1600 ANSI LUMENS 13 POUNDS SVGA
The S290U ColorView™ LCD projector from Mitsubishi offers the perfect
combination of performance, reliability and value. Whether in the classroom or
the boardroom, the fully-featured S290U is lightweight for portability but delivers
big, bold presentations. Plus, it’s so easy to operate you can concentrate on your
audience, not the projector.
■1600 ANSI lumens for super bright presentations
■Exclusive, award-winning ColorView Natural Color Matrix for rich, vivid colors
■Polysilicon three-panel LCD system; 800 x 600 SVGA native resolution
■Projects images from 40 inches to 300 inches; suitable for front, rear or ceiling
mount installations
■190-watt NSH lamp
■Point-’n-Zoom digital image magnification
■Picture-in-Picture with split screen from two sources
■Accepts S-Video, NTSC, NTSC 4.43, PAL, and SECAM video formats and
computer inputs from Apple, IBM, and many workstation computers
■Three-year parts and labor warranty, 90-day warranty on the lamp, toll-free tech-
nical support, plus a two-year Emergency Roadside Assistance (ERA) program
that guarantees free replacement product shipped overnight for next business
day delivery when and where available
COLORVIEW
PROJECTOR
S290U
The Perfect
Combination
Of Performance,
Reliability
And Value.

1600 ANSI LUMENS 13 POUNDS SVGA
S290U
COLORVIEW PROJECTORI
SPECIFICATIONS
Display 1.3" Polysilicon panel x 3
Resolution True SVGA 800 x 600 with compression for SXGA 1024 x 768, 560 video lines
Brightness 1600 ANSI Lumens
Colors 16,770,000 colors
Contrast Ratio 250:1
Zoom/Focus Electronically controlled (zoom ratio: 1.3 : 1)
Picture Size 40" ~ 300" diagonal
Lamp Type: 190 W NSH lamp
Computer Compatibility Windows based PC, MacIntosh, Sync on green
Video Compatibility NTSC/NTSC 4.43/PAL (including PAL-M, N)/SECAM, PAL-60 DVD (component)
Input Terminals RGB1: mini D-sub 15 pin x 2; PC audio: stereo mini jack x 2 (3.5mm); Video: BNC x 1 +
SVHS x 2 + RCA x 1; Audio: stereo RCA x 2
Output Terminals RGB: mini D-sub 15 pin x 1; Audio: stereo mini jack x 1 (3.5mm)
Communication Terminals RS-232C x 1 (direct command is available); wired remote terminal x 1
(3.5mm stereo mini jack); USB terminal x 1
Audio Speaker 2 W stereo
Scanning Rates Horizontal: 15 - 69 kHz, Vertical: 50 - 85 Hz, Dot clock: max. 100 MHz
Fan Noise 35 dB
Remote Control/Laser Pointer Wireless type with built-in laser pointer
Power Consumption 280 W
Dimensions (W x H x D) 11.6 x 4.8 x 13.8" (295 x 122 x 350 mm)
Weight 13 lbs. (5.9 kg)
Power Supply AC 100 ~ 240 V / ±10%, 50/60 Hz
Safety Approvals CSA, CSA NRT L/C, FCC Class-A
Warranty Three-year parts and labor; 90 days on lamp. Also includes two-year Emergency
Roadside Assistance program that guarantees free replacement projector shipped overnight
for next business day when and where available
Accessories Standard: AC power cable; RGB cable; RS-232C cable; USB cable; remote control; wired
cable for remote unit; mouse adapter (PC); lens cap; and user manual
Optional: Spare lamp (VLT-X300LP), hard carrying case (X300ATA), ceiling mount kit
(X300CM), Mac adapter (video and mouse)
Special Features ColorView Natural Color Matrix, CineView Video Line-Doubler, power zoom and focus
For more information on the S290U or any of Mitsubishi’s other projectors or presentation products, contact Mitsubishi
Digital Electronics today. Detailed technical specifications available upon request.
Projector Part Number: S290U
PP1079-11/01-5M-LITS290U
©2001 Mitsubishi Digital Electronics America, Inc. Standard features, options and specifications subject to change without notice.
Microsoft, Windows, and the Windows logo are registered trademarks of Microsoft Corporation. Mac and the Mac logo are trademarks of Apple Computer, Inc, registered in the
U.S. and other countries. All other trademarks or registered trademarks are the property of their respective holders.
Printed on 50% recycled paper including 20% post-consumer fibers, processed chlorine free. Printed with vegetable based inks.
Mitsubishi Digital Electronics America, Inc.
Presentation Products Division
9351 Jeronimo Road
Irvine, CA 92618
Toll Free: 888-880-6351
email: [email protected]
www.mitsubishi-presentations.com
Canada:
Mitsubishi Electric Sales Canada Inc.
Information Technologies Group
Markham, Ontario
905-475-7728
Technical Support:
Toll Free: 888-307-0309
Email: [email protected]
INPUT & OUTPUT
TERMINALS
DIMENSIONS
COLORVIEW™ NATURAL
COLOR MATRIX
Mitsubishi’s award-winning
ColorView enables the
S290U to produce vivid colors
that precisely match their real-life
counterparts, as well as giving you
the ability to precisely adjust color
saturation and control color tones.
Without ColorView With ColorView
Screen
S290U
Projection distance (Lw~Lt)
81
122
163
203
244
284
325
366
406
610
61
91
122
152
183
213
244
274
305
457
Screen size
155
235
315
394
474
564
634
714
794
1194
Wide (shortest)
Lw
195
296
396
496
597
697
797
898
998
-
Tele (longest)
Lt
Projection distance
H
Width
40
60
80
100
120
140
160
180
200
300
Inches Height
(H)
14.5"
9.73"
2.03"
.83"
13"
3.6"
3.88"
.63"
2.95"
5"
3.21"
11.77"
