC
RF exposure compliance requirements, a separation distance of at least 20 cm must be
maintained between the antenna of this device and all persons. This transmitter
must not be collocated or operating in conjunction with any other antenna or transmitter.
Caution: Changes or modifications to this equipment not expressly approved
by manufacturer could void the user’s authority to operate this equipment.
CE Statement
This product complies with the requirements of the Low Voltage Directive 2006/95/EC
and the EMC Directive 2004/108/EC and carries the CE mark accordingly.
Directions for Recycling Battery
Recycle battery in accordance with local laws. In the United States and Canada,
visit www.call2recycle.org or call 1-800-8-BATTERY (1-800-822-8837)
or 1-877-2-RECYCLE (1-877-273-2925) for the nearest recycling center.
Product Disposal
The SHOWWX+™ laser pico projector should not be placed in household waste bins.
Please check local regulations for information about the disposal of electronic products
in your area.
Made for iPod, iPhone, and iPad
“Made for iPod, iPhone, and iPad” mean that an electronic
accessory has been designed to connect specifically to iPod,
iPhone, or iPad, respectively, and has been certified by the
developer to meet Apple performance standards. Apple is not responsible for the operation
of this device or its compliance with safety and regulatory standards.
Please note that the use of this accessory with iPod, iPhone, or iPad may affect wireless
performance. Specifications subject to change without notice.
Copyright & Trademarks
©2010 MicroVision, Inc. All rights reserved. PicoP®and SHOWWX+™ are trademarks of MicroVision Inc.
iPhone, iPod, iPod classic, iPod nano, and iPod touch are trademarks of Apple Inc., registered
in the U.S. and other countries. iPad is a trademark of Apple Inc.
FCC Declaration of Conformity
7

+-
B
Package Contents
Please make sure you have received all items included with the product.
For missing items contact customer support.
SHOWWX+
Laser Pico Projector
SHOWWX+
Cable for iPod,
iPhone, and iPad
SHOWWX+
Wall Charger
SHOWWX+
Composite Adapter
Wrist Strap
SHOWWX+
Rechargable Battery
Micro-USB Cable
Storage Pouch User Guide
and Warranty Card
8

Window
Up/Hot Key 1
Down/Hot Key 2
Power Button
Menu/Select Button
LED Indicators
Micro-USB/Power Input
3.5 mm Audio Jack
Video Input
Wrist Strap Holder
SHOWWX+™ Laser Pico Projector
9

Introduction
Thank you for purchasing the MicroVision SHOWWX+™laser
pico projector. The SHOWWX+ projects big, bright, and colorful
images that are always in focus, yet is small enough to fit in your
pocket. Connect the SHOWWX+ to a video output-capable device to
spontaneously share photos and videos, presentations
and more, in a big screen experience.
What is the PicoP®Display Engine?
The PicoP display engine is the world’s first ultra miniature
laser-based projector engine. It uses red, green and blue laser light
sources, electronics, optics, and a unique, tiny mirror-like device that
“paints” the image line-by-line on the projection surface.
Getting Started
Install Battery
» Make sure the projector is OFF and unplugged before replacing battery.
» Do not force the battery in. Make sure the battery + / - symbols are lined up.
10
Remove Battery Door
Insert Battery
Close Battery Door
1
2
3
2
112
2
1

Charge Battery
Note:
» Allow for a minimum of 4 hours charging before first time use.
» The wall charger will not charge the battery while the SHOWWX+ is powered ON.
» The supplied battery is designed specifically for the SHOWWX+ and no other battery
should be used.
Power ON or OFF
Note: Do not have the SHOWWX+ connected to any video
device before turning ON.
Turning ON: Press and hold the button.
The blue LED will come on and the image will appear
in about 15 seconds.
Turning OFF: Press the button.
Note:
» During startup the image will flash with a series of different colors. This is normal.
» A blinking Blue LED indicates the unit is starting up. A solid Blue LED indicates
the unit is ready for use.
11
Plug Wall Charger Into Outlet Connect To
Micro-USB/Power Input
Orange LED: Battery charging
Green LED: Battery fully charged
1 2
3

