minkaAire STEAL F729 User manual

INSTRUCTION MANUAL WARRANTY CERTIFICATE
STEAL
BY

©2017 Minka Lighting, Inc. Manual design and all elements of manual design are protected by U.S. Federal and/or State Law, including Patent,
Trademark and/or Copyright laws.

The Minka-Aire® warranty is for one (1) year from the date of purchase from an authorized Minka-Aire® dealer.
This warranty is only valid to the original purchaser or user against all defects in material and workmanship (light bulbs
excluded) for one (1) full year. Additionally, Minka-Aire® warrants the motor only for the lifetime of the Minka Aire ceiling
fan (excluding wall controls and electrical components), to the original purchaser or user.
* The warranty is voided with the use of any non- Minka-Aire®electrical devices, E.g., wall controls or electrical dimmer switches, etc…
* The warranty is void once the original purchaser or user ceases to own the fan or the fan is moved from its original point of installation.
* The warranty is void with the use of any hanger bracket (non-Minka Aire or non-fan specific) other than the hanger bracket supplied & installed
with this specific fan.

Date Purchased Store Purchased Model Number Serial Number
F729
Warranty Service Information
To obtain warranty service during the warranty period, the purchaser should return the fan with the sales receipt to the original place of
purchase. The authorized Minka-Aire® dealer, at its sole discretion, will either repair or replace the fan after verifying the legitimacy of the warranty
claim. Replacement is subject to availability of the same model. If the model is unavailable it will be replaced by one of equal value. This is a
limited warranty; the original purchaser or user is responsible for the cost of removal and reinstallation of repaired or replacement product.
To obtain the name of the Minka-Aire® authorized dealer nearest you call the Minka-Aire® customer care department at 1-800-307-3267, or
contact Minka-Aire® through www.minkagroup.net and select FAQ to answer any questions or if you require additional assistance submit the
question form found there.

CONTENTS
SAFETY RULES...........................................................................................
PACKAGE CONTENTS............................................................................
INSTALLING THE FAN............................................................................
HANGING THE FAN................................................................................
ELECTRICAL CONNECTIONS..............................................................
INSTALLING THE WALL CONTROL.................................................
FINISHING THE INSTALLATION.......................................................
BLADE INSTALLATION ..................................................................................
ATTACHING THE SWITCH CUP.................................................................
OPERATING THE WALL CONTROL.........................................................
CARE OF YOUR FAN.......................................................................................
TROUBLESHOOTING....................................................................................
SPECIFICATIONS.............................................................................................
1
2
3
4
5
6
7
8
9
10
11
12
13
1151 W. Bradford Court, Corona, CA 92882 For Customer Assistance Call: 1-800-307-3267
UL
LISTED
R

SAFETY RULES
1
1. Before you begin installing the fan, shut power off at the circuit breaker of the fuse box.
2. Be cautious! Read all instructions and safety information before installing your new fan. Review accompanying assembly diagrams.
3. Make sure that all electrical connections comply with local codes, ordinances, or National Electrical Codes. Hire a qualified electrician or consult a
do-it-yourself wiring handbook if you are unfamiliar with installing electrical wiring.
4. Make sure the installation site you choose allows the fan blades to rotate without any obstructions. Allow a minimum clearance of 10 feet from
the floor and 18 inches from the tip of the blades to the wall.
5. If you are mounting the fan to a ceiling fan outlet box, use a U.L. Listed metal octagonal outlet box marked "Acceptable for Fan Support". Secure the
box directly to the building structure. The outlet box and its support must be able to support the moving weight of the fan (at least 35 pounds) Do
not use a plastic box.
6. Caution: To reduce the risk of injury use only the screws provided with the outlet box in conjunction with the lock washers provided with the fan.
7. If you are mounting the fan to a joist, make sure it is able to support the moving weight of the fan (at least 35 pounds).
8. After you install the fan, make sure that all mounting components are secured to prevent the fan from falling.
9. Do not insert anything into the fan blades while the fan is operating.
10. Turn the fan off and wait for the blades to stop completely before performing any maintenance or cleaning.
11. To reduce the risk of injury to a person, install fan so that the blades are at least 3.0M (10 feet) above the floor.

WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR OTHER PERSONAL INJURY, MOUNT FAN ONLY TO A U.L. LISTED OUTLET BOX OR SUPPORTING SYSTEM MARKED
ACCEPTABLE FOR FAN SUPPORT AND USE MOUNTING SCREWS PROVIDED WITH THE OUTLET BOX IN CONJUCTION WITH THE LOCK WASHERS PROVIDED WITH THE
FAN. MOST OUTLET BOXES COMMONLY USED FOR FAN SUPPORT OF LIGHTING FIXTURES ARE NOT ACCEPTABLE FOR FAN SUPPORT AND NEED TO BE REPLACED.
CONSULT A QUALIFIED ELECTRICIAN IF IN DOUBT.
TO REDUCE THE RISK OF PERSONAL INJURY, DO NOT BEND THE BLADE HOLDERS WHILE INSTALLING, BALANCING THE BLADES OR CLEANING THE FAN. DO NOT
INSERT FOREIGN OBJECTS BETWEEN ROTATING FAN BLADES.
TO REDUCE THE RISK OF FIRE OR ELECTRONIC SHOCK, THIS FAN ONLY CAN USE UC9020 SPEED CONTROL ONLY.
NOTE: The important safeguards and instructions appearing in this manual are not meant to cover all possible conditions and situations that may
occur. It must be understood that common sense, caution and care are factors which can not be built into this product. These factors must be
supplied by the person (s) installing, caring for and operating the unit.
NOTE: READ AND SAVE ALL INSTRUCTIONS!

2
A. Mounting hardware:
#10 x 1.5" Wood screws (2 PCs.)
#8 x 3/4" Machine screws (2 PCs.)
Lock washers (2 PCs.)
4mm Star washers (2 PCs.)
Wire nuts (3 PCs. )
Washers (2 PCs.)
B. Blade attachment hardware:
1/4" x 1/2"mm Allen screws (7PCs.)
C. Allen wrench (3mm)
Allen wrench (5mm)
1. Fan blades (3)
2. Hanger bracket
3. Canopy
4. Canopy cover
5. Downrod assembly
6. Coupling cover
7. Fan motor/housing assembly
8. Switch cup
9. Remote control with holder and 2
mounting screws
PACKAGE CONTENTS
Unpack your fan and check the contents. You should have the following items:
A
C
1
27
8
9
3
4
5
6
B

3
Tools Required: Phillips screw driver; slotted screw driver; step-ladder; wire cutters; electrical tape.
INSTALLING THE FAN
MOUNTING OPTIONS
If there isn't an existing mounting box, then read the following instructions. Disconnect the
power by removing fuses or turning off circuit breakers.
Secure the outlet box directly to the building structure. Use appropriate fasteners and building
materials. The outlet box and its support must be able to fully support the moving weight of
the fan (at least 35 lbs.). Use a UL Listed metal outlet box. Do not use a plastic outlet box.
Figure 1, 2 and 3 are examples of different ways to mount the outlet box.
Note: You may need a longer downrod to maintain proper blade clearance when installing on a
steep, sloped ceiling. Longer downrods are available from your Minka-Aire®dealer.
To hang your fan where there is an existing fixture but no ceiling joist, you may need to install
a hanger bar as shown in Fig. 4 (available at your Minka-Aire® dealer).
Note: To reduce the risk of injury to a person, install fan so that the blades are at least 3.0M
(10 feet) above the floor.
FIG. 1
FIG. 3
FIG. 2
FIG. 4
CROSS BRACE
CEILING
JOIST
CEILING
jOIST
CEILING
JOIST
OUTLET BOX
PARALLEL WOOD BRACE
(MIN. 2" THICK)
OUTLET
BOX
OUTLET BOX
CEILING JOIST OR
CROSS BRACE
ANGLED CEILING
MAXIMUM 18 ANGLE PROVIDE
STRONG
SUPPORT
RECESSED
OUTLET BOX
HANGER
OPENING
must be
FACING
UPSIDE
HANGER BAR
(OPTIONAL)
HANGER
BRACKET

