Morphy Richards MRICE17SS User manual

Model: MRICE17SS
INSTRUCTION MANUAL
Read these instructions carefully before
using this appliance for the rst time.
STORE THESE INSTRUCTIONS CAREFULLY
Nugget Ice Maker
For product hints and tips plus more join us at
facebook.com/MorphyRichardsAUS instagram.com/morphyrichardsau
www.morphyrichards.com.au

2
WARNING
To reduce the risk of fire, electric shock, injury to persons or
damage to property, follow basic precautions including the
following:
• WARNING: Misuse of appliance could cause personal injury.
• Do not remove any safety, warning, or product information
labels from your ice maker.
• Check your ice maker to ensure it is in good condition and that
there is no damage to the ice maker, power cord or plug.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
• This appliance is intended to be used in household and similar
applications such as
–staff kitchen areas in shops, offices and other working
environments;
–farm houses and by clients in hotels, motels and other residential
type environments;
–bed and breakfast type environments;
IMPORTANT SAFETY INSTRUCTIONS

3
• WARNING: Do not store explosive substances such as aerosol
cans with a flammable propellant in this appliance.
• WARNING: Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
• WARNING: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
• WARNING: Do not damage the refrigerant circuit.
• WARNING: Do not pour coloured drinks or congee drinks into
the machine (including the water tank and ice tray).
• WARNING: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are of the
type recommended by the manufacturer.
• WARNING: Do not locate multiple portable socket-outlets or
portable power supplies at the rear of the appliance.
• WARNING: When disposing of the appliance, do so only at an
authorized waste disposal centre. Do not expose to flame.
• WARNING: This appliance contains a small quantity of R600a
refrigerant which is flammable.
• WARNING: It is hazardous for anyone other than an Authorised
Service Person to service this appliance. In Queensland - the
authorised Service Person MUST hold a Gas Work Authorisation
for hydrocarbon refrigerants to carry out servicing or repairs
where the gas system is being opened or charged.
WARNING: The refrigerant isobutene (R600a)
is contained within the refrigerant circuit of the
appliance, a natural gas with a high level of
environmental compatibility, which is nevertheless
flammable. During transportation and installation of
the appliance, ensure that none of the components of
the refrigerant circuit becomes damaged.

4
If the refrigerant circuit should be damaged:
• Avoid opening flames and sources of ignition.
• Thoroughly ventilate the room in which the appliance is
situated.
Location
• Before using the Ice Maker for the first time, please wait 2 hours
after positioning it, and keep the transparent lid open for at
least 2 hours.
• For indoor use only. Do not use outdoors or near water.
• Always locate your appliance away from the edge of the
worktop.
• Do not upend this product or incline it over a 45° angle. Ensure
that the appliance is used on a firm, flat surface.
• Keep the appliance 15cm from other objects to ensure the heat
generated is heat released.
• Do not use the appliance close to flames, hot plates or stoves.
Power cord
• WARNING: When positioning the appliance, ensure the power
cord is not trapped or damaged.
• The power cord should reach from the socket to the appliance
without straining the connections.
• If the power cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
• Remove the plug from the socket, grasp the plug and pull out
the power cord, do not pull on the cord directly.

5
• Do not let the cord hang over the edge of a table or counter and
keep it away from any hot surfaces.
• Do not let the cord run across an open space e.g. between a
low socket and table.
Personal safety
• WARNING: To protect against fire, electric shock and personal
injury do not immerse cord, plug and appliance in water or any
other liquid.
• WARNING: The appliance surface is subject to residual heat
after use.
• WARNING: Fill with potable water only.
• The temperature of accessible surfaces may be high when the
appliance is operating.
• Unplug from the outlet before cleaning and allow to cool before
putting on or taking off parts and before cleaning.
• Do not move the appliance while switched on.
• Do not use accessories which are not recommended by the
manufacturer.
• Do not touch the evaporator when using the ice maker as the
user may suffer from frostbite.
Electrical requirements
• WARNING: This appliance should NOT be used with extension
leads and/or power boards.
• Check that the voltage on the rating label of your appliance
corresponds with your house electricity supply which must be
A.C.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE

6
Model: MRICE17SS
Colour: Stainless Steel
Rated Power: 150W
Rated Voltage & Frequency: 220-240V~ 50Hz
Water Tank Capacity: 1.8L
Ice Bin Capacity: 1.1kg
Refrigerant/Refrigerant Amount: R600a/17g
Foaming Agent: Cyclopentane
Dimensions (W x D x H): 243 x 312 x 378mm
Net Weight: 12.1kg
SPECIFICATIONS
CONTROL PANEL
Function
Starts and stops the appliance
Starts the Clean function
Illuminates solid when making ice
Illuminates solid during cleaning function
Indicator flashes when water needs to be
added to the water tank
Illuminates solid when the ice basket is full
The appliance is defrosting
Solid
Button / Indicator
Flashes

7
PRODUCT OVERVIEW
Top CoverControl Panel
Viewing Window
Power Cord
Infrared Diode Ice Outlet Box Cover
Housing
Cooling Fan
Ice Box
Drainage Plug Bottom Plate Ice Basket
Ice Scoop

8
BEFORE FIRST USE
1. Remove all packaging materials and read all instructions.
2. Check that all accessories are complete and the appliance is
not damaged.
3. Clean all parts to remove any dust or manufacturing residue.
4. Clean the water storage tank and ice collecting tray with clean
water.
5. The incline angle of the ice maker should not exceed 45°
during transportation or use. Do not turn the ice maker upside
down. Doing so could cause the compressor or refrigerating
system to operate incorrectly. Please allow time for the liquid
in the compressor to settle after the ice maker is moved or
transported. Before using the ice maker for the first time, please
wait for 2 hours after the unit has been positioned on a level
surface.
6. The appliance must be placed on a dry and level surface with
sufficient ventilation, far from heat sources such as ovens,
heaters and corrosive gases. Leave around 15cm clearance on
all sides of the ice maker for proper ventilation.
7. Do not fill the water reservoir with hot water. This may damage
the ice maker. It is best to fill the water tank with water that is
room temperature or lower. The water quality added to the tank
should be drinkable.
8. Do not use the appliance at a very cold environment (lower than
5°C).
9. Run the Clean Function.

