Mitsubishi Electric 3D DLP C12 Series Installation guide

3D DLP
™HOME-CINEMA TELEVISION
MODELS
642 Series
C12 Series
BASIC OWNER’S GUIDE
®
This manual provides basic connection, setup, and operating instructions. For use of additional fea-
tures of this television, please visit our website at www.Mitsubishi-tv.com to view or download a sup-
plemental Owner’s Guide. Follow the Support link to the Product Documents page.
• For questions:
- Visit our website at www.mitsubishi-tv.com.
- E-mail us at [e-mail].
- Call Consumer Relations at 800-332-2119 for operational or connection assistance.
• For information on System Reset, please see the back cover.
• To order replacement or additional remote controls, visit our website at www.mitsuparts.com or call
800-553-7278.
642 Series only

2
For assistance call 1(800) 332-2119
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING: To reduce the risk of fire or electric shock, do
not expose this apparatus to rain or moisture.
This apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such as vases,
shall be placed on the apparatus.
Cet appareil ne doit pas être exposé à des gouttes ou
à des éclaboussures et aucun objet rempli d’un liquide,
comme un vase, ne doit être placé sur l’appareil.
WARNING: This product contains chemicals known
to the State of California to cause cancer and/or birth
defects or other reproductive harm.
TV WEIGHT: This TV is heavy. Exercise extreme care
when lifting or moving it. Lift or move the TV with a
minimum of two adults. To prevent damage to the TV,
avoid jarring or moving it while it is turned on. Always
power off your TV, unplug the power cord, and disconnect
all cables before moving it.
CAUTION: When selecting a stand, base, or other fur-
niture to support the TV, please make sure it is designed
with the appropriate dimensions for stability and to
support the TV’s weight plus the weight of any additional
equipment you plan to store.
MAINS DISCONNECTION: The mains plug is used
as the disconnect device. The mains plug shall remain
readily operable.
FCC Declaration of Conformity
Product: Projection Television Receiver
Models: WD-73642
WD-82642
WD-73C12
WD-82C12
Responsible
Party:
Mitsubishi Electric Visual Solutions
America, Inc.
9351 Jeronimo Road
Irvine, CA 92618-1904
Telephone: [phone]
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired
operation.
Note: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursu-
ant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interfer-
ence in a residential installation. This equipment gener-
ates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television recep-
tion, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
the receiver.
- Connect the equipment into an outlet on a circuit dif-
ferent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV techni-
cian for help.
Changes or modifications not expressly approved by
Mitsubishi could cause harmful interference and would
void the user’s authority to operate this equipment.
The lightning flash with arrowhead symbol within an
equilateral triangle is intended to alert the user of the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important oper-
ating and maintenance (servicing) instructions in the
literature accompanying the product.
Custom cabinet installation must allow for proper air
circulation around the television.
Note: Features and specifications described in this
owner’s guide are subject to change without notice.
TV Software
Do not attempt to update the software of this TV with
software not provided by or authorized by Mitsubishi
Electric Visual Solutions America, Inc. Non-authorized
software may damage the TV and will not be covered by
the warranty.
Children and TV Viewing
The American Academy of Pediatrics discourages
media use by children younger than two years. For more
information, visit www.aap.org <http://www.aap.org/>.

3
For assistance call 1(800) 332-2119
Contents
Important Safety Instructions ................ 4
1 Basic Setup and Operation
Package Contents ....................... 5
Installing the Remote Control Batteries......... 5
TV Overview ........................... 5
Before You Begin ........................ 5
Remote Control ......................... 6
Setting Up and Using TV Inputs .............. 7
Basic TV Operation....................... 9
TV Menus ............................ 12
2 TV Connections
Before You Begin ....................... 13
Connection Types and Audio/Video Quality .... 13
Input and Output Jacks................... 14
Connection Diagrams .................... 15
3 TV Features
FAV (Favorites) ......................... 19
Sleep Timer ........................... 19
3D Video ............................. 20
Appendices
Appendix A: Auto Input Sensing ............ 23
Appendix B: TV Care .................... 24
Appendix C: Troubleshooting .............. 27
Mitsubishi TV Software.................... 31
Warranty .............................. 37
NOTE TO CATV SYSTEM INSTALLER: THIS REMINDER IS
PROVIDED TO CALL THE CATV SYSTEM INSTALLER’S ATTEN-
TION TO ARTICLE 820-40 OF THE NEC THAT PROVIDES
GUIDELINES FOR THE PROPER GROUNDING AND, IN PARTIC-
ULAR, SPECIFIES THAT THE CABLE GROUND SHALL BE CON-
NECTED TO THE GROUNDING SYSTEM OF THE BUILDING, AS
CLOSE TO THE POINT OF CABLE ENTRY AS PRACTICAL.
Lamp Replacement
For lamp-replacement instructions, see Appendix B.
To Order a Replacement Lamp Under Warranty
Visit our website www.mitsuparts.com or call
[phone]. Please have television model number,
serial number, and proof of purchase available.
To Order a Replacement Lamp After Warranty
Visit our website at www.mitsuparts.com or call
[phone]. Please have the television model
number available. Order new lamp part number
915B455012.
Mitsubishi Electric Visual Solutions
America and the Environment
As part of its ongoing environmental efforts, Mitsubishi
Electric Visual Solutions America, Inc. (MEVSA) joined
the Electronic Manufacturers Recycling Management
Company’s (MRM) national recycling initiative. Your
MEVSA TV can be recycled at no charge to the con-
sumer through MRM’s growing infrastructure of drop-
off locations around the United States.
We encourage all of our customers to recycle their used
electronics. All waste computer monitors, portable
computers, digital picture frames, televisions, portable
DVD players, desktop printers, VCRs, and video game
consoles should be recycled.
For a listing of MRM recycling drop-off locations,
please visit www.MRMrecycling.com. MRM can also
be reached toll free at 1-888-769-0149
For more information about Maine’s electronic waste
law, please visit the Maine Department of Environmental
Protection website at www.maine.gov/dep/rwm/ewaste/
index.htm.
For other states please check your state or local gov-
ernment web sites for more information about local
laws and recycling options.

