Contents
1. Safety precautions.....................................................................................1
2. Installation location....................................................................................2
3. Installing the indoor unit ............................................................................3
4. Installing the refrigerant piping ..................................................................5
5. Drainage piping work.................................................................................6
6. Electrical work ...........................................................................................6
7. Test run....................................................................................................12
8. Easy maintenance function .....................................................................16
en
1. Safety precautions
Note:
The phrase “Wired remote controller” in this installation manual refers to the PAR-41MAA. If you need any information for other remote controller, please
refer to the installation manual that is included with the optional remote controller.
►Beforeinstallingtheunit,makesureyoureadallthe“SafetyPrecautions”.
►The“SafetyPrecautions”provideveryimportantpointsregardingsafety.Makesureyoufollowthem.
►Pleasereporttoyoursupplyauthorityorobtaintheirconsentbeforeconnectingthisequipmenttothepowersupplysystem.
Symbolsusedinthetext
Warning:
Describesprecautionsthatshouldbeobservedtopreventdangerofinjuryor
death to the user.
Caution:
Describesprecautionsthatshouldbeobservedtopreventdamagetotheunit.
Symbolsusedintheillustrations
: Indicates a part which must be grounded.
: Be sure not to do.
After installation work has been completed, explain the “Safety Precautions,” use,
and maintenance of the unit to the customer according to the information in the
Operation Manual and perform the test run to ensure normal operation. Both the
Installation Manual and Operation Manual must be given to the user for keeping.
These manuals must be passed on to subsequent users.
MEANINGSOFSYMBOLSDISPLAYEDONINDOORUNITAND/OROUTDOORUNIT
WARNING
(Risk of re)
This mark is for R32 refrigerant only. Refrigerant type is written on nameplate of outdoor unit.
In case that refrigerant type is R32, this unit uses a ammable refrigerant.
If refrigerant leaks and comes in contact with re or heating part, it will create harmful gas and there is risk of re.
Read the OPERATION MANUAL carefully before operation.
Service personnel are required to carefully read the OPERATION MANUAL and INSTALLATION MANUAL before operation.
Further information is available in the OPERATION MANUAL, INSTALLATION MANUAL, and the like.
Warning:
• Carefullyreadthelabelsa󰀩xedtothemainunit.
• Askadealeroranauthorizedtechniciantoinstall,relocateandrepairthe
unit.
• Theusershouldneverattempttorepairtheunitortransferittoanotherloca-
tion.
• Forinstallationandrelocationwork,followtheinstructionsintheInstallation
Manualandusetoolsandpipecomponentsspecicallymadeforusewith
refrigerantspeciedintheoutdoorunitinstallationmanual.
• Theunitmustbeinstalledaccordingtotheinstructionsinordertomini-
mizetheriskofdamagefromearthquakes,typhoons,orstrongwinds.An
incorrectlyinstalledunitmayfalldownandcausedamageorinjuries.
• Donotaltertheunit.Itmaycausere,electricshock,injuryorwaterleak-
age.
• Theunitmustbesecurelyinstalledonastructurethatcansustainits
weight.
• Theapplianceshallbestoredinawell-ventilatedareawheretheroomsize
correspondstotheroomareaasspeciedforoperation.
• If the air conditioner is installed in a small room or closed room, measures
mustbetakentopreventtherefrigerantconcentrationintheroomfrom
exceedingthesafetylimitintheeventofrefrigerantleakage.Shouldthe
refrigerantleakandcausetheconcentrationlimittobeexceeded,hazards
duetolackofoxygenintheroommayresult.
• Keepgas-burningappliances,electricheaters,andotherresources(igni-
tion sources) away from the location where installation, repair, and other air
conditionerworkwillbeperformed.
 Ifrefrigerantcomesintocontactwithaame,poisonousgaseswillbe
released.
• Ventilatetheroomifrefrigerantleaksduringoperation.Ifrefrigerantcomes
intocontactwithaame,poisonousgaseswillbereleased.
• Allelectricworkmustbeperformedbyaqualiedtechnicianaccordingto
localregulationsandtheinstructionsgiveninthismanual.
• Do not use intermediate connection of the electric wires.
• Useonlyspeciedcablesforwiring.Thewiringconnectionsmustbemade
securelywithnotensionappliedontheterminalconnections.Also,never
splicethecablesforwiring(unlessotherwiseindicatedinthisdocument).
 Failuretoobservetheseinstructionsmayresultinoverheatingorare.
• Wheninstallingorrelocating,orservicingtheairconditioner,useonlythe
speciedrefrigerantwrittenonoutdoorunittochargetherefrigerantlines.
Donotmixitwithanyotherrefrigerantanddonotallowairtoremaininthe
lines.
 Ifairismixedwiththerefrigerant,thenitcanbethecauseofabnormalhigh
pressureintherefrigerantline,andmayresultinanexplosionandother
hazards.
 Theuseofanyrefrigerantotherthanthatspeciedforthesystemwill
causemechanicalfailureorsystemmalfunctionorunitbreakdown.Inthe
worstcase,thiscouldleadtoaseriousimpedimenttosecuringproduct
safety.
• Theapplianceshallbeinstalledinaccordancewithnationalwiringregula-
tions.
• Thisapplianceisnotintendedforusebypersons(includingchildren)with
reducedphysical,sensoryormentalcapabilities,orlackofexperienceand
knowledge,unlesstheyhavebeengivensupervisionorinstructioncon-
cerninguseoftheappliancebyapersonresponsiblefortheirsafety.
• Childrenshouldbesupervisedtoensurethattheydonotplaywiththeair
conditioner.
• Theterminalblockcoverpaneloftheunitmustbermlyattached.
• Ifthesupplycordisdamaged,itmustbereplacedbythemanufacturer,its
serviceagentorsimilarlyqualiedpersonsinordertoavoidahazard.
• UseonlyaccessoriesauthorizedbyMitsubishiElectricandaskadealeror
anauthorizedtechniciantoinstallthem.
• Afterinstallationhasbeencompleted,checkforrefrigerantleaks.Ifrefrig-
erantleaksintotheroomandcomesintocontactwiththeameofaheater
orportablecookingrange,poisonousgaseswillbereleased.
• Donotusemeanstoacceleratethedefrostingprocessortoclean,other
thanthoserecommendedbythemanufacturer.
• Theapplianceshallbestoredinaroomwithoutcontinuouslyoperating
ignitionsources(forexample:openames,anoperatinggasapplianceor
anoperatingelectricheater).
• Donotpierceorburn.
• Beawarethatrefrigerantsmaynotcontainanodour.
• Pipe-workshallbeprotectedfromphysicaldamage.
• Theinstallationofpipe-workshallbekepttoaminimum.
• Compliancewithnationalgasregulationsshallbeobserved.
• Keepanyrequiredventilationopeningsclearofobstruction.
• Donotuselowtemperaturesolderalloyincaseofbrazingtherefrigerant
pipes.
• Whenperformingbrazingwork,besuretoventilatetheroomsu󰀩ciently.
 Makesurethattherearenohazardousorammablematerialsnearby.
 Whenperformingtheworkinaclosedroom,smallroom,orsimilarloca-
tion,makesurethattherearenorefrigerantleaksbeforeperformingthe
work.
 Ifrefrigerantleaksandaccumulates,itmayigniteorpoisonousgasesmay
bereleased.

