Miele TMV 840 WP User manual

Operating instructions
Heat pump tumble dryer
To avoid the risk of accidents or damage to the appliance, it is essential
to read these instructions before it is installed and used for the first time.
en-AU, NZ M.-Nr. 10 263 330

Caring for the environment
2
Disposal of the packing
material
The packaging is designed to protect
the appliance from damage during
transportation. The packaging materials
used are selected from materials which
are environmentally friendly for disposal
and should be recycled.
Recycling the packaging reduces the
use of raw materials in the
manufacturing process and also
reduces the amount of waste in landfill
sites. Ensure that any plastic
wrappings, bags etc. are disposed of
safely and kept out of the reach of
babies and young children. Danger of
suffocation.
Disposing of your old
appliance
Electrical and electronic appliances
often contain materials which, if
handled or disposed of incorrectly,
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your appliance.
Therefore, please do not dispose of
your old appliance with your household
waste.
Please dispose of it at your local
community waste collection / recycling
centre.
Ensure that your old appliance presents
no danger to children while being
stored for disposal.
Energy saving tips
To avoid unnecessarily long drying
times and high consumption of energy:
– Make sure that your laundry is
thoroughly spun before drying.
The higher the spin, the greater the
savings that can be made in energy
and time during drying, e.g. approx.
20% energy can be saved if spun at
1600 rpm instead of 1000 rpm.
– Load according to the optimum
amount of laundry recommended for
the programme being used.
Underloading is uneconomical.
Overloading gives a poorer quality of
drying and may cause unnecessary
creasing.
– Make sure the room temperature is
not too high. If there are other heat
producing appliances in the room in
which the tumble dryer is located,
make sure the room is well-ventilated
and switch the other appliances off, if
possible.
– Clean the fluff filters in the door
opening after every drying cycle.

Contents
3
Caring for the environment .................................................................................. 2
Warning and Safety instructions ......................................................................... 6
Operating the tumble dryer................................................................................. 17
Control panel.......................................................................................................... 17
Touch display and sensors .................................................................................... 18
Main menu ......................................................................................................... 18
Examples on how to operate the appliance........................................................... 19
Before using for the first time............................................................................. 21
EcoFeedback........................................................................................................ 23
1. Notes on correct laundry care........................................................................ 24
Points to note regarding washed laundry .............................................................. 24
Preparing the laundry before drying ...................................................................... 24
Garment care label symbols............................................................................. 25
Laundry care when drying in a tumble dryer ......................................................... 25
2. Loading the tumble dryer................................................................................ 26
3. Selecting a programme and starting it .......................................................... 27
(1) Programmes...................................................................................................... 27
(2) Favourite programmes ...................................................................................... 30
(3) Drying assistant................................................................................................. 30
(4) Mixed items....................................................................................................... 30
Selecting any Extras or Delay start (if required)..................................................... 31
Starting the programme......................................................................................... 32
4. Removing the laundry at the end of the programme.................................... 33
End of programme/Anti-crease.............................................................................. 33
Removing the laundry............................................................................................ 33
Extras .................................................................................................................... 34
Freshen up ............................................................................................................. 34
ECO........................................................................................................................ 34
Anti-crease............................................................................................................. 34
Auto load control.................................................................................................... 34
Gentle tumble......................................................................................................... 34
Turbo...................................................................................................................... 34
Drying programme chart - Extras........................................................................... 35
Favourite programmes ........................................................................................ 36

