MODEL MAKER DA450 Installation and operating instructions

Thank you for purchasing the Model Maker™DA450 airbrush. This manual
contains the instruction you need to use and maintain your new airbrush. Read
over this manual thoroughly before operating the Model Maker airbrush.
• Never spray near an open flame.
• Always wear an adequate respirator when using the paint gun.
• Always spray in a well ventilated area.
• Never spray near an item where overspray can get on them and
cause damage.
• Always properly maintain you paint gun to achieve optimal performance and
extended life of the paint gun.
• Never allow children to use the paint gun without adult supervision.
• Always properly dispose of excess paint in the proper location.
• Always use caution when handling the needle. It is extremely sharp and
easily damaged.
• Always shut off the air source before disconnecting the air hose.
• Always disconnect the air hose from the air source before disconnecting it
from the paint gun.
Remove the DA450 airbrush from the plastic storage case. Thread the
small end of your airbrush hose onto the bottom of the airbrush. Attach the
other end of the hose to the air source (air compressor/propellant).Make sure
the hose is securely installed at both ends to prevent air leaks.If attaching to
an air compressor, set the regulator between 25 and 40 psi depending on the
type of paint that you are using.This is a general starting point and will vary
from paint to paint.You will have to find the psi setting that works best for you
and your paint.
Remove the color cup or jar assembly from the plastic storage case. If
using the color cup, install it onto the body of the airbrush. Make sure it is
securely in place to prevent it from falling off during use.Add the desired paint
to the color cup. If using the jar assembly, add the desired paint to the jar and
securely attach the jar nozzle assembly to the jar. Attach the jar assembly to
the airbrush. Again, make sure the jar is securely attached to the body of the
airbrush to prevent it from falling off during use.
Gently press the airbrush trigger down. This regulates how much air is
being sprayed through the airbrush. With the trigger slightly compressed,
gently start to pull back on the trigger. You should start to notice paint
beginning to spray out of the airbrush.
You should practice with the airbrush on a scrap piece of paper or
cardboard. Make various strokes with the airbrush, varying the amount of air
and paint being sprayed.This will help you achieve the desired spray pattern.
For small, thin lines, use more air and less paint, holding the airbrush
slightly closer to the surface.To achieve larger lines, add more paint with the air.
To change colors while using the color cup, simply drain the excess
from the color cup into an acceptable container. Then remove the color cup
from the airbrush and wash it out using airbrush cleaner or lacquer thinner.
Again, this depends on the type of paint being used. Flush the remainder of
the previous color out of the airbrush using the necessary cleaner. Re-install
the color cup onto the airbrush and pour in the new color.
To change colors using the jar assembly simply remove the jar from the
airbrush. Pour the remainder of the color in the jar back into its original
container. Thoroughly clean the jar and jar nozzle assembly using the
included cleaner or lacquer thinner depending on the type of paint being
used. Flush the remainder of the previous color out of the airbrush using the
necessary cleaner.Pour the new color into the jar and securely attach the jar
nozzle assembly. Secure the jar assembly to the airbrush.
Note: The process of changing colors goes faster if you have a
separate jar assembly filled with the proper cleaner to flush the airbrush out
between colors.
Properly cleaning and maintaining your airbrush is vital to the continued
consistent performance of the airbrush. The airbrush must be thoroughly
cleaned out after each use to prevent dried paint in the passages.
If you are using water based paints:
After you have finished spraying a color, you should detach the color
cup and spray the remaining paint in the airbrush onto a scrap piece of paper.
Then flush the airbrush out with airbrush cleaner.(Window cleaner will act as
a suitable substitute.) When flushing the airbrush out, make sure to spray
both fine and broad patterns, working the needle back and forth.This will help
get as much of the leftover paint out as possible.
If you are using a paint that requires lacquer thinner for clean-up:
After you have finished spraying a color, you should detach the color
cup and spray the remaining paint in the airbrush onto a scrap piece of paper.
Then flush the airbrush out with lacquer thinner. When flushing the airbrush
out, make sure to spray both fine and broad patterns, working the needle
back and forth.This will help get as much of the leftover paint out as possible.
BETWEEN COLORS
MAINTENANCE
CHANGING COLORS
OPERATION
SAFETY PRECAUTIONS
DA450
Airbrush
ASSEMBLY AND OPERATION MANUAL
READ THROUGH THIS MANUAL BEFORE USING YOUR AIRBRUSH. IT CONTAINS IMPORTANT INSTRUCTIONS AND
WARNINGS CONCERNING THE USE OFTHIS airbrush.
If the buyer is not prepared to accept the liability associated with the use of this product, the buyer is advised to return it
immediately in new and unused condition to the place of purchase.