4
For assistance call 1(800) 332-2119
Important Safety Instructions
Please read the following safeguards for your TV and
retain for future reference. Always follow all warnings
and instructions marked on the television.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong are
provided for your safety. If the provided plug does
not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10) Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart,
stand, tripod, bracket,
or table specified
by the manufacturer,
or sold with the
apparatus. When
a cart is used, use
caution when moving
the cart/apparatus
combination to avoid
injury from tip-over.
13) Unplug this apparatus
during lightning storms or when unused for long
periods of time.
14) Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
ANTE NNA
LEAD IN WIRE
ANTE NNA
DIS CHAR G E UNIT
(NE C AR TIC LE 810-20)
GROUNDING
CONDUCTORS
(NEC ARTICLE 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NE C AR T 250, PAR T H)
GROUND CLAMP
ELECTRIC
SERVICE
EQUIPMENT
NEC — NATIONAL ELECTRICAL CODE
EXAMPLE OF ANTENNA GROUNDING
Outdoor Antenna Grounding
If an outside antenna or cable system is connected
to the TV, be sure the antenna or cable system is
grounded so as to provide some protection against
voltage surges and built-up static charges.
Replacement Parts
When replacement parts are required, be sure the
service technician has used replacement parts speci-
fied by the manufacturer or have the same character-
istics as the original part. Unauthorized substitutions
may result in fire, electric shock or other hazards.
To avoid the risk of injury to the eyes and face, do not
look directly into the air vents while the television is
operating.
To avoid the risk of fire, do not use flammable solvents
(such as benzene or paint solvents) or flammable aero-
sols (such as polishes, cleaners, or insecticides) near
the television while it is operating or cooling.

5
For assistance call 1(800) 332-2119
Basic Setup and Operation
1
Installing the Remote Control
Batteries
1. Remove the remote control’s back cover by
gently pressing in the tab and lifting off the cover.
2. Load the batteries, making sure the polarities
(+) and (-) are correct. For best results, insert
the negative (-) end first.
3. Snap the cover back in place.
2
1
The remote
control
requires two
AA batteries.
Package Contents
Please take a moment to review the following list of
items to ensure that you have received everything.
TV Overview
Remote
Control
AA
AA
Two AA
Batteries
Basic
Owner’s
Guide
Quick
Setup
Guide
Product
Registration
Card
Before You Begin
1. Review the important safety, installation, and oper-
ating information at the beginning of this book.
2. Choose a location for your TV.
• See the stand requirements on page 2.
• Allow at least four inches of space on all sides
of the TV to help prevent overheating. Over-
heating may cause premature failure of the TV.
• Avoid locations where light may reflect off the
screen.
3. Install the batteries in the remote control.
4. Plug the TV into an AC power outlet.
(120 V AC, 60 Hz)
TV Control Panel
Buttons on the control panel duplicate some keys on
the remote control.
To display the main menu, press INPUT and VOL+ simul-
taneously for about 10 seconds. Press and hold INPUT
and VOL+ for 10 seconds to clear the menu.
System Reset
If the TV fails to respond to the remote control, the
control-panel buttons, or will not power on/off, perform
System Reset. Press and hold the POWER button on the
control panel for ten seconds.
Sample TV controls and
location of the STATUS
indicator. See page 30.
Rear Connection
Jacks
Lamp-Compartment
Door

