Mitsubishi SD105U User manual

Quality and Versatility Made Affordable
Native SVGA resolution (800x600)
DLP®technology
Bright 1600 ANSI lumens and 1800:1 contrast ratio
Lightweight design
Anti-theft security anchor
Filter-free design
Up to 4000-hour lamp life*
* low mode rating
SD105U
VERSATILITY AND VALUE
DLP®ULTRAPORTABLE SVGA PROJECTOR
www.mitsubishi-presentations.com
Mitsubishi SD105U is a value DLP®projector that offers SVGA
resolution, a bright 1600 lumens and rich 1800:1 contrast in a
small, light-weight package just over 6 lbs.
Enjoy all the essential features you’d come to expect of what
Mitsubishi projectors can offer at a highly affordable price.
Versatile features such as menu locks, security anchors, and
external monitor hook-up easily make Mitsubishi SD105U the
new classroom favorite for even the most budget-conscious
schools. Plus, an available serial RS232C port enables easy controls,
and full integration with interactive white board systems.
Mitsubishi SD105U continues our commitment to offer projectors
that come with a low cost of ownership through its low maintenance,
filter-free design, and a longer lamp life of up to 4,000 hours when
used in low mode. When you consider the time and cost savings of
not having to maintain filters, replace lamps as often, a generous
Express Replacement Assistance (ERA) warranty, plus the proven durability
of DLP®technology in projectors, the SD105U is one smart investment
for you and your organization.
FILTER-FREE
DESIGN

SCREEN DISTANCE FROM SCREEN (L) Hd
Diagonal Size Width Height Max.Zoom Min.Zoom
inch cm inch cm inch cm inch m inch m inch cm
40 102 32 81 24 61 56 1.4 60 1.5 3.5 8.8
60 152 48 122 36 91 85 2.2 91 2.3 5.2 13.3
80 203 64 163 48 122 113 2.9 122 3.1 7.0 17.7
100 254 80 203 60 152 142 3.6 153 3.9 8.7 22.1
150 381 120 305 90 229 214 5.4 229 5.8 13.0 33.1
200 508 160 406 120 305 285 7.2 306 7.8 17.4 44.2
250 635 200 508 150 381 357 9.1 383 9.7 21.7 55.2
300 762 240 610 180 457 429 10.9 - - 26.1 66.3
Unit measured in inches. *Hd is distance from lens axis to image bottom.
Unit measured in millimeters (mm)
SD105U
SD105U DLP™ ULTRAPORTABLE SVGA PROJECTOR
©2006 Mitsubishi Digital Electronics America, Inc. Standard
features, options and specifications subject to change without
notice. All trademarks are the property of their respective holders.
PP6053-11/06-15M-LITHL650U
Canada
Mitsubishi Electric Sales Canada Inc.
Information Technologies Group
Phone: [phone]
www.mitsubishielectric.ca
MITSUBISHI DIGITAL ELECTRONICS AMERICA, INC.
Presentation Products Division
Toll Free: 888.307.0349
Email: [email protected]
www.mitsubishi-presentations.com
• Lens cap
• Safety Manual/Quick Start Guide
• User Manual CD
• Carrying Bag
DISPLAY TECHNOLOGY
RESOLUTION
BRIGHTNESS
CONTRAST RATIO
ZOOM/FOCUS
PROJECTION LENS
THROW RATIO
OFF SET AXIS
PICTURE SIZE
SOURCE LAMP
PC COMPATIBILITY
VIDEO COMPATIBILITY
INPUT TERMINALS
OUTPUT TERMINAL
COMMUNICATION TERMINAL
SCANNING RATE
AUDIO SPEAKER
HEIGHT ADJUSTER
HAND HELD REMOTE
POWER CONSUMPTION
DIMENSION
WEIGHT
POWER REQUIREMENTS
FAN NOISE
SUPPLIED ACCESSORIES
OPTIONAL ACCESSORIES
WARRANTY
OUTSTANDING FEATURES
0.55" 1-Chip DMD, 12deg.DDR, DDP2000
800 x 600 (Total 480,000 pixels), 500 Video lines
1600 ANSI lumens
1800 : 1
Manual Focus & Zoom Lens (Zoom Ratio 1.1:1)
f=19.9-21.4 mm, F=2.5(Wide/Tele), 11.8"-12.79"@100" diagonal
1.8-1.9
7.9 : -1 up (No variable lens shift)
40-300 inches diagonal
Normal Mode: 160W (Shut Off Time: 3000hrs), Low Mode:128W (Shut Off Time: 4000hrs)
Resolution; 640 x 400 - 800 x 600 + Compressed 1024 x 768
Sync on Green available
NTSC / NTSC 4.43 / PAL (including PAL-M, N) / SECAM / PAL-60
Component Video; 480i/p(525i/p), 576i/p(625i/p), 720p(750p), 1080i(1125i 60Hz),
1080i(1125i 50Hz)
RGB: Mini D-sub 15pin x 1, Audio: Stereo mini jack (ø3.5mm) x 1
Video: RCA x 1, S-VIDEO x 1
RGB: Mini D-Sub 15pin x 1, Audio: Stereo mini jack (ø3.5mm) x 1
RS-232C D-Sub and Page Up / Down (USB)
[H] 15 - 80 kHz
[V] 50 - 85 Hz
[Dot Clock] max.110 MHz
2W Mono
Frontward lifting leg x 1
Full Projector Control, MS PowerPoint™ Page Up/Down via USB (cable not included)
260 W (100V AC) / 2.6 A, Standby: Less than 10W
8.8" x 10.1" x 3.5" (223 x 256 x 88 mm) (W x H x D)
6.39 lbs. (2.9 kg.)
AC 100-240V, 50/60Hz
34 dBA (Low mode: 32 dBA)
• Power Cable
• VGA (D-sub) Cable
• Composite Cable
• Remote Control Unit with Batteries
• Replacement Lamp (VLT-SD105LP)
• Ceiling Mount (PROJ-UCM or PROJ-UCM-PRO)
• Wireless LAN Unit (MA-WL-DVI)
2-Years Limited Parts and Labor Warranty, 2-Years Express Replacement Assistance (ERA),
90-Days lamp warranty, 3-Years or 10,000-hours on the TI-DLP® DMD Chip (Main
imaging device)
• Digital keystone-correction for Vertical
• Video Line Doubler (DDP2000); 2:3 pull-down
• Instant Shutdown
• Anti-theft security anchor
• 10 languages OSD
• Password protected menu access
