Mitsubishi Electric Y Series User manual

CM20AN-E-NZ
VRF City Multi Product Catalogue

Founded in 1921, Mitsubishi Electric is a globally-renowned household name with a
solid reputation for excellent products and services. Since our foundation, we have
risen to the very pinnacle of the air conditioning industry and we continue to maintain
that position.
The company is proud of its achievements in providing some of the most
energy-efficient systems on the market.
Unparalleled
Mitsubishi Electric
Air Conditioning Systems
Outdoor/Heat Source Units ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.6
BC Controllers ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.101
Indoor Units ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.112
Technologies and functions ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.162
Ventilation Systems∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.181
Remote Controller ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.190
Hot Water Solution/Air to Water Series ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.214
Installation Information∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.236
Maintenance Equipment ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.246
Contents
VRF
2

Founded in 1921, Mitsubishi Electric is a globally-renowned household name with a
solid reputation for excellent products and services. Since our foundation, we have
risen to the very pinnacle of the air conditioning industry and we continue to maintain
that position.
The company is proud of its achievements in providing some of the most
energy-efficient systems on the market.
Unparalleled
Mitsubishi Electric
Air Conditioning Systems
Outdoor/Heat Source Units ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.6
BC Controllers ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.101
Indoor Units ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.112
Technologies and functions ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.162
Ventilation Systems∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.181
Remote Controller ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.190
Hot Water Solution/Air to Water Series ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.214
Installation Information∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.236
Maintenance Equipment ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.246
Contents
VRF
Founded in 1921, Mitsubishi Electric is a globally-renowned household name with a
solid reputation for excellent products and services. Since our foundation, we have
risen to the very pinnacle of the air conditioning industry and we continue to maintain
that position.
The company is proud of its achievements in providing some of the most
energy-efficient systems on the market.
Unparalleled
Mitsubishi Electric
Air Conditioning Systems Outdoor/Heat Source Units ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.6
BC Controllers ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.101
Indoor Units ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.112
Technologies and functions ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.162
Ventilation Systems∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.181
Remote Controller ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.190
Hot Water Solution/Air to Water Series ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.214
Installation Information∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.236
Maintenance Equipment ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.246
Contents
VRF
3

Air cooled
Water cooled
Y-Series WY-Series
Cooling or Heating
*CITY MULTI R2/WR2-Series systems require the use of
a BC controller.
S-Series
Standard 1-fan type 2-fan typeHigh efficiency
PUHY- PPQHY- P
PUMY-
SP
PUMY- P
OUTDOOR/HEAT SOURCE UNITS/BC CONTROLLER
CMB- /
M P
Ceiling cassette type
INDOOR UNITS
VENTILATION Air to Water Series
Ceiling concealed type
Air cooled
Water cooled
WR2-Series
Simultaneous Cooling and Heating
PLFY- P
BC CONTROLLER
Standard High efficiency
PQRY- P
Individual Remote Controllers Centralized Remote Controllers
REMOTE CONTROLLERS
R2-Series
PURY- P
PUHY-
EP
PUHY-
HP
PURY-
EP
Main BC controller
Main BC controller with sub BC controller
Sub BC controller
Wired Remote Controller
Wireless Remote Controller
4-way airflow type
2-way ariflow type
PFFY- P
Exposed type
Concealed type
PEFY- P
Low noise type
Compact depth type
Low static pressure type
Medium static pressure type
High static pressure type
Fresh air intake type
PMFY- P
1-way ariflow type
Ceiling suspended type Wall-mounted type
Floor standing type
PCFY- PPKFY- P
LGH/GUF-Series PWFY-Series
Advanced Touch Controller
ON/OFF Remote Controller
AHC adapter
PI/DIDO/AI controller
LONWORKS®interface
BACnet®interface
P.91 P.68P.11
P.69P.12 P.101
P.182
Air Handling Unit Controller P.189
P.215 QAHV-Series P.226 CAHV-Series P.229
P.115 P.126 P.129
P.148
P.194
P.155
P.151
P.200
SELECTION
SELECTION
4

Air cooled
Water cooled
Y-Series WY-Series
Cooling or Heating
*CITY MULTI R2/WR2-Series systems require the use of
a BC controller.
S-Series
Standard 1-fan type 2-fan typeHigh efficiency
PUHY- PPQHY- P
PUMY-
SP
PUMY- P
OUTDOOR/HEAT SOURCE UNITS/BC CONTROLLER
CMB- /
M P
Ceiling cassette type
INDOOR UNITS
VENTILATION Air to Water Series
Ceiling concealed type
Air cooled
Water cooled
WR2-Series
Simultaneous Cooling and Heating
PLFY- P
BC CONTROLLER
Standard High efficiency
PQRY- P
Individual Remote Controllers Centralized Remote Controllers
REMOTE CONTROLLERS
R2-Series
PURY- P
PUHY-
EP
PUHY-
HP
PURY-
EP
Main BC controller
Main BC controller with sub BC controller
Sub BC controller
Wired Remote Controller
Wireless Remote Controller
4-way airflow type
2-way ariflow type
PFFY- P
Exposed type
Concealed type
PEFY- P
Low noise type
Compact depth type
Low static pressure type
Medium static pressure type
High static pressure type
Fresh air intake type
PMFY- P
1-way ariflow type
Ceiling suspended type Wall-mounted type
Floor standing type
PCFY- PPKFY- P
LGH/GUF-Series PWFY-Series
Advanced Touch Controller
ON/OFF Remote Controller
AHC adapter
PI/DIDO/AI controller
LONWORKS®interface
BACnet®interface
P.91 P.68P.11
P.69P.12 P.101
P.182
Air Handling Unit Controller P.189
P.215 QAHV-Series P.226 CAHV-Series P.229
P.115 P.126 P.129
P.148
P.194
P.155
P.151
P.200
SELECTION
SELECTION
5

Mitsubishi Electric offers a wide range of products in order to meet air-conditioning needs
for both new constructions and existing buildings.
Mitsubishi Electric offers a wide range of products in order to meet air-conditioning needs
Outdoor/Heat Source Units
VRF
6

SERIES INTRODUCTION
Air-Cooled Units
(Cooling/Heating Changeover, Simultaneous Cooling/Heating)
Cooling or Heating
Air cooledAir cooled
P.11
Heat pump
• A two-pipe refrigerant system allows for a system
changeover from cooling to heating, and ensures that a
constant indoor climate is maintained in all zones
• Wide range of standard and high-efficiency models up to
54HP
Horizontal Airflow Units
Water-Cooled Units
(Cooling/Heating Changeover, Simultaneous Cooling/Heating)
*Data as of 1992, researched by Mitsubishi Electric Corporation
*Color of the external finish depends on the production location.
Please refer to the specification for details on the external finish.
Water cooled
Heat pump
Cooling or Heating
• Allows heat source units to be installed on separate floors,
making it suitable for use in high-rise buildings
• Installation of heat source units in machine rooms helps
maintain the exterior appearance of the building
Heat recovery
Y-Series
WY-Series
Simultaneous Cooling and Heating
P.69
• Simultaneous cooling and heating operation with a
two-pipe system available only from Mitsubishi Electric*
• Greater energy efficiency made possible by using the
waste heat from both the heat source units and indoor
units
Heat recovery
Simultaneous Cooling and Heating
P.12
• Simultaneous cooling and heating operation with a
two-pipe system available only from Mitsubishi Electric*
• Energy-efficient with heat recovery feature
*Data as of 1992, researched by Mitsubishi Electric Corporation
R2-Series
WR2-Series
P.91
Cooling or Heating
Heat pump • Compact design that allows individual air conditioning in
small-scale buildings and stores
S-Series
P.68
Standard: 8-54HP
8-36HP
1-fan type: 3.5-6HP
2-fan type:
4.5-8HP
8-36HP
High efficiency: 8-54HP Standard: 8-44HP High efficiency: 8-44HP
7
VRF
Lineup
VRF
Y-Series
VRF
R2-Series
VRF
Zubadan
VRF
WY-Series
VRF
WR2-Series
VRF
S-Series
VRF
Indoor Units
Ventilation
Systems
Technologies
and Functions
Remote
Controller
Hot Water
Solution
VRF
BC Controllers

