Zanussi ZTE7101PZ User manual

GETTING
STARTED?
EASY.
User Manual
ZTE7101PZ
EN User Manual
Tumble Dryer

SAFETY INFORMATION
Before the installation and use of the appliance, carefully read the
supplied instructions. The manufacturer is not responsible if an
incorrect installation and use causes injuries and damages.
Always keep the instructions with the appliance for future
reference.
CHILDREN AND VULNERABLE PEOPLE SAFETY
WARNING!
Risk of suffocation, injury or permanent disability.
•This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
•Do not let children play with the appliance.
•Children of less than 3 years should be kept away unless
continuously supervised.
•Keep all packaging away from children.
•Keep all detergents away from children.
•Keep children and pets away from the appliance door when it is
open.
•If the appliance has a child safety device, we recommend you
activate it.
•Cleaning and user maintenance shall not be made by children
without supervision.
GENERAL SAFETY
•Do not change the specification of this appliance.
•If the tumble dryer is put on top of a washing machine, use the
stacking kit. The stacking kit, available from your authorized
vendor, can be used only with the appliance specified in the
instructions, supplied with the accessory. Read it carefully
before installation (Refer to the Installation leaflet).
2

•The appliance can be installed as freestanding or below the
kitchen counter with correct space (Refer to the Installation
leaflet).
•Do not install the appliance behind a lockable door, a sliding
door or a door with a hinge on the opposite side, where the
appliance door can not be fully opened.
•The ventilation openings in the base (if applicable) must not be
obstructed by a carpet.
•Connect the mains plug to the mains socket only at the end of
the installation. Make sure that there is access to the mains
plug after the installation.
•Ensure you have good ventilation in the installation room to
avoid the back flow of gases into the room from appliances
burning other fuels, including open fires.
•Exhaust air must not be discharged into a flue which is used for
exhausting fumes from appliances burning gas or other fuels. (if
applicable)
•If the supply cord is damaged, it must be replaced by the
manufacturer, its Authorised Service Centre or similarly
qualified persons in order to avoid a hazard.
•Obey the maximum load volume of 7kg (refer to the
“Programme chart” chapter).
•Do not use the appliance if industrial chemicals have been used
for cleaning.
•Wipe away lint that has accumulated around the appliance.
•Do not run the appliance without a filter. Clean the lint filter
before or after each use.
•Do not dry unwashed items in the tumble dryer.
•Items that have been soiled with substances such as cooking
oil, acetone, alcohol, petrol, kerosene, spot removers,
turpentine, waxes and wax removers should be washed in hot
water with an extra amount of detergent before being dried in
the tumble dryer.
•Items such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles and clothes or
pillows fitted with foam rubber pads should not be dried in the
tumble dryer.
3

•Fabric softeners, or similar products, should be used as
specified by the fabric softener instructions.
•Remove all objects from pockets such as lighters and matches.
•Never stop a tumble dryer before the end of the drying cycle
unless all items are quickly removed and spread out so that the
heat is dissipated.
•The final part of a tumble dryer cycle occurs without heat (cool
down cycle) to ensure that the items are left at a temperature
that ensures that the items will not be damaged.
•Before maintenance, deactivate the appliance and disconnect
the mains plug from the mains socket.
SAFETY INSTRUCTIONS
INSTALLATION
• Remove all the packaging.
• Do not install or use a damaged appliance.
• Obey the installation instruction supplied with
the appliance.
• Always be careful when you move the appliance
because it is heavy. Always wear safety gloves.
• Do not install or use the appliance where the
temperature is less than 5°C or higher than
35°C.
• Make sure that the floor where you install the
appliance is flat, stable, heat resistant and clean.
• Make sure that there is air circulation between
the appliance and the floor.
• Always move the appliance vertically.
• The rear surface of the appliance must be put
against the wall.
• When the appliance is put in its permanent
position, check if it is fully level with the aid of a
spirit level. If it is not, adjust the feet until it is.
ELECTRICAL CONNECTION
WARNING! Risk of fire and electrical
shock.
• The appliance must be earthed.
• Make sure that the electrical information on the
rating plate agrees with the power supply. If not,
contact an electrician.
• Always use a correctly installed shockproof
socket.
• Do not use multi-plug adapters and extension
cables.
• Do not pull the mains cable to disconnect the
appliance. Always pull the mains plug.
• Do not touch the mains cable or the mains plug
with wet hands.
• Only for UK and Ireland. The appliance has a 13
amp mains plug. If it is necessary to change the
fuse in the mains plug, use a 13 amp ASTA (BS
1362) fuse.
• This appliance complies with the E.E.C.
Directives.
USE
WARNING! Risk of injury, electrical
shock, fire, burns or damage to the
appliance.
• Use this appliance in a household only.
• Do not dry the damaged items which contain
padding or fillings.
• Only dry fabrics which are applicable to dry in
the tumble dryer. Follow the instructions on the
fabric label.
• If you have washed your laundry with a stain
remover start an extra rinse cycle before you
start the dryer.
• Do not drink or prepare food with the
condensed water/distilled water. It can cause
health problems to people and pets.
• Do not sit or stand on the open door.
• Do not dry dripping wet clothes in the tumble
dryer.
CARE AND CLEANING
WARNING! Risk of injury or damage
to the appliance.
4