2
1.1. Beforeinstallation(Environment)
Caution:
• Donotusetheunitinanunusualenvironment.Iftheairconditionerisinstalled
inareasexposedtosteam,volatileoil(includingmachineoil),orsulfuricgas,
areasexposedtohighsaltcontentsuchastheseaside,theperformancecan
besignicantlyreducedandtheinternalpartscanbedamaged.
• Donotinstalltheunitwherecombustiblegasesmayleak,beproduced,ow,
oraccumulate.Ifcombustiblegasaccumulatesaroundtheunit,reorexplo-
sion may result.
• Donotkeepfood,plants,cagedpets,artwork,orprecisioninstrumentsinthe
directairowoftheindoorunitortooclosetotheunit,astheseitemscanbe
damagedbytemperaturechangesordrippingwater.
• When the room humidity exceeds 80% or when the drainpipe is clogged,
water may drip from the indoor unit. Do not install the indoor unit where such
drippingcancausedamage.
• Wheninstallingtheunitinahospitalorcommunicationso󰀩ce,bepreparedfor
noiseandelectronicinterference.Inverters,homeappliances,high-frequency
medicalequipment,andradiocommunicationsequipmentcancausetheair
conditionertomalfunctionorbreakdown.Theairconditionermayalsoa󰀨ect
medicalequipment,disturbingmedicalcare,andcommunicationsequipment,
harmingthescreendisplayquality.
1.2. Beforeinstallationorrelocation
Caution:
• Beextremely carefulwhen transportingthe units.Two ormore persons
areneededtohandletheunit,asitweighs20kgormore.Donotgraspthe
packagingbands.Wearprotectiveglovesasyoucaninjureyourhandson
thensorotherparts.
• Besuretosafelydisposeofthepackagingmaterials.Packagingmaterials,
suchasnails andothermetalorwooden partsmaycausestabsor other
injuries.
• Thermalinsulationoftherefrigerantpipeisnecessarytopreventcondensa-
tion.Iftherefrigerant pipeisnotproperlyinsulated,condensation willbe
formed.
1.3. Beforeelectricwork
Caution:
• Besuretoinstallcircuitbreakers.Ifnotinstalled,electricshockmayresult.
• Forthepowerlines,usestandardcablesofsu󰀩cientcapacity.Otherwise,a
shortcircuit,overheating,orremayresult.
• Wheninstallingthepowerlines,donotapplytensiontothecables.
• Besuretogroundtheunit.Iftheunitisnotproperlygrounded,electricshock
may result.
1.4. Beforestartingthetestrun
Caution:
• Turnonthemainpowerswitchmorethan12hoursbeforestartingoperation.
Startingoperationjustafterturningonthepowerswitchcanseverelydamage
the internal parts.
• Beforestartingoperation,checkthatallpanels,guardsandotherprotective
partsarecorrectlyinstalled.Rotating,hot,orhighvoltagepartscancause
injuries.
• Donotoperatetheairconditionerwithouttheairltersetinplace.Iftheair
lterisnotinstalled,dustmayaccumulateandbreakdownmayresult.
• Donottouchanyswitchwithwethands.Electricshockmayresult.
• Donottouchtherefrigerantpipeswithbarehandsduringoperation.
• Afterstoppingoperation,besuretowaitatleastveminutesbeforeturning
o󰀨themainpowerswitch.Otherwise,waterleakageorbreakdownmayresult.
• Placethermalinsulationonthepipestopreventcondensation.Ifthedrain-
pipeisinstalledincorrectly,waterleakageanddamagetotheceiling,oor,
furniture, or other possessions may result.
• Donotcleantheairconditionerunitwithwater.Electricshockmayresult.
• Tightenallarenutstospecicationusingatorquewrench.Iftightenedtoo
much,thearenutcanbreakafteranextendedperiod.
• Usecircuitbreakers(groundfaultinterrupter,isolatingswitch(+Bfuse),and
moldedcasecircuitbreaker)withthespeciedcapacity.Ifthecircuitbreaker
capacityislargerthanthespeciedcapacity,breakdownorremayresult.
1. Safety precautions
2. Installation location
(mm)
W
Fig.2-1
2.1.Outlinedimensions(Indoorunit)(Fig.2-1)
Select a proper position allowing the following clearances for installation and main-
tenance.
(mm)
Models W
M35, 50 960
M60, 71 1280
M100, 125, 140 1600
Warning:
Mounttheindoorunitonaceilingstrongenoughtowithstandtheweightof
the unit.
2.2.Outlinedimensions(Outdoorunit)
Refer to the outdoor unit installation manual.
Min.300
Max. 250
Min. 270
Min. 500
Min. 2200
en

3
3. Installingtheindoorunit
123
456
7 8
A
A
BC
D
F
H
G
J
E
236
B
2
75
80320
680
2
19046
6
233
246 C
D
233
246
IF
E
E
H G
H
G
86 285
138
126
19046
3.1.Checktheindoorunitaccessories(Fig.3-1)
The indoor unit should be supplied with the following accessories
(contained in the inside of the intake grille).
Accessory name Q’ty
1Washer 4 pcs
2Pipe cover 1 pc Large size (For gas tubing)
3Pipe cover 1 pc Small size (For liquid tubing)
4Band 4 pcs
5Joint socket 1 pc Marked with “UNIT”
6Socket cover 1 pc
7Drain tubing cover 1 pc
8Flare nut 1 pc ø6.35 (M60 only)
3.2.Preparationforinstallation(Fig.3-2)
3.2.1.Suspensionboltinstallingspacing
(mm)
Models A B
M35, 50 917 960
M60, 71 1237 1280
M100, 125, 140 1557 1600
3.2.2.Refrigerantanddraintubinglocation
(mm)
Models C D
M35, 50 184 203
M60 179 203
M71-140 180 200
AFront side outlet FLeft drain tubing
BLeft side outlet GGas tubing
CRight side outlet HLiquid tubing
DIndependent piece (Removable) IRubber plug
ERight drain tubing Jwith Joint socket 5
In case of the rear pipe arrangement, make sure to remove the shaded portions from
the Dindependent piece. Then put the Dindependent piece back in initial position.
(The heat exchanger might be clogged because of dust)
Fig.3-1
Fig.3-2
(mm)
UNIT
en

4
3. Installingtheindoorunit
(mm)
(mm)
B
AD
E
H
G
2
J
L
KM
C
1F
(mm)
a g
e
g
e
f
b
10 –20
dc
e
g
A
a
b
B
D
E
A
C
B
125
175
190
70
80 ø65 ø100
7~12
B
C
A
D
E
F
A
G
C
3.3.Installingtheindoorunit(Fig.3-5)
Use a proper suspending method depending on the presence or absence of ceiling
materials as follows.
AIn the presence of ceiling materials cCeiling
BIn the absence of ceiling materials dSuspending bolt
aSuspending bracket eWasher 1
bUnit fWasher (Local procurement)
gDouble nuts
1)Directlysuspendingtheunit
Installing procedures
1. Install the washer 1 (supplied with the unit) and the nuts (to be locally procured).
2. Set (hook) the unit through the suspending bolts.
3. Tighten the nuts.
Check the unit installing condition.
• Check that the unit is horizontal between the right and left sides.
• Check that the front and the rear of suspending brackets are horizontal.
(To keep drainage,the unit is inclined to the suspending brackets. The unit slopes
continuously downward from the front to the rear is the right installation position.)
2)Installingthesuspendingbracketrstontotheceiling(Fig.3-6)
Installing procedures
1. Remove the suspending brackets and U-shaped washers from the unit.
2. Adjust the suspending bracket holding bolts on the unit.
3. Attach the suspending brackets to the suspending bolts.
4. Check that the suspending brackets are horizontal (front and rear/right and left).
5. Set (hook) the unit to the suspending brackets.
6. Tighten xed bolts of the suspending brackets.
wBe sure to install the U-shaped washers.
ASuspending bracket holding bolt
BUnit
CU-shaped washer
DSuspending bolt
EWasher 1
FDouble nuts
3.2.3.Selectionofsuspensionboltsandtubingpositions(Fig.3-3)
Using the pattern paper provided for installation, select proper positions for suspen-
sion bolts and tubing and prepare relative holes.
APattern paper
BSuspension bolt hole
CIndoor unit width
Secure the suspension bolts or use angle stock braces or square timbers for bolt
installation.
DUse inserts of 100 kg to 150 kg each.
EUse suspension bolts of W3/8 or M10 in size.
3.2.4.Indoorunitpreparation(Fig.3-4)
1. Install the suspending bolts. (Procure the W3/8 or M10 bolts locally.)
Predetermine the length from the ceiling (1 within 100 mm).
ACeiling surface BSuspending bolt CSuspending bracket
2. Remove the intake grille.
Slide the intake grille holding knobs (at 2 or 3 locations) backward to open the
intake grille.
3. Remove the side panel.
Remove the side panel holding screws (one in each side, right and left) then slide
the side panel forward for removal.
DIntake grille JSlide the side panel forward.
EIntake grille holding knob KSide panel
FSlide LRemove the side panel holding screws.
GHinge MRemove the protective vinyl of vane.
HPushing the hinge, pull out the intake grille.
2Forcing open the intake grille or opening it to an angle of more than 120° may
damage the hinges.
Fig.3-4
Fig.3-5
Fig.3-3
Fig.3-6
(mm)
GM35, 50 882-887
M60, 71 1202-1207
M100-140 1522-1527
en