Contents
4
Drying assistant ................................................................................................... 38
Selecting a textile type........................................................................................... 38
List of textile types................................................................................................. 39
Mixed items .......................................................................................................... 40
Selecting items....................................................................................................... 40
List of items ...................................................................................................... 41
Delay start............................................................................................................. 42
Programme chart ................................................................................................. 43
Changing the programme sequence.................................................................. 50
Cleaning and care................................................................................................ 51
Emptying the condensed water container............................................................. 51
Preparing the condensed water container for Steam smoothing.......................... 52
Fluff filters .............................................................................................................. 53
Removing visible fluff........................................................................................ 53
Cleaning the fluff filters and air flow openings thoroughly................................ 54
Plinth filter .............................................................................................................. 55
Removing the plinth filter.................................................................................. 55
Cleaning the plinth filter.................................................................................... 55
Cleaning the plinth filter panel .......................................................................... 56
Checking the heat exchanger unit .................................................................... 56
Replacing the plinth filter .................................................................................. 57
Fragrance flacon .................................................................................................. 59
Inserting a fragrance flacon ................................................................................... 59
Replacing the fragrance flacon .............................................................................. 61
Problem solving guide......................................................................................... 63
Problem solving guide ........................................................................................... 63
Messages in the display ........................................................................................ 63
Unsatisfactory drying results ................................................................................. 65
Other problems ...................................................................................................... 66
Bottom right grille .................................................................................................. 69
Fluff filter in the condensed water container.......................................................... 70
Steam smoothing spray jet .................................................................................... 71
After sales service ............................................................................................... 72
Repairs................................................................................................................... 72
Optional accessories ............................................................................................. 72
Warranty................................................................................................................. 72

Contents
5
Installation and connection................................................................................. 73
Front view............................................................................................................... 73
Rear view ............................................................................................................... 74
Transporting the dryer............................................................................................ 74
Installation.............................................................................................................. 75
Levelling the dryer............................................................................................. 75
Ventilation ......................................................................................................... 76
Before moving the tumble dryer again (e.g. when moving houses).................. 76
Additional installation requirements....................................................................... 77
Externally draining condensed water..................................................................... 78
Installation conditions requiring a non-return valve.......................................... 78
Arranging the drain hose................................................................................... 79
Examples .......................................................................................................... 80
Changing the door hinging .................................................................................... 82
Changing the hinging over................................................................................ 82
Refitting............................................................................................................. 87
Electrical connection.............................................................................................. 88
Consumption data ............................................................................................... 89
Technical data ..................................................................................................... 90
Settings menu ...................................................................................................... 91
Calling up settings ................................................................................................. 91
Language ............................................................................................................ 91
Time ....................................................................................................................... 92
Drying levels .......................................................................................................... 92
Extended cool down.............................................................................................. 92
Airways indicator.................................................................................................... 92
Buzzer volume ...................................................................................................... 93
Keypad tone........................................................................................................... 93
Conductivity........................................................................................................... 93
Total consumption ................................................................................................. 94
PIN Code................................................................................................................ 94
Display brightness ................................................................................................ 95
Display switch-off status........................................................................................ 95
Appliance switch-off status ................................................................................... 95
Display maximum load........................................................................................... 95
Memory.................................................................................................................. 96
Anti-crease............................................................................................................. 96
Delay start.............................................................................................................. 96

Warning and Safety instructions
6
It is essential to read these instructions.
This tumble dryer complies with current local and national safety
requirements. Inappropriate use can, however, lead to personal
injury and damage to property.
To avoid the risk of accidents and damage to the tumble dryer,
please read these instructions carefully before using it for the first
time. They contain important information on its safety, installation,
use and maintenance.
Keep these instructions in a safe place and ensure that new users
are familiar with the content. Pass them on to any future owner.
Correct application
This tumble dryer is designed for domestic use and for use in
similar environments by guests in hotel or motel rooms, bed &
breakfasts and other typical living quarters. This does not include
common/shared facilities or commercial facilities within hotels,
motels or bed & breakfasts.
This tumble dryer is not suitable for outdoor use.
It must only be used to dry items which have been washed in a
water solution and which are marked on the manufacturer's care
label as being suitable for tumble drying. If using dry cleaning kits,
do so at your own risk, and follow the instructions provided on the
packaging.
Any other applications may be dangerous. Miele cannot be held
liable for damage resulting from incorrect or improper use or
operation.

Warning and Safety instructions
7
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience or knowledge, unless they are supervised whilst
using it or have been shown how to use it by a person responsible
for their safety.
Safety with children
Young children must not be allowed to use this appliance.
Older children may only use the appliance when its operation has
been clearly explained to them and they are able to use it safely,
recognising the dangers of misuse.
Children must not be allowed to clean or maintain the tumble
dryer unsupervised.
Please supervise children in the vicinity of the tumble dryer and
do not let them play with it.