• Do not use water spray and steam to clean the
appliance.
• Clean the appliance with a moist soft cloth. Only
use neutral detergents. Do not use abrasive
products, abrasive cleaning pads, solvents or
metal objects.
DISPOSAL
WARNING! Risk of injury or
suffocation.
• Disconnect the appliance from the mains
supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent children and
pets to get closed in the appliance.
INSTALLATION
UNPACKING
CAUTION! Before use all parts of the
transport packaging must be removed.
1 2 3
Open loading door.1
Pull off adhesive strips from inside machine on top of drum.2
Remove foil hose and polystyrene padding from the machine.3
VENT HOSE
As to the outlet itself, if you have
decided on a install wall/window grille,
a good local builder’s merchant can
supply you with the necessary fittings
and installation advice.
Make sure that the vent hose length is
less than 2 m, and that it contains no
more than 2 bends.
WARNING! It is important not to
connect the vent hose to, for example,
a cooker hood, or a chimney or flue
pipe designed to transmit the exhaust
from a fuel burning appliance.
Note that to prevent condensation problems, it is
essential that the dryer be installed with the flexible
hose to transmit its “exhaust” at least beyond the
kitchen units; preferable outside the kitchen. In
order to prevent the appliance from overheating, it
is important that the steam exhaust is unobstructed.
Thus, if a permanent hose installed to an external
wall or ceiling, it must be ensured an exhaust
capacity of minimum 150 m3/h. If the dryer is
installed adjacent to kitchen units, make sure that
the vent hose is not squashed. If the hose is not
fully squashed, drying efficiency will be decreased ,
5

resulting in longer drying times and higher energy
consumption. If the hose is fully squashed, the
automatic cut-outs with which the appliance is
fitted can operate. When operating the tumble
dryer, the room temperature must not be lower than
+5°C and higher than +35°C, as it can affect the
performance of the appliance.
If the hose is long and the room
temperature low, the moisture might
condense to water inside the hose.
This is an usual occurrence. To
prevent this water from the hose, it is
recommend to drill a small hole (via. 3
mm) in the lowest point of the hose
and to put a small container below it.
(See picture, point B).
B
There are 3 vent outlets: on the left,
right side and at the rear.
A
1
A
2
Pull the ring nut Afrom the vent outlet at the rear.1
Screw on the ring nut to the hose and push it into position.2
The not used vents must be sealed with supplied covers.3
DOOR REVERSAL
To make it easier to load or unload the laundry, the
door can be reversed.
WARNING! The door must only be
reversed by an authorised service
engineer.
Please contact your Authorised Service Centre.
The engineer will carry out the door reversal at your
cost.
SPECIAL ACCESSORIES
•stack kit
Available from your Authorised
Service Centre or your specialist
dealer
To enable the mounting of the dyer on top of a
front loading washing machine with cover’s
depth between 48 and 60 cm.
Read carefully the instructions supplied with the
kit.
6