61. Basic Setup and Operation
For assistance call 1(800) 332-2119
Remote Control
Powers TV on or off.
Number/letter keys
Channel tuning, page 8
Pass-code entry
Sleep Timer, page 19
GUIDE
Not used in this model.
INFO
TV status or TV help (page 11)
MUTE
Mutes the TV speakers.
TOOLS
Not used in this model.
VOL Controls volume of TV speakers.
CH
PAGE
Changes channels; moves to another
page in a menu or list.
Adds a separator in digital channel
numbers. Clears some menu entries.
AUDIO
Audio settings
VIDEO
Video settings
MENU
Displays or clears the TV main
menu (page 12). In menus,
steps back one menu.
EXIT
Clears all menus and on-
screen displays.
LAST
Returns to the previous channel.
ENTER
Selects a channel number or menu item.
Navigation and adjustment controls
FAV
Displays up to nine favorite
sources, page 19.
FORMAT
Changes picture shape,
page 10
FREEZE
Freezes a broadcast TV picture
INPUT
Press to select a TV input,
page 8.
Aim the remote control at the TV screen. The
TV can detect control signals over the entire
screen area.

1. Basic Setup and Operation 7
For assistance call 1(800) 332-2119
1. Install batteries in the remote control. See page 5.
2. Aim the emitter (bulb) end
of the remote control at the
TV and press the POWER key
.Wait for the Welcome
screen.
3. If you wish to change the
menu language to Español,
press then ENTER .
4. Press to move to the
energy-mode selections.
Select Home.
5. Press to highlight EXIT.
Press ENTER to clear the menu.
First-Time Power-On
Setting Up and Using TV Inputs
Welcome Screen Energy Options
• Mitsubishi recommends the Home setting,
which produces a picture suitable for home
viewing and uses less power.
• The Retail setting looks best under the bright
lighting often found in commercial settings. In
this mode, the TV uses more power than when
in the Home setting.
This table compares energy choices offered in the
Welcome screen.
Home Retail
Picture Mode Bright Brilliant
Lamp Energy Standard Bright
• Use the Picture > Video menu to change the
Picture Mode.
• Use the Setup > Energy menu to change
Lamp Energy.
Setting the lamp mode to Standard may extend the
life of the lamp.
The ANT (Antenna) Input
If using an antenna or direct cable service (no cable
box), connect the incoming coaxial cable to the TV’s
ANT input. Refer to page 16.
You must perform a channel scan to enable recep-
tion of digital channels. If you skip this step, the TV
can receive only analog channels. The channel scan
will search for high-definition and standard-definition
channels available in your area. Note: Direct cable
service will not include scrambled or premium chan-
nels.
Memorizing Channels with Channel Scan
1. Power on the TV.
2. Press MENU and open the Setup > Channel menu.
Start channel memorization from the Setup > Channel
menu.
3. Press to enter the menu.
4. Highlight Ant Air if connected to an
over-the-air antenna. Highlight Ant
Cable for service over direct cable
(no cable box). Press
ENTER to add a
check.
5. Select the scan type.
• For first-time setup, highlight All channels.
• To scan for channels not already in memory,
highlight Add only new channels. Press
ENTER to add a check.
6. Highlight Scan and press ENTER .
Channel memorization may take up
to 15 minutes to complete.
To stop channel memorization before completion,
press CANCEL . The channels already memorized
before cancellation remain in the memory.
At any time after Channel Scan,
• Use the Setup > Channel > Edit menu to add or
delete individual channels from memory.
• Repeat the All channels scan if you reposition the
antenna or move the TV to a new geographic area
with a different channel line-up.