Warning and Safety instructions
8
Technical safety
Before setting up the tumble dryer, check it for any externally
visible damage.
Do not install or use a damaged tumble dryer.
Before connecting the tumble dryer, ensure that the connection
data on the data plate (fuse rating, voltage and frequency) matches
the mains electricity supply. If in any doubt, consult a qualified
electrician.
The electrical safety of this tumble dryer can only be guaranteed
when correctly earthed. It is essential that this standard safety
requirement is met. If in any doubt, please have the household
wiring system tested by a qualified electrician. Miele cannot be held
liable for the consequences of an inadequate earthing system (e.g.
electric shock).
Reliable and safe operation of this tumble dryer can only be
assured if it has been connected to the mains electricity supply.
Do not connect the tumble dryer to the mains electricity supply by
an extension lead. Extension leads do not guarantee the required
safety of the appliance (e.g. danger of overheating).
If the connection cable is faulty, it must only be replaced by a
Miele approved service technician to protect the user from danger.
Unauthorised repairs could result in unforeseen dangers for the
user, for which Miele cannot accept liability. Repairs should only be
undertaken by a Miele authorised service technician, otherwise any
subsequent damage will not be covered by the warranty.
Faulty components must only be replaced by genuine Miele spare
parts. Miele can only guarantee the safety of the appliance when
Miele replacement parts are used.

Warning and Safety instructions
9
In the event of a fault or for cleaning purposes, the tumble dryer is
only completely isolated from the electricity supply when:
– it is switched off at the wall socket and the plug is withdrawn, or
– it is switched off at the mains circuit breaker.
This tumble dryer must not be installed and operated in mobile
installations (e.g. on a ship).
Do not make any alterations to the tumble dryer, unless
authorised to do so by Miele.
Heat pump technology and refrigerant:
The heat pump in this tumble dryer uses a refrigerant which is
condensed by the compressor and led in a closed circuit through
the heat exchanger unit where heat exchange with the circulating
drying air takes place.
– The humming noises caused by the heat pump are normal and do
not impair the efficient functioning of the dryer.
– The refrigerant is not flammable or explosive.
– In general it is not necessary to leave the dryer standing for any
length of time before it is connected to the mains provided it has
been transported and installed correctly.

Warning and Safety instructions
10
Please observe the instructions in "Installation and connection"
and "Technical data".
The accessibility of the plug must be always ensured in order to
separate the tumble dryer from the mains.
Do not block the gap between the bottom of the tumble dryer and
the floor with plinth facings, deep pile carpet etc. This would hinder
a sufficient flow of air to the tumble dryer.
Make sure the dryer door can be opened without hindrance after
installation.

Warning and Safety instructions
11
Correct use
Caution! Risk of fire.
To avoid the possible danger of fire, please read these warnings
carefully.
A clogged filter is a fire hazard!
The fluff filter must be cleaned after every programme.
The maximum load for this tumble dryer is 9.0 kg (dry weight).
See the "Programme chart" for the maximum recommended loads
for individual programmes.
To prevent the risk of fire, do not connect the tumble dryer via a
controllable socket (e.g. a timer or a peak-load switch-off device).
If the drying programme is interrupted before the end of the cooling
down phase, this could cause the laundry to self-ignite.

Warning and Safety instructions
12
To prevent the risk of fire, the following textiles must not be dried
in this tumble dryer:
– Items which have not been washed.
– Items, such as workwear, which have not been thoroughly
cleaned and which are still soiled with grease, oil or other
desposits (such as cosmetics, lotions etc). If items have not been
thoroughly cleaned, there is a danger that these might ignite
when heated, even after they have been removed from the dryer
at the end of the programme.
– Items that have been soiled with substances such as cooking oil,
acetone, petrol, kerosene, spot removers, turpentine, waxes, wax
removers and other chemicals (e.g. mops and floor cloths).
– Items which have been splashed with hair lacquer, hair spray, nail
varnish remover or similar substances.
When washing such heavily soiled items ensure that you use
sufficient detergent and select a high temperature. If in doubt,
wash the items several times.
Oil-affected items can ignite spontaneously, especially when
exposed to heat sources such as in a tumble dryer.
The items become warm, causing an oxidation reaction in the oil.
Oxidation creates heat.
If the heat cannot escape, the items can become hot enough to
catch fire. Piling, stacking or storing oil-affected items can prevent
heat from escaping and so create a fire hazard.
If it is unavoidable that fabrics contaminated with vegetable or
cooking oil, or hair care products, be placed in a tumble dryer, they
should first be washed in hot water with extra detergent - this will
reduce, but not eliminate, the hazard.
Remove all items from pockets (e.g. lighters, matches).