System Air cooled
Type Heat pump
Model name
Y-Series Standard Y-Series High efficiency
PUHY-P YNW-A1(-BS) PUHY-P YSNW-A1(-BS) PUHY-EP YNW-A1(-BS) PUHY-EP YSNW-A1(-BS)
Model
size S size L size XL size S size L size XL
modules
HP S L XL S L XL S L XL S L XL
8HP P200 8 8
10HP P250 10 10
12HP P300 12 12
14HP P350 14 14
16HP P400 16 8 8 16 8 8
18HP P450 18 8 10 18 8 10
20HP P500 20 10 10 20 10 10
22HP P550 10 12 10 12
24HP P600 12 12 12 12
26HP P650 10 16 10 16
28HP P700 14 14 14 14
30HP P750 14 16 14 16
32HP P800 14 18 14 18
34HP P850 16 18 16 18
36HP P900 18 18 18 18
38HP P950 10 14 14 10 14 14
40HP P1000 10 14 16 10 14 16
42HP P1050 10 16 16 10 16 16
44HP P1100 14 14 16 14 14 16
46HP P1150 14 16 16 14 16 16
48HP P1200 16 16 16 16 16 16
50HP P1250 16 16 18 16 16 18
52HP P1300 16 18 18 16 18 18
54HP P1350 18 18 18 18 18 18
* Indicates single modules and indicates combination modules.
*The circled numbers in the table indicate the horse power, and the combination of S, L, and XL modules.
*For combination modules, be sure to check the complete module’s model name including the last part of the model name (e.g.: -A1).
Please refer to the “Set Model” rows in the “SPECIFICATIONS”.
8LINEUP

System Air cooled
Type Heat recovery
Model name
R2-Series Standard R2-Series High efficiency
PURY-P YNW-A1(-BS) PURY-P YSNW-A1(-BS) PURY-EP YNW-A1(-BS) PURY-EP YSNW-A1(-BS)
Model
size S size L size XL size S size L size XL
modules
HP S L XL S L XL S L XL S L XL
8HP P200 8 8
10HP P250 10 10
12HP P300 12 12
14HP P350 14 14
16HP P400 16 8 8 16 8 8
18HP P450 18 8 10 18 8 10
20HP P500 20 10 10 20 10 10
22HP P550 10 12 10 12
24HP P600 12 12 12 12
26HP P650 12 14 12 14
28HP P700 14 14 14 14
30HP P750 14 16 14 16
32HP P800 16 16 16 16
34HP P850 16 18 16 18
36HP P900 18 18 18 18
38HP P950 18 20 18 20
40HP P1000 20 20 20 20
42HP P1050 20 22 20 22
44HP P1100 22 22 22 22
* Indicates single modules and indicates combination modules.
*The circled numbers in the table indicate the horse power, and the combination of S, L, and XL modules.
*Color of the external  nish depends on the production location. Please refer to the speci cation for details on the external  nish.
*1. 22HP (P550) can be used only in combination with others.
*For combination modules, be sure to check the complete module’s model name including the last part of the model name (e.g.: -A1).
Please refer to the “Set Model” rows in the “SPECIFICATIONS”.
*1 *1
*1 *1 *1 *1
9
LINEUP
VRF
Lineup
VRF
Y-Series
VRF
R2-Series
VRF
Zubadan
VRF
WY-Series
VRF
WR2-Series
VRF
S-Series
VRF
Indoor Units
Ventilation
Systems
Technologies
and Functions
Remote
Controller
Hot Water
Solution
VRF
BC Controllers

System Water cooled Air cooled
Type Heat pump Heat recovery Heat pump
Model name
WY-Series WR2-Series S-Series
1-fan type
S-Series
2-fan type
PQHY-P YLM-A1 PQHY-P YSLM-A1 PQRY-P YLM-A1 PQRY-P YSLM-A1
PUMY-SP VKMD-A(-BS)
PUMY-SP YKMD-A(-BS)
PUMY-P VKM 5(-BS)
PUMY-P YKM4(-BS)
PUMY-P YKMD-A(-BS)
Model
modules
HP S L S L S L S L - -
3.5HP P80 3.5
4.5HP P112 4.5 4.5
5HP P125 5 5
6HP P140 6 6
8HP P200 8 8 8
10HP P250 10 10
12HP P300 12 12
14HP P350 14 14
16HP P400 16 8 8 16 8 8
18HP P450 18 8 10 18 8 10
20HP P500 20 10 10 20 10 10
22HP P550 22 10 12 22 10 12
24HP P600 24 12 12 24 12 12
28HP P700 14 14 14 14
30HP P750 14 16 14 16
32HP P800 16 16 16 16
34HP P850 16 18 16 18
36HP P900 18 18 18 18
* Indicates single modules and indicates combination modules.
*The circled numbers in the table indicate the horse power, and the combination of S, L, and XL modules.
*For combination modules, be sure to check the complete module’s model name including the last part of the model name (e.g.: -A1).
Please refer to the “Set Model” rows in the “SPECIFICATIONS”.
10 LINEUP

Y-Series
A two-pipe zoned system designed for
heat pump operation
Header
Joint
Outdoor unit
*1 90m [295ft] is available. When the piping length exceeds 40m [131ft], use one size larger liquid pipe starting
with the section of piping where 40m [131ft] is exceeded and all piping after that point.
*2 90m [295ft] is available depending on the model and installation conditions. For more detailed information, contact your local distributor.
*3 60m [196ft] is available depending on the model and installation conditions. For more detailed information, contact your local distributor.
*4 30m [98ft] is available. If the height difference between indoor units exceeds 15m [49ft] (but does not exceed 30m [98ft] ), use one size larger pipes for indoor unit liquid pipes.
*5 When the outdoor unit is installed below the indoor unit, top-bottom differential is 40m [131ft].
Outdoor unit
Indoor unit
Between indoor units
top-bottom differential
15m [49ft] *4
Between indoor units
top-bottom differential
15m [49ft] *4
Furthest piping length
190m [623ft]
(equivalent length)
(actual length 165m [541ft])
Furthest piping length
190m [623ft]
(equivalent length)
(actual length 165m [541ft])
Top-bottom
differential
50m [164ft]
*2 *3 *5
Top-bottom
differential
50m [164ft]
*2 *3 *5
• Installation image (Y-Series)
• System Pipe Lengths [(E)P200–(E)P1350]
Refrigerant Piping Lengths
Total length
Maximum allowable length
Furthest indoor from first branch
Vertical differentials between units
Indoor/outdoor (outdoor higher)
Indoor/outdoor (outdoor lower)
Indoor/indoor
Maximum meters [Feet]
1,000 [3,280]
165 (190 equivalent)
[541(623)]
40 [131]*1
Maximum meters [Feet]
50 [164]*2
40 [131]*3
15 [49]*4
*This image shows the standard type.
Cooling or Heating Heat pump
Standard
High eciency
• Features∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙P.14 - P.16
• Specifications
• Optional parts∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙P.41
• Technologies and functions∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙P.162
PUHY-P Y(S)NW-A1(-BS)∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙P.17 - P.28
PUHY-EP Y(S)NW-A1(-BS) ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙P.29 - P.40
The CITY MULTI Y-Series (for large applications) makes use of a two-pipe refrigerant system, which allows for system
changeover from cooling to heating, ensuring that a constant indoor climate is maintained in all zones. The compact
outdoor unit utilizes an inverter-driven compressor for effective energy use.
With a wide lineup of indoor units connected to a flexible piping system, the CITY MULTI Series can be configured to suit
diverse applications. Up to 50 (Y-Series) indoor units can be connected with up to 130% connected capacity to maximize
engineering design options. This feature allows easy air conditioning in each area with convenient individual controllers.
*For details of the installation restrictions, refer to the
DATABOOK.
EPEP
11
VRF
Lineup
VRF
R2-Series
VRF
Zubadan
VRF
WY-Series
VRF
WR2-Series
VRF
S-Series
VRF
Indoor Units
Ventilation
Systems
Technologies
and Functions
Remote
Controller
Hot Water
Solution
VRF
BC Controllers
VRF
S-Series
VRF
Y-Series

