Mindray SV600 Assembly instructions

The guidelines apply to SV600/SV650/SV800/SV850 ventilator.
This product is intended to be used in intensive care situations within a professional
healthcare facility, or during transport within a professional healthcare facility. This
product is intended to provide ventilation assistance and breathing support for adult,
pediatric and neonate patients. This product shall be operated by authorized medical
personnel well trained in the use of this product. This product is not suitable for use in an
MRI environment.
There are no absolute contraindications for this product. For some special diseases,
however, some necessary treatments shall be taken for ventilator mechanical ventilation,
or special ventilation modes shall be adopted to prevent possible patient injury.
This guideline briefs the ventilator, its basic operation, daily maintenance, cleaning and
disinfection. For more information,please refer to the Operator’s Manual.
Basic Operation, Daily Maintenance and Disinfection Guidelines
Introduction to Ventilator:
A. Display
B. Inspiration valve
C. Expiration valve
D. Connectors (USB connector, VGA connector, Internet connector and RS-232 connector etc.)
E. Trolley handrail
F. AC power input connector
A
B
C
E
F
D
Front View Back View
-Page 1 of 4-

G
H
I
J
K
M
L
N
G. O2supply inlet H. Air supply inlet
I. Water traps and drainage valve pole J. Air intake dust filter
K. Fan dust filter L. Ventilator outlet
M. Neonatal flow sensor connector N. Module slot
abcd
f
e
a. Mode and Patient size area b. Information display area
c. Icon area d. Functional key area
e. Vent mode and Parameter Setting area
f. Waveforms/Parameter/Spirometry/Dynamic Lung/Trend Display Area
Right View Left View
Main Screen
Basic Operation, Daily Maintenance and Disinfection Guidelines
-Page 2 of 4-

1. Connect the ventilator and humidifier to the AC power supply. Connect the gas supply.
2. Start the humidifier and set the relevant parameters by following the humidifier
instructions for use (check if the water level of the humidifier complies with the
requirement before starting the humidifier).
3. When the ventilator is turned on, it runs self-test automatically.
4. Connect the breathing tubes, and select to run (recommended) or skipthe system check.
5. Once system check is finished, the ventilator starts to work in the set mode. For new patients,
you need to set the IBW, Patient Type (adult, pediatric or neonate), Gender, and Vent Type
(invasive or non-invasive) .
6. Connect the test lung, and check the status of the test lung. If the test lung is in good
condition, you can disconnect the test lung and connect the ventilator to the patient
(recommended).
7. Connect the patient and breathing tubes, and start ventilation. Keep the patient under
close monitoring for a period and pay attention to the vital signs of the patient and
ventilation status of the ventilator.
8. Keep observing the parameters and alarms during ventilation. Reconfigure the ventilation
mode or parameters if necessary.
9. After use, turn off the ventilator and humidifier in sequence.
Basic Operation:
Routine Maintenance:
yBefore each use or after continuous use of two weeks, perform system check. Check
the breathing system resistance and leakage.
yPerform the following maintenance several times a day or as necessary: check the
breathing tubes and water traps for water build-up. Empty water build-up if there is.
Inspect the parts for damage. Replace as necessary.
yPerform the following maintenance
each patient or as necessary: Perform pressure and
flow zeroing, system check and flow sensor calibration. Replace with disinfected parts or
new disposable parts.
yPerform the following maintenance daily or as necessary (recommended):Clean the
external surfaces and calibrate the O2sensor. Replace the O2sensor if it is damaged.
When the patient’s exhaled gas may contaminate the inspiratory safety valve
assembly, it is necessary to replace with disinfected inspiratory safety valve and
membrane.Replace the expiration valve if it is damaged.Calibrate the CO2module
when the CO2measured value has a great deviation. Calibrate the touch screen if its
function is degraded. Check water traps at air supply inlet. Empty water build-up if
there is. Please contact your service personnel if any cracks and leakage are found on
the water traps.
yPerform the following maintenance monthly or as necessary: Check the air intake
dust filter, fan dust filter and main unit air outlet dust filter for dust build-up. Clean or
replace as necessary.
yWhen cleaning or installation, check the parts for damage and replace as necessary.
yCheck lithium battery charging and discharging every 6 months and replace every
three years. Please contact your service personnel for replacement.
Basic Operation, Daily Maintenance and Disinfection Guidelines
-Page 3 of 4-

yPerform the following cleaning and disinfection for each patient:
Wipe ventilator external
surface (including housing, power cord, supply gas hose), trolley, support arm, and touch
screen for cleaning. Wipe or place them under ultraviolet radiation for disinfection.
yPerform the following cleaning and disinfection for each patient or every week:
Immerse expiration valve assembly (except membrane), expiration valve membrane
and patient tube (including water trap, Y piece, adapter) in detergent for cleaning.
Immerse or autoclave them for disinfection. For cleaning and disinfection of
mainstream CO2sensor, SpO2sensor, SpO2sensor cable, nebulizer and humidifier,
refer to the instructions provided by the vendors.
yPerform the following cleaning and disinfection as necessary: Immerse inspiration
safety valve assembly in detergent for cleaning. Immerse or autoclave it for
disinfection.
yPerform the following cleaning and disinfection every 4 weeks or as necessary: Immerse
the fan dust filter, main unit air outlet dust filter, and air intake dust filter in detergent
for cleaning and disinfection.
Shenzhen Mindray Bio-Medical Electronics Co., Ltd.
Floor 1-4, Mindray Building, Keji 12th Road South, High-tech Industrial Park, Nanshan, Shenzhen, P. R. China
Tel:[phone] Fax:[phone]
www.mindray.com
Cleaning and Disinfection:
yAnnually or as necessary, check the inspiration safety valve membrane. Contact your
service personnel for replacement if necessary.
yEach year, per 5000 hours or as necessary, replace air intake HEPA filter. Check the
expiration valve membrane and contact us for replacement if necessary. If the O2Cell
damages, please replace one. Please contact us for preventive maintenance.
yReplace clock module battery every six years or as necessary. Contact us for
replacement if necessary.
yPlease contact us if the preventive and maintenance buttons are shown
on the
system check interface or circuit test interface.
The table below lists the cleaning and disinfecting agents and autoclaving process that may
be used on the ventilator.
Name Type
Ethanol (75%) Moderately efficient disinfectant
Islpropanol (70%) Moderately efficient disinfectant
Glutaraldehyde (2%) High-efficient disinfectant
Ortho-phthalaldehyde (e.g. Cidex®OPA
）High-efficient disinfectant
Soap water (pH value of 7.0~10.5) Rinsing agent
Clean water Rinsing agent
Steam autoclave (134℃recommended) Highly efficient disinfection
Basic Operation, Daily Maintenance and Disinfection Guidelines
-Page 4 of 4- 0 4 6 - 0 0 9 9 8 3 - 0 0 ( 4 . 0 )
