Mobelli One Touch Umbrella User manual

ASSEMBLY INSTRUCTIONS
One Touch Umbrella

ASSEMBLY INSTRUCTIONS
One Touch Umbrella
ACCESSORIES
Screw 1 B D E 1 Set
Screw 2 A C E 1 Set
Screw 3 G H J 4 Sets
Screw 5 F E 1 Set
Screw 6 K E 1 Set
Screw 7 K E 1 Set
Screw cap L 4 Pc Stopper cap M 1 Pc
TOOLS
Adjustable
spanner /
wrench
(not supplied)
Allen Key
(1 pc)
10mm 10mm wrench
(not supplied)
Handlebar
(1 Set)
Umberlla Top
Sidearm
Screw 1
Screw 2
Screw 3 x 4
Screw 5 Screw 6
Screw 7
Stopper cap
Plastic base
Prepare at least 100kg of sand to fill umbrella base.
• Assemble plastic base. See page 2.
• Screw all parts. See page 3-4.
• Connect the umbrella to the base.
• Open umbrella slowly.
PROTECTION COVER
(Optional)
Remove the protective
cover before assembly.

BASE PREPARATION
Sand
Sand
Fill up the plastic base with at
least 100kg of sand.
Add water and small stones for
further stability.
Stopper cap M
WARNING:
Do not pour sand into
the 4 screw wells.

ARM ASSEMBLY
A x 1 C x 2 E x 3
B x 1 D x 2 F x 1
Base plate
connection
E
E
D
D
C
C
A
B
Arm connection
detail
E
F
G x 4 H x 4 J x 4
Connecting the arm to the plastic base

Tilt the arms of the umbrella forward and connect the
remaining bolts to the base plate.
K x 2 E x 2
K
K
E
E

SMALL BASE
COVER Place the screw caps on exposed
screw head
L x 4
OPENING
Open the umbrella top.
Push the umbrella slowly
to open.

ROTATING
TILTING
LOOSE
Push the lever in the centre of
the umbrella to the horizontal
position. Take the end of a rib
and push or pull the cover to
desired tilt position.
FIXED
Always pull the lever to the
fixed position when the
umbrella is in use.

Redefining the value of style
mobelli.co.za | 0861 66 23 55
Paarden Eiland | Sea Point | Illovo | Fourways | Umhlanga Ridge
CLOSING
MOVING
Release the lever to the loose
position.
Press the plastic bar and
push the umbrella to
close. Place protective
cover when not in use.
Rotate the handle bar to
lift and lower wheels.