5
4. Installingtherefrigerantpiping
G
C
D
E
F
C
B
A
DE
E
F
B
A B
C
D
A
45 2
4.3.Indoorunit(Fig.4-3)
Installingprocedures
1. Slide the supplied pipe cover 2over the gas tubing until it is pressed against the
sheet metal inside the unit.
2. Slide the provided pipe cover 3over the liquid tubing until it is pressed against
the sheet metal inside the unit.
3. Tighten the pipe covers 2and 3 at the both ends (20 mm) with the supplied
bands 4.
AGas tubing EPipe cover 3
BLiquid tubing FPress the pipe cover against the sheet metal.
CBand 4GRefrigerant tubing heat insulating material
DPipe cover 2
4.4.Fortwin/triplecombination
Refer to the outdoor unit installation manual.
4.1. Precautions
FordevicesthatuseR32/R410Arefrigerant
• Usetherefrigerantoil(smallamount)appliedtothearedsections.
• UseC1220copperphosphorusforcopperandcopperalloyseamlesspipes,
toconnecttherefrigerantpipes.Userefrigerantpipeswiththethicknesses
speciedinthetable below.Makesuretheinsidesofthe pipesareclean
and do not contain any harmful contaminants such as sulfuric compounds,
oxidants,debris,ordust.
Warning:
Wheninstalling orrelocating, orservicingthe airconditioner, useonlythe
speciedrefrigerantwrittenonoutdoorunittochargetherefrigerantlines.Do
notmixitwithanyotherrefrigerantanddonotallowairtoremaininthelines.
Ifairismixedwiththerefrigerant,thenitcanbethecauseofabnormalhigh
pressureintherefrigerantline,andmayresultinanexplosionandotherhazards.
Theuseofanyrefrigerantotherthanthatspeciedforthesystemwillcause
mechanicalfailureorsystemmalfunctionorunitbreakdown.Intheworstcase,
thiscouldleadtoaseriousimpedimenttosecuringproductsafety.
M35, 50 M60-140
Liquid pipe ø6.35 thickness 0.8 mm ø9.52 thickness 0.8 mm
Gas pipe ø12.7 thickness 0.8 mm ø15.88 thickness 1.0 mm
• Donotusepipesthinnerthanthosespeciedabove.
4.2. Connectingpipes(Fig.4-1)
• When commercially available copper pipes are used, wrap liquid and gas pipes
with commercially available insulation materials (heat-resistant to 100 °C or more,
thickness of 12 mm or more).
• The indoor parts of the drain pipe should be wrapped with polyethylene foam insula-
tion materials (specic gravity of 0.03, thickness of 9 mm or more).
• Apply thin layer of refrigerant oil to pipe and joint seating surface before tightening
are nut.
• Use 2 wrenches to tighten piping connections.
• Use refrigerant piping insulation provided to insulate indoor unit connections. Insulate
carefully.
• After connecting the refrigerant piping to the indoor unit, be sure to test the pipe
connections for gas leakage with nitrogen gas. (Check that there is no refrigerant
leakage from the refrigerant piping to the indoor unit.)
• Use ared nut installed to this indoor unit.
• In case of reconnecting the refrigerant pipes after detaching, make the ared part
of pipe re-fabricated.
BFlare nut tightening torque
Copper pipe O.D.
(mm)
Flare nut O.D.
(mm)
Tightening torque
(N·m)
ø6.35 17 14-18
ø6.35 22 34-42
ø9.52 22 34-42
ø12.7 26 49-61
ø12.7 29 68-82
ø15.88 29 68-82
C Apply refrigerating machine oil over the entire are seat surface.
Do not apply refrigerating machine oil to the screw portions.
(This will make the are nuts more apt to loosen.)
D Use correct are nuts meeting the pipe size of the outdoor unit.
Availablepipesize
M35, 50 M60 M71-140
Liquid side ø6.35 Ο ø6.35 —
—ø9.52 Ο ø9.52 Ο
Gas side ø12.7 Ο ø15.88 Ο ø15.88 Ο
Ο : Factory are nut attachment to the heat exchanger.
AFlare cutting dimensions
Copper pipe O.D.
(mm)
Flare dimensions
øA dimensions (mm)
ø6.35 8.7 - 9.1
ø9.52 12.8 - 13.2
ø12.7 16.2 - 16.6
ø15.88 19.3 - 19.7
Copper pipe O.D.
(mm)
B (mm)
Flare tool for R32/R410A
Clutch type
ø6.35 (1/4″) 0 - 0.5
ø9.52 (3/8″) 0 - 0.5
ø12.7 (1/2″) 0 - 0.5
ø15.88 (5/8″) 0 - 0.5
Fig.4-3
Fig.4-1
Fig.4-2
90° ± 0.5°
R0.4 - R0.8
EDie
FCopper pipe
en

6
5. Drainagepipingwork
6. Electricalwork
BC
A
AC
F
D
B
E
C
D
B
E
ABC D
EF
D
H
I
G
i
• For left side tubing, be sure to insert the rubber plug into the right drain port. (Fig. 5-1)
• Use VP-20 (O.D. ø26 (1”) PVC TUBE) for drain piping and provide 1/100 or more
downward slope.
• After completion of work, check that correct drain is available from the outow port
of the drain tubing.
ADrain pan
BPlug
CInsert the driver etc.in the plug deeply.
Installingprocedures(Fig.5-2)
1. Attach the joint socket 5supplied with the unit to the drain port on the unit with a
vinyl chloride adhesive.
2. Fasten the socket cover 6supplied with the unit to the joint socket 5.
3. Attach the eld drain tubing (VP-20) to the joint socket 5with a vinyl chloride
adhesive.
4. Wrap the drain tubing cover 7 supplied with the unit. (Seam taping)
ADrain pan
BDrain tubing
CSocket cover 6
DJoint socket 5
EDrain tubing cover 7
FInsertion length 37 mm
5. Check for correct drainage. (Fig. 5-3)
* Fill the drain pan with water of about 1 L from the air outlet.
6.1.Electricwiring(Fig.6-1)
Wiring procedures
1. Remove the tapping screw Cthen remove the beam.
2. Remove the (2) tapping screws Bthen remove the electric part cover A.
3. Connect the electric wires securely to the corresponding terminals.
4. Reinstall the removed parts.
5. Tie the electric wires with the local wiring clamp located in the right side of the
junction box.
ACover HGrounding cable connector
B Set screws (2 pcs) ITerminal block for remote controller
C Set screws (Beam) iSecure with the wiring clamp.
DWiring clamp
EControl board
FWire service entrance
GTerminal block for indoor and outdoor units connection: S1, S2 and S3, have
polarity
Fig.5-1
Fig.5-2
Fig.5-3
Fig.6-1
en

7
6.1.1. Indoorunitpowersuppliedfromoutdoorunit
The following connection patterns are available.
The outdoor unit power supply patterns vary on models.1 System
S1
S2
L
N
1
2
S1
S2
S3
S3
AB C
D
E
F
G
S1
S2
L
N
1
2
S1
S2
S3
1
2
S1
S2
S3
S3
1
2
S1
S2
S3
1
2
S1
S2
S3
D
E
F
G G G G
AB C
HH H
* A󰀩x label A that is included with the manuals near each wiring diagram for the indoor and outdoor units.
A Outdoor unit power supply
B Earth leakage breaker
C Wiring circuit breaker or isolating switch
D Outdoor unit
E Indoor unit/outdoor unit connecting cables
F Remote controller
G Indoor unit
* A󰀩x label A that is included with the manuals near each wiring diagram for the indoor and outdoor units.
Indoor unit model PCA
Wiring
Wire No. × size
(mm²)
Indoor unit-Outdoor unit *1 3 × 1.5 (polar)
Indoor unit-Outdoor unit earth *1 1 × Min.1.5
Indoor unit earth 1 × Min.1.5
Remote controller-Indoor unit *2 2 × 0.3 (Non-polar)
Circuit rating
Indoor unit (Heater) L-N *3 -
Indoor unit-Outdoor unit S1-S2 *3 230 V AC
Indoor unit-Outdoor unit S2-S3 *3 *4 24 V DC / 28 V DC
Remote controller-Indoor unit *3 12 V DC
*1. <For 50-140 outdoor unit application>
Max. 45 m
If 2.5 mm2used, Max. 50 m
If 2.5 mm2used and S3 separated, Max. 80 m
<For 200/250 outdoor unit application>
Max. 18 m
If 2.5 mm2used, Max. 30 m
If 4 mm2used and S3 separated, Max. 50 m
If 6 mm2used and S3 separated, Max. 80 m
*2. Max. 500 m
(When using 2 remote controllers, the maximum wiring length for the remote controller cables is 200 m. If 2 remote controllers are connected, set one to “Main” and the other to
“Sub”. For setting procedures, refer to “Initial settings” in the installation manual for the remote controller.)
*3. The gures are NOT always against the ground.
S3 terminal has 24 V DC / 28 V DC against S2 terminal. However between S3 and S1, these terminals are not electrically insulated by the transformer or other device.
*4. It depends on the outdoor unit.
Notes: 1. Wiringsizemustcomplywiththeapplicablelocalandnationalcode.
2.
Powersupplycordsandindoorunit/outdoor unitconnecting cordsshall notbe lighterthan polychloroprenesheathed exiblecord.
(Design60245IEC57)
 3. Installanearthlongerthanothercables.
 4. Indoorandoutdoorconnectingwireshavepolarities.Makesuretomatchtheterminalnumber(S1,S2,S3)forcorrectwirings.
 5. Wiringforremotecontrollercableshallbeapart(50mmormore)frompowersourcewiringsothatitisnotinuencedbyelectricnoise
frompowersourcewiring.
Simultaneoustwin/triple/quadruplesystem
1:1 System
6.1.2. Separateindoorunit/outdoorunitpowersupplies(ForPUZ/PUHZapplicationonly)
The following connection patterns are available.
The outdoor unit power supply patterns vary on models.
1:1 System
6. Electricalwork
A Outdoor unit power supply
B Earth leakage breaker
C Wiring circuit breaker or isolating switch
D Outdoor unit
E Indoor unit/outdoor unit connecting cables
F Remote controller
G Indoor unit
H Indoor unit earth
S1
S2
L
N
1
2
L
N
S1
S2
S3
S3
D
E
F
G
H
AB C B C
J
* The indoor power supply terminal kit is required. A Outdoor unit power supply
B Earth leakage breaker
C Wiring circuit breaker or isolating switch
D Outdoor unit
E Indoor unit/outdoor unit connecting cables
F Remote controller
G Indoor unit
H Option
J Indoor unit power supply
* A󰀩x label B that is included with the manuals near each wiring diagram for the indoor and outdoor units.
en

