Mitsubishi MIrage 2019 User guide

2019 Owner’s Handbook

PLEASE PLACE COPIES OF THE FOLLOWING ITEMS IN THIS BOOKLET:
1. Pre-Delivery Inspection Form (Customer Copy)
2. Triple Diamond Delivery Checklist (Customer Copy)
3. Salesperson or Key Dealership Contact’s Business Card

1
Thank you for buying a Mitsubishi MIrage. There’s no doubt you’ve already realized how well
your car drives on the open road. What you may not know is all the great features that help
your car perform the way it does. In the pages ahead we’re going to run through the basics
and prepare you for the road.
We hope you will visit the Mitsubishi Owner’s site where we store the latest Mitsubishi news
and special offers. Here you can also keep track of your car’s warranty and servicing needs,
get Roadside Assistance Information and tap into other owner-centric details. Just log on to
WWW.MITSUBISHICARS.COM/OWNERSONLY.
Some of the information contained in this booklet may not be correct due to product changes which may
have occurred after the time it was published. Mitsubishi Motors North America, Inc. reserves the right to
make changes at any time, without notice, to prices, color, materials, specification and models.
TABLE OF CONTENTS
Driver’s View ................ Page 2
Controls .................... Page 4
Technology ................. Page 6
Air Conditioning and
USB Connection.............. Page 7
Audio/Bluetooth® ............ Page 9
Smartphone Link Display Audio (SDA)
(If Equipped) ............... Page 12
Mitsubishi Connect .......... Page 13
FAQ’s ..................... Page 14

32
DRIVER'S VIEW
1Side Mirror Adjustment ........... Page 5
2Headlights ..................... Page 5
3Windshield Wiper Lever........... Page 5
4Heated Seat Switch (if equipped) ... Page 6
5Cruise Control (if equipped)........ Page 5
6Multi-Information Display (MID) .... Page 6
7ASC Off Switch.................. Page 6
8Start/Stop Engine Switch
(if equipped with F.A.S.T.-KEY) .... Page 11
9Climate Controls ............... Page 11
10 Audio Remote Control Switch
(if equipped) .................. Page 12
11 Audio System ................. Page 12
12 Bluetooth®Controls (if equipped) .. Page 18 12
8
10
5
1
3
7
11
11
6
2
9
4

4CONTROLS
SIDE MIRROR ADJUSTMENTWINDSHIELD WIPERS (MIRAGE)
WINDSHIELD WIPERS (G4) HEATED SEAT SWITCH (IF EQUIPPED)
MIST The wipers will operate once.
OFF Off
INT Intermittent (speed sensitive)
LO Slow
HI Fast
MIST The wipers will operate once.
OFF Off
INT Intermittent (speed sensitive)
LO Slow
HI Fast
POSITION ACTION
HI For quick heating
NEUTRAL Heater off
LO Keeps seat warm
REAR WINDOW WIPER AND WASHER (MIRAGE)
Turn the knob
B
to operate the rear
window wiper.
INT The wiper operates continuously
for several seconds then operates
intermittently at intervals of about
8 seconds.
OFF
Washer fluid is sprayed, the wiper will
automatically operate 2 or 3 times.
B
The side mirrors can be adjusted when
the ignition switch is in the “ON” or “ACC”
position or the operation mode is put in ON
or ACC.
Move the lever
A
to the same side as the
mirror you wish to adjust.
A

Each time the multi-information
display switch is operated, the
buzzer sounds and the
multi-information display
changes between information
such as warnings, trip
odometer, average and
momentary fuel consumption,
distance range, etc.

5
CONTROLS
REGULAR HEADLIGHTS
Headlights and other lights on.
Parking, tail, front and rear
sidemarker lights, license plate
and instrument panel lights on.
All lights off.
A- CANCEL: Used to deactivate the set
speed driving.
B- RES + : Used to increase the set speed
and to return to the original set speed.
C- SET – : Used to reduce the set speed and
to set the desired speed.
D- ON/OFF: Used to turn on and off the
cruise control.
CRUISE CONTROL (IF EQUIPPED)
NOTE: Then operating the cruise control switches, press the cruise
control switches correctly. The set speed driving may be deactivated
automatically if two or more switches of the cruise control are pressed at
the same time. Minimum speed to operate cruise control is about 25 mph.
A
B
C
D
1. TEMPERATURE INDICATOR LAMP ILLUMINATED GREEN
When the temperature indicator lamp is illuminated
Green this indicates the engine has not reached normal
operating temperature.
NOTE: This will result in cooler heater outlet temperatures
until engine reaches normal operating temperatures.
2. TEMPERATURE INDICATOR LAMP OFF
When the temperature indicator lamp is Off this indicates
the engine is at normal operating temperature.
3. TEMPERATURE INDICATOR LAMP ILLUMINATED RED
When the temperature indicator is illuminated Red this
indicates the engine is overheating
NOTE: If the engine is overheating, find a safe place
to park the vehicle, then shut the engine off and call
Roadside Assistance as continued driving could cause the
engine to fail.
TEMPERATURE INDICATOR LAMP OPERATION

6
When the vehicle is placed in Reverse, the rearview
camera system automatically activates. A wide-
angle view behind the vehicle is shown.
REARVIEW CAMERA
(IF EQUIPPED)
While carrying the F.A.S.T.-KEY, press the driver’s door lock/unlock switch A.