R2-Series
*R2-Series systems require
the use of a BC controller.
Office area
Office compartment
Office area
Office area
Meeting room
BC controller
Refrigerant piping:
2-pipe type
Meeting room
Cooling
Cooling
Cooling
Heating
Heating
Heating
Outdoor
unit
*As of 1992 (according to our in-house survey)
BC controller (required)*
*1 When you install a sub-BC controller, please refer to DATABOOK for full details.
*2 When the outdoor unit is installed below the indoor unit, top-bottom differential is 40m [131ft].
*3 Depending on the model and installation conditions, top-bottom differential 90m [295ft] (o/u above) and 60m [196ft] (o/u below) is available. For more detailed information,
please contact your nearest sales office or distributor.
*4 Distance of Indoor sized P200, P250 from BC must be less than 10m [32ft], if any.
*5 Distance of Indoor sized P200, P250 from BC must be less than 20m [65ft], if any.
• System example
• System Pipe Lengths [(E)P200–(E)P1100]
Simultaneous Cooling and Heating
Standard
High eciency
• Features∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙P.13 - P.16
• Specifications
• Optional parts∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙P.62
• BC controllers∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.101 - P.111
• Technologies and functions∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙P.162
PURY-P Y(S)NW-A1(-BS)∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙P.42 - P.51
PURY-EP Y(S)NW-A1(-BS) ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙P.52 - P.61
Heat recovery
Outdoor unit
Between indoor unit and
BC controller top-
bottom differential 15m [49ft] *4
Between indoor unit and
BC controller top-
bottom differential 15m [49ft] *4
Between indoor unit
and BC controller
top-bottom differential 15m [49ft] *4
Between indoor unit
and BC controller
top-bottom differential 15m [49ft] *4
Furthest piping length
190m [623ft]
(equivalent length)
(actual length 165m [541ft])
Furthest piping length
190m [623ft]
(equivalent length)
(actual length 165m [541ft])
Top-bottom
differential
50m [164ft]
*2 *3
Top-bottom
differential
50m [164ft]
*2 *3
Between indoor units
top-bottom
differential 30m [98ft] *5
Between indoor units
top-bottom
differential 30m [98ft] *5
BC controllerBC controller
Indoor unit
Indoor unit
The world’s first* two-pipe system that
simultaneously cools and heats
The CITY MULTI R2-Series offers the ultimate in freedom and flexibility. Cool one zone while heating another. Our
exclusive BC controller makes two-pipe simultaneous cooling and heating possible. It is the technological heart of the
CITY MULTI R2-Series. It houses a liquid and gas separator, allowing the outdoor unit to deliver a mixture of hot gas for
heating and liquid for cooling, all through the same pipe.
This innovation results in virtually no energy wasted by being expelled outdoors. Depending on capacity, up to 50 indoor
units can be connected with up to 150% connected capacity.
• Installation image (R2-Series)
Refrigerant Piping Lengths
Total piping length
(E)P200–(E)P300
(E)P350–(E)P550 (single module)
(E)P400–(E)P600
(E)P650
(E)P700–(E)P1100
Maximum allowable length
Maximum length between outdoor
and single/main BC controller
Maximum length between single/main
BC controller and indoor
and sub-BC controller*1
Vertical differentials between units
Indoor/outdoor (outdoor higher)
Indoor/outdoor (outdoor lower)
Indoor/BC controller (single/main)
Indoor/indoor
Main BC Controller/Sub-BC Controller
Maximum meters [Feet]
550 [1,804]
600 [1,968]
750 [2,460]
800 [2,624]
1,000 [3,280]
165 (190 equivalent)
[541(623)]
110 [360]
40-90 [131-295]
Maximum meters [Feet]
50 [164]*3
40 [131]*3
15 [49]*4
30 [98]*5
15 [49]
*Maximum length between single/main BC controller and
indoor is dependent upon the vertical differential between
the single/main BC controller and the indoor unit.
*Maximum total length is dependent upon the distance between
the outdoor unit and the single/main BC Controller.
*This image shows the standard type.
*For details of the installation restrictions, refer to the DATABOOK.
EP
12

R2-Series
*R2-Series systems require
the use of a BC controller.
Office area
Office compartment
Office area
Office area
Meeting room
BC controller
Refrigerant piping:
2-pipe type
Meeting room
Cooling
Cooling
Cooling
Heating
Heating
Heating
Outdoor
unit
*As of 1992 (according to our in-house survey)
BC controller (required)*
*1 When you install a sub-BC controller, please refer to DATABOOK for full details.
*2 When the outdoor unit is installed below the indoor unit, top-bottom differential is 40m [131ft].
*3 Depending on the model and installation conditions, top-bottom differential 90m [295ft] (o/u above) and 60m [196ft] (o/u below) is available. For more detailed information,
please contact your nearest sales office or distributor.
*4 Distance of Indoor sized P200, P250 from BC must be less than 10m [32ft], if any.
*5 Distance of Indoor sized P200, P250 from BC must be less than 20m [65ft], if any.
• System example
• System Pipe Lengths [(E)P200–(E)P1100]
Simultaneous Cooling and Heating
Standard
High eciency
• Features∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙P.13 - P.16
• Specifications
• Optional parts∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙P.62
• BC controllers∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ P.101 - P.111
• Technologies and functions∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙P.162
PURY-P Y(S)NW-A1(-BS)∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙P.42 - P.51
PURY-EP Y(S)NW-A1(-BS) ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙P.52 - P.61
Heat recovery
Outdoor unit
Between indoor unit and
BC controller top-
bottom differential 15m [49ft] *4
Between indoor unit and
BC controller top-
bottom differential 15m [49ft] *4
Between indoor unit
and BC controller
top-bottom differential 15m [49ft] *4
Between indoor unit
and BC controller
top-bottom differential 15m [49ft] *4
Furthest piping length
190m [623ft]
(equivalent length)
(actual length 165m [541ft])
Furthest piping length
190m [623ft]
(equivalent length)
(actual length 165m [541ft])
Top-bottom
differential
50m [164ft]
*2 *3
Top-bottom
differential
50m [164ft]
*2 *3
Between indoor units
top-bottom
differential 30m [98ft] *5
Between indoor units
top-bottom
differential 30m [98ft] *5
BC controllerBC controller
Indoor unit
Indoor unit
The world’s first* two-pipe system that
simultaneously cools and heats
The CITY MULTI R2-Series offers the ultimate in freedom and flexibility. Cool one zone while heating another. Our
exclusive BC controller makes two-pipe simultaneous cooling and heating possible. It is the technological heart of the
CITY MULTI R2-Series. It houses a liquid and gas separator, allowing the outdoor unit to deliver a mixture of hot gas for
heating and liquid for cooling, all through the same pipe.
This innovation results in virtually no energy wasted by being expelled outdoors. Depending on capacity, up to 50 indoor
units can be connected with up to 150% connected capacity.
• Installation image (R2-Series)
Refrigerant Piping Lengths
Total piping length
(E)P200–(E)P300
(E)P350–(E)P550 (single module)
(E)P400–(E)P600
(E)P650
(E)P700–(E)P1100
Maximum allowable length
Maximum length between outdoor
and single/main BC controller
Maximum length between single/main
BC controller and indoor
and sub-BC controller*1
Vertical differentials between units
Indoor/outdoor (outdoor higher)
Indoor/outdoor (outdoor lower)
Indoor/BC controller (single/main)
Indoor/indoor
Main BC Controller/Sub-BC Controller
Maximum meters [Feet]
550 [1,804]
600 [1,968]
750 [2,460]
800 [2,624]
1,000 [3,280]
165 (190 equivalent)
[541(623)]
110 [360]
40-90 [131-295]
Maximum meters [Feet]
50 [164]*3
40 [131]*3
15 [49]*4
30 [98]*5
15 [49]
*Maximum length between single/main BC controller and
indoor is dependent upon the vertical differential between
the single/main BC controller and the indoor unit.
*Maximum total length is dependent upon the distance between
the outdoor unit and the single/main BC Controller.
*This image shows the standard type.
*For details of the installation restrictions, refer to the DATABOOK.
EP
COP of the heat recovery system
The more frequently cooling and heating are performed
simultaneously, the greater the energy saving effect.
Total
connections
20
CITY MULTI R2
Drastically
reduces the
amount of
piping
Outdoor unit
BC controller
Indoor
units
Total
connections
58
Outdoor unit
Solenoid
box
Indoor
units
Solenoid
box
Solenoid
box
Solenoid
box
0 20 40 60 80 100
Heating ratio (%)
Energy consumption
efficiency (COP)
Well-balanced cooling
and heating operation COP
UP
Cooling main mode Heating main mode
Outdoor unit
Heat
Exchanger
Heat
Exchanger
Outdoor unit
The direction of flow is
always constant.
The direction of flow is
always constant.
Comp.
Comp.
Low pressure
gas
High pressure
2-phase
Low pressure
2-phase
High pressure
gas
Cooling main mode Heating main mode
Outdoor unit
Heat
Exchanger
Comp.
Intermediate-
pressure liquid
The direction of flow is
reversed.
Outdoor unit
Heat
Exchanger
Comp.
Intermediate-
pressure liquid
Low pressure
gas
High pressure
gas
Low pressure
gas
High pressure
gas
• COP of the heat recovery system
• Compressor shuts down.
• All indoor units stop for a few minutes.
• There is no need to stop the compressor.
• The refrigerant noise that is generated when the
refrigerant flow is switched can be lowered.
When cooling/heating mode switches When cooling/heating mode switches
=Piping connections
=Piping connections
Unique to Mitsubishi Electric, our heat recovery technology uses just two pipes, as opposed to the market conventional
three. Our R2 system, designed for effective simultaneous heating and cooling, offers substantial savings on installation
and annual running costs.
Mitsubishi Electric 2-pipe R2 system:
less piping/connections compared to a 3-pipe system
Cooling/heating modes can be switched
without stopping operation
Heat recovery operation for greater energy savings
• Comparison example of piping connections
2 pipes
3 pipes
CITY MULTI R2
2 pipes Conventional 3 pipes
Benefits of the R2 system
13
VRF
Lineup
VRF
R2-Series
VRF
Zubadan
VRF
WY-Series
VRF
WR2-Series
VRF
S-Series
VRF
Indoor Units
Ventilation
Systems
Technologies
and Functions
Remote
Controller
Hot Water
Solution
VRF
BC Controllers
VRF
S-Series
VRF
Y-Series
FUNCTIONS