8
6. Electricalwork
Simultaneoustwin/triple/quadruplesystem
S1
S2
L
N
1
2
L
N
S1
S2
S3
1
2
L
N
S1
S2
S3
1
2
L
N
S1
S2
S3
1
2
L
N
S1
S2
S3
S3
D
E
F
H
G G G G
KKK
HHH
AB C B C
J
ON
OFF 1 2 (SW8)
3
S1
S2
S3
L
N
CN01
S1
S2
S3
L
N
CN01
BLUE BLUE
YELLOW
BLACK
CN01
BLACK
CN01
YELLOW
BLUE
YELLOW
YELLOW
BLUE
* A󰀩x label B that is included with the manuals near each wiring diagram for the indoor and outdoor units.
If the indoor and outdoor units have separate power supplies, refer to the table below.
If the indoor power supply terminal kit is used, change the indoor unit electrical box
wiring refering to the gure in the right and the DIP switch settings of the outdoor
unit control board.
Indoor unit specications
Indoor power supply terminal kit (option) Required
Indoor unit electrical box connector connec-
tion change
Required
Label a󰀩xed near each wiring diagram for the
indoor and outdoor units
Required
Outdoor unit DIP switch settings (when us-
ing separate indoor unit/outdoor unit power
supplies only)
* There are 3 types of labels (labels A, B and C). A󰀩x the appropriate labels to the
units according to the wiring method.
Indoor unit model PCA
*1. A breaker with at least 3.0 mm contact separation in each pole shall be pro-
vided. Use earth leakage breaker (NV).
The breaker shall be provided to ensure disconnection of all active phase
conductors of the supply.
*2. Max. 120 m
*3. Max. 500 m
(When using 2 remote controllers, the maximum wiring length for the remote
controller cables is 200 m. If 2 remote controllers are connected, set one to
“Main” and the other to “Sub”. For setting procedures, refer to “Initial settings”
in the installation manual for the remote controller.)
*4. The gures are NOT always against the ground.
*5. It depends on the outdoor unit.
Indoor unit power supply ~/N (single), 50/60 Hz, 230 V
Indoor unit input capacity
Main switch (Breaker) *1 16 A
Wiring
Wire No. ×
size (mm²)
Indoor unit power supply & earth 3 × Min. 1.5
Indoor unit-Outdoor unit *2 2 × Min. 0.3
Indoor unit-Outdoor unit earth –
Remote controller-Indoor unit *3 2 × 0.3 (Non-polar)
Circuit
rating
Indoor unit L-N *4 230 V AC
Indoor unit-Outdoor unit S1-S2 *4 –
Indoor unit-Outdoor unit S2-S3 *4 *5 24 V DC / 28 V DC
Remote controller-Indoor unit *4 12 V DC
Notes: 1. Wiringsizemustcomplywiththeapplicablelocalandnationalcode.
2.
Powersupplycordsandindoorunit/outdoorunitconnectingcordsshallnotbelighterthanpolychloroprenesheathedexiblecord.(Design60245IEC57)
 3. Installanearthlongerthanothercables.
 4. Wiringforremotecontrollercableshallbeapart(50mmormore)frompowersourcewiringsothatitisnotinuencedbyelectricnoisefrompower
sourcewiring.
A Outdoor unit power supply
B Earth leakage breaker
C Wiring circuit breaker or isolating switch
D Outdoor unit
E Indoor unit/outdoor unit connecting cables
F Remote controller
G Indoor unit
H Option
J Indoor unit power supply
K Indoor unit earth
Never splice the power cable or the indoor-outdoor connection cable, otherwise it may result in a smoke, a re or communication failure.
Warning:
* The indoor power supply terminal kits are required.
Set the SW8-3 to ON.
Option
Option
Indoor unit power supplied from outdoor unit
(initial setting)
Separate indoor unit/outdoor unit power supplies
Connectors (connections of initial setting
are for indoor unit power supplied from
outdoor unit)
If the indoor and
outdoor units have
separate power
supplies, change the
connections of the
connectors as shown
in the following
gure.
Connectors
Indoor unit
control board
Indoor unit
control board
en

9
6. Electricalwork
en
6.2. Functionsetting
6.2.1. Functionsettingontheunit(Selectingtheunitfunctions)
1 (Fig. 6-2)
• Select “Service” from the Main menu, and press the [SELECT] button.
• Select “Settings” from the Service menu, and press the [SELECT] button.
2 (Fig. 6-3)
• Select “Function setting” with the [SELECT] button.
3 (Fig. 6-4)
• Set the indoor unit refrigerant addresses and unit numbers with the [F1]
through [F4] buttons, and then press the [SELECT] button to conrm the cur-
rent setting.
<CheckingtheIndoorunitNo.>
When the [SELECT] button is pressed, the target indoor unit will start fan
operation. If the unit is common or when running all units, all indoor units for the
selected refrigerant address will start fan operation.
4 (Fig. 6-5)
• When data collection from the indoor units is completed, the current settings
appears. Screen appearance varies depending on the “Unit No.” setting.
• Toggle through the pages with the [F3] or [F4] button.
• Select the mode number with the [F1] or [F2] button, and then press the [SE-
LECT] button.
5 (Fig. 6-6)
• Select the setting number with the [F1] or [F2] button.
Setting range for modes 1 through 28: 1 through 3
Setting range for modes 31 through 66: 1 through 15
6 (Fig. 6-7)
• When the settings are completed, press the [SELECT] button to send the set-
ting data from the remote controller to the indoor units.
• When the transmission is successfully completed, the screen will return to the
Function setting screen.
Settings menu
Cursor
Service menu:
Function setting
Rotation setting
F1 F2 F3 F4
F1 F2 F3 F4
Service menu
Cursor
Main menu:
Test run
Input maintenance info.
Settings
Check
Others
Function setting
Cursor Address
Monitor:
Ref. address
Unit No.
Grp./1/2/3/4/All
F1 F2 F3 F4
Fig.6-3Fig.6-2
Fig.6-4
F1 F2 F3 F4
Function setting
Cursor Page
Ref. address
Mode 1
Mode 2
Mode 3
Mode 4
Grp.
Save:
1/8
F1 F2 F3 F4
Function setting
Request:
Ref. address
Mode 1
Mode 2
Mode 3
Mode 4
Grp.
1/8
Value
Fig.6-5
Fig.6-6
F1 F2 F3 F4
Function setting
Ref. address
Sending data
Grp.
Fig.6-7
Note:
•MaketheabovesettingsonMr.Slimunitsasnecessary.
•Functiontablesummarizesthesettingoptionsforeachmodenumber.
• Besuretowritedownthesettingsforallfunctionsifanyoftheinitialset-
tingshasbeenchangedafterthecompletionofinstallationwork.

10
6. Electricalwork
Functiontable
Select unit number “Grp.”
Mode Settings Mode no. Setting no. Initial setting setting
Power failure automatic recovery Not available 01 1
Available *1 2Ο *2
Indoor temperature detecting Indoor unit operating average
02
1Ο
Set by indoor unit’s remote controller 2
Remote controller’s internal sensor 3
LOSSNAY connectivity Not Supported
03
1Ο
Supported (indoor unit is not equipped with outdoor-air intake)
2
Supported (indoor unit is equipped with outdoor-air intake) 3
Power voltage 240 V 04 1
220 V, 230 V 2Ο
Auto operation mode Single set point (Available 14 °C cooling setting *3) 06 1
Dual set point (Not available 14 °C cooling setting *3) 2Ο
Smart Defrost *3 Available 20 1Ο
Not Available 2
Select unit numbers 1 to 4 or “All”
Mode Settings Mode no. Setting no. Initial setting setting
Filter sign 100 Hr
07
1
2500 Hr 2Ο
No lter sign indicator 3
Fan speed Silent
08
1
Standard 2Ο
High ceiling 3
Installed options (high e󰀩ciency lter) Not supported 10 1Ο
Supported 2
Up/down vane setting No vanes
11
1
Equipped with vanes (vanes angle setup 1)2Ο
Equipped with vanes (vanes angle setup 2)3
Fan speed during the cooling thermostat is OFF Setting fan speed
27
1
Stop 2
Extra low 3 Ο
*1 When the power supply returns, the air conditioner will start 3 minutes later.
*2 Power failure automatic recovery initial setting depends on the connecting outdoor unit.
*3 It is available when the indoor unit is connected to any of the particular outdoor units.
en

