CECILIA semplice – Romantic:
instructions for use
Description
MIDI expander with 11 true stops containing real sound samples of romantic organ. The registers are divided into two
groups: manual and pedalboard. The choice of registers is carried out by means of illuminated push buttons; all
functions and settings are accessible via display and cursor buttons.
Disposition:
The stops consist of the top uality samples of Sonus Paradisi project, disposition is inspired by French romantic style:
Pedal Manual
• Soubasse 16' • Bourdon 16'
• Contre-basse 16' • Prestant 8'
• Accouplement (couple) • Bourdon8'
• Flûte Harmoni ue 8'
• Voix Céleste 8'
• Prestant 4'
• Octavin 2'
• Carillon
• Basson-Hautbois 8'
Technical parameters:
•Supply: adapter 12 V/1 A.
•Extra galvanic isolation.
•Input USB MIDI IN: 5-pin DIN connector available via MIDI/USB converter.
•Stereo audio output: 6.3 mm JACK.
•Manual range: 60 tones (C-c4).
•Pedal range: 30 tones.
•Adjustable additional prolongation of reverberation.
•Polyphony: 250 parallel samples.
•Latency: <15 ms.
•Dimensions: 220x103x53 mm.
•Weight: 0.7 Kg

Module functions:
•Four memories for stop combinations.
•Loudness level indication in the real time, limitation indicator.
•Safe limitation – the exceeding limitation results gradually in the decreasing sound uality, but no sudden
disturbing effects (cracking…) occur.
•Setting of the total loudness, setting of individual registers' loudness.
•Setting of true tone height (pitch shift) continually (± one semitone).
•Three temperament systems: e ual, ¼ coma middle tone, Young well tempered tuning.
•Reverberation time: there is possibility to extend reverberation with artificial algorithm in several levels or
completely disable reverb (dry samples).
•Setting of an arbitrary intonation deviation of virtual pipes from their nominal values. Using smaller intonation
deviations, a more realistic sound can be obtained. During the switching on of the module, the distribution of
deviations in each specimen changes randomly within the given tolerance limits.
•Function “dynamic pressure“. Particularly in the case of smaller organs, fine changes in pressure during the
play dependent on the actual air consumption are typical and result in the deviations of intonation. The module
contains the algorithm with optional parameters simulating these pressure changes.
•Automatic matching of MIDI channels via “MIDI listen“ function.
•“MIDI learn” functions for all stops and couples. It is possible to use individual stops or their combinations
using external MIDI device. Moreover there is a possibility to use any key from a playing manual (e.g. upper
octave of a keyboard) to toggle stops or their combinations.
•Restoration of manufacture setting – all optional parameters can be rewritten by the original values of
manufacturer, if necessary.
Switching on
The e uipment is powered from 12 V/1 A adapter. After the adapter has been connected, the all LEDs under push
buttons light up. Within several seconds the sound samples are recorded and the inscription “ Reading samples please
wait…“ appears at the display. The module is ready as long as the small dot in the bottom corner appears on the display.
Connection of audio output, MIDI equipment and setting MIDI channels
The module is intended for one MIDI keyboard with possibility of added MIDI pedalboard. Thus, it is possible to match
each register group with its own independent channel. As the module enables the automatic selection of MIDI channels,
it is not necessary to know the corresponding channel number.
1. Connect earphones or amplifier to JACK 6.3 stereo audio output. The module has a galvanic isolated power;
thus, when the amplifier is used, the effect of earth loop remains suppressed.
2. Connect “MIDI IN” connector of USB/MIDI cable to MIDI OUT connector of the digital organ, keyboard or
another MIDI e uipment.
3. Connect opposite end of the USB/MIDI to USB connector in the back side of the CECILIA organ module.
Instead of USB/MIDI converter there is possible to use USB cable directly – for keyboards with the USB
output.
WARNING: due to many various implementations of USB-MIDI standard direct USB connection can be in
rare cases problematic and we cannot guarantee compatibility with every USB keyboard.
4. In the menu, choose “Set MIDI“ and press “OK”. According to your choice of register group with which the
MIDI channel should be matched, choose via vertical arrays one of items “Set MAN channel?“, “Set P
channel?“. After the OK button has been pressed, the inscription “Press a … tone“ appears – it means that the
system is waiting for the MIDI message.
5. Press any tone on the manual (pedalboard) – the corresponding MIDI channel is stored into e uipment
memory. As long as the inscription “Press a … tone“ lights, it means that no MIDI message has been
received. Check the connection of MIDI cable up and verify the right setting of your keyboard for MIDI
transmission.
6. For the next register group, repeat steps 4 and 5.
Use of the module
After the MIDI channels have been set, the module is ready to play. For registration, simple push buttons are used. The
stop is activated when the particular LED is lighting. Except of this, all stops and couples (and their combinations) are
possible to control via any MIDI message.
Any stop combination can be saved into the memory. Just press and hold any memory button (1-4). In a moment the
particular LED blinks – the combination of stops is saved.
After the “OK“ button has been pressed, the items of menu (functions) are accessible. By means of horizontal cursor