COP
EER
Compared to previous models, all the single modules (Y-series) in YNW-Series have improved EER and COP. For
example, EER of the 14HP model (PUHY-EP350YNW-A1) is higher by about 12%. All these models ensure high
energy saving.
EER COP
• Y-Series (High efficiency type)
• Y-Series (Standard type)
*In the low noise mode, the capacity will reduce.
Energy Saving
The low-noise mode, which conventionally only had one pattern, has been increased to four patterns. Including the
rated pattern, a mode can be selected from a total of five patterns. The low-noise mode has four patterns (85%,
70%, 60% and 50%) in respect to the fan speed. This can be set with the outdoor unit’s dip switch. The pattern can
be selected according to the customer’s requests when low-noise operation is required.
Flexible Noise Setting
R2-Series EP R2-Series P Y-Series EP Y-Series P
YNW-Series (Y/R2)
3.66 3.46 3.53 3.39
3.99 3.86 3.58 3.68 3.48 3.39 3.50
0.00
1.00
2.00
3.00
4.00
5.00
8HP 10HP 12HP 14HP 16HP 18HP 20HP
Previous model (PUHY-P YKB-A) New model (PUHY-P YNW-A1)
4.31 4.06 3.91
3.42 3.67 3.38
4.41 4.16 3.93 3.85 3.69 3.73 3.50
0.00
1.00
2.00
3.00
4.00
5.00
8HP 10HP 12HP 14HP 16HP 18HP 20HP
Previous model (PUHY-EP YLM-A1) New model (PUHY-EP YNW-A1)
4.36 4.10 4.09
3.59 3.80 3.48
4.67 4.49 4.27 3.92 3.83 3.73
4.20
0.00
1.00
2.00
3.00
4.00
5.00
8HP 10HP 12HP 14HP 16HP 18HP 20HP
Previous model (PUHY-EP YLM-A1) New model (PUHY-EP YNW-A1)
4.06 3.78 3.79 3.40
4.47 4.28 4.12 3.98 3.65 3.43
3.91
0.00
1.00
2.00
3.00
4.00
5.00
8HP 10HP 12HP 14HP 16HP 18HP 20HP
Previous model (PUHY-P YKB-A) New model (PUHY-P YNW-A1)
*Comparison under the nominal condition.
Energy Saving
Various key components have been equipped,
improving energy-saving performance and meeting
customers' requirements.
Flexible Noise Setting
All models in the series are equipped with low-noise
operating mode as a standard feature. Choose from five
different patterns for the optimum setting to meet the
low-noise requirements.
Design
The modern design blends in well with most
building architectures.
BC controller
Up to 11 sub-BC controllers can be connected to the main
BC controller.
The 4-face air induction structural design and core components,
such as compressor and fan, realizes energy-saving performance.
14

A height difference of up to 90m from the
outdoor unit to the indoor unit can be
supported with no extra-cost options.
This increases design flexibility and facilitates
installation of these units even in high-rise
buildings.
Height difference from outdoor unit to
indoor unit:
The system can be configured with a
height difference of up to 90m with
no extra-cost options.
* Whether the system can be configured with such a
height difference varies depending on the model.
* The maximum height difference is 60 m when the
outdoor unit is located lower than the indoor unit.
* Requires switch settings.
Usable in an application with a large vertical separation
of up to 90 meters
R2-Series EP R2-Series P Y-Series EP Y-Series P
Four-way suction and new fan
R2-Series EP R2-Series P Y-Series EP Y-Series P
Previous model (YLM)
The concave-shaped blade of the propeller fan enables air to flow along the outer circumference of the blade while reducing a
disturbance of air flow that occurs in the upstream and downstream of conventional propeller fans. This helps reduce power
consumption as well as minimises sound levels.
Furthermore, the change of the orientation of the fan blade from the outer circumference direction to the inner circumference
direction reduces air leakage from the outer circumference and sends more air to the upstream of the fan.
Visualization of air flow of fan
Large
Small
Previous three-sided coil design caused fan airflow
turbulence.
Visualization of air flow of fan
New four-sided coil design allows heat exchange without
causing a disturbance of air flow in all directions.
Fan and four-way
suction reduce
disturbance of air flow
Disturbance
• Air suction structure
• Fan structure
Latest model (YNW)
Previous model
(YLM)
Latest model
(YNW)
Air flow
Blade
Inner
circumference
Outer
circumference
Air flow
Large disturbance Small disturbance
Large disturbance Small disturbance
Key Components of YNW-Series
15
VRF
Y-Series
VRF
Lineup
VRF
R2-Series
VRF
Zubadan
VRF
WY-Series
VRF
WR2-Series
VRF
S-Series
VRF
Indoor Units
Ventilation
Systems
Technologies
and Functions
Remote
Controller
Hot Water
Solution
VRF
BC Controllers
YNW-Series (Y/R2)

Conventional model (YLM)
Latest model (YNW)
Crank angle (deg)
Discharge
pressure
Intake
pressure
Compression chamber (MPaG)
Multi-port
Conventional
Over-compression area can be
eliminated in this structure
The compressor, known as the heart of the air conditioner, has been improved. A centrifugal force canceling mechanism and
a multi-port mechanism have been developed. In addition, we have mounted a high-efficiency motor. The synergetic effect of
these latest technologies increases the compressor performance and efficiency, and also helps to improve the performance
of the outdoor unit.
The structure of the scroll compressor causes a centrifugal force during operation. Conventionally, that centrifugal force is applied onto the scroll section.
This causes refrigerant to leak, and restricts the increase in rotational speed to a maximum of 120rps.
With the latest compressor, the latest structure (centrifugal force canceling mechanism) has been mounted to suppress the centrifugal force. This mecha-
nism successfully suppresses the centrifugal force generated at the scroll section, reduces refrigerant leakage losses, and increases the compressor
efficiency. The maximum rotational speed has been increased from the conventional 120rps to 140rps.
This mechanism also speeds up the start of operation, and enables operations such as preheat defrost operation and the smooth auto-shift startup mode.
Compressor with centrifugal force canceling mechanism
Partial
load
Operation pattern
Rating, high
pressure
difference
Open
Open
Open
Sub-port
Main port Valve
Valve
Valve
Open
Closed
Closed
Partial
load
Operation pattern
Rating, high
pressure
difference
OpenMain port Valve Open
Conventional structure
Reduced over-compression loss (multi-port)
Multi-port structure
Fixed
scroll
Orbiting
scroll Discharge port
Valve
Fixed
scroll
Orbiting
scroll
Valve
Valve Valve
Discharge port Multi-port
Latest structure
Centrifugal force canceling mechanism (8 to 14HP)
The insulator section that traditionally created a
dead space is eliminated by insulating the motor’s
stator film. Since winding can be set in that
section, the winding area can be increased by
approx. 9%. The wire diameter has also been
increased by two ranks, so the resistance between
terminals is reduced, and the insulation distance
is shorter. This improves the motor’s operation
performance and contributes to high-efficiency
operation of the compressor.
Improved high-efficiency motor
Fixed scroll
Conventional mechanism
Orbiting scroll F
Slider
Vortex pressing load (F) is high.
Centrifugal force canceling mechanism
F
F’
Vortex pressing load (F-F’) is low.
Centrifugal force
cancelling slider
Spindle
Large loss Small loss
Latest structure
Centrifugal force
applied on scroll
section: Large
Refrigerants leakage
loss:
Large
Max. speed 120rps
Centrifugal force
applied on scroll
section: Small
Refrigerant leakage
loss:
Small
Max. speed 140rps
The sub-port is opened during partial load
operation to discharge the over-compressed gas.
Multi-port
When the target discharge pressure is
reached, the multiport opens, and the gas
refrigerant is discharged. This reduces drive
losses caused by over-compression.
Conventional model
Conventionally, gas refrigerant is compressed
to a set pressure, and then lowered to the
target discharge pressure at which it is
discharged. This causes drive losses from
over-compression.
The motor can be wound in the section where the
insulator was, and a larger wire diameter can be used.
The insulator section is large, and the
area where the copper wire can be wound
is small.
15
15
120
140
Rotational speed (rps)
Compressor efficiency
With canceling mechanism
Improved
compressor
efficiency
Max. speed 120rps 140rps contribute
to speedy compressor start up
Insulator
Stator core
Insulation film
Insulator
Stator core
Insulation film
Magnet Wire
Magnet Wire
Increase in area
available for
winding
Efficient partial load operation is realised by avoiding over-
compression. With the scroll compressor, the distance of
the compression process in the scroll is usually fixed, so
over-compression occurs during low loads and low rotation.
The latest compressor is equipped with two sub-ports in
addition to the conventional discharge port to reduce this
over-compression loss during low loads. In operating
conditions with a low compression rate, the distance in the
compression process is kept short by successfully avoiding
unnecessary compression, and contributing to efficient
partial load operation.
Multi-port mechanism
F: Centrifugal force applied on scroll section F’: Centrifugal force applied on cancelling slider
R2-Series EP R2-Series P Y-Series EP Y-Series P
16 YNW-Series (Y/R2)