EASY START
PRODUCT DESCRIPTION
1
3
4
2
7
6
5
1Control panel
2Appliance door
3Fluff filter
4Rating plate
5Adjustable feet
6Sideways vent outlets / back vent outlet
7Ring nut
7

CONTROL PANEL
1 2 3 4 65
1Programme knob and OFF switch
2Delicates button
3Anti-crease button
4Alarm button
5Indicators: Drying , End/Anti-crease ,
Filter
6Start/Pause button
PROGRAMME TABLE
Programmes Type of load Load (max.)1) /
Fabric mark
Cottons
Extra Dry Drying level: extra dry. 7kg/
Strong Dry Drying level: strong dry. 7kg/
Cupboard
Dry2)3) Drying level: cupboard dry. 7kg/
Damp Drying level: textiles which are still to be ironed. 7kg/
Iron Dry 3) Drying level: applicable for iron. 7kg/
Synthetics
Extra Dry Drying level: extra dry. 3kg/
Cupboard Dry 3) Drying level: cupboard dry. 3kg/
8

Programmes Type of load Load (max.)1) /
Fabric mark
Iron Dry Drying level: applicable for iron. 3kg/
Specials
30' Time programme to dry individual items of laundry. 1kg/
Easy Iron
Easy care fabrics for which a minimum of ironing is
necessary. The drying results can be different from
one type of fabric to the other. Shake the items be-
fore you put them in the appliance. When the pro-
gramme is completed, Immediately remove the items
and put them on a hanger.
1kg (or 5
shirts)/
Mixed Cotton and synthetic fabrics. Low temperature pro-
gramme. Delicate programme with warm air. 3kg/
Baby Baby cycle is a special programme for jumpers to be
dried “ready to wear”. 2kg/
Jeans Leisure clothing such as jeans, sweat-shirts of differ- ent material thicknesses (e.g. at the neck, cuffs and
seams). 7kg/
Cooling Refreshing a textiles that were in storage. 1kg
1) The maximum weight refers to dry items.
2) The Cottons Cupboard Dry programme is the “Standard cotton programme” and it is suitable to
dry normal wet cotton laundry and it is the most efficient programme in terms of energy consumption for
drying wet cotton laundry.
3) For test institutes only: Standard programmes for tests are specified in the EN 61121 document.
OPTIONS
DELICATES
With this option you can set a delicate drying
programme that has a low temperature. Use this
option with a fabrics that have the symbol on
the fabric label (e.g. acrylic, viscose).
ANTI-CREASE
Extends of 60 minutes the standard anticrease
phase (30 minutes) at the end of the drying cycle.
This function prevents the laundry from creases.
The laundry can be removed during the anticrease
phase.
ALARM
you can hear the buzzer at the:
• cycle end
• start and end of crease guard phase
• cycle interruption
The buzzer function is by default always on. You
can use this function to activate or deactivate the
sound.
You can activate the Alarm option with
all programmes.
9

OPTIONS TABLE
Programmes1) Delicates Anti-crease Alarm
Cottons
Extra Dry ■ ■ ■
Strong Dry ■ ■ ■
Cupboard Dry ■ ■ ■
Damp ■ ■ ■
Iron Dry ■ ■ ■
Synthetics
Extra Dry ■ ■ ■
Cupboard Dry ■ ■ ■
Iron Dry ■ ■ ■
Specials
30' ■ ■ ■
Easy Iron ■ ■ ■
Mixed ■ ■ ■
Baby ■ ■ ■
Jeans ■ ■ ■
Cooling ■
1) Together with the programme you can set 1 or more options. To activate or deactivate them, press the
related touchpad.
SETTINGS
A B C D
A) Delicates button
B) Anti-crease button
C) Alarm button
D) Start/Pause button
BUZZER ON/OFF
To deactivate or activate the acoustic signals, press
and hold for approximately 2 seconds touchpads
(A) and (B) at the same time.
ADJUSTMENT OF THE REMAINING LAUNDRY
MOISTURE DEGREE
To change the default degree of the remaining
moisture of the laundry:
1. Use the programme knob to set any
programme.
2. Wait approximately 8 seconds.
3. Press and hold buttons (B) and (D) at the same
time.
One of the these indicators comes on:
10