Remove the manual key by releasing the key from the remote. Insert the key
into the door to unlock the door. Then to start the engine, place the remote
into the FAST Key slot located on the front center instrument panel.
 
OPERATION INDICATOR LIGHT
LOCK ( ) BUTTON
UNLOCK ( ) BUTTON
POWER LIFTGATE BUTTON
(IF EQUIPPED)
PANIC BUTTON
A

7

START/STOP ENGINE SWITCH (IF EQUIPPED WITH F.A.S.T.-KEY)
While carrying the F.A.S.T.-KEY within the
operating range, the Start/Stop Engine
Switch can be used to start the engine.
• Move the selector lever in “P” position
and hold the brake pedal down. Push
the Start/Stop Engine Switch.
• To stop the engine, stop the vehicle
completely and move the selector
lever to “P” then press the Start/Stop
Engine Switch.
*If you have to bring the engine to an emergency stop while
driving, press and hold the Start/Stop Engine Switch for 3
seconds or more, or press it quickly 3 times or more.
• If you press the Start/Stop Engine Switch without depressing
the brake pedal, you can change the operation mode in the
order of OFF, ACC, ON, OFF.
* If the engine cannot be started by depressing the brake
pedal, depress the brake pedal more firmly than usual with
the right foot. Then, press the Stop/Start Engine Switch.
• If the engine cannot be started or the operation mode cannot
be changed, check the position of the F.A.S.T.-KEY or the
battery performance of the F.A.S.T.-KEY.
You can deactivate the system by pressing down
the “ASC OFF” switch for 3 seconds or longer.
When the ASC is deactivated, the
display/indicator will turn on.
To reactivate the ASC, momentarily press the “ASC
OFF” switch; the display/indicator is turned off.


The Tire Pressure Monitoring System
light illuminates when one or more of
your tires is significantly under inflated.
Please note that changes in the outside
temperature may decrease tire pressure
causing the TPMS light to turn on. If the
TPMS light remains illuminated, check
your tire pressure. If the warning light
illuminates, take the necessary measures
referring to the owner’s manual.
ECO INDICATOR
This indicator will be displayed
when fuel efficient driving is
achieved.

8AIR CONDITIONING AND USB CONNECTION
MANUAL AIR CONDITIONING AUTOMATIC AIR CONDITIONING (IF EQUIPPED)
A- Temperature Control Dial/Switch
B- Air conditioning switch
C- Mode Selection Dial/Switch
D- Air Selection Lever/Switch
E- Blower Speed Selection Dial/Switch
F- Defogger switch
G- AUTO switch
H- Electric rear window defogger switch
I- OFF switch
CONNECTING A USB OR SMARTPHONE DEVICE (IF EQUIPPED)
CONNECTING A USB OR SMARTPHONE DEVICE
1. Park your vehicle in a safe place and turn the ignition switch to the “OFF” position or put the Operation
Mode in OFF.
2. Plug in the USB connecting cable that is supplied with your device and connect the USB end into the
input terminal located in the floor console box.
3. Turn the ignition switch or the Operation Mode to the “ACC” position. Turn on the audio system.
4. Press MENU on your Mirage’s audio touch screen.
5. Touch USB.
6. Touch Folder then select a track and begin playback. The phone and cord are not included in
the purchase of the vehicle.
B
F
C
G
D
H I
A E
B H
EA C
D
IF

9
AUDIO / BLUETOOTH®
LISTENING TO THE RADIO
A- Selects AM/FM
B- Selects type of Media
(MP3 and BT-A)
C- Phone
D- Power and Volume knob
E- Seek stations up or down
F- Returns to the initial display
G- Tune stations / adjust
sound settings
TO ADJUST THE CLOCK
1. Press the HOME key
2. Touch SETTING, then CLOCK
• The display changes to the clock setting where time
and format can be adjusted.
3. Touch SET
4. To return to the settings, touch BACK
5. The time setting change is completed
This HD Radio receiver enables:
PSD Program Service Data: Contributes to the superior user
experience of HD Radio Technology. Presents song
name, artist, station IDs, HD2/HD3 Channel Guide, and
other relevant data streams.
HD2/HD3 Adjacent to traditional main stations are extra local
FM channels. These HD2/HD3 Channels provide new,
original music as well as deep cuts into traditional
genre.
DIGITAL SOUND Digital, CD-quality sound. HD Radio Technology enables
local radio stations to broadcast a clean digital signal.
AM sounds like today’s FM and FM sounds like a CD.
A
E
B
C
D
F
G
To Register a Bluetooth®Device:
1. Press the HOME key
2. Touch SETTING, then BLUETOOTH
3. Touch the NEW DEVICES
(IF NO BLUETOOTH®DEVICES ARE REGISTERED, STEP 3 IS
NOT REQUIRED)
• If the Bluetooth®device is permitted to pair then it will
allow the connection to be made.
• Supports Ver. 2.1 + EDR
• Supported profiles: Bluetooth®Audio A2DP(V1.1),
AVRCP(V1.3); Hands-free HFP(v1.5); Phonebook transfer
PBAP(v1.0)
When Bluetooth®is connected, 3 icons will display – the
antenna level (1 to 6), battery, Bluetooth®connected (shown
on the HOME screen).
BLUETOOTH®INFORMATION
