Sony TCM-343 User manual
TCM-343
E Model
Chinese Model
SERVICE MANUAL
CASSETTE-CORDER
SPECIFICATIONS
Model Name Using Similar Mechanism NEW
Tape Transport Mechanism Type MT-323-118
Recording system
2-track 1 channel monaural
Frequency range
250 - 6 300 Hz
Speaker
Approx. 3.6 cm (1 7/ 16 in.) dia.
Power output (at 10% harmonic
distortion)
250 mW
Output
Earphone jack (minijack) for 8 -
300Ωearphone
Power requirements
• 3 V DC batteries R6 (AA) ×2
• External DC 3 V power sources
Dimensions (w/h/d) (incl. projecting
parts and controls)
Approx. 112 ×36.6 ×90.3 mm
(4 1⁄2×1 1⁄2×3 5⁄8in.)
Mass (not incl. batteries)
Approx. 180 g (6.4 oz.)
Design and specifications are subject
to change without notice.
Ver 1.0 2000. 11
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
— 2 —
Notes on chip component replacement
•Never reuse a disconnected chip component.
•Notice that the minus side of a tantalum capacitor may be
damaged by heat.
Flexible Circuit Board Repairing
•Keep the temperature of soldering iron around 270˚C
during repairing.
•Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
•Be careful not to apply force on the conductor when soldering
or unsoldering.
TABLE OF CONTENTS
1. GENERAL ·········································································· 2
2. DISASSEMBLY
2-1. Lid Sub Assy, Cassette···················································· 3
2-2. Main Board, Mechanism Deck ······································· 3
2-3. Belt·················································································· 4
2-4. “Head, Magnetic”, Pinch Roller ····································· 4
3. MECHANICAL ADJUSTMENT ·································· 5
4. ELECTRICAL ADJUSTMENT ···································· 5
5. DIAGRAMS
6-1. IC Block Diagrams ························································· 6
6-2. Block Diagram ································································ 7
6-3. Schematic Diagram ························································· 9
6-4. Printed Wiring Board ···················································· 11
6. EXPLODED VIEWS
6-1. Cabinet Section ····························································· 13
6-2. Mechanism Deck Section-1 (MT-323-118) ·················· 14
6-3. Mechanism Deck Section-2 (MT-323-118) ·················· 15
7. ELECTRICAL PARTS LIST ······································· 16