81. Basic Setup and Operation
For assistance call 1(800) 332-2119
Setting Up Inputs with Auto Input Sensing
Connection information starts on page 13. Learn more
about Auto Input Sensing on page 23.
1. Power on the TV.
2. Power on the devices to ensure detection.
3. Connect one device to the TV, making note of the
TV input jack.
The TV will display the New Device Found screen if
the connection type is detectable.
4. Highlight the device type in the on-screen list and
press ENTER . The name you select here will appear
in the Input Selection menu.
Sample New Device Found screen.
5. Press EXIT to close the New Device Found screen.
6. Repeat the preceding steps for each additional
device you want to add.
Setting Up and Using TV Inputs, continued
More About the Input Selection Menu
• To assign helpful names to the icons, see the
Inputs > Name menu.
• To remove unwanted Antenna or HDMI device icons
from the Input Selection menu, see the Inputs >
Name menu.
• To rearrange the icons, use the Inputs > Order
menu.
Detailed information on using these menus
is in the supplemental Owner’s Guide at
www.mitsubishi-tv.com.
Selecting an Input to Watch
1. Press INPUT .
2. Press and to highlight an
input icon.
Sample Input Selection menu, DVD input selected
3. Press ENTER to switch to the input.
Note: In most cases, to see a named icon for a con-
nected device (as in the samples), you must first
assign a name :
• When the device is first connected and the
New Device Found menu offers a choice
of names.
• By using the Inputs > Name menu to
assign or change a name at any time after
the TV has detected the connection.
Watching Broadcast TV
TV Connected to an Antenna or Direct Cable
Service (no cable box)
Note: Perform channel memorization to enable recep-
tion of digital channels. See page 7.
1. Press INPUT to display the Input Selection menu.
2. Highlight the antenna or cable icon and press ENTER .
Sample Input Selection menu, antenna input selected
3. To tune to a channel from the ANT input, use any of
these methods.
• Enter the channel number using the number
keys on the remote control and press
ENTER
.
For a two-part digital channel, such as 3-1,
press 3
—
CANCEL
1
ENTER
.
• Press
CH
to change channels one channel at
a time.
• Press and hold
CH
to speed through channels.
• Press
LAST
to return to the previous channel.
• Use the Fav (Favorites) feature to tune to up to
nine favorite channels. See page 19.

1. Basic Setup and Operation 9
For assistance call 1(800) 332-2119
Basic TV Operation
Picture Settings
To get the best picture under different viewing condi-
tions, set the Picture Mode first before changing other
video settings.
1. Press VIDEO.
2. Press until the Picture Mode
option displays.
3. Press to make one of these selections:
Name When to Use
Brilliant Under very bright lighting
Game With gaming consoles (inputs
named Game or PC only)
Bright For most daytime viewing
Natural For most nighttime viewing
4. Press to display the name of another adjustment.
5. Press to make the adjustment.
6. Wait a few seconds and the display will clear.
More picture adjustments can be found in these menus:
• Picture > Video
• Picture > Picture Plus
• Picture > 3D Mode (page 20)
Audio Controls
Controlling Sound Volume
Press VOL to adjust the sound level of
the TV speakers.
Changing Audio Settings (TV Speakers Only)
1. Press AUDIO .
2. Press to display the name of the
adjustment you want.
3. Press to change.
Using an External Sound System
To switch from the internal TV speakers to an external
sound system:
1. Press AUDIO .
2. Press to display the TV Speakers option.
3. Press to select either On (to hear sound from the
TV speakers) or Off (to hear sound from an external
sound system).
See page 17 for suggestions on connecting your sound
system to the TV.
Disconnecting an A/V Receiver
When you disconnect an A/V receiver, change the TV
Speakers setting to On to hear sound from the TV
speakers. Use the Sound > Audio > TV Speakers
menu.
HDMI Control (CEC-Enabled HDMI A/V Receiver)
The TV’s remote control may control some functions of
the A/V receiver. See the supplemental Owner’s Guide
at www.mitsubishi-tv.com.

10 1. Basic Setup and Operation
For assistance call 1(800) 332-2119
Basic TV Operation, continued
The FORMAT Key and Picture Shape
Important
Black bars at the edges of the
screen are common in HD pictures.
Black bars are not a defect of the
TV.
• Broadcasters add black bars to fill
the 16:9 screen area while pre-
serving the original aspect ratio
of older material not created for
modern HD TVs.
• Your cable box, satellite receiver,
or other device may also have
controls for altering the shape
of the broadcast picture. If your
device offers output in native
format, try using it with the TV
picture formats.
Sample Uses of the FORMAT Key
You can use the FORMAT key to display the image as originally intended or
to reduce or eliminate black areas at the edges.
Press
High-definition signal with
squarish 4:3 image embedded.
The image is narrower than the
16:9 screen; unused areas at
the sides are filled with black.
Wide Expand mode stretches
the picture sideways to fill the
screen.
Press
Standard 2.35:1 anamorphic
DVD image; unused areas at
the top and bottom are filled
with black (letterbox effect).
Zoom mode. The picture fills
the screen. All four edges are
cropped in this mode.
Press the FORMAT key
t o cycle through picture
shapes for the current
image. The TV will
remember the format you
last used on each input.
For more on TV formats and signal
types, see the supplemental Owner’s
Guide at www.mitsubishi-tv.com.
More TV Features
See the supplemental Owner’s Guide at
www.mitsubishi-tv.com for more on these and other
topics.
• Parental controls (Lock menu). Requires first
setting a pass code.
• TV Clock (Setup > Clock menu). Set the TV Clock
if you plan to use the TV Timer, or the TV’s Lock by
Time feature.
• Changing input names in the Input Selection menu
(Inputs > Name menu)
• HDMI (CEC) control of other A/V devices
• Using the TV with a computer

