Superior Brightness and Flexibility
at a Low Cost.
The SD110R offers exceptional performance, reliability and
quality at an affordable price. Designed for the mobile user
in-mind, this SVGA projector features a bright 1700 ANSI
lumens, 2000:1 contrast ratio, up to 4000 hours lamp life and
only weighs a total of 5.3 pounds. This DLP™ projector sup-
ports high quality data and video images and is backed by
Mitsubishi’s exclusive ERA and warranty program.
DLP™ technology
Native SVGA (800x600) resolution
1700 ANSI lumens
2000:1 High contrast ratio
Up to 4000 hours lamp life
Lightweight at only 5.3 lbs
3-years or 10,000-hours on the TI-DLP DMD Chip, 2-years parts and
labor, 2-years Express Replacement Assistance (ERA), 90-days or
300-hours lamp warranty
The SD110R is an excellent choice for
the cost conscious user who does not
want to compromise on performance,
quality and reliability.
www.mitsubishi-presentations.com
SD110R
SVGA DLPTM PROJECTOR

SCREEN DISTANCE FROM SCREEN (L) Hd
Diagonal Size Width Height Max.Zoom Min.Zoom
inch cm inch cm inch cm inch m inch m inch m
40 102 32 81 24 61 50 1.3 60 1.5 3.5 8.8 60 152 48 122 36 91 76 1.9 91 2.3 5.2 13.3 80 203 64 163 48 122 101 2.6 121 3.1 7.0 17.7
100 254 80 203 60 152 126 3.2 151 3.8 8.7 22.1 150 381 120 305 90 229 189 4.8 227 5.8 13.1 33.2 200 508 160 406 120 305 252 6.4 302 7.7 17.4 44.2 250 635 200 508 150 381 315 8.0 378 9.6 21.8 55.3 300 762 240 610 180 457 378 9.6 - - 26.1 66.3
Unit measured in millimeters (mm)
SD110R
DISPLAY TECHNOLOGY
RESOLUTION
BRIGHTNESS
CONTRAST RATIO
ZOOM/FOCUS
PROJECTION LENS
THROW RATIO
OFF SET AXIS
PICTURE SIZE
SOURCE LAMP
PC COMPATIBILITY
VIDEO COMPATIBILITY
INPUT TERMINALS
OUTPUT TERMINAL
COMMUNICATION TERMINAL
SCANNING RATE
AUDIO SPEAKER
HEIGHT ADJUSTER
HAND REMOTE UNIT
POWER CONSUMPTION
DIMENSION
WEIGHT
POWER REQUIREMENTS
FAN NOISE
SUPPLIED ACCESSORIES
OPTIONAL ACCESSORIES
WARRANTY
OUTSTANDING FEATURES
©2006 Mitsubishi Digital Electronics America, Inc. Standard features, options and specifications subject to change without notice. The DLP™ logo and DLP™ medallion are trademarks of Texas Instruments. Microsoft, Windows, and the Windows logo are registered trademarks of Microsoft Corporation. Mac and the Mac logo are trademarks of Apple Computer, Inc, registered in the U.S. and other countries. All other trademarks are the property of their respective holders. *The projector lamp contains mercury. Please dispose of properly. PP6014-03/06-15M-LITSD110R
Canada Mitsubishi Electric Sales Canada Inc. Information Technologies Group Phone: [phone] www.mitsubishielectric.ca MITSUBISHI DIGITAL ELECTRONICS AMERICA, INC. Presentation Products Division Toll Free: 888.307.0349 Email: [email protected] www.mitsubishi-presentations.com
SD110R SVGA DLPTM PROJECTOR
0.55", 1-Chip DMD, 12 deg. DDR, DDP2000 800 x 600 (Total 480,000 pixels), 500 Video Lines, 1024 x 768 Compressed 1700 ANSI Lumens 2000 : 1 Manual Focus & Zoom Lens F= 2.4 (Wide) 100"@3.2m (Wide) 1.56 - 1.87 7.9 : -1 up 40-300 (Diagonal) inch 200W (Shut Off Time 2000 Hrs) with Low Mode (160W: Shut Off Time 4000 Hrs) Resolution: 640 x 400 - 800 x 600 + Compressed 1024 x 768 Sync on Green available NTSC/NTSC 4.43/PAL (including PAL-M, N) /SECAM/PAL-60, Component Video; 480i/p (525i/p), 576i/p (625i/p), 720p (750p), 1080i (1125i 60Hz), 1080i (1125i 50Hz) RGB: Mini D-sub 15pin x 1 Audio: Stereo Mini Jack (ø 3.5mm) x 1 Video: RCA x 1 + S-VIDEO x 1 RGB: Mini D-sub 15pin x 1 Audio: Stereo minijack (ø 3.5mm) x 1 USB terminal for Page Up/Down mouse control [H] 15 - 80 kHz, [V] 50 - 85 Hz, [Dot Clock] max 110 MHz 2 W Mono Rear tilt leg x 2 Power Point™ Page Up/Down mouse control, Full Projector control 280W/2.9A 10.27 x 8.58 x 3.43 inches (L x W x H) 5.3 lbs. (2.4 Kg) AC 100-240V, 50/60 Hz 34 dBA (Low mode: 29 dBA) • Remote control (with 2 batteries) • Power cable • VGA (D-sub) 15pin cable • Composite video cable • Owner’s manual (CD-ROM) • Safety manual • Quick start manual • Lamp (VLT-XD110LP) • Wheeled ATA Approved Shipping Case (DKT1-ATAC) • Ceiling Mount (PROJ-UCM) • Learning remote (R-SC1) 3-years or 10,000-hours on the TI-DLP DMD Chip, 2-years part and labor, 2-years Express Replacement Assistance (ERA), 90-days or 300-hours lamp warranty • Quick shutdown/start • Digital keystone (vertical) • Video line doubler • 3D-Y/C • 10 languages OSD • Menu password lock • Anti-theft security hook for Kensington lock