© Copyright 2004 HCAR4014
™

Remove the air hose from the airbrush so that it is easier to work on. Remove
the handle from the body of the airbrush.
Remove the needle locking nut from the airbrush.This should allow you to remove
the needle from the rear of the airbrush assembly. Be careful not to damage the
needle when removing it from the airbrush assembly.
A good quality masking tape or Hobbico®Master Mask™liquid are both
good masking materials.The job should be evaluated and then decide which
will work best for each situation.Make sure to properly seal the masking tape
down to prevent bleeds. If using Hobbico Master Mask, make sure you follow
the instructions on the container.Using too little of the Master Mask will cause
problems when you try to remove it.
Model Maker warrants this product to be free from defects in material and
workmanship for a period of one (1) year from the date of purchase. During that
time, we will repair or replace, at our option, any product that does not meet these
standards,You will be required to provide proof of purchase date (receipt with UPC
proof-of-purchase or invoice).
If, during the one year warranty period, your Model Maker product shows
defects caused by abuse, misuse, or accident, it will be repaired or replaced, at our
option, at a service charge not greater than 50% of the current retail list price. Be
sure to include your daytime telephone number in case we need to contact you
about your repair.
Under no circumstances will the purchaser be entitled to consequential or
incidental damages.
This warranty gives you specific legal rights, and you may also have other
rights, which vary from state to state.
If you attempt to disassemble or repair this unit yourself, it may void
the warranty.
For service on your Model Maker product, either in or out of warranty, send
it post paid and insured to:
Hobby Services
3002 N. Apollo Drive, Suite 1
Champaign IL 61822 USA
[phone]
www.hobbyservices.com
This warranty applies to USA and Canada only. For service in other
countries, please inquire at the place of purchase.Customers residing outside the
USA and Canada who wish to have service performed at our USA service center
will be responsible for all postage charges.
This product contains a chemical known to the State of
California to cause cancer and birth defects or other
reproductive harm.
WARRANTY
MASKING
AFTER EACH USE
1HCAR4201 NEEDLE CAP
2HCAR4202 NOZZLE CAP
3HCAR4203 NOZZLE 0.2MM
3HCAR4204 NOZZLE 0.3MM
4HCAR4205 SPRAY NOZZLE ASSEMBLY
5HCAR4206 PISTON O-RING
6HCAR4207 TEFLON SEAL
7HCAR4208 BODY
8HCAR4210 TEFLON SEAL
9HCAR4211 LOCK SCREW
10 HCAR4212 FIXED NUT
11 HCAR4213 BODY SCREW
12 HCAR4214 NEEDLE CHUCK
13 HCAR4215 NEEDLE SPRING
14 HCAR4216 SPRING STOP
15 HCAR4217 NEEDLE 1.2MM
15 HCAR4218 NEEDLE 1.4MM
16 HCAR4219 NEEDLE STOP SCREW DA450
17 HCAR4221 TAIL CAP DA450
18 HCAR4223 NEEDLE ADJUSTER
19 HCAR4224 PUSH BUTTON
20 HCAR4225 PISTON
21 HCAR4226 BACK LEVER
22 HCAR4227 PISTON O-RING
23 HCAR4228 AIR VALVE O-RING LARGE
24 HCAR4229 AIR VALVE CASING
25 HCAR4230 AIR VALVE O-RING SMALL
26 HCAR4231 AIR VALVE PIN
27 HCAR4232 AIR VALVE SPRING
28 HCAR4233 VALVE PIN GUIDE
29 HCAR4234 AIR TUBE ASSEMBLY
32 HCAR4235 JAR ADAPTER
33 HCAR4236 JAR 22CC
35 HCAR4244 WRENCH
36 HCAR4239 TUBE
PROBLEM: The paint gun does not spray when the trigger is pulled.
SOLUTION:
1.The paint may be too thick.
2.The PSI may be too low.
3.The paint gun may be clogged.
PROBLEM: The paint pulsates.
SOLUTION:
1.The nozzle is loose on the body.
2.The air hole in the top of the jar assembly is plugged.
PROBLEM: The trigger action is rough.
SOLUTION:
1.The needle is bent.
2.The paint gun needs cleaned.
PROBLEM: Paint bubbles in the color cup.
SOLUTION:
The paint gun is clogged.
PROBLEM: The paint sprays out grainy.
SOLUTION:
The paint is too thick. Gradually thin the paint using the proper solution.
PROBLEM: Splattering.
SOLUTION:
This is caused by letting the tip snap back into place. Always release the trigger gently.
TROUBLE SHOOTING