1. Basic Setup and Operation 11
For assistance call 1(800) 332-2119
Press the INFO key to see
the on-screen status
display. The most
common displays are
shown here. Sample information from the
on-screen status display
1. Current Input. Examples:
Antenna
DVD
DVR
Game
Sat. Rcvr.
2. Audio Indicator. Key:
TV speakers External sound system Mute
3. Channel number (antenna source only)
Digital channel includes major and sub-channel numbers.
4. Digital channel name (if broadcast); antenna source only.
5. V-Chip rating
• Antenna source only for digital signal
• Antenna or VIDEO composite jack for analog signal
6. Program name (if broadcast); digital antenna source only
7. Program description (if broadcast); digital source, antenna only.
Press the INFO key additional times to see more of the description if
available.
8. Sleep Timer remaining time
9. Day and time
10. Signal type being received. See “Signal Definitions” on this
page.
11. Screen format in use
12. Program audio indicator (antenna source only)
13. Available language (digital source, antenna only)
14. Signal-strength indicator (digital source, antenna only)
Status Display
Sleep 30 min
8
13
Tuesday 9:10 PM
English
1080i Standard
Surround
12
11
10
9
About Channel Numbers
Channel Numbers for Over-the-Air
Reception or Reception by Direct
Cable
Note: All signals are automatically
converted to 1080p for display.
Standard-Definition Analog Channels
Cable 3
480i Stretch
Receiving Standard-Definition
Analog Signal (480i)
Cable Reception Channel 3
Standard-Definition Digital Channels
Ant 7-1 KABC-SD
480i Stretch
Receiving Standard-Definition
Digital Signal (SD)
Over-the-Air
Antenna
Reception
Main Channel 7
Sub-Channel 1
High-Definition Digital Channels
Ant 7-1 KABC-HD
1080i Standard
Receiving High-Definition
Digital Signal (HD)
Over-the-Air
Antenna Reception
Main Channel 7
Sub-Channel 1
INFO
Signal Definitions
480i: Standard-definition, older type interlaced signals from the ANT ,
composite VIDEO , component Y Pb Pr , or HDMI jacks.
480p: Standard-definition progressive-scan signals on the ANT ,
component Y Pb Pr, or HDMI jacks.
720p and 1080i: High-definition signals received through the ANT,
component Y Pb Pr , or HDMI jacks. These signals are always 16:9
(widescreen), but may contain embedded 4:3 images with sidebars.
1080p: High-definition signals from a PC, Blu-ray player, or some
satellite and set-top boxes; HDMI inputs only.
402-101 KABC Monday Night Football
TV-PG DLSV St. Louis vs. Tampa Bay, played in Tampa for
1
3
2
46
7
5
14

12 1. Basic Setup and Operation
For assistance call 1(800) 332-2119
Video Basic picture settings
Picture+ Specialized picture controls
Reset Reset of sound and picture adjustments
for the current input
Advanced
(642 Series
only)
Highly customized picture adjust-
ments for each input. Mitsubishi
recommends these adjustments be
made only by a trained professional
installer.
3D Mode
Setup for 3D viewing. See page 20.
Sound
Basic audio settings
Captions
Settings for closed captions
Setup
Language Menu language
Clock Set the TV clock to use the TV Timer, or
to lock the TV by time.
Timer Setup for the TV Timer. The Timer tells
the TV to power on automatically at a
time you set. Set the TV clock before
using the TV Timer.
Channel Setup for a channel scan on the ANT
input; addition to or deletion of channels
from TV memory
Energy Controls for TV energy usage
TV Menus
Inputs
Name Name assignments for TV inputs
HDMI
Control
Setup for HDMI Control (CEC) of external
devices
Order Setup of icons in the Input Selection
menu
Update Instructions for updating TV software.
Lock
Parental Controls to limit TV use by content
ratings (composite video and antenna
inputs only).
Time Setup to lock the TV by time of day. Set
the TV clock before using this menu.
Channel Setup to lock specific channels (antenna
input only)
Panel Control-panel lock
Other Controls to limit TV use based on rating
systems that may come into effect in the
future (digital channels on the antenna
input only).
Press MENU on the remote control to open the
main menu. Find detailed descriptions of all
menus in the supplemental Owner’s Guide at
www.mitsubishi-tv.com.