• End/Anti-crease - the maximum dry
laundry
• Drying - the more dry laundry
• End/Anti-crease and Drying the
standard dry laundry
4. Press the button (D) again and again until the
indicator of the correct level comes on.
5. To confirm the adjustment, press and hold
buttons (B) and (D) at the same time for
approximately 2 seconds.
BEFORE FIRST USE
Before you use the appliance for the first time do
these operations:
• Clean the tumble dryer drum with a moist cloth.
• Start a short programme (e.g. 30 minutes) with
moist laundry.
DAILY USE
START A PROGRAMME
1. Prepare the laundry and load the appliance.
CAUTION! Make sure that when
you close the door, the laundry
does not catch between the
appliance door and the rubber
seal.
2. Set the correct programme and options for the
type of load.
3. Press the Start/Pause touchpad.
The programme starts.
CHANGE A PROGRAMME
1. Turn the Programme knob to OFF
2. Set the programme.
AT THE END OF THE PROGRAMME
When the programme is completed:
• An intermittent acoustic signal operates (If the
Buzzer function is on).
• The indicators End/Anti-crease and Filter
comes on.
• The Start/Pause indicator is on.
The appliance continues to operate with the crease
guard phase for approximately other 30 minutes.
The crease guard phase removes creases from
your laundry.
You can remove the laundry before the crease
guard phase is completed. We recommend, for
better results, that you remove the laundry when the
phase is almost completed or completed.
When the crease guard phase is completed:
• Start/Pause indicator goes off.
1. Turn the Programme knob to OFF
2. Open the appliance door.
3. Remove the laundry.
4. Close the appliance door.
Always clean the filter when a
programme is completed.
STAND-BY FUNCTION
To decrease the energy consumption, this function
automatically deactivates the appliance:
• After 5 minutes if you do not start the
programme.
• After 5 minutes from the end of the programme.
INDICATOR LIGHTS
These lights indicate the following functions:
• Drying : This light indicates that the
appliance is in the drying phase.
• End/Anti-crease : This light is on at the end
of the cooling phase, during the anticreasing
phase and at the end of the programme.
• Filter : This light illuminates at the end of the
programme to remind you that the filters must
be cleaned.
HINTS AND TIPS
PREPARING THE LAUNDRY
• Close the zippers.
• Close the fasteners of the duvet covers.
• Do not keep ties or ribbons loose (e.g. apron
ribbons). Tie them before you start a
programme.
• Remove all items from the pockets.
11

• If an item has the internal layer made of cotton,
turn it inside out. Make sure that the cotton layer
is always external
• We recommend that you set the correct
programme applicable for the type of fabrics
that are in the appliance.
• Do not put fabrics with strong colours together
with fabrics with light colours. Strong colours
can bleed.
• Use an applicable programme for cotton jersey
and knitwear to prevent the items to shrink.
• Make sure that the laundry weight is not more
than the maximum weight that is in the
programme table.
• Dry only the laundry that is applicable for tumble
dryer. Refer to the fabric label on the items.
Fabric label Description
Laundry that is applicable for tumble drying.
Laundry that is applicable for tumble drying and resists higher drying temperature.
Laundry that is applicable for tumble drying but only with low drying temperature.
Laundry that is not applicable for tumble drying.
CARE AND CLEANING
CLEANING THE FILTER
At the end of each cycle the filter indicator is on to
tell you that the filter must be cleaned.
The filter collects the fluff. The fluff
occurs while the cloths are dried in the
tumble dryer.
1 2 3
Open the door.1
Pull the filter.2
Open the filter3
Use a moist hand to clean the filter.4
If necessary clean the filter with warm water using a brush.5
Close the filter.6
Remove fluff from the filter socket. For this a vacuum cleaner can be used.7
Put the filter inside the filter socket.8
12