Conventional model (YLM)
Latest model (YNW)
Crank angle (deg)
Discharge
pressure
Intake
pressure
Compression chamber (MPaG)
Multi-port
Conventional
Over-compression area can be
eliminated in this structure
The compressor, known as the heart of the air conditioner, has been improved. A centrifugal force canceling mechanism and
a multi-port mechanism have been developed. In addition, we have mounted a high-efficiency motor. The synergetic effect of
these latest technologies increases the compressor performance and efficiency, and also helps to improve the performance
of the outdoor unit.
The structure of the scroll compressor causes a centrifugal force during operation. Conventionally, that centrifugal force is applied onto the scroll section.
This causes refrigerant to leak, and restricts the increase in rotational speed to a maximum of 120rps.
With the latest compressor, the latest structure (centrifugal force canceling mechanism) has been mounted to suppress the centrifugal force. This mecha-
nism successfully suppresses the centrifugal force generated at the scroll section, reduces refrigerant leakage losses, and increases the compressor
efficiency. The maximum rotational speed has been increased from the conventional 120rps to 140rps.
This mechanism also speeds up the start of operation, and enables operations such as preheat defrost operation and the smooth auto-shift startup mode.
Compressor with centrifugal force canceling mechanism
Partial
load
Operation pattern
Rating, high
pressure
difference
Open
Open
Open
Sub-port
Main port Valve
Valve
Valve
Open
Closed
Closed
Partial
load
Operation pattern
Rating, high
pressure
difference
OpenMain port Valve Open
Conventional structure
Reduced over-compression loss (multi-port)
Multi-port structure
Fixed
scroll
Orbiting
scroll Discharge port
Valve
Fixed
scroll
Orbiting
scroll
Valve
Valve Valve
Discharge port Multi-port
Latest structure
Centrifugal force canceling mechanism (8 to 14HP)
The insulator section that traditionally created a
dead space is eliminated by insulating the motor’s
stator film. Since winding can be set in that
section, the winding area can be increased by
approx. 9%. The wire diameter has also been
increased by two ranks, so the resistance between
terminals is reduced, and the insulation distance
is shorter. This improves the motor’s operation
performance and contributes to high-efficiency
operation of the compressor.
Improved high-efficiency motor
Fixed scroll
Conventional mechanism
Orbiting scroll F
Slider
Vortex pressing load (F) is high.
Centrifugal force canceling mechanism
F
F’
Vortex pressing load (F-F’) is low.
Centrifugal force
cancelling slider
Spindle
Large loss Small loss
Latest structure
Centrifugal force
applied on scroll
section: Large
Refrigerants leakage
loss:
Large
Max. speed 120rps
Centrifugal force
applied on scroll
section: Small
Refrigerant leakage
loss:
Small
Max. speed 140rps
The sub-port is opened during partial load
operation to discharge the over-compressed gas.
Multi-port
When the target discharge pressure is
reached, the multiport opens, and the gas
refrigerant is discharged. This reduces drive
losses caused by over-compression.
Conventional model
Conventionally, gas refrigerant is compressed
to a set pressure, and then lowered to the
target discharge pressure at which it is
discharged. This causes drive losses from
over-compression.
The motor can be wound in the section where the
insulator was, and a larger wire diameter can be used.
The insulator section is large, and the
area where the copper wire can be wound
is small.
15
15
120
140
Rotational speed (rps)
Compressor efficiency
With canceling mechanism
Improved
compressor
efficiency
Max. speed 120rps 140rps contribute
to speedy compressor start up
Insulator
Stator core
Insulation film
Insulator
Stator core
Insulation film
Magnet Wire
Magnet Wire
Increase in area
available for
winding
Efficient partial load operation is realised by avoiding over-
compression. With the scroll compressor, the distance of
the compression process in the scroll is usually fixed, so
over-compression occurs during low loads and low rotation.
The latest compressor is equipped with two sub-ports in
addition to the conventional discharge port to reduce this
over-compression loss during low loads. In operating
conditions with a low compression rate, the distance in the
compression process is kept short by successfully avoiding
unnecessary compression, and contributing to efficient
partial load operation.
Multi-port mechanism
F: Centrifugal force applied on scroll section F’: Centrifugal force applied on cancelling slider
R2-Series EP R2-Series P Y-Series EP Y-Series P
Notes:
*1,*2 Nominal conditions (subject to JIS B8615-1,-2)
*3 In case of connecting PLFY-P**VEM type indoor unit
*4 Cooling mode / Heating mode
*5 The sound pressure level measured by the conventional method in JIS for reference purpose.
*6 External static pressure option is available (30 Pa, 60 Pa, 80 Pa/3.1 mmH2O, 6.1 mmH2O, 8.2 mmH2O).
Consult your dealer about the speci cation when setting External static pressure option.
*Due to continuing improvement, above speci cations may be subject to change without notice.
Indoor Outdoor Pipe length Level di󰀨 erence
Cooling 27ºC DB/19ºC WB
(81ºF DB/66ºF WB)
35ºC DB/24ºC WB
(95ºF DB/75ºF WB) 7.5m (24-9/16ft.) 0m (0ft.)
Heating 20ºC DB(68ºF DB) 7ºC DB/6ºC WB(45ºF DB/43ºF WB) 7.5m (24-9/16ft.) 0m (0ft.)
Model PUHY-P200YNW-A1 (-BS) PUHY-P250YNW-A1 (-BS) PUHY-P300YNW-A1 (-BS)
Power source 3-phase 4-wire 380-400-415 V 50/60 Hz 3-phase 4-wire 380-400-415 V 50/60 Hz 3-phase 4-wire 380-400-415 V 50/60 Hz
Cooling capacity *1,*3 kW 22.4 28.0 33.5
BTU / h 76,400 95,500 114,300
Power input kW 5.61 7.25 9.35
Current input A 9.4-8.9-8.6 12.2-11.6-11.2 15.7-14.9-14.4
EER kW / kW 3.99 3.86 3.58
Temp. range of Indoor W.B. 15.0~24.0°C (59~75°F) 15.0~24.0°C (59~75°F) 15.0~24.0°C (59~75°F)
cooling Outdoor D.B. -5.0~52.0°C (23~126°F) -5.0~52.0°C (23~126°F) -5.0~52.0°C (23~126°F)
Heating capacity *2,*3 kW 25.0 31.5 37.5
BTU / h 85,300 107,500 128,000
Power input kW 5.59 7.35 9.10
Current input A 9.4-8.9-8.6 12.4-11.7-11.3 15.3-14.5-14.0
COP kW / kW 4.47 4.28 4.12
Temp. range of Indoor D.B. 15.0~27.0°C (59~81°F) 15.0~27.0°C (59~81°F) 15.0~27.0°C (59~81°F)
heating Outdoor W.B. -20.0~15.5°C (-4~60°F) -20.0~15.5°C (-4~60°F) -20.0~15.5°C (-4~60°F)
Indoor unit Total capacity 50~130% of outdoor unit capacity 50~130% of outdoor unit capacity 50~130% of outdoor unit capacity
connectable Model / Quantity P10~P250/1~20 P10~P250/1~25 P10~P250/1~30
Sound pressure level
(measured in anechoic room) *4,*5 dB <A> 58.0/59.0 60.0/61.0 61.0/64.5
Sound power level
(measured in anechoic room) *4 dB <A> 75/77 78/80 80/84
Refrigerant piping
diameter
Liquid pipe mm (in.) 9.52 (3/8) Brazed 9.52 (3/8) Brazed
(12.7 (1/2) Brazed, farthest length >= 90 m)
9.52 (3/8) Brazed
(12.7 (1/2) Brazed, farthest length >= 40 m)
Gas pipe mm (in.) 22.2 (7/8) Brazed 22.2 (7/8) Brazed 22.2 (7/8) Brazed
FAN Type x Quantity Propeller fan x 1 Propeller fan x 1 Propeller fan x 1
Air  ow rate m3/min 170 185 240
L/s 2,833 3,083 4,000
cfm 6,003 6,532 8,474
Control, Driving mechanism
Inverter-control, Direct-driven by motor Inverter-control, Direct-driven by motor Inverter-control, Direct-driven by motor
Motor output kW 0.92 x 1 0.92 x 1 0.92 x 1
*6 External static press. 0 Pa (0 mmH2O) 0 Pa (0 mmH2O) 0 Pa (0 mmH2O)
Compressor Type Inverter scroll hermetic compressor Inverter scroll hermetic compressor Inverter scroll hermetic compressor
Starting method Inverter Inverter Inverter
Motor output kW 3.5 5.3 6.7
Case heater kW – – –
External  nish Pre-coated galvanized steel sheets
(+powder coating for -BS type)
<MUNSELL 3Y 7.8/1.1 or similar>
Pre-coated galvanized steel sheets
(+powder coating for -BS type)
<MUNSELL 3Y 7.8/1.1 or similar>
Pre-coated galvanized steel sheets
(+powder coating for -BS type)
<MUNSELL 3Y 7.8/1.1 or similar>
External dimension HxWxD mm 1,858 (1,798 without legs) x 920 x 740 1,858 (1,798 without legs) x 920 x 740 1,858 (1,798 without legs) x 920 x 740
in. 73-3/16 (70-13/16 without legs)
x 36-1/4 x 29-3/16
73-3/16 (70-13/16 without legs)
x 36-1/4 x 29-3/16
73-3/16 (70-13/16 without legs)
x 36-1/4 x 29-3/16
Protection devices High pressure protection High pressure sensor, High pressure switch
at 4.15 MPa (601 psi)
High pressure sensor, High pressure switch
at 4.15 MPa (601 psi)
High pressure sensor, High pressure switch
at 4.15 MPa (601 psi)
Inverter circuit (COMP./FAN)
Over-current protection Over-current protection Over-current protection
Compressor –––
Fan motor –––
Refrigerant Type x original charge R410A x 6.5 kg (15 lbs) R410A x 6.5 kg (15 lbs) R410A x 6.5 kg (15 lbs)
Net weight kg (lbs) 213 (470) 213 (470) 226 (499)
Heat exchanger Salt-resistant cross  n & copper tube Salt-resistant cross  n & copper tube Salt-resistant cross  n & copper tube
Optional parts Joint: CMY-Y102SS/LS-G2
Header: CMY-Y104/108/1010-G
Joint: CMY-Y102SS/LS-G2
Header: CMY-Y104/108/1010-G
Joint: CMY-Y102SS/LS-G2
Header: CMY-Y104/108/1010-G
Y-Series Standard
PUHY-P YNW-A1(-BS)
17
SPECIFICATIONS
VRF
Lineup
VRF
R2-Series
VRF
Zubadan
VRF
WY-Series
VRF
WR2-Series
VRF
S-Series
VRF
Indoor Units
Ventilation
Systems
Technologies
and Functions
Remote
Controller
Hot Water
Solution
VRF
BC Controllers
VRF
S-Series
VRF
Y-Series