Connect to a Video Source
The SHOWWX+™ can connect to a variety of devices with TV-out such as an iPod, iPhone,
iPad, a laptop, cell phone, camera, and more. The following describes the connectivity
options available with the SHOWWX+.
How to Connect to an iPod, iPhone, or iPad
To see compatible devices with the SHOWWX: http://www.MicroVision.com/showwx/compatibility.html
Cable
SHOWWX+ Cable for iPod,
iPhone, and iPad
SHOWWX+ Composite Video
Adapter (NTSC/PAL)
SHOWWX+ VGA Dock
Connect SHOWWX+ to...
iPod, iPhone, or iPad with
Component TV-out
Any device with a male
RCA Video out connection
Laptop and PC devices
Included
Yes
Yes
No
Sold Separately
Yes
Yes
Yes
Note:
» While connected to an iPod, iPhone, or iPad
the Audio Jack on the iPod can also be used.
» To see compatible devices with the SHOWWX+
visit http://www.MicroVision.com/showwx/
12
Ready To Use
Ready To Use
Ready To Use
Power on the projector
1Connect the cable to the projector 2
Connect the cable to the iPod, iPhone,
or iPad (already on)
3Wait to see “Ready To Use” alert 4
Select Picture or Video content
and Press play on iPod, iPhone,
or iPad
5

Connecting to Other Composite
(TV-out) Video Sources
The SHOWWX+ can connect to other video sources that have Composite (TV/Video-Out)
using the included Composite adapter. To display content, make sure the source device
has TV/Video-Out set to “ON” or “Enabled”. To learn if your video source device is capable
of TV/Video-Out and how to enable, refer to its User Guide.
13
Connect the adapter to the projector
Power on the projector
Connect the Composite adapter
to the yellow video RCA connector
that is connected to your
TV-out device
Enable video out from source
device and play video
1
3
2
4
Ready To Use

Semi-Lit
Home / Office
Semi-Dark
Dimmed Lighting
Note:
Image diagonal is approximately equal to the distance from the projector to the screen.
There are two main factors to consider when using
the SHOWWX+.
Ambient light
» It is recommended to shut blinds, close curtains
and turn lights down to make the room dark
so the projected image looks the best.
Distance from screen
» The projector distance from the screen will impact
the appearance of the image brightness.
The closer to the screen the brighter the image will appear.
Complete Darkness
<12”
24”-36”
70”-100”
Usage Guidelines
The following is a guideline of what image sizes are possible under
various lighting conditions:
14

Advanced Controls
Menu Controls
The SHOWWX+ was designed as a plug-and-play device, however, some users may want
to make adjustments to the settings such as change colors, adjust aspect ratio, and adjust
brightness. The following information will help you understand how to fully operate
the SHOWWX+.
Hot Keys
The SHOWWX+ includes two hot keys to allow the
user to quickly adjust the image depending on the
type of content being shown.
Color Mode: Color mode can be changed without
going into the Menu screen by pressing the button
to change the color mode. Press the button to
cycle through the color modes.
Gamma Mode: Gamma mode can be changed
without going into the Menu screen by pressing on
the button. Press the button to cycle through
the gamma modes.
Note: The Color Mode hot key also includes the
ability to invert the image. Inverting the image may
improve the readability of certain images. Also,
if the content background is predominately white,
then inverting the image (e.g., white becomes black) will extend battery life.
Onscreen Menu
The SHOWWX+ has an onscreen display to allow the user the ability to make advanced
changes to the projector. All settings changed by the user will remain even when powered off.
Brightness: High (default) / Medium / Low
Color Mode: Brilliant (default) / Standard / Inverted / Gamma
Aspect Ratio: Widescreen (default) / Normal / Zoom
System: Image Alignment / Color Alignment / Properties / Reset Defaults
15