11
6. Electricalwork
en
6.2.2. Rotationsetting
You can set these functions by wired remote controller. (Maintenance monitor)
Rotation setting
Select :
Rotation
TempDifTrigger
− Content +
Backup only
+4°C
Cur.
F1 F2 F3 F4
Reset
4Set the rotation function.
• Select "Rotation" with the [F1] button.
• Select the switching period or "Backup only" with the [F2] or [F3] button.
■"Rotation" setup options
None, 1 day, 3 days, 5 days, 7 days, 14 days, 28 days, Backup only
5Set the support function.
• Select "TempDifTrigger" with the [F1] button.
• Select the di󰀨erence between the suction temperature and the set temperature with the [F2] or [F3]
button.
1Select “Service” from the Main menu, and press the [SELECT] button.
2Select “Settings” with the [F1] or [F2] button, and press the [SELECT] button.
3Select “Rotation setting” with the [F1] or [F2] button, and press the [SELECT] button.
F1 F2 F3 F4
Settings menu
Cursor
Service menu:
Function setting
Rotation setting
Rotation setting
Select :
Rotation
TempDifTrigger
− Content +
Backup only
+4°C
Cur.
F1 F2 F3 F4
Reset
Notes:
• When 1 to 28 days are selected from the setup options, the backup function is also enabled.
• When "Backup only" is selected, the rotation function will be disabled. The systems with refrigerant ad-
dresses of 00 or 01 (00 system/ 01 system) will be operated as a main system while the 02 system is
the standby mode as backup.
6Press the [SELECT] button to update the setting.
■"TempDifTrigger" setup options
None, +4ºC, +6ºC, +8ºC
Notes:
• The support function is available only in the COOL mode. (Not available in the HEAT, DRY and AUTO
mode.)
• The support function is enabled when any option other than "None" is selected from the "Rotation"
setup options.
Reset method
• Press the [F4] button in step 4 or 5 to reset the operation time of the rotation function. Once it is reset, operation will start from the systems with
refrigerant addresses of 00 or 01.
Note: When the system with refrigerant address of 02 is in the backup operation, the 00 or 01 systems will be operated again.

12
7. Test run
7.2. Test run
7.2.1. Usingwiredremotecontroller.
■ Make sure to read operation manual before test run. (Especially items to secure safety)
Step 1 Turn on the power.
● Remote controller: The system will go into startup mode, and the remote controller power lamp (green) and “Please Wait” will blink. While the lamp and message are
blinking, the remote controller cannot be operated. Wait until “Please Wait” is not displayed before operating the remote controller. After the power is turned on, “Please
Wait” will be displayed for approximately 2 minutes.
● Indoor controller board: LED 1 will be lit up, LED 2 will be lit up (if the address is 0) or o󰀨 (if the address is not 0), and LED 3 will blink.
● Outdoor controller board: LED 1 (green) and LED 2 (red) will be lit up. (After the startup mode of the system nishes, LED 2 will be turned o󰀨.) If the outdoor controller
board uses a digital display, [- ] and [ -] will be displayed alternately every second.
If the operations do not function correctly after the procedures in step 2 and thereafter are performed, the following causes should be considered and eliminated if they
are found.
(The symptoms below occur during the test run mode. “Startup” in the table means the LED display written above.)
Symptoms in test run mode
Cause
Remote Controller Display OUTDOORBOARDLEDDisplay
< > indicates digital display.
Remote controller displays “Please Wait”, and
cannot be operated. After “startup” is displayed, only green lights up. <00> • After power is turned on, “Please Wait” is displayed for 2 minutes during system startup. (Normal)
After power is turned on, “Please Wait” is
displayed for 3 minutes, then error code is
displayed.
After “startup” is displayed, green (once) and red
(once) blink alternately. <F1> • Incorrect connection of outdoor terminal block (~/N: L, N and S1, S2, S3) (3N~: L1, L2, L3, N and S1, S2, S3)
After “startup” is displayed, green (once) and red
(twice) blink alternately. <F3, F5, F9> • Outdoor unit’s protection devise connector is open.
No display appears even when remote control-
ler operation switch is turned on. (Operation
lamp does not light up.)
After “startup” is displayed, green (twice) and red
(once) blink alternately. <EA. Eb>
• Incorrect wiring between the indoor and outdoor unit (Polarity is
wrong for S1, S2, S3.)
• Remote controller transmission wire short.
After “startup” is displayed, only green lights up.
<00> • There is no outdoor unit of address 0. (Address is other than 0.) • Remote controller transmission wire open.
Display appears but soon disappears even
when remote controller is operated. After “startup” is displayed, only green lights up. <00> • After canceling function selection, operation is not possible for about 30 seconds. (Normal)
Step 2 Switch the remote controller to “Test run”.
1
Select “Test run” from the Service menu, and press the [SELECT] button. (Fig. 7-1)
2 Select “Test run” from the Test run menu, and press the [SELECT] button. (Fig. 7-2)
3The test run operation starts, and the Test run operation screen is displayed.
unemecivreS
rosruC
:unemniaM
Test run
Input maintenance info.
Function setting
Check
Self check
F1 F2 F3 F4
Fig.7-1
Test run menu
Cursor
Service menu:
Test run
Drain pump test run
F1 F2 F3 F4
Fig.7-2
Cool Auto
Switch disp.
Mode Fan
RemainTest run
F1 F2 F3 F4
Pipe
Fig.7-3
Remain
Vane
F1 F2 F3 F4
Fig.7-4
Step3 Performthetestrunandchecktheairowtemperatureandautovane.
1 Press the [F1] button to change the operation mode. (Fig. 7-3)
Cooling mode: Check that cool air blows from the unit.
Heating mode: Check that warm air blows from the unit.
2Press the [SELECT] button to display the Vane operation screen, and then press
the [F1] and [F2] buttons to check the auto vane. (Fig. 7-4)
Press the [RETURN] button to return to the Test run operation screen.
Step4 Conrmtheoperationoftheoutdoorunitfan.
The speed of the outdoor unit fan is controlled in order to control the performance of the unit. Depending on the ambient air, the fan will rotate at a slow speed and will keep
rotating at that speed unless the performance is insu󰀩cient. Therefore, the outdoor wind may cause the fan to stop rotating or to rotate in the opposite direction, but this is
not a problem.
► Donotcarryoutthistestonthecontrolwiring(lowvoltagecircuit)terminals.
Warning:
Do not use the air conditioner if the insulation resistance is less than 1 M .
7.1. Beforetestrun
► Aftercompletinginstallation andthewiringandpipingoftheindoorand
outdoorunits,checkforrefrigerantleakage,loosenessinthepowersupply
orcontrolwiring,wrongpolarity,andnodisconnectionofonephaseinthe
supply.
► Usea500-voltmegohmmetertocheckthattheresistancebetweenthepower
supplyterminalsandgroundisatleast1M .
en

13
7. Test run
Step5 Stopthetestrun.
1 Press the [ON/OFF] button to stop the test run. (The Test run menu will appear.)
Note: If an error is displayed on the remote controller, see the table below.
LCD Description of malfunction LCD Description of malfunction LCD Description of malfunction
P1 Intake sensor error P9 Pipe sensor error (dual-wall pipe)
E0 ~ E5
Communication error between the
remote controller and the indoor
unit
P2 Pipe sensor error (liquid pipe) PA Leakage error (refrigerant system)
P4 Drain oat switch connector
disconnected (CN4F)
Pb Indoor unit fan motor error
PL Refrigerant circuit abnormal
P5 Drain overow protection operation FB Indoor controller board error
E6 ~ EF Communication error between the
indoor unit and the outdoor unit
P6 Freezing/overheating protection
operation
U*, F*
(* indicates an
alphanumeric
character
excluding FB.)
Outdoor unit malfunction
Refer to the wiring diagram for the
outdoor unit.
P8 Pipe temperature error
See the table below for the details of the LED display (LED 1, 2, and 3) on the indoor controller board.
LED 1 (microcomputer power supply) Indicates whether control power is supplied. Make sure that this LED is always lit.
LED 2 (remote controller power supply) Indicates whether power is supplied to the wired remote controller. The LED is lit only for the indoor unit that is connected
to the outdoor unit that has an address of 0.
LED 3 (indoor/outdoor unit communication) Indicates whether the indoor and outdoor units are communicating. Make sure that this LED is always blinking.
7.2.2. Usingwirelessremotecontroller(Fig.7-5)
1. Press the button 1to stop the air conditioner.
• If the weekly timer is enabled ( is on), press the button 3to disable
it ( is o󰀨).
2. Press the button 2for 5 seconds.
• comes on and the unit enters the service mode.
3. Press the button 2.
• Bcomes on and the unit enters the test run mode.
4. Press the following buttons to start the test run.
: Switch the operation mode between cooling and heating and start the test run.
: Switch the fan speed and start the test run.
: Switch the airow direction and start the test run.
: Switch the louver and start the test run.
: Start the test run.
5. Stop the test run.
• Press the button 1to stop the test run.
• After 2 hours, the stop signal is transmitted.
7.2.3. UsingSW4inoutdoorunit
Refer to the outdoor unit installation manual.
7.3. Self-check
7.3.1. Wired remote controller
■ Refer to the installation manual that comes with each remote controller for details.
7.3.2. Wirelessremotecontroller(Fig.7-6)
1. Press the button 1to stop the air conditioner.
• If the weekly timer is enabled ( is on), press the button 3to disable
it ( is o󰀨).
2. Press the button 2for 5 seconds.
• Acomes on and the unit enters the self-check mode.
3. Press the button 5 to select the refrigerant address (M-NET address) Bof the
indoor unit for which you want to perform the self-check.
4. Press the button 4.
• If an error is detected, the check code is indicated by the number of beeps from
the indoor unit and the number of blinks of the OPERATION INDICATOR lamp.
5. Press the button 1.
• A and the refrigerant address (M-NET address) B go o󰀨 and the self-check
is completed.
Fig.7-5
Fig.7-6
1
A
B
2
3
5
B
1
A
4
2
3
en