arrows, the chosen item is set; its value is set by means of vertical arrows. A rapid change of the value can be carried out
by holding the vertical arrow. Particular sub-menu (when present) is accessible by “OK” button. For return to the basic
level, “esc“ button is used. The setting of all functions takes place in the real time and can be changed during the play.
Actual values of setting are immediately stored in the e uipment memory and, thus, they are valid after the repeated
switching on. The restoration of all parameters to the original values given by manufacturer is uite simple.
The first item in the menu is the level indicator. With the help of this indicator in the lower line, the total sound level is
indicated dynamically. In the case of too high setting of total loudness and many switched on registers, the limitation
can be reached. This state is indicated by “!!!!!!!!!!!!“ sign on the display. The limitation manifests itself by a
deterioration of the sound uality and should not be reached too often; thus, the setting of loudness level should meet
this condition. On the other hand, an occasional occurrence of limitation is hardly to notice.
Description of menu items
1. “Level“: level indicator for correct sound level setting.
2. “Pitch (cents)“: setting of the height of total tuning in cent units (-99 – +99).
3. “Master vol. (%)“: total loudness level (0 – 100).
4. “Temperament“: tuning type (e ual, ¼ coma middle tone, Young well tempered tuning).
5. “Randomize tuning“: setting of tuning tolerance of pipes in cents. Within the framework of this tolerance,
virtual pipes are put out of tune randomly (0 – 100).
6. “Reverb level“: (0-8) – when set “0”, sampled release is disabled. It is convenient for spaces with good
natural acoustic. Degree “1” enables natural sampled release for every pipe. The next levels are adding extra
reverberation using mathematical model.
7. “Dynamic pressure“
1. „Dynam. pr. size“: setting of the time constant of dynamic pressure effect (0 – 100). The effect is
switched off as long as this item is set on zero. Too high values can deteriorate the reality of this effect.
2. „Dynam. pr. depth“: setting of the fre uency response of dynamic pressure effect (0 – 100). The effect is
switched off as long as this item is set on zero. Too high values can deteriorate the reality of this effect.
8. “Stops volume“
1. “Vol:Bourdon 16”: setting of loudness level of individual stops (0 – 100): 11 stops altogether.
2. …
9. “Set MIDI“
1. “Set Ped. channel?”: setting of a MIDI channels for pedal.
2. “Set Man. channel?”: setting of a MIDI channels for manual.
3. “MIDI:Bourdon 16?”: setting of a control MIDI message for control particular stop/couple/memory
button.
4. …
15. “Reset con. MIDI?”: reset control MIDI setting for individual stops/couples/memory buttons.
10. „Restore setting“: restore of original setting – the values of all items will be replaced by manufacturer setting.
Setting of control MIDI for individual stops/couples
It is possible to control every stop/couple by any MIDI message. Every stop has its menu item for this purpose (see
menu structure above). By vertical arrays is possible to choose activities “listen stop ON”, “listen stop OFF” or
“disable MIDI” (to reset control MIDI of particular stop). After pressing “OK” the device is listening some MIDI
message. When the first MIDI message comes, it is paired to particular activity. Two different MIDI messages can be
used for stop ON or stop OFF. When the both activities get the same MIDI message, the message is automatically used
for toggling the stop ON/OFF.
One MIDI message can control more stops/couples simultaneously. It is convenient for simple stop combinations. After
assigning more stops to one MIDI message toggling them, switching all stops off by “G.C.” button is necessary. It
prevents the state, when the same button (key) is toggling some stops on and the other stops off in one moment.
Example 1 – using digital organ:
Majority of commercial digital organ and consoles transmit MIDI messages when stop buttons are used. In this case
stop tabs (buttons) can be used for control stops of Cecilia module. Just choose some stop/couple from menu, choose
activity (stop ON) and activate some stop button at digital organ. Particular MIDI message will be paired. Of course, it
is necessary also to set an event for stop off. Just use stop OFF function and deactivate the stop tab/button at digital
organ.
Example 2 – using simple keyboard:
In the case of using Cecilia module with simple keyboard only there is possible to set any tone for toggling stops.
Typically several tones in upper octave are rarely used for playing and can be used for effective switching stops. For
uick changing of stop combinations it is convenient to map particular memory buttons for switching via some keys.

Switching off
The module is switched off using “OFF“ button. Press an hold the button for several seconds, the inscription “Unplug
device“ appears. Then, unplug the module from the power supply. In principle, do not disconnect the e uipment from
the power supply without previous safe switching off by the button (the e uipment shall not be unplugged from the
power supply without previous safe switching off by the button).
WARNING:
The module shall not be switched on without supervision; before you leave unplug it from the
power supply.