How To Change Color Mode
The SHOWWX+ has 3 default color modes.
Brilliant Colors: Bright and vivid colors.
Standard Colors: More accurate flesh tones and grey scales.
Inverted Colors: All colors are inverted. Useful for presentations with black
text on white backgrounds.
Press the button to bring up the on screen menu.
Use the or buttons to navigate to COLOR MODE and press .
Select the desired setting and press to accept.
How To Adjust Aspect Ratio
The image may appear cropped or skinny. The aspect ratio may be different
from the video source device.
Press the button to bring up the on screen menu.
Use the or buttons to navigate to ASPECT RATIO and press .
Select the desired setting and press to accept.
How To Adjust Brightness
The image brightness can be reduced for close distance viewing in darker environments.
Press the button to bring up the on screen menu.
Use the or buttons to navigate to BRIGHTNESS and press .
Select the desired setting and press to accept.
The image may appear to be slightly fuzzy. Adjustment of the image alignment
may be necessary.
Press the button to bring up the on screen menu.
Use the or buttons to navigate to SYSTEM and press .
Navigate to IMAGE ALIGNMENT and press .
Press the or buttons to adjust the image until all vertical lines appear sharp and clear.
How To Adjust The Image Alignment
16
1
1
1
1
2
2
2
2
3
3
3
3
4

How To Reset Default Settings
To reset all user selectable settings to factory defaults.
Press the button to bring up the on screen menu.
Use the or buttons to navigate to SYSTEM and press .
Use the or buttons to navigate to RESET DEFAULTS and press .
Press the or buttons to select YES and press .
Users can adjust horizontal or vertical alignment of each individual color
(red, green, and blue).
Press the button to bring up the on screen menu.
Use the or buttons to navigate to SYSTEM and press .
Use the or buttons to navigate to COLOR ALIGNMENT and press .
An image of a vertical and horizontal crossed in the middle will appear
in the center of the screen.
Use the or buttons to select the desired color (Red Adjust, Green Adjust,
Blue Adjust) to adjust and press .
Use the or buttons to select either HORIZONTAL or VERTICAL ADJUSTMENT
and press .
Use the or buttons to move the selected color until a solid white line isvisible
either vertically or horizontally.
How To Adjust The Color Alignment
Note:
» When adjusting colors HORIZONTALLY use the Vertical line (top-bottom) as the reference.
» When you exit the configuration menu after image alignment it will take 10 seconds
for the normal image to appear.
17
1
3
1
2
4
2
3
5
6
7
4

How to Check Remaining Battery Life
Follow these instructions to view how much battery life is remaining.
Press the button to bring up the on screen menu.
Use the or buttons to navigate to SYSTEM and press .
Use the or buttons to navigate to PROPERTIES and press .
Use the or buttons to navigate to BATTERY INFORMATION and press .
The image may appear to have green shadows or a magenta color when it should be white.
Adjustment of the Green/Magenta color may be necessary
Auto Adjustment
Turn on the projector and let it run for 5 minutes.
Press the button to bring up the on-screen menu.
Use the or buttons to navigate to SYSTEM and press .
Use the or buttons to navigate to GREEN/MAGENTA BAL and press .
Use the or buttons to navigate to AUTO and press .
Note:
Vertical magenta lines will appear. The lines will automatically adjust to white.
Once adjustment is done, the splashscreen will appear after about 10 seconds.
Manual Adjustment
Follow steps 1-4
Use the or buttons to navigate to MANUAL PATTERN or MANUAL VIDEO
and press .
Manual Pattern: A grid image will appear. Manual Video: Requires content from a video
source device. Use of a photo when making adjustments is recommended.
Use the or buttons to adjust the grid pattern until all lines appear completely
white. Or, adjust until all green shadows or magenta highlights are gone from the photo.
Press the button to confirm. After 10 seconds of no activity, the splashscreen
will reappear.
How to Adjust The Green and Magenta Color
18
1
1
1
2
2
2
3
3
3
5
4
4
4