13
For assistance call 1(800) 332-2119
2TV Connections
Auto Input Sensing
The TV’s Auto Input Sensing feature automatically rec-
ognizes many connections and prompts you to identify
the type of device connected. See pages 8 and 23 for
more on Auto Input Sensing.
Connection Types
Use the connection types available on your input
devices that will give the best video quality. For
example, choose HDMI over component video; choose
component video over composite video.
Picture Quality
For best picture quality, route signals directly from the
source device to the TV.
Surround Sound
The TV accepts PCM stereo or Dolby Digital 5.1 over
the ANT and HDMI inputs and passes the audio out on
the DIGITAL AUDIO OUTPUT jack.
IMPORTANT
Accessories such as cables, adapters, splitters,
or combiners required for TV connections
are not supplied with the TV. These items are
available at most electronics stores.
Before You Begin
Connection Types and Audio/Video Quality
Component
GOODBEST GOODBEST
VIDEO QUALITY AUDIO QUALITY
DVI-to-HDMIHDMI Video Video
Composite L/R Analog Stereo
Mini
Plug
AudioCoaxial Audio
Digital
HDMI
High-definition or standard-definition video Dolby Digital 5.1,
PCM 2.0 (stereo) Stereo only
Standard-definition
video only

14 2. TV Connections
For assistance call 1(800) 332-2119
Input and Output Jacks
HDMI Cable Categories
HDMI cables are available as Standard and High-Speed
types.
• High-Speed HDMI Cables. Blu-ray players, newer
DVD players, video games, 3D content, and set-top
boxes require High-Speed HDMI cables, suitable
for clock frequencies up to 340 MHz or data rates
of up to 10.2 gigabits per second. Use high-speed
cables for 1080p HD signals carrying extended color
encodings (i.e., 30 or more bits, also called Deep
Color). High-Speed HDMI cables are also suitable for
standard HDTV signals.
• Standard HDMI Cables. Standard HDMI cables
may be unmarked. They are suitable for standard
HDTV 720p, 1080i, and 1080p signals with 8-bit color
depth. Use Standard HDMI cables for clock fre-
quencies up to 74.25 MHz or data rates of up to 2.23
gigabits per second.
L/R
Analog
stereo audio
inputs
USB
For software updates only.
To check for updates, visit
www.mitsubishi-tv.com and
follow the support link.
HDMI
(page 15, page 17)
Inputs are HDMI
HDCP compliant.
DVI/PC
INPUT
Audio
input
(page 16)
DIGITAL
AUDIO
OUTPUT
(page 17)
Y
Composite
video input
(page 16)
Y Pb Pr
Component
video input
(page 15)
ANT
Coaxial antenna
input
(page 16)
3D
GLASSES
EMITTER
(page 20)
123
HDMI
Pb
Pr
INPUT 1
DIGITAL
AUDIO
OUTPUT
DVI/PC
INPUT
AUDIO
Y
3D
GLASSES
EMITTER
ANT
L
R
D
(
p
3D GLASSES
EMITTER offered
on the 642 series.
HDMI-3 offered on
the 642 series.

2. TV Connections 15
For assistance call 1(800) 332-2119
3D
GLASSES
EMITTER
ANT
L
R
DIGITAL
AUDIO
OUTPUT
3D
GLASSE
S
E
MITTER
L
R
D
IGITAL
AUDIO
OUTPU
T
HDMI
cable
TV jack panel
Any device with
HDMI output
CABLE IN or
SATELLITE IN
Incoming from
cable service or
satellite dish
Pb
Y
Pr
AUDIO
L
R
3D
GLASSES
EMITTER
ANT
L
R
DIGITAL
AUDIO
OUTPUT
3D
G
LASSE
S
EMITTER
AN
T
L
R
R
D
IGITAL
AUDIO
OUTPU
T
TV jack panel
L
R
L
R
DIGITAL
AUDIO
OUTPUT
D
IGITAL
AUDIO
OUTPUT
Incoming from
cable service or
satellite dish
Component
video cables
Component
video device
Audio
cables
CABLE IN or
SATELLITE IN
H DMI Device
Examples: HDTV Cable Box, Satellite Receiver,
or DVD/Blu-ray Player
Required: HDMI cable.
Connect an HDMI cable from the TV to the device’s
HDMI output. HDMI-connectable devices provide
video and audio through a single cable.
Mitsubishi recommends using high-speed HDMI cables
to connect newer devices incorporating HDMI technol-
ogy. See “HDMI Cable Categories” on the opposite page
for more on HDMI cable types.
Note:
• This connection carries high-definition video,
3D video, and Dolby Digital 5.1 audio signals.
• This connection supports copy protection
(HDCP).
Y Pb Pr Component Video Device
Examples: HDTV Cable Box, Satellite Receiver,
or DVD/Blu-ray Player
If your source device has an HDMI output, use the con-
nections for an HDMI device described on this page
instead of component video.
Required:
Component video cables
RCA-type analog audio cables
Note:
• This connection carries high-definition video
signals.
• To hear digital surround sound from an A/V
receiver, connect the digital audio output from the
device directly to your digital A/V receiver.