Notes:
*1,*2 Nominal conditions (subject to JIS B8615-1,-2)
*3 In case of connecting PLFY-P**VEM type indoor unit
*4 Cooling mode / Heating mode
*5 The sound pressure level measured by the conventional method in JIS for reference purpose.
*6 External static pressure option is available (30 Pa, 60 Pa, 80 Pa/3.1 mmH2O, 6.1 mmH2O, 8.2 mmH2O).
Consult your dealer about the speci cation when setting External static pressure option.
*Due to continuing improvement, above speci cations may be subject to change without notice.
Indoor Outdoor Pipe length Level di󰀨 erence
Cooling 27ºC DB/19ºC WB
(81ºF DB/66ºF WB)
35ºC DB/24ºC WB
(95ºF DB/75ºF WB) 7.5m (24-9/16ft.) 0m (0ft.)
Heating 20ºC DB(68ºF DB) 7ºC DB/6ºC WB(45ºF DB/43ºF WB) 7.5m (24-9/16ft.) 0m (0ft.)
Model PUHY-P350YNW-A1 (-BS) PUHY-P400YNW-A1 (-BS) PUHY-P450YNW-A1 (-BS) PUHY-P500YNW-A1 (-BS)
Power source
3-phase 4-wire 380-400-415 V 50/60 Hz 3-phase 4-wire 380-400-415 V 50/60 Hz 3-phase 4-wire 380-400-415 V 50/60 Hz 3-phase 4-wire 380-400-415 V 50/60 Hz
Cooling capacity *1,*3 kW 40.0 45.0 50.0 56.0
BTU / h 136,500 153,500 170,600 191,100
Power input kW 10.86 12.93 14.74 16.00
Current input A 18.3-17.4-16.7 21.8-20.7-19.9 24.8-23.6-22.7 27.0-25.6-24.7
EER kW / kW 3.68 3.48 3.39 3.50
Temp. range of Indoor W.B. 15.0~24.0°C (59~75°F) 15.0~24.0°C (59~75°F) 15.0~24.0°C (59~75°F) 15.0~24.0°C (59~75°F)
cooling Outdoor D.B. -5.0~52.0°C (23~126°F) -5.0~52.0°C (23~126°F) -5.0~52.0°C (23~126°F) -5.0~52.0°C (23~126°F)
Heating capacity *2,*3 kW 45.0 50.0 56.0 63.0
BTU / h 153,500 170,600 191,100 215,000
Power input kW 11.30 13.69 16.32 16.11
Current input A 19.0-18.1-17.4 23.1-21.9-21.1 27.5-26.1-25.2 27.1-25.8-24.9
COP kW / kW 3.98 3.65 3.43 3.91
Temp. range of Indoor D.B. 15.0~27.0°C (59~81°F) 15.0~27.0°C (59~81°F) 15.0~27.0°C (59~81°F) 15.0~27.0°C (59~81°F)
heating Outdoor W.B. -20.0~15.5°C (-4~60°F) -20.0~15.5°C (-4~60°F) -20.0~15.5°C (-4~60°F) -20.0~15.5°C (-4~60°F)
Indoor unit Total capacity
50~130% of outdoor unit capacity 50~130% of outdoor unit capacity 50~130% of outdoor unit capacity 50~130% of outdoor unit capacity
connectable Model / Quantity P10~P250/1~35 P10~P250/1~40 P10~P250/1~45 P10~P250/1~50
Sound pressure level
(measured in anechoic room) *4,*5 dB <A> 62.0/64.0 65.0/67.0 65.5/69.5 63.5/66.5
Sound power level
(measured in anechoic room) *4 dB <A> 80/83 82/86 84/89 82/85
Refrigerant piping Liquid pipe mm (in.) 12.7 (1/2) Brazed 12.7 (1/2) Brazed 15.88 (5/8) Brazed 15.88 (5/8) Brazed
diameter Gas pipe mm (in.) 28.58 (1-1/8) Brazed 28.58 (1-1/8) Brazed 28.58 (1-1/8) Brazed 28.58 (1-1/8) Brazed
FAN Type x Quantity Propeller fan x 2 Propeller fan x 2 Propeller fan x 2 Propeller fan x 2
Air  ow rate m3/min 270 300 305 365
L/s 4,500 5,000 5,083 6,083
cfm 9,534 10,593 10,770 12,888
Control, Driving mechanism
Inverter-control, Direct-driven by motor Inverter-control, Direct-driven by motor Inverter-control, Direct-driven by motor Inverter-control, Direct-driven by motor
Motor output kW 0.46 x 2 0.46 x 2 0.46 x 2 0.92 x 2
*6 External static press. 0 Pa (0 mmH2O) 0 Pa (0 mmH2O) 0 Pa (0 mmH2O) 0 Pa (0 mmH2O)
Compressor Type
Inverter scroll hermetic compressor Inverter scroll hermetic compressor Inverter scroll hermetic compressor Inverter scroll hermetic compressor
Starting method Inverter Inverter Inverter Inverter
Motor output kW 8.6 11.4 11.7 13.3
Case heater kW – – – –
External  nish Pre-coated galvanized steel sheets
(+powder coating for -BS type)
<MUNSELL 3Y 7.8/1.1 or similar>
Pre-coated galvanized steel sheets
(+powder coating for -BS type)
<MUNSELL 3Y 7.8/1.1 or similar>
Pre-coated galvanized steel sheets
(+powder coating for -BS type)
<MUNSELL 3Y 7.8/1.1 or similar>
Pre-coated galvanized steel sheets
(+powder coating for -BS type)
<MUNSELL 3Y 7.8/1.1 or similar>
External dimension HxWxD mm 1,858 (1,798 without legs)
x 1,240 x 740
1,858 (1,798 without legs)
x 1,240 x 740
1,858 (1,798 without legs)
x 1,240 x 740
1,858 (1,798 without legs)
x 1,750 x 740
in. 73-3/16 (70-13/16 without legs)
x 48-7/8 x 29-3/16
73-3/16 (70-13/16 without legs)
x 48-7/8 x 29-3/16
73-3/16 (70-13/16 without legs)
x 48-7/8 x 29-3/16
73-3/16 (70-13/16 without legs)
x 68-15/16 x 29-3/16
Protection devices High pressure protection
High pressure sensor, High pressure
switch at 4.15 MPa (601 psi)
High pressure sensor, High pressure
switch at 4.15 MPa (601 psi)
High pressure sensor, High pressure
switch at 4.15 MPa (601 psi)
High pressure sensor, High pressure
switch at 4.15 MPa (601 psi)
Inverter circuit (COMP./FAN)
Over-current protection Over-current protection Over-current protection Over-current protection
Compressor – – – –
Fan motor – – – –
Refrigerant Type x original charge R410A x 9.8 kg (22 lbs) R410A x 9.8 kg (22 lbs) R410A x 10.8 kg (24 lbs) R410A x 10.8 kg (24 lbs)
Net weight kg (lbs) 277 (611) 277 (611) 293 (646) 334 (737)
Heat exchanger Salt-resistant cross  n &
copper tube
Salt-resistant cross  n &
copper tube
Salt-resistant cross  n &
copper tube
Salt-resistant cross  n &
copper tube
Optional parts Joint: CMY-Y102SS/LS-G2,
CMY-Y202S-G2
Header: CMY-Y104/108/1010-G
Joint: CMY-Y102SS/LS-G2,
CMY-Y202S-G2
Header: CMY-Y104/108/1010-G
Joint: CMY-Y102SS/LS-G2,
CMY-Y202S-G2
Header: CMY-Y104/108/1010-G
Joint: CMY-Y102SS/LS-G2,
CMY-Y202S-G2
Header: CMY-Y104/108/1010-G
Y-Series Standard
PUHY-P YNW-A1(-BS)
18 SPECIFICATIONS