14
7. Test run
• Refer to the following tables for details on the check codes. (Wireless remote controller)
[Output pattern A]
[Output pattern A] Errors detected by indoor unit
Wireless remote controller Wired remote
controller
Symptom Remark
Beeper sounds/OPERATION
INDICATOR lamp blinks
(Number of times)
Check code
1 P1 Intake sensor error
2P2 Pipe (TH2) sensor error
P9 Pipe (TH5) sensor error
3 E6, E7 Indoor/outdoor unit communication error
4 P4 Float switch connector open
5P5 Drain pump error
PA Forced compressor stop (due to water leakage abnormality)
6 P6 Freezing/Overheating protection operation
7 EE Communication error between indoor and outdoor units
8 P8 Pipe temperature error
9 E4 Remote controller signal receiving error
10 — —
11 Pb Indoor unit fan motor error
12 Fb Indoor unit control system error (memory error, etc.)
14 PL Refrigerant circuit abnormal
No sound E0, E3 Remote controller transmission error
No sound E1, E2 Remote controller control board error
No sound – – – – No corresponding
OPERATION
INDICATOR
lamp blinking
pattern
Beep Beep Beep Beep Beep Beep Beep
O󰀨
Approx. 2.5 sec.
On
Approx. 3 sec.
On
0.5 sec.
On
0.5 sec.
On
0.5 sec.
On
0.5 sec.
O󰀨
Approx. 2.5 sec.
On
Approx. 3 sec.
On
0.5 sec.
On
0.5 sec.
· · · Repeated
Number of blinks/beeps in pattern indicates the check
code in the following table (i.e., n=5 for “U2”) Number of blinks/beeps in pattern
indicates the check code in the
following table
nth 1st 2nd 3rd 1st 2nd
Self-check
starts
(Start signal
received)
Beeper sounds
[Output pattern B]
OPERATION
INDICATOR
lamp blinking
pattern
Beep Beep Beep Beep Beep Beep Beep
O󰀨
Approx. 2.5 sec.
On
0.5 sec.
On
0.5 sec.
On
0.5 sec. On
0.5 sec.
O󰀨
Approx. 2.5 sec.
On
0.5 sec.
On
0.5 sec.
· · · Repeated
Number of blinks/beeps in pattern indicates the check
code in the following table (i.e., n=5 for “P5”)
Number of blinks/beeps in pattern indicates
the check code in the following table
nth
1st 2nd 3rd 1st 2nd
Self-check
starts
(Start signal
received)
Beeper sounds
en

15
7. Test run
[Output pattern B] Errors detected by unit other than indoor unit (outdoor unit, etc.)
Wireless remote controller Wired remote
controller
Symptom Remark
Beeper sounds/OPERATION
INDICATOR lamp blinks
(Number of times)
Check code
1 E9 Indoor/outdoor unit communication error (Transmitting error) (Outdoor unit)
For details, check the LED
display of the outdoor controller
board.
2 UP Compressor overcurrent interruption
3 U3, U4 Open/short of outdoor unit thermistors
4 UF Compressor overcurrent interruption (When compressor locked)
5 U2 Abnormal high discharging temperature/49C worked/insu󰀩cient refrigerant
6 U1, Ud Abnormal high pressure (63H worked)/Overheating protection operation
7 U5 Abnormal temperature of heat sink
8 U8 Outdoor unit fan protection stop
9 U6 Compressor overcurrent interruption/Abnormal of power module
10 U7 Abnormality of super heat due to low discharge temperature
11 U9, UH Abnormality such as overvoltage or voltage shortage and abnormal
synchronous signal to main circuit/Current sensor error
12 — —
13 — —
14 Others Other errors (Refer to the technical manual for the outdoor unit.)
*1.Ifthebeeperdoesnotsoundagainaftertheinitial2beepstoconrmtheself-checkstartsignalwasreceivedandtheOPERATIONINDICATORlampdoes
not come on, there are no error records.
*2.Ifthebeepersounds3timescontinuously“beep,beep,beep(0.4+0.4+0.4sec.)”aftertheinitial2beepstoconrmtheself-checkstartsignalwasreceived,
thespeciedrefrigerantaddressisincorrect.
• On wireless remote controller
The continuous buzzer sounds from receiving section of indoor unit.
Blink of operation lamp
• On wired remote controller
Check code displayed in the LCD.
• If the unit cannot be operated properly after test run, refer to the following table to nd the cause.
Symptom Cause
Wired remote controller LED 1, 2 (PCB in outdoor unit)
Please Wait For about 2 minutes
after power-on
After LED 1, 2 are lit, LED 2 is turned o󰀨,
then only LED 1 is lit. (Correct operation)
•For about 2 minutes after power-on, operation of the remote
controller is not possible due to system start-up. (Correct
operation)
Please Wait →Error code
Subsequent to about
2 minutes after
power-on
Only LED 1 is lit. →LED 1, 2 blink.
•Connector for the outdoor unit’s protection device is not con-
nected.
Reverse or open phase wiring for the outdoor unit’s power
terminal block (~/N: L, N) (3N~: L1, L2, L3, N)
Display messages do not appear
even when operation switch is
turned ON
(operation lamp does not light up).
Only LED 1 is lit. →LED 1 blinks twice,
LED 2 blinks once.
•Incorrect wiring between indoor and outdoor units (incorrect
polarity of S1, S2, S3)
•Remote controller wire short
On the wireless remote controller with condition above, following phenomena take place.
• No signals from the remote controller are accepted.
• Operation lamp is blinking.
• The buzzer makes a short ping sound.
Note:
Operationisnotpossibleforabout30secondsaftercancellationoffunctionselection.(Correctoperation)
For description of each LED (LED 1, 2, 3) provided on the indoor controller, refer to the following table.
LED 1 (power for microcomputer) Indicates whether control power is supplied. Make sure that this LED is always lit.
LED 2 (power for remote controller) Indicates whether power is supplied to the remote controller. This LED lights only in the case of
the indoor unit which is connected to the outdoor unit refrigerant address “0”.
LED 3 (communication between indoor and outdoor units) Indicates state of communication between the indoor and outdoor units. Make sure that this LED
is always blinking.
en

16
8. Easymaintenancefunction
en
Maintenance data, such as the indoor/outdoor unit’s heat exchanger temperature and compressor operation current can be displayed with “smooth maintenance”.
* Thiscannotbeexecutedduringtestoperation.
* Dependingonthecombinationwiththeoutdoorunit,thismaynotbesupportedbysomemodels.
• Select “Service” from the Main menu, and press the [SELECT] button.
• Select “Check” with the [F1] or [F2] button, and press the [SELECT] button.
• Select “Smooth maintenance” with the [F1] or [F2] button, and press the [SELECT]
button.
Select each item.
• Select the item to be changed with the [F1] or [F2] button.
• Select the required setting with the [F3] or [F4] button.
“Ref. address” setting ………. “0” - “15”
“Stable mode” setting……….. “Cool” / “Heat” / “Normal”
• Press the [SELECT] button, xed operation will start.
* Stable mode will take approx. 20 minutes.
The operation data will appear.
The Compressor-Accumulated operating time (COMP. run time) is 10-hour unit,
and the Compressor-Number of operation times (COMP. On/O󰀨) is a 100-time unit
(fractions discarded)
Navigatingthroughthescreens
• To go back to the Service menu................[MENU] button
• To return to the previous screen .......... [RETURN] button
F1 F2 F3 F4
Check menu
Cursor
Service menu:
Error history
Diagnosis
Smooth maintenance
Request code
Smooth maintenance
Begin:
Smooth maintenance
Exit:
Ref.address
Stable mode
Cursor
Ref.address
Stable mode
Stabilization→Collecting
Cool / Heat/Normal
Address
Cool / Heat/Normal
Smooth maintenance
Return:
Smooth maintenance
Return:
Smooth maintenance
Return:
Page
Page
Page
COMP. current
COMP. run time
COMP. On / Off
COMP. frequency
A
Hz
Hr
times
Hr
Ref. address
Cool
Ref.address
Cool
Ref.address
Cool
Sub cool
OU TH4 temp.
OU TH6 temp.
OU TH7 temp.
IU air temp.
IU HEX temp.
IU filter time
1
2
3