Warning and Safety instructions
13
Warning: Ensure that you always wait until the end of the
programme before removing the laundry. If the drying programme is
stopped prematurely, remove the laundry immediately and hang it
up or spread it out to cool it down.
Fabric softener and similar products must be used according to
the instructions on the manufacturer's packaging.
To prevent the risk of fire, the following textiles must not be dried
in this tumble dryer:
– Items which have been cleaned using chemicals (e.g.
professional dry-cleaning agents).
– Fabrics which contain a large proportion of rubber, foam rubber
or rubber-like materials. For example, products made from latex
foam rubber, shower caps, waterproof textiles, rubberised articles
and items of clothing and pillows with foam rubber filling.
– Damaged fabrics which contain padding or fillings (e.g. pillows,
jackets). When damaged, the filling can get out with the risk of it
igniting in the dryer.
In many programmes, the heating phase is followed by a cooling
down phase to ensure that the items are not too hot to handle when
you remove them (this also avoids the danger of the laundry self-
igniting). The programme is not finished until the cooling down
phase has been completed.
As soon as the programme has finished, remove all laundry from the
drum.
Do not let anyone sit or lean on the door, as this can cause the
tumble dryer to tip up.
Always close the door after use. This way you will avoid the
danger of:
– children climbing onto or into the dryer or hiding things in it.
– pets or other small animals climbing into it.

Warning and Safety instructions
14
The tumble dryer must not be used without or
– with damaged fluff filters.
– with a damaged plinth filter.
This would cause an excessive build-up of fluff which in turn would
cause a fault.
The fluff filters must be cleaned after every drying cycle.
Fluff must not be allowed to accumulate around the tumble dryer.
The fluff filters and the plinth filter must be thoroughly dried after
cleaning. Do no replace them if they are damp or wet. Damp or wet
filters could cause operational faults.
Do not install the tumble dryer in a room where there is a risk of
frost occurring. At temperatures around freezing point the tumble
dryer may not be able to operate properly. There is a risk of damage
if the condensed water is allowed to freeze in the pump and hoses.
If the water is drained externally through the drain hose instead of
being collected in the condensed water container, make sure the
drain hose is securely attached if you hang it in a sink or basin to
avoid the hose slipping and the water causing damage.
Condensed water is not drinking water.
It can cause health problems in both people and animals.
Always keep the area around the tumble dryer free of dust and
fluff.
Dust drawn into the tumble dryer can cause blockages in the heat
exchanger over time.
The tumble dryer must not be hosed down.

Warning and Safety instructions
15
Using a fragrance flacon (optional accessory)
Only use genuine Miele original fragrance flacons.
The fragrance flacon must be stored in its packaging so please
make sure you retain this.
Caution. The fragrance can run out of the flacon. Make sure that
you always keep the flacon, or the fluff filter with the flacon inserted
in it, in a horizontal position when carrying and do not tip or place
down on any surface.
Use an absorbent cloth immediately to wipe up any fragrance
which has run out of the flacon onto the floor, the dryer or any dryer
components (e.g. the fluff filter).
If fragrance which has run out of a flacon should come in contact
with the skin - wash the skin thoroughly with soap and water; come
in contact with the eyes - rinse the eyes with clean water for at least
15 minutes; be swallowed - rinse out the mouth thoroughly with
clean water. Seek medical advice in the case of contact with the
eyes or if fragrance has been swallowed.
If fragrance which has run out of a flacon comes in contact with
clothing, change the clothing immediately. Wash the clothing or any
cloths used for mopping up fragrance thoroughly with plenty of
water and detergent.
There is the risk of fire or damage to the tumble dryer if the
following instructions are not observed:
– Never refill a flacon with fragrance.
– Never use a faulty fragrance flacon.
Dispose of an empty fragrance flacon with the household waste
and never use it for any other purpose.
Please also observe the information supplied with the fragrance
flacon.