16 2. TV Connections
For assistance call 1(800) 332-2119
DVI OUT
3D
GLASSES
EMITTER
ANT
L
R
DIGITAL
AUDIO
OUTPUT
3D
G
LASSE
S
E
MITTE
R
AN
T
L
R
R
D
IGITAL
AUDIO
OUTPU
T
TV panel
Digital DVI
device
DVI-to-HDMI
cable
Audio cable
AUDIO
OUT
DVI Video Device
Examples: Computer or Older A/V Device
Note:
• This connection can carry high-definition video
signals.
• The HDMI connection supports copy protection
(HDCP).
Connect a DVI device (digital only) to one of the TV’s
HDMI input jacks.
Required:
Analog audio cable with stereo mini-plug
DVI-to-HDMI cable or DVI/HDMI adapter and HDMI
cable
Some devices require a connection using an analog
output first in order to view on-screen menus and to
select DVI as the output. Please review your equipment
instructions for DVI connectivity and compatibility.
Antenna or Cable TV Service
Connect the incoming cable to the TV’s ANT input.
Reception over direct cable (no box) is limited to non-
scrambled analog and digital channels.
IN OUT
1
3D
GLASSES
EMITTER
ANT
1
L
R
DIGITAL
AUDIO
OUTPUT
3D
G
LASSE
S
EMITTER
ANT
1
1
L
R
R
D
IGI
T
AL
TT
AUDIO
OUTPU
T
ANT
ANT
Cable
TV
service
UHF/VHF
antenna
TV panel
Not recommended. Other connec-
tion types provide better quality
audio and video.
Direct cable (no cable box)
or
or
Older
cable
box
Composite Video Device
VCR or other device with composite video
output
Note: This connection does not support high-defini-
tion video signals.
Required:
Composite video cable (usually yellow)
RCA-type analog audio cables
3D
GLASSES
EMITTER
ANT
L
R
DIGITAL
AUDIO
OUTPUT
3D
G
LASSE
S
E
MITTE
R
AN
T
L
R
R
D
IGITAL
AUDIO
OUTPU
T
TV jack panel
L
R
L
R
DIGITAL
AUDIO
OUTPUT
D
IGITAL
AUDIO
OUTPUT
AUDIO OUT
COMPOSITE
VIDEO OUT
L
R
Audio
cables
VCR or other device
with composite
video output
Composite
video cable

2. TV Connections 17
For assistance call 1(800) 332-2119
A/V Receiver
Required:
Digital coaxial audio cable
To send audio from TV channels received on the
ANT
input or from devices connected directly to the TV, you
must use this connection.
The TV makes all incoming audio available as an output
in digital format on the
DIGITAL AUDIO OUTPUT jack:
• Analog incoming audio is available as output in
digital stereo format.
• Digital incoming audio is available as digital audio.
See page 9 for tips on using an external sound system.
COAXIAL
INPUT
OPTICAL
INPUT
CO
AXIAL
INPUT
O
PTI
C
AL
INPUT
COAXIAL
INPUT
3D
GLASSES
EMITTER
ANT
L
R
DIGITAL
AUDIO
OUTPUT
3D
G
LASSE
S
E
MITTER
AN
T
L
R
R
D
IGITAL
AUDI
O
OUTPU
T
DIGITAL
AUDIO
OUTPUT
DIGITAL
AUDIO
OUTPUT
Digital A/V
receiver back
panel
Digital
coaxial
cable
Note: On rare occasions, the audio portion of an
HDMI signal may be copy-restricted and can-
not be output from the TV as a digital signal.
A/V Receiver with HDMI Output
Required: One HDMI cable
This option allows you to view and hear content from
devices connected to an A/V receiver. The A/V receiver
can send audio and video to the TV over a single HDMI
cable.
You can add an optional audio connection from the
TV’s audio output. The optional audio connection
allows you to hear, through the A/V receiver, devices
connected to the TV only, e.g., an antenna on the
ANT
input.
See page 9 for tips on using an external sound system.
3D
GLASSES
EMITTER
ANT
L
R
DIGITAL
AUDIO
OUTPUT
3D
GLASSE
S
E
MITTER
AN
T
L
R
R
D
IGITAL
AUDI
O
OUTPU
T
DIGITAL
AUDIO
OUTPUT
1
HDMI
23
DIGITAL
AUDIO
OUTPUT
VCR
Cable
box
DVD
player
A/V receiver with
HDMI output
If your A/V receiver converts
all video signals for output
on HDMI, you can use any
connection types from
external devices (content
can be HD or SD video).
HDMI OUT
DIGITAL
AUDIO IN
TV
HDMI
cable
Digital coaxial audio cable