Model PUHY-P400YSNW-A1 (-BS) PUHY-P450YSNW-A1 (-BS)
Power source 3-phase 4-wire 380-400-415 V 50/60 Hz 3-phase 4-wire 380-400-415 V 50/60 Hz
Cooling capacity *1,*3 kW 45.0 50.0
BTU / h 153,500 170,600
Power input kW 11.62 13.15
Current input A 19.6-18.6-17.9 22.1-21.0-20.3
EER kW / kW 3.87 3.80
Temp. range of Indoor W.B. 15.0~24.0°C (59~75°F) 15.0~24.0°C (59~75°F)
cooling Outdoor D.B. -5.0~52.0°C (23~126°F) -5.0~52.0°C (23~126°F)
Heating capacity *2,*3 kW 50.0 56.0
BTU / h 170,600 191,100
Power input kW 11.54 13.23
Current input A 19.4-18.5-17.8 22.3-21.2-20.4
COP kW / kW 4.33 4.23
Temp. range of Indoor D.B. 15.0~27.0°C (59~81°F) 15.0~27.0°C (59~81°F)
heating Outdoor W.B. -20.0~15.5°C (-4~60°F) -20.0~15.5°C (-4~60°F)
Indoor unit Total capacity 50~130% of outdoor unit capacity 50~130% of outdoor unit capacity
connectable Model / Quantity P10~P250/1~40 P10~P250/1~45
Sound pressure level
(measured in anechoic room) *4,*5 dB <A> 61.0/62.0 62.0/63.0
Sound power level
(measured in anechoic room) *4 dB <A> 78/80 80/82
Refrigerant piping Liquid pipe mm (in.) 12.7 (1/2) Brazed 15.88 (5/8) Brazed
diameter Gas pipe mm (in.) 28.58 (1-1/8) Brazed 28.58 (1-1/8) Brazed
Set Model PUHY-P200YNW-A1 (-BS) PUHY-P200YNW-A1 (-BS) PUHY-P200YNW-A1 (-BS) PUHY-P250YNW-A1 (-BS)
FAN Type x Quantity Propeller fan x 1 Propeller fan x 1 Propeller fan x 1 Propeller fan x 1
Air  ow rate m3/min 170 170 170 185
L/s 2,833 2,833 2,833 3,083
cfm 6,003 6,003 6,003 6,532
Control, Driving mechanism
Inverter-control, Direct-driven by motor Inverter-control, Direct-driven by motor
Motor output kW 0.92 x 1 0.92 x 1 0.92 x 1 0.92 x 1
*6 External static press. 0 Pa (0 mmH2O) 0 Pa (0 mmH2O) 0 Pa (0 mmH2O) 0 Pa (0 mmH2O)
Compressor Type Inverter scroll hermetic compressor Inverter scroll hermetic compressor
Starting method Inverter Inverter Inverter Inverter
Motor output kW 3.5 3.5 3.5 5.3
Case heater kW – – – –
External  nish Pre-coated galvanized steel sheets
(+powder coating for -BS type)
<MUNSELL 3Y 7.8/1.1 or similar>
Pre-coated galvanized steel sheets
(+powder coating for -BS type)
<MUNSELL 3Y 7.8/1.1 or similar>
External dimension HxWxD mm 1,858 (1,798 without legs)
x 920 x 740
1,858 (1,798 without legs)
x 920 x 740
1,858 (1,798 without legs)
x 920 x 740
1,858 (1,798 without legs)
x 920 x 740
in. 73-3/16 (70-13/16 without legs)
x 36-1/4 x 29-3/16
73-3/16 (70-13/16 without legs)
x 36-1/4 x 29-3/16
73-3/16 (70-13/16 without legs)
x 36-1/4 x 29-3/16
73-3/16 (70-13/16 without legs)
x 36-1/4 x 29-3/16
Protection devices High pressure protection High pressure sensor, High pressure switch at 4.15 MPa (601 psi) High pressure sensor, High pressure switch at 4.15 MPa (601 psi)
Inverter circuit (COMP./FAN)
Over-current protection Over-current protection
Compressor – – – –
Fan motor – – – –
Refrigerant Type x original charge R410A x 6.5 kg (15 lbs) R410A x 6.5 kg (15 lbs) R410A x 6.5 kg (15 lbs) R410A x 6.5 kg (15 lbs)
Net weight kg (lbs) 213 (470) 213 (470) 213 (470) 213 (470)
Heat exchanger Salt-resistant cross  n & copper tube Salt-resistant cross  n & copper tube
Pipe between unit Liquid pipe mm (in.) 9.52 (3/8) Brazed 9.52 (3/8) Brazed 9.52 (3/8) Brazed 9.52 (3/8) Brazed
and distributor Gas pipe mm (in.) 22.2 (7/8) Brazed 22.2 (7/8) Brazed 22.2 (7/8) Brazed 22.2 (7/8) Brazed
Optional parts Outdoor Twinning kit: CMY-Y100VBK3
Joint: CMY-Y102SS/LS-G2, CMY-Y202S/302S-G2
Header: CMY-Y104/108/1010-G
Outdoor Twinning kit: CMY-Y100VBK3
Joint: CMY-Y102SS/LS-G2, CMY-Y202S/302S-G2
Header: CMY-Y104/108/1010-G
Notes:
*1,*2 Nominal conditions (subject to JIS B8615-1,-2)
*3 In case of connecting PLFY-P**VEM type indoor unit
*4 Cooling mode / Heating mode
*5 The sound pressure level measured by the conventional method in JIS for reference purpose.
*6 External static pressure option is available (30 Pa, 60 Pa, 80 Pa/3.1 mmH2O, 6.1 mmH2O, 8.2 mmH2O).
Consult your dealer about the speci cation when setting External static pressure option.
*Due to continuing improvement, above speci cations may be subject to change without notice.
Indoor Outdoor Pipe length Level di󰀨 erence
Cooling 27ºC DB/19ºC WB
(81ºF DB/66ºF WB)
35ºC DB/24ºC WB
(95ºF DB/75ºF WB) 7.5m (24-9/16ft.) 0m (0ft.)
Heating 20ºC DB(68ºF DB) 7ºC DB/6ºC WB(45ºF DB/43ºF WB) 7.5m (24-9/16ft.) 0m (0ft.)
Y-Series Standard
PUHY-P YSNW-A1(-BS)
19
SPECIFICATIONS
VRF
Lineup
VRF
R2-Series
VRF
Zubadan
VRF
WY-Series
VRF
WR2-Series
VRF
S-Series
VRF
Indoor Units
Ventilation
Systems
Technologies
and Functions
Remote
Controller
Hot Water
Solution
VRF
BC Controllers
VRF
S-Series
VRF
Y-Series