1
Inhaltsverzeichnis
1. Sicherheitsvorkehrungen...........................................................................1
2. Aufstellort ..................................................................................................2
3. Anbringung der Innenanlage.....................................................................3
4. Installation der Kältemittelrohrleitung ........................................................5
5. Verrohrung der Dränage............................................................................6
6. Elektroarbeiten ..........................................................................................6
7. Testlauf....................................................................................................12
8. Funktion für einfache Wartung ................................................................16
1. Sicherheitsvorkehrungen
►VordemEinbauderAnlagevergewissern,daßSiealleInformationenüber„Sicherheitsvorkehrungen“gelesenhaben.
►Die„Sicherheitsvorkehrungen“enthaltensehrwichtigeSicherheitsgesichtspunkte.Siesolltensieunbedingtbefolgen.
►VordemAnschließendiesesGerätsandasStromnetzIhrEnergieversorgungsunternehmeninformierenoderdessenGenehmigungeinholen.
ImTextverwendeteSymbole
Warnung:
BeschreibtVorkehrungen,diebeachtetwerdensollten,umdenBenutzervor
derGefahrvonVerletzungenodertödlicherUnfällezubewahren.
Vorsicht:
BeschreibtVorkehrungen,diebeachtetwerdensollten,damitanderAnlage
keineSchädenentstehen.
IndenAbbildungenverwendeteSymbole
: Verweist auf einen Teil der Anlage, der geerdet werden muß.
: Tun Sie dieses auf keinen Fall.
Erläutern Sie dem Kunden nach Abschluß der Installationsarbeiten die „Sicher-
heitsvorkehrungen“ sowie die Nutzung und Wartung der Anlage entsprechend den
Informationen in der Bedienungsanleitung und führen Sie einen Testlauf durch,
um sicherzustellen, daß die Anlage ordnungsgemäß funktioniert. Geben Sie dem
Benutzer sowohl die Installations- als auch die Bedienungsanleitung zur Aufbe-
wahrung. Diese Anleitungen sind auch den nachfolgenden Besitzern der Anlage
weiterzugeben.
BEDEUTUNGDERAUFDEMINNENGERÄTUND/ODERAUSSENGERÄTANGEBRACHTENSYMBOLE
WARNUNG
(Brandgefahr)
Dieses Symbol gilt nur für das Kältemittel R32. Der Kältemitteltyp ist auf dem Typenschild des Außengeräts angegeben.
Falls der Kältemitteltyp dieses Geräts R32 ist, ist das Kältemittel des Geräts entzündlich.
Wenn Kältemittel austritt und mit Feuer oder heißen Teilen in Berührung kommt, entsteht schädliches Gas und es besteht Brandgefahr.
Lesen Sie vor dem Betrieb sorgfältig das BEDIENUNGSHANDBUCH.
Servicetechniker müssen vor dem Betrieb das BEDIENUNGSHANDBUCH und die INSTALLATIONSANLEITUNG sorgfältig lesen.
Weitere Informationen sind im BEDIENUNGSHANDBUCH, in der INSTALLATIONSANLEITUNG usw. enthalten.
Warnung:
• SorgfältigdieaufderHauptanlageaufgebrachtenAufschriftenlesen.
• BittenSieIhrenFachhändlerodereinengeprüftenFachtechniker,dieInstal-
lation,UmpositionierungundReparaturderAnlagevorzunehmen.
• DerNutzersolltekeinesfallsversuchen,dieAnlageselbstzureparierenoder
aneineandereStellezutransferieren.
•
FolgenSiebeiderInstallationundUmpositionierungdenAnweisungenin
derInstallationsanleitungundverwendenSieWerkzeugeundRohrleitungs-
komponenten,dieausdrücklichfürdenEinsatzmitdemKältemittelausgelegt
sind,dasinderInstallationsanleitungdesAußengerätsangegebenist.
• DieAnlagemußentsprechenddenAnweisungeninstalliertwerden,um
dieGefahrvonSchädeninFolgevonErdbeben,Stürmenoderstarkem
Windeinußzuminimieren.EinefalschinstallierteAnlagekannherabfallen
unddabeiVerletzungenoderSachschädenverursachen.
• VerändernSiedieAnlagenicht.DieskönnteeinenBrand,einenelektri-
schenSchlag,VerletzungenoderWasserleckagenverursachen.
• DieAnlagemußsicheraneinemBauteilinstalliertwerden,dasdasGewicht
derAnlagetragenkann.
• DasGerätmussineinemgutbelüftetenBereichaufbewahrtwerden,des-
senRaumgrößederfürdenBetriebvorgegebenenRaumächeentspricht.
• WenndieKlimaanlageineinemkleinenodergeschlossenenRaum
installiertwird,müssenMaßnahmenergri󰀨enwerden,damitimFall
einesKältemittelaustrittsdieKältemittelkonzentrationindemRaumden
Sicherheitsgrenzwertnichtüberschreitet.SollteKältemittelaustretenund
derGrenzwertderKältemittelkonzentrationüberschrittenwerden,können
durchdenSauersto󰀨mangelimRaumGefahrenentstehen.
• HaltenSieGasbrenner,elektrischeHeizungenundandereFeuerquellen
(Zündquellen)vondemOrtfern,andemInstallations-,Reparatur-oder
sonstigeArbeitenanderKlimaanlagedurchgeführtwerden.
WenndasKältemittelmiteinerFlammeinKontaktkommt,werdengiftige
Gasefreigesetzt.
• LüftenSiedenRaum,wennbeiBetriebKältemittelaustritt.WennKälte-
mittelmiteinerFlammeinBerührungkommt,werdendabeigiftigeGase
freigesetzt.
• AlleElektroarbeitenmüssenentsprechenddenörtlichenVorschriftenund
denAnweisungenindieserAnleitungvonqualiziertenFachelektrikern
ausgeführtwerden.
• FürdieelektrischenLeitungenkeineZwischenverbindungenverwenden.
•
VerwendenSiezurVerdrahtungnurdieangegebenenKabel.DieAnschlüsse
müssenfestundsicherohneZugbelastungaufdenKlemmenvorgenom-
menwerden.SpleißenSieaußerdemniemalsdieKabelfürdieVerdrahtung
(außereswirdindiesemDokumententsprechendangegeben).Wenndie
Kabelfalschangeschlossenoderinstalliertsind,kanndiesÜberhitzung
odereinenBrandzurFolgehaben.
• VerwendenSienachderInstallation,demUmsetzenoderWartenderKlima-
anlagenurdasaufdemAußengerätangegebeneKältemittelzumFüllender
Kältemittelleitungen.VermischenSieesnichtmitanderemKältemittelund
lassenSienichtzu,dassLuftindenLeitungenzurückbleibt.
 WennsichLuftmitdemKältemittelvermischt,kanndieszueinemunge-
wöhnlichhohenDruckinderKältemittelleitungführenundeineExplosion
oderandereGefahrenverursachen.
 DieVerwendungeinesanderenalsdesfürdasSystemangegebenenKälte-
mittelsführtzumechanischemVersagen,einerFehlfunktiondesSystems
odereinerBeschädigungdesGeräts.ImschlimmstenFallkannsieein
schwerwiegendesHindernisfürdieAufrechterhaltungderProduktsicher-
heitdarstellen.
• DasGerätmussentsprechenddenörtlichenVorschriftenzurVerkabelung
eingebautwerden.
• DiesesGerätdarfvonPersonen(einschließlichKindern)miteingeschränk-
tenphysischen,sensorischenodermentalenFähigkeiten,bzw.ohneaus-
reichendeErfahrungundWissen,erstnachEinweisungundAnleitungzum
GebrauchdesGerätsdurcheinefürihreSicherheitverantwortlichePerson
verwendetwerden.
• Kindersolltenbeaufsichtigtwerden,umsicherzustellen,dasssienichtan
derKlimaanlageherumspielen.
• DieKlemmleistenabdeckungderAnlagemussordnungsgemässange-
brachtsein.
• WenndasNetzkabelbeschädigtist,musservomHersteller,dementspre-
chendenKundendienstmitarbeiterodereinerähnlichqualiziertenPerson
ersetztwerden,umGefahrensituationenzuvermeiden.
•
VerwendenSienurvonMitsubishiElectriczugelassenesZubehör,undlassen
SiediesesdurchIhrenFachhändlerodereineVertragswerkstatteinbauen.
• PrüfenSiedieAnlagenachAbschlußderInstallationaufKältemittelaustritt.
WennKältemittelindenRaumgelangtundmitderFlammeeinerHeizungoder
einesGasherdsinBerührungkommt,werdendabeigiftigeGasefreigesetzt.
• VerwendenSiekeineanderenalsvomHerstellerempfohlenenMittel,um
dasAbtauenzubeschleunigenoderdasGerätzureinigen.
• DasGerätmussineinemRaumohnekontinuierlichbetriebeneZündquel-
len(zumBeispiel:o󰀨enesFeuer,eininBetriebbendlichesGasgerätoder
eineinBetriebbendlicheElektroheizung)aufbewahrtwerden.
• Nichtdurchstechenoderverbrennen.
• BedenkenSie,dassKältemittelgeruchslosseinkönnen.
• RohrleitungenmüssenvorphysischenBeschädigungengeschütztwerden.
• DieInstallationvonRohrleitungenmussaufeinMindestmaßbeschränkt
werden.
• DieEinhaltungnationalerGasverordnungenmusssichergestelltwerden.
• HaltenSiealleerforderlichenLüftungsö󰀨nungenstetsfrei.
• VerwendenSiebeimLötenderKältemittelleitungenkeineNiedrigtempera-
tur-Lötlegierung.
• BeiLötarbeitenmussderRaumausreichendbelüftetwerden.
 AchtenSiedarauf,dasssichkeinegefährlichenoderentzündlichenMateri-
alieninderNähebenden.
VergewissernSiesichvordemArbeitenineinemgeschlossenenoderkleinen
RaumoderanähnlichenÖrtlichkeiten,dassnirgendwoKältemittelaustritt.
 AustretendesKältemittel,dassichansammelt,kannsichentzündenoder
giftigeGasefreisetzen.
Hinweis:
DerTeil“VerdrahteteFernbedienung”indiesemInstallationshandbuchbeziehtsichaufdiePAR-41MAA.WennSieInformationenzuranderenFernbedie-
nungbenötigen,sehenSieimInstallationshandbuchderoptionalenFernbedienungnach.
de