18 2. TV Connections
For assistance call 1(800) 332-2119
VCR or DVD Recorder to an
Antenna or Wall Outlet Cable
Required:
• Video cables
- Component video cables (red/blue/green)
or
- Composite video cable (usually yellow)
• RCA-type analog audio cables
• Two-way RF splitter
• Two coaxial cables
Note:
• Use composite video only if component
video or HDMI are unavailable. A
composite video connection cannot carry
high-definition video signals.
• If your recording device has an analog-only
tuner, you must use a digital converter box
to enable recording of digital broadcasts.
AUDIO OUT COMPOSITE
VIDEO OUT
COMPONENT
VIDEO OUT
L
R
3D
GLASSES
EMITTER
ANT
L
R
DIGITAL
AUDIO
OUTPUT
3D
G
LASSE
S
E
MITTER
AN
T
L
R
R
D
IGITAL
AUDIO
OUTPU
T
ANT
L
R
DIGITAL
AUDIO
OUTPUT
D
IGITAL
AUDIO
OUTPUT
ANT
L
R
ANTENNA
IN
or
TV panel
Incoming
cable
RF Splitter
DVD Recorder or VCR
Composite video cable
Component
video cables
Audio
cables

19
For assistance call 1(800) 332-2119
TV Features
3
The FAV key gives you quick access to favorite program
sources. Sources can be channels from the ANT input
or devices connected to the TV. You can store up to
nine favorites.
Sample Favorites menu. Switch to favorite channels or
inputs using number keys.
Adding Favorites
1. Press INPUT and switch the TV to the input you
want to add. If adding a channel, switch to
the ANT input and tune to the channel.
2. Press the FAV key.
3. Move the highlight to the number position you
want to assign to the channel or input.
4. Press ENTER .
Removing
1. While watching TV, press the FAV key.
2. In the Favorites menu, highlight the channel
or input you want to remove.
3. Press
CANCEL .
Tuning
1. While watching TV, press the FAV key.
2. Press the number key for the channel or input
you want.
FAV (Favorites) Sleep Timer
The Sleep Timer turns the TV off after the length of time
you set. To set the TV to turn on at a certain time of
day, see the Setup > Timer menu.
Setting the Sleep Timer
1. Press SLEEP .
2. Press SLEEP additional times to increase the time in
30-minute increments up to the maximum of 120
minutes.
3. Press EXIT or wait five seconds without pressing any
keys for the message to clear.
Viewing or Changing the Sleep Timer
1. Press SLEEP to display the on-screen message.
2. Press SLEEP additional times to change the time
before the TV powers off. To cancel the Sleep
Timer, press SLEEP repeatedly until OFF is dis-
played.

20 3. TV Features
For assistance call 1(800) 332-2119
3D Video
To display 3D content, your Mitsubishi TV requires:
• Active-shutter 3D glasses compatible with any one
of the following:
- A matching external synchronization emitter
connected to the TV’s back panel
-DLPlink
• A compatible 3D source device connected to the
TV via HDMI and outputting a 3D signal in one of
these formats:
- Frame Packing 1080p@24 Hz or 720p@60 Hz
- Side-by-Side(Half) 1080p@24/30/60 Hz,
1080i@60 Hz, or 720p@60 Hz
- Top-and-Bottom 1080p@24/30/60 Hz or
720p@60 Hz
- Checkerboard 1080p@60 Hz (lower resolutions
may be supported but will not fill the screen)
Initial Setup
1. If your 3D glasses came with a synchronization emitter,
connect the emitter to the 3D GLASSES EMITTER jack.
Place the emitter at the front of the TV where there is a
clear path to the glasses.
Note: No emitter is required if using DLP Link.
3D
GLASSES
EMITTER
ANT
L
R
DIGITAL
AUDIO
OUTPUT
3D
G
LASSE
S
E
MITTER
AN
T
L
R
R
D
IGITAL
AUDIO
OUTPU
T
3D
GLASSES
EMITTER
3D
GLASSES
EMITTER
3D
GLASSES
EMITTER
3D
GLASSES
EMITTER
2. Power on the TV and the source device.
3. Connect the source device to the TV’s HDMI input.
4. When the New Device Found screen displays,
name the input.
5. Press EXIT to close the New Device Found screen.
Use the Picture > 3D Mode
menu to enable 3D video.
Choice of Source Formats
If your device is not HDMI 1.4a
compliant, you must choose the
correct setting from this list.
Off
• Turns off 3D images; displays 3D
content as 2D (you may see two
images).
• Restores normal TV adjustment
options when viewing an ordinary 2D
signal.
Automatic
• Switches the TV to 3D mode and selects the
correct 3D format when the TV detects a 3D
signal from an HDMI 1.4a-compliant device.
• Automatically switches the TV out of 3D
mode when receiving a normal 2D signal.
(642 Series only)