4
WARNING: All of the parts, hardware and components such as the
hanger bracket and hanger ball have been provided for your safety and
the proper installation of your new ceiling fan. The use of other parts,
hardware or components not supplied by Minka Aire®with the fan will
void the Minka Aire®Warranty.
REMEMBER to turn off the power. Follow the steps below to hang your
fan properly:
Step 1. Secure the hanger bracket to the ceiling outlet box using screws
included with your outlet box, lock washers included with the fan. (Fig.5)
Step 2. Loosen the two set screws and remove the hitch pin and lock pin
from the top coupling of the motor assembly. (Fig. 6)
Step 3. Remove hanger ball from downrod assembly by loosening set
screw, removing the cross pin, and sliding ball off rod. (Fig.7)
Step 4. Carefully feed fan wires up through the downrod. (Fig. 8)
Thread the rod into the coupling, next line up holes and replace lock
pin and hitch pin. Tighten set screws.
Step 5. Slip coupling cover, canopy cover and canopy onto downrod.
(Fig. 9) Carefully reinstall hanger ball onto rod being sure that cross pin
is in the correct position, set screws are tighten and wires are not
twisted.
Step 6. Now lift motor assembly into position and place hanger ball
into hanger bracket. Rotate until the check groove has dropped into the
registration slot and seats firmly. (Fig. 10) Rod should not rotate if this
is done correctly.
HANGING THE FAN

Fig. 5
Fig. 7 Fig. 8Fig. 6 Fig. 10
Fig. 9
CANOPY COVER
OUTLET BOX
HANGER BRACKET
DOWNROD
SUPPLY
WIRES REGISTRATION
SLOT
CROSS PIN
HANGER
BALL
DOWNROD
HITCH
PIN LOCK
PIN
SET SCREWS
SET SCREW
DOWNROD
CANOPY
SET SCREWS
HITCH PIN
LOCK PIN
COUPLING COVER

5
ELECTRICAL CONNECTIONS
NOTE: This fan includes a WC105 wall control. If you are to add a light
kit you would need to purchase the WC106 wall control. (Available at your
Minka-Aire®retailer.)
NOTE: If you feel that you do not have enough electrical wiring knowledge
or experience, have your fan installed by a licensed electrician.
Use the wire nuts supplied with your fan. Secure the connectors with
electrical tape and make sure there are no loose connections or wire
strands.
1. Connect the wiring from the fan motor to house supply. (Fig. 11)
Connect the RED live supply wire to the BLUE fan light wire.
Connect the BLACK live supply wire to the BLACK fan live wire.
Connect the WHITE neutral wire to the WHITE fan neutral wire.
Connect the COPPER house ground wire to the GREEN fan ground wire.
2. After connecting the wires, spread them apart so that the green and
white wires are on one side of the outlet box and the black wires are on
the other side.
3. Connect the wiring from the wall switch receptacle to wall control
unit. (Fig. 11)
Remove the existing wall plate and switch from the wall junction box.
Connect one BLACK wire from the wall to one BLACK wire (labeled "TO
FAN") from the wall control.
Connect the other BLACK wire (labeled "TO POWER SUPPLY") from the
wall control to the remaining BLACK wire from the wall (A/C supply
source).
4. If your junction box has a ground wire (green or bare copper), connect
the wall control's ground wire to it. Otherwise, connect the wall control
ground wire directly to one of the screws from the outlet box.

Fig. 11
WHITE
(NEUTRAL) LINE VOLTAGE
(BLACK WIRE FROM MAIN FUSE BOX)
GROUND
BLACK BLACK
BLACK
YELLOW/GREEN
BLUE
RED
GREEN
WHITE
WHITE
GROUND
CONDUCTOR
BLACK
BLACK
OUTLET BOX

6
Fig. 12
WARNING! HOOK UP "IN SERIES" ONLY. DO NOT CONNECT NEUTRAL SUPPLY WIRE
OF ELECTRIC CIRCUIT TO THE WALL SWITCH, DAMAGE TO THE WALL SWITCH AND
POSSIBLE FIRE COULD OCCUR.
Step 1. Make the electrical connections as shown in Fig.11. If your outlet box has a ground
wire (Green or Bare Copper) connect the wall control's ground wire directly to one of the
screws from the outlet box. Secure all wire connections with the plastic wire nuts
provided.
Step 2. Carefully tuck the wire connections inside the outlet box. Use the screws provided
to secure the wall control and wall plate to the outlet box. (Fig. 12)
INSTALLING THE WALL CONTROL