CLEANING THE DRUM
WARNING! Disconnect the appliance
before you clean it.
Use a standard neutral soap detergent to clean the
inner surface of the drum and drum ribs. Dry the
cleaned surfaces with a soft cloth.
CAUTION! Do not use abrasive
materials or steel wool to clean the
drum.
CLEANING THE CONTROL PANEL AND
HOUSING
Use a standard neutral soap detergent to clean the
control panel and housing.
Use a moist cloth to clean. Dry the cleaned
surfaces with a soft cloth.
CAUTION! Do not use furniture
cleaning agents or cleaning agents
which can cause corrosion to clean
the appliance.
TROUBLESHOOTING
Problem Possible solution
You cannot activate the appliance. Make sure that the mains plug is connected to
the mains socket.
Check fuse in fuse box (domestic installation).
The programme does not start. Press Start/Pause.
Make sure that the appliance door is closed.
The appliance door does not close. Make sure that the installation of the filter is cor-
rect.
Make sure that the laundry does not catch be-
tween the appliance door and the rubber seal.
The display shows a long programme duration. 1) Make sure that the weight of the laundry is appli-
cable to the duration of the programme.
Make sure that the filter is clean.
The laundry is too wet. Spin the laundry in the
washing machine again.
Make sure that the room temperature is not too
warm.
The display shows a short programme duration. Set the Time Drying or the Extra Dry programme.
The display shows Err2).If you want to set a new programme, deactivate
and activate the appliance.
Make sure that the options are applicable to the
programme.
The display shows (e.g. E51)2).Deactivate and activate the appliance. Start a
new programme. If the problem occurs again,
contact the Service.
1) After maximum 5 hours, the programme ends automatically
2) only dryers with the display.
If the drying results are not satisfactory • The set programme was incorrect.
• The filter is clogged.
13

• There was too much laundry in the appliance.
• The drum is dirty.
• Incorrect setting of the conductivity sensor.
• The airflow slots are clogged.
TECHNICAL DATA
Height x Width x Depth 850 x 600 x 600 mm (maximal 630 mm)
Max. depth with the appliance door open 1090 mm
Max. width with the appliance door open 950 mm
Adjustable height 850 mm (+ 15 mm - feet regulation)
Drum volume 108 l
Maximum load volume 7kg
Voltage 230-240 V
Frequency 50 Hz
Necessary fuse 13 A
Total power 2600 W
Energy efficiency class C
Energy consumption1) 4,25 kWh
Annual energy consumption2) 512 kWh
Left—on mode power absorption 0,50 W
Off mode power absorption 0,50 W
Type of use Household
Permitted ambient temperature + 5°C to + 35°C
Level of protection against ingress of solid parti-
cles and moisture ensured by the protective cov-
er, except where the low voltage equipment has
no protection against moisture
IPX4
1) With reference to EN 61121. 7kg of cotton centrifuged at 1000 rpm.
2) Energy consumption per year in kWh, based on 160 drying cycles of the standard cotton programme at
full and partial load, and the consumption of the low-power modes. Actual energy consumption per cycle
will depend on how the appliance is used (REGULATION (EU) No 392/2012).
CONSUMPTION DATA
Programme Spun at / residual humidity Drying time Energy con-
sumption
Cottons 7 kg
Cupboard Dry 1400 rpm / 50% 110 min. 3,70 kWh
1000 rpm / 60% 125 min. 4,25 kWh
14

Programme Spun at / residual humidity Drying time Energy con-
sumption
Iron Dry 1400 rpm / 50% 85 min. 2,55 kWh
1000 rpm / 60% 97 min. 3,20 kWh
Synthetics 3 kg
Cupboard Dry 1200 rpm / 40% 44 min. 1,20 kWh
800 rpm / 50% 49 min. 1,47 kWh
ENVIRONMENT CONCERNS
Recycle the materials with the symbol . Put the
packaging in applicable containers to recycle it.
Help protect the environment and human health
and to recycle waste of electrical and electronic
appliances. Do not dispose appliances marked with
the symbol with the household waste. Return the
product to your local recycling facility or contact
your municipal office.
15
*

WWW.ZANUSSI.COM/SHOP
136937200-A-042015