(mm)
W
Abb.2-1
Min. 300
Max. 250
Min. 270
Min. 500
Min. 2200
2
2. Aufstellort
1.2. VorInstallationoderTransport
Vorsicht:
• LassenSiebeimTransportderAnlagenbesondereVorsichtwalten.ZumTrans-
portderAnlagesindmindestenszweiPersonennötig,dadieAnlage20kgoder
mehrwiegt.TragenSiedieAnlagenichtandenVerpackungsbändern.TragenSie
Schutzhandschuhe,umVerletzungenderHändedurchdieKühlrippenoderandere
Teilezuvermeiden.
• SorgenSie füreineordnungsgemäße Entsorgung der Verpackungsmaterialien.
Verpackungsmaterialien wie Nägel sowie andere metallene oder hölzerne Teile
könnenVerletzungenverursachen.
•
UmKondenswasserbildungzuverhindern,mussdieKühlmittelleitungisoliertwerden.
WenndieKühlmittelleitungnichtkorrektisoliertist,bildetsichKondenswasser.
1.1. VorderInstallation(Umgebung)
Vorsicht:
• SetzenSiedieAnlagenichtinunüblichemUmfeldein.WenndieKlimaanlagein
Bereicheninstalliert ist,in denen sieRauch, austretendem Öl(einschliesslich
Maschinenöl)oderSchwefeldämpfenausgesetztist,oderinGegendenmithohem
Salzgehalt,etwaamMeer,kanndieszuerheblichenLeistungsbeeinträchtigungen
undSchädenandenGeräteteilenimInnerenderAnlagezurFolgehaben.
• InstallierenSiedieAnlagenichtinBereichen,indenenentzündlicheGaseaus-
treten,hergestelltwerden,ausströmenodersichansammelnkönnen.Wennsich
entzündlicheGaseimBereichderAnlageansammeln,kanndieszueinemBrand
odereinerExplosionführen.
• AchtenSie darauf,daß sich wederNahrungsmittel, Panzen,Kägtiere,Kunst-
gegenständenochPräzisionsinstrumenteimdirektenLuftstromderInnenanlage
oderzunahederAnlagebenden,dadiesedurchTemperaturschwankungenoder
tropfendesWasserbeschädigtwerdenkönnen.
• WenndieLuftfeuchtigkeitimRaum80%überschreitetoderwenndieAblaßleitung
verstopftist,kannWasservonderInnenanlagetropfen.InstallierenSiedieInnen-
anlagenichtanStellen,andenentropfendesWasserSchädenverursachenkann.
• BeiderInstallationderAnlageinKrankenhäusernoderKommunikationseinrich-
tungen müssen Sie mit Lärmbelastung und elektronischen Störungen rechnen.
Inverter,Haushaltsgeräte,medizinischeHochfrequenzapparateundTelekommu-
nikationseinrichtungenkönnenFehlfunktionenoderdenAusfallderKlimaanlage
verursachen.DieKlimaanlagekannauchmedizinischeGeräteinMitleidenschaft
ziehen,die medizinischeVersorgung und Kommunikationseinrichtungendurch
BeeinträchtigungderBildschirmdarstellungstören.
• BringenSieThermoisolierungenandenRohrenan,umKondenswasserbildungzu
verhindern.WenndieAbußleitungnichtordnungsgemäßinstalliertist,können
WasseraustrittundBeschädigungenvonDecke,Fußboden,Möbelnoderanderen
GegenständendieFolgesein.
• DieKlimaanlagedarfnichtmitWassergereinigtwerden.DabeikanneszuStrom-
schlägenkommen.
• AlleKonusmuttern müssenmiteinem Drehmomentschlüssel entsprechend der
technischenAnweisungenangezogenwerden.WenndieMutternzufestangezogen
werden,bestehtdieGefahr,dasssienacheinergewissenZeitbrechen.
1.3. VordenElektroarbeiten
Vorsicht:
• InstallierenSieaufjedenFallLeistungsschalter.AndernfallsbestehtdieGefahr
vonStromschlägen.
•
VerwendenSiefürdieNetzleitungenhandelsüblicheKabelmitausreichenderKapazität.
AndernfallsbestehtdieGefahrvonKurzschlüssen,ÜberhitzungodereinesBrandes.
• AchtenSiebeiderInstallationderNetzleitungendarauf,daßkeineZugspannung
fürdieKabelentsteht.
• DieAnlagemußgeerdetwerden.WenndieAnlagenichtordnungsgemäßgeerdet
ist,bestehtdieGefahrvonStromschlägen.
• Verwenden Sie Leistungsschalter (Erdschlußunterbrecher, Trennschalter (+B-
Sicherung)undgußgekapselteLeistungsschalter)mitderangegebenenKapazität.
WenndieLeistungsschalterkapazitätgrößeristalsvorgeschrieben,kanndieseinen
AusfallderKlimaanlageodereinenBrandzurFolgehaben.
1.4. VordemTestlauf
Vorsicht:
• SchaltenSiedenNetzschaltermehrals12 Stunden vorBetriebsbeginnein.Ein
BetriebsbeginnunmittelbarnachEinschaltendesNetzschalterskannzuschwer-
wiegendenSchädenderInnenteileführen.
• PrüfenSievorBetriebsbeginn,oballePlatten,SicherungenundweitereSchutz-
vorrichtungenordnungsgemäßinstalliertsind.Rotierende,heißeoderunterHoch-
spannungstehendeBauteilekönnenVerletzungenverursachen.
• BetreibenSiedieKlimaanlagenichtohneeingesetztenLuftlter.WennderLuftlter
nichtinstalliertist,bestehtdieGefahr,daßsichSchmutzansammeltunddieAnlage
dadurchausfällt.
• BerührenSieSchalternichtmitnassenHänden.DadurchbestehtdieGefahreines
Stromschlags.
• BerührenSiedieKältemittelrohrewährenddesBetriebsnichtmitbloßenHänden.
• NachBeendigung desBetriebs müssen mindestensfünf Minuten verstreichen,
eheder Hauptschalterausgeschaltetwird. Andernfallsbestehtdie Gefahrvon
WasseraustrittoderAusfallderAnlage.
1. Sicherheitsvorkehrungen
2.1. Außenabmessungen(Innenanlage)(Abb.2-1)
Wählen Sie einen geeigneten Aufstellort mit nachstehenden Freiräumen für Aufstel-
lung und Wartung.
(mm)
Modelle W
M35, 50 960
M60, 71 1280
M100, 125, 140 1600
Warnung:
DieInnenanlageaneinerDeckemontieren,diestarkgenugist,umdasGewicht
derAnlagezutragen.
2.2. Außenmaße(Außenanlage)
Siehe Aussenanlagen-Installationsanleitung.
de