Troubleshooting
Problem Cause Solution
The projector does
not turn on.
Battery not inserted
correctly.
Battery not charged.
Make sure the battery
is correctly inserted.
Make sure the battery is fully charged.
The projector colors look
incorrect.
Different Color Mode
may be selected.
Change to preferred Color Mode.
The projector randomly
turns off but the Blue
LED stays on.
The projector may be
out of the recommend-
ed operating range.
Make sure the projector is well ventilated
and within the operating temperature
range. Turn off for 5 minutes and restart.
Not working with my
iPod, iPhone, or iPad
Not securely connected,
- OR –
No TV-out signal
detected
Make sure cable is securely connected at
both ends and a “Ready to Use” message
appears on the projector.
Make sure you have pressed the play
button on the videos or picture controls.
The projector won’t turn
off or on and the Blue
LED stays on.
System is frozen. Press and hold the Power button for 20
seconds. If this does not work, remove
battery. Then re-insert and turn on.
I can’t connect
to my laptop.
SHOWWX+ VGA Dock
sold separately.
Purchase the SHOWWX+ VGA Dock.
The projector doesn’t
work with my cell phone.
Not all cell phones have
the TV-out feature.
Refer to your cell phone manufacturer’s
user guide if TV-out is available and how
to configure.
The image looks
a little fuzzy.
Debris on Window,
- OR -
Image is misaligned.
Clean the Window,
-OR-
Adjust Image Alignment.
The green LED keeps
blinking while charging.
The battery is not
correctly inserted in the
SHOWWX+.
Make sure battery is correctly inserted
into the SHOWWX+.
The red LED is blinking. Out of operating range.
Temporary problem.
Turn projector off. Remove battery.
Re-insert and power on.
Battery doesn’t charge. Battery may not be
capable of holding
a charge.
Install new battery.
The red LED is constantly
on even after trying to
restart.
System failure. Contact Customer Support.
Part of the image has
a green or magenta
shadow.
Green or Magenta color
out of alignment.
Adjust the Green and Magenta
Color alignment.
How to Adjust The Green and Magenta Color
19

LED Status & Meaning
LED Status Meaning
Solid Blue SHOWWX+ is powered on
Blinking Blue SHOWWX+ is powering up
Solid Orange Battery is charging
Solid Green Battery is fully charged
Blinking Orange Battery is low
Blinking Red Temporary problem
Solid Red System failure
Customer Support
Registering your new MicroVision product online is quick and easy. Your registration will allow
us to serve you better over the lifetime of your product. Being a registered owner also keeps
you informed of important product notifications and helps us continue to design products that
meet your needs. Please have the Product Serial Number when you register.
http://www.MicroVision.com/showwx/register
Register your Product Online
For Technical Questions, service and support please visit us online at
http://www.MicroVision.com/showwx/support/ Please have your Serial Number
and purchase information available. You can find the Serial Number located under the battery.
How To Clean The Window
Fingerprints and other debris may impact the image quality.
Keep the window clean for best image quality.
Apply a non-abrasive camera lens cleaner to a soft, dry cloth.
Lightly wipe the cleaning cloth over the window until clean.
Note: Do not attempt to use solvents or other harsh chemicals as it may damage the window.
Make sure cleaning cloth is free of dust or debris to avoid scratching the window.
Care & Maintenance
How to Store & Transport
Proper care should be taken to safely store
and transport the projector. Please use the
included storage pouch. Do not drop the
SHOWWX+ or spill liquids on it.
How to Use the Audio Jack
The audio jack on the SHOWWX+ works
only when the Audio signal is combined
with the Video signal. The Audio Jack
is for output only.
20
1
2