7
Step 1. Remove 1 of the 2 screws from the bottom of the hanger bracket and loosen the other one
half a turn from the screw head.
Step 2. Slide the canopy up towards the hanger bracket and place the key hole on the canopy over
the screw on the hanger bracket, turn canopy until it locks in place at the narrow section of the key
holes. (Fig. 13)
Step 3. Align the circular hole on canopy with the remaining hole on the hanger bracket, secure by
tightening the two set screws.
Note: Adjust the canopy screws as necessary until the canopy and canopy cover are snug.
FINISHING THE INSTALLATION
Fig. 13
OUTLET BOX
HANGER
BRACKET
HANGER
BALL
CANOPY
CANOPY
COVER

8
BLADE INSTALLATION
Note: To reduce the risk of injury to a person, install fan so that
the blades are at least 3.0M (10 feet) above the floor.
1. Insert the blade into the fan motor, align holes from blade to
fan motor and secure with two Allen screws and Allen wrench
provided. (Fig. 14)
2. Repeat process with the other blades.
Fig. 14
BLADES
ALLEN SCREWS
ALLEN WRENCH
10 FEET
(3M)

9
Fig. 15
NOTE:
NOTE:
Before starting installation, disconnect the power by turning off the circuit breaker
or removing the fuse at fuse box.
Step 1. While holding the switch cup, firmly snap the wire connectors together. (Fig. 15)
Step 2. Remove the screws from the switch cup plate. Slide switch cup up against plate and
rotate it until the screw holes are aligned.
Secure with the Allen screws and Allen wrench
provided.
(Fig. 15)
NOTE: DO NOT PINCH WIRES BETWEEN THE SWITCH CUP AND THE SWITCH CUP PLATE.
ATTACHING THE SWITCH CUP
SWITCH CUP
SWITCH CUP
PLATE
ALLEN
SCREWS
ALLEN
WRENCH
CONNECTORS

10
Fig. 16
OPERATING THE WALL CONTROL
Restore power to the ceiling fan and test for proper operation.
1. The fan 4-speed control is used to set the fan speed as follows: (Fig. 16)
0 = Turns the fan off 1 = High Speed 2 = Medium High Speed
3 = Medium Speed 4 = Low Speed
2. Light Control
Your ceiling fan is equipped with a light, however there is no light kit control included.
Please contact your original place of purchase for light kit control options.

11
Here are some suggestions to help maintain your fan.
1. Because of the fan's natural movement some connections may become
loose. Check the support connections, brackets and blade attachments
twice a year. Make sure they are secure. (It is not necessary to remove
fan from the ceiling).
2. Clean your fan periodically to help maintain its new appearance over
the year. CAUTION: many common household cleaning products contain
chemicals that could damage the finish of your fan. Use only a soft lint
free cloth and soapy water.
3. If your fan is provided with wood veneer blades; you can apply a light
coat of furniture polish for additional protection and enhanced beauty.
Cover small scratches with a light application of shoe polish.
4. Use a lint free lightly damp cloth or duster to remove dust from
the blades.
5. There is no need to oil your fan. The motor has permanently lubricated
bearings.
6. If your fan is provided with glass shades, clean with lukewarm soapy water
and a soft cloth or sponge. DO NOT IMMERSE GLASS SHADES IN HOT WATER.
DO NOT PUT GLASS SHADES INTO AN AUTOMATIC DISHWASHER.
CARE OF YOUR FAN
WARNING!
MAKE SURE THE POWER IS OFF AT THE
ELECTRICAL PANEL BOX BEFORE YOU ATTEMPT
ANY REPAIRS. REFER TO THE SECTION,
"ELECTRICAL CONNECTIONS".

12
TROUBLESHOOTING
SYMPTOM
Fan will not start
Check to make sure the wall switch is turned on.
Check circuit fuses or breakers.
Caution! Make sure the power is turned off before performing the
following steps.
Remove canopy and check wire connections.
Check wall control transmitter connections (if applicable).
SOLUTION
SYMPTOM
Fan Sounds Noisy
Allow a 24-hour "break in" period. Most noises associated with a new
fan will go away during this time.
Make sure the screws that attach the fan blade holder to the motor
hub is tight.
Make sure outlet box is secured to building structure, if necessary
use the wood screws provided to further secure outlet box to joist.
Make sure hanger bracket is secure to the outlet box, screws are
tight.
SOLUTION
