Mikomi RX-65 User manual

Instruction Manual - Please keep for future reference
Personal Stereo Cassette Player with AM/FM Mono Radio
RX-65
6-05

1
WARNING -To reduce risk of fire or electric shock, do not expose this
unit to rain or moisture.
IMPORTANT SAFETY INSTRUCTIONS
PRECAUTIONS
To Maintain Optimum Performance
Do not use the unit in places which are extremely hot, cold, dusty or humid. Do not use
or keep the unit in following places.
•In a high humidity area such as a bathroom or near a heater.
•In an area exposed to direct sunlight (where it can become extremely hot).
•Near sources of strong magnetism, such as televisions, speakers, or magnets.
•Where there is a lot of movement, vibration or an unstable shelf.
For Safety
•Do not attempt to disassemble this unit.
•Make sure that pins or other foreign objects do not get inside the unit.
•Take care not to drop the unit or subject it to strong shocks.
•Inside a car which become extremely hot and softer shocks & vibrations.
Children
•Children do not understand the dangers associated with operating electronic products.
Never allow children to use this product.
Note on listening with the earphones
•Listen at moderate volumes to avoid hearing damage.
•Do not wear the earphones while driving or cycling. It may create a traffic hazard.
•You should use extreme caution or temporarily discontinue use in potentially hazardous
situations, such as walking, jogging, etc.
•If you hear no sound when playing, DO NOT turn the volume up high because the
music could suddenly begin at high volume. To avoid hurting your ears or damaging
the speakers, turn the volume control to the lowest level before starting playback and
slowly turn it up to the desired level.
Mains Lead
•If this unit has a mains lead or is connected with a mains adaptor do not allow the lead
to become strained or damaged as it creates a hazard.
Read all instructions before use and keep for future reference.

32
1 x Radio/Cassette Player
KNOW YOUR MACHINE
GCassette Door HBass Button
ADC In BStop Button
CPlay Button DFast Forward Button
FEarphone Jack
ITape/Radio
Switch
Tuning
Knob
EVolume Control
KAM/FM Switch
J
CONTENTS
Know Your Machine ..........................................................................................3
Using with Batteries ........................................................................................ 4
Using with AC/DC Adaptor ............................................................................. 5
Operation ...........................................................................................................6
• Insertion and Removal of Cassette Tape........................................................6
• Play ...............................................................................................................7
• Automatic Stop ..............................................................................................7
• Radio Operation ............................................................................................8
• Bass .............................................................................................................8
Specifications ....................................................................................................9
L1 x Headphone

4
fig. 1
5
IMPORTANT:
Please read the important safety
instructions before use.
Note on batteries:
• Do not mix different types of
batteries or an old battery with a
new one.
• To prevent the risk of leakage or
explosions, never recharge
batteries, apply heat or take them
apart.
• When not using the unit for
prolonged periods remove the
batteries to prevent battery drain
or leakage.
• If liquid leaks from the batteries,
throw them away. Thoroughly clean
the battery compartment with a dry
cloth.
fig. 2
fig. 3
fig. 4
Adaptor
USING WITH AC/DC ADAPTORUSING WITH BATTERIES
Using with a Battery
1. Open the battery compartment.
See fig. 1.
2. Insert two new 1.5V AA alkaline
batteries with the and
terminals correctly aligned.
See fig. 2.
3. Carefully slide the battery door
closed.
See fig. 3.
1. Plug in a DC 3V Adaptor (not
included) into the power supply
and insert the jack into the DC
IN A socket. 
See fig. 4.
A
Side View
Using with AC/DC Adaptor

76
fig. 5
CAUTION:
• If you do not remove the excess
slack, the tape might become
tangled in the record/playback
mechanism.
fig. 6
fig. 7
fig. 8
fig. 9
fig. 10
OPERATION OPERATION
4. Press the Play Button C and
adjust the Volume Control E for
the desired listening level. Stop
the tape by pressing the Stop
Button B.
See fig. 8 and 9.
1. Load the cassette tape.
NOTE: To protect your hearing, set
Volume Control E to its lowest
setting before you begin playing
a cassette tape.
See fig. 9.
3. Put on your Headphones L and
plug into the Earphone Jack F.
See fig. 8.
2. Set switch I to TAPE.
See fig. 8.
Insertion and Removal of Cassette
Tape
Automatic Stop
- Please note when the tape comes
to the end during play the tape will
stop automatically.
1. Take up any slack in the tape by
turning one of the cassette's hubs
with a pencil.
See fig. 5.
2. Open the Cassette Door G.
See fig. 6.
3. Load the cassette with its open
edge up, the side you want to play
facing out and its full reel to the
left.
See fig. 7.
4. Close the Cassette Door G.
G
L
F
D
C
B
Side View
Top View
E
I
Play

8 9
WARNING
fig. 11
fig. 12
fig. 13
Radio Operation
Bass
1. Push the Bass Button H to turn
on and off the Bass Function.
See fig. 13
4. Adjust the sound level using the
Volume Control E.
See fig. 12.
SPECIFICATIONSOPERATION
1. Put on your Headphones L and
plug into the Earphone Jack F.
See fig. 11.
2. Set switch I to RADIO. Then set
switch K to AM or FM. 
See fig. 11.
3. Select your desired station by
turning the Tuning Knob J.
See fig. 11.
Technical Data
Model no.  RX-65
Voltage 230VAC-50Hz
L
F
E
IJ
H
Side View
Top View
K
Recommendation on the AC/DC adaptor :
- Input : 230V~ 50Hz
- Output : DC 3V 500 mA
- Only the safety isolating transformer with CE marking that complies with
British Standard BS EN 61588-1 and BS EN 61588-2-6 as giving presumption
of compliance with the essential requirements in the Low Voltage Directive
73/23/EEC amended by 93/68/EEC should be used. In case of any doubt,
please consult a qualified electrical professional.