Warning and Safety instructions
16
Accessories
Only use genuine Miele spare parts and accessories with this
appliance. If spare parts or accessories from other manufacturers
are used, this will invalidate the warranty, and Miele cannot accept
liability.
A Miele tumble dryer can be stacked on top of a Miele washing
machine using the appropriate stacking kit (available as an optional
accessory). Please make sure you order the correct one for the Miele
washing machine and Miele tumble dryer.
Miele cannot be held liable for damage caused by non-
compliance with these Warning and Safety instructions.

Operating the tumble dryer
17
Control panel
aTouch display
See the next page for more
information.
bStart/Stop sensor
For starting the programme selected
and cancelling a programme once it
has started.
The programme selected can be
started as soon as the sensor starts
flashing.
csensor
The sensor lights up when
information about the menu in the
display is available.
dsensor
For returning to the main menu.
Values set previously are not saved.
eOptical interface
For service technicians.
fbutton
For switching the tumble dryer on
and off. To save energy, the tumble
dryer will switch off automatically 15
minutes after the end of the
programme/Anti-crease phase or
after being switched on if no other
selection is made.

Operating the tumble dryer
18
Touch display and sensors
The , and Start/Stop sensors and
the sensors in the display react to
fingertip contact.
The display can be scratched by
pointed or sharp objects, e.g. pens.
Only touch the touch display with
your fingertips.
Touching the sensors in the display
reveals a list of options or a sub-menu
and also takes you to another menu.
In some instances, if you do not touch
one of the sensors for several seconds,
the display will revert to the previous
menu. You may then need to enter the
settings again.
Main menu
After switching on, the main menu will
appear in the display.
You access all the important sub-
menus from the main menu.
You can return to the main menu at
any time by touching the sensor.
Values set previously are not saved.
10:30
Programmes
Favourite programmes
Drying assistant
< >
1
2
3
4
5
Programmes
For selecting a programme.
Favourite programmes
You can save up to ten of your own
customised programmes.
See "Favourite programmes" for more
information.
Drying assistant
The Drying assistant guides you step by
step so that you can select the
optimum drying programme for your
laundry.
See "Drying assistant" for more
information.
Scroll bar
The scroll bar indicates that further
options or more text follows.
The width of the scroll bar changes
depending on the length of the option
list or information.
The position of the scroll bar indicates
where you are in a list or block of text.
Navigation sensors
You can use the < and > sensors to
scroll through a list or block of text.
Touch the > sensor to scroll to the
second page of the main menu .
10:30
Mixed items
Settings
< >
6
7

Operating the tumble dryer
19
Mixed items
For drying a small mixed load
consisting of different types of fabric
when it is not obvious which
programme is the most suitable.
The tumble dryer will use the list of
items to determine the correct
programme setting.
See "Mixed items" for more
information.
Settings
You can alter the tumble dryer's
electronics to suit changing
requirements in the Settings menu.
See "Settings menu" for more
information.
Examples on how to operate
the appliance
Option lists
Programmes menu (single option list):
Programmes
Delicates Express
< >
Minimum iron
Automatic plus
Cottons
Denim
Touching the < or > sensor scrolls to
the left or right of the list.
The scroll bar indicates that further
options follow.
Touch a programme name to select the
programme.
The load for the programme selected
will appear in the display.
After a few seconds or if you confirm
with the OK sensor, the display will
change to show the standard menu for
the programme selected.

Operating the tumble dryer
20
Extras menu (multiple option list):
Extras
Freshen up
Anti-crease
ECO
Auto load
control
OK
Gentle tumble Turbo
Touch an Extra to select it.
The Extra currently selected will be
marked with a and only the Extras
which can be combined with it will be
displayed.
The OK sensor activates / saves the
marked Extra.
The sensor takes you back a menu
level.
Touch the Extra again to deselect it.
Setting numerical values
You can set numerical values in some
menus.
Duration
OK
0
–+
(0:20–2:00
h
h )
: 20
The numerical value is highlighted in
white. Touching the –sensor decreases
the value and touching the +sensor
increases it. The OK sensor is used to
adopt the selected value.
Useful tip: The values will count
upwards and downwards automatically
if you keep your finger on the +or –
sensor.
Other manuals for TMV 840 WP
1
Table of contents
Other Miele Tumble Dryer manuals