Model PUHY-P500YSNW-A1 (-BS) PUHY-P550YSNW-A1 (-BS)
Power source 3-phase 4-wire 380-400-415 V 50/60 Hz 3-phase 4-wire 380-400-415 V 50/60 Hz
Cooling capacity *1,*3 kW 56.0 63.0
BTU / h 191,100 215,000
Power input kW 14.97 17.54
Current input A 25.2-24.0-23.1 29.6-28.1-27.1
EER kW / kW 3.74 3.59
Temp. range of Indoor W.B. 15.0~24.0°C (59~75°F) 15.0~24.0°C (59~75°F)
cooling Outdoor D.B. -5.0~52.0°C (23~126°F) -5.0~52.0°C (23~126°F)
Heating capacity *2,*3 kW 63.0 69.0
BTU / h 215,000 235,400
Power input kW 15.18 16.99
Current input A 25.6-24.3-23.4 28.6-27.2-26.2
COP kW / kW 4.15 4.06
Temp. range of Indoor D.B. 15.0~27.0°C (59~81°F) 15.0~27.0°C (59~81°F)
heating Outdoor W.B. -20.0~15.5°C (-4~60°F) -20.0~15.5°C (-4~60°F)
Indoor unit Total capacity 50~130% of outdoor unit capacity 50~130% of outdoor unit capacity
connectable Model / Quantity P10~P250/1~50 P10~P250/2~50
Sound pressure level
(measured in anechoic room) *4,*5 dB <A> 63.0/64.0 63.5/66.0
Sound power level
(measured in anechoic room) *4 dB <A> 81/83 82/85
Refrigerant piping Liquid pipe mm (in.) 15.88 (5/8) Brazed 15.88 (5/8) Brazed
diameter Gas pipe mm (in.) 28.58 (1-1/8) Brazed 28.58 (1-1/8) Brazed
Set Model PUHY-P250YNW-A1 (-BS) PUHY-P250YNW-A1 (-BS) PUHY-P250YNW-A1 (-BS) PUHY-P300YNW-A1 (-BS)
FAN Type x Quantity Propeller fan x 1 Propeller fan x 1 Propeller fan x 1 Propeller fan x 1
Air  ow rate m3/min 185 185 185 240
L/s 3,083 3,083 3,083 4,000
cfm 6,532 6,532 6,532 8,474
Control, Driving mechanism
Inverter-control, Direct-driven by motor Inverter-control, Direct-driven by motor
Motor output kW 0.92 x 1 0.92 x 1 0.92 x 1 0.92 x 1
*6 External static press. 0 Pa (0 mmH2O) 0 Pa (0 mmH2O) 0 Pa (0 mmH2O) 0 Pa (0 mmH2O)
Compressor Type Inverter scroll hermetic compressor Inverter scroll hermetic compressor
Starting method Inverter Inverter Inverter Inverter
Motor output kW 5.3 5.3 5.3 6.7
Case heater kW – – – –
External  nish Pre-coated galvanized steel sheets
(+powder coating for -BS type)
<MUNSELL 3Y 7.8/1.1 or similar>
Pre-coated galvanized steel sheets
(+powder coating for -BS type)
<MUNSELL 3Y 7.8/1.1 or similar>
External dimension HxWxD mm 1,858 (1,798 without legs)
x 920 x 740
1,858 (1,798 without legs)
x 920 x 740
1,858 (1,798 without legs)
x 920 x 740
1,858 (1,798 without legs)
x 920 x 740
in. 73-3/16 (70-13/16 without legs)
x 36-1/4 x 29-3/16
73-3/16 (70-13/16 without legs)
x 36-1/4 x 29-3/16
73-3/16 (70-13/16 without legs)
x 36-1/4 x 29-3/16
73-3/16 (70-13/16 without legs)
x 36-1/4 x 29-3/16
Protection devices High pressure protection High pressure sensor, High pressure switch at 4.15 MPa (601 psi) High pressure sensor, High pressure switch at 4.15 MPa (601 psi)
Inverter circuit (COMP./FAN)
Over-current protection Over-current protection
Compressor – – – –
Fan motor – – – –
Refrigerant Type x original charge R410A x 6.5 kg (15 lbs) R410A x 6.5 kg (15 lbs) R410A x 6.5 kg (15 lbs) R410A x 6.5 kg (15 lbs)
Net weight kg (lbs) 213 (470) 213 (470) 213 (470) 226 (499)
Heat exchanger Salt-resistant cross  n & copper tube Salt-resistant cross  n & copper tube
Pipe between unit Liquid pipe mm (in.) 9.52 (3/8) Brazed 9.52 (3/8) Brazed 9.52 (3/8) Brazed 12.7 (1/2) Brazed
and distributor Gas pipe mm (in.) 22.2 (7/8) Brazed 22.2 (7/8) Brazed 22.2 (7/8) Brazed 22.2 (7/8) Brazed
Optional parts Outdoor Twinning kit: CMY-Y100VBK3
Joint: CMY-Y102SS/LS-G2, CMY-Y202S/302S-G2
Header: CMY-Y104/108/1010-G
Outdoor Twinning kit: CMY-Y100VBK3
Joint: CMY-Y102SS/LS-G2, CMY-Y202S/302S-G2
Header: CMY-Y104/108/1010-G
Notes:
*1,*2 Nominal conditions (subject to JIS B8615-1,-2)
*3 In case of connecting PLFY-P**VEM type indoor unit
*4 Cooling mode / Heating mode
*5 The sound pressure level measured by the conventional method in JIS for reference purpose.
*6 External static pressure option is available (30 Pa, 60 Pa, 80 Pa/3.1 mmH2O, 6.1 mmH2O, 8.2 mmH2O).
Consult your dealer about the speci cation when setting External static pressure option.
*Due to continuing improvement, above speci cations may be subject to change without notice.
Indoor Outdoor Pipe length Level di󰀨 erence
Cooling 27ºC DB/19ºC WB
(81ºF DB/66ºF WB)
35ºC DB/24ºC WB
(95ºF DB/75ºF WB) 7.5m (24-9/16ft.) 0m (0ft.)
Heating 20ºC DB(68ºF DB) 7ºC DB/6ºC WB(45ºF DB/43ºF WB) 7.5m (24-9/16ft.) 0m (0ft.)
Y-Series Standard
PUHY-P YSNW-A1(-BS)
20 SPECIFICATIONS