9
USING YOUR ICE MAKER
1. Ensure the drainage plug underneath the appliance is closed
securely. Refer to page 11.
2. Plug the ice maker into a wall outlet, the indicator will
blink.
NOTE: The appliance should be rested for 30 minutes before
plugging into a wall outlet, if it has been moved.
3. Open the front lid with viewing window. Remove the ice basket
and fill the water tank with drinkable water.
NOTE: Do not fill above the MAX water level mark.
4. Replace the ice basket and close the front lid.
5. Press the ON/OFF button and the indicator lights solidly.
6. The ice making cycle will take approximately 20-30 minutes,
depending on the ambient temperature and water temperature.
7. The ice making assembly is equipped inside the appliance, and
the appliance will keep producing ice when water is pumped
into it. When ice forms in the assembly, ice nuggets will transfer
into the ice tray and the ice nuggets will drop into the ice
basket. The above action will be repeated until the ice basket is
full.
8. The indicator will illuminate when the ice basket is full
and the ice maker will stop the ice making cycle automatically.
Open the front lid and gently remove the ice from the ice basket
with the ice scoop.
9. Replace the ice basket and close the front lid. Press the ON/
OFF button to restart the appliance.
NOTE: If the ice is not removed from the ice basket, the machine
will restart the ice making process automatically after 4 hours.

10
USING YOUR ICE MAKER
10. The indicator will flash when the water tank is out of
water. Remove the ice basket and refill the water tank with
drinkable water to “MAX” mark.
11. Close the front lid and the appliance will restart the ice making
cycle automatically.
12. When you have the desired amount of ice, stop the ice making
cycle by pressing the ON/OFF button and unplug the unit from
the wall outlet.
13. Open the front lid and transfer the ice to a freezer, if required.
14. Allow the ice maker to reach room temperature.
NOTE: It is recommended to replace the water every week. Empty
the water tank if the ice maker will not be used for a long time.
CARE & CLEANING
NOTE: Clean the water tank if the appliance has water in the tank
and has not been used for 48 hours.
NOTE: If the appliance is left empty for long periods, switch
off, defrost, clean, dry, and leave the lid open to prevent mold
developing within the appliance.
1. Remove the ice basket, add water and mild detergent into the
water tank.
2. Hold and press the CLEAN button for about 3 seconds. The
indicator illuminates and the appliance enters into the cleaning
mode.
3. After cleaning for 5 minutes, the appliance stops working and the
c indicator flashes.

11
CARE & CLEANING
Drainage Plug
4. Tilt the appliance around 30° and move it forward to the place
where the drainage plug is about 75mm away from the counter
top. Open the drainage plug and drain the excess water (see
below).
5. Close the drainage plug and fill the water tank with water. Press
the CLEAN button again, the indicator lights up and the
appliance enters into the cleaning mode.
6. Remove the ice basket and clean the ice maker interior with a
soft cloth soaked with warm water and vinegar, then rinse with
clean water and drain all the water, following step 4.
7. Rinse the drainage tube and replace the drainage plug securely
in position. Wash the ice basket and ice scoop in warm soapy
water. Rinse and dry.
8. Clean the exterior of the ice maker with a soft damp cloth. Use
a mild dishwashing soap, if necessary.
NOTE: Do not use organic solvents, boiling water, detergent,
strong acid and strong alkali etc. for cleaning.
NOTE: Empty the water reservoir and dry it for storage if the ice
maker will not used for a long time.
Drainage PlugDrainage Plug

12
MAINTENANCE
WARRANTY
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SUGGESTED
SOLUTIONS
Flashes
1. Lack of water.
2. The water screen on the
bottom of water tank is
blocked.
3. Pump malfunction.
4. There are foreign objects
blocked the oat of the
water tank.
1. Stop making ice, rell
water and press ON/OFF
button to restart ice making
cycle.
2. Remove the water screen
at the bottom of water tank
for cleaning.
3. Contact the relevant
Customer Care Centre.
4. Check the foreign objects
and restart the appliance.
Illuminates
1. Ice basket is full.
2. A malfunction of the
infrared diode.
1. Remove the ice from
ice basket press ON/OFF
button to restart ice making
cycle.
2. Contact the relevant
Customer Care Centre.
Illuminates
Flashes
1. The ice making assembly
is defrosting.
1. No action required, as
the appliance will return to
normal operation after 30-
45 minutes.
Alternatively, you can hold
and press the CLEAN
button for 3 seconds,
and press the ON/OFF
button again to restart the
appliance after the cleaning
procedure is nished.
Flashes
Flashes
1. The ice making assembly
is frozen.
1. No action required. Allow
the appliance to defrost au-
tomatically for 20 mins. The
program buttons can not
be operated. The appliance
can be used again after the
defrosting has nished. If
this problem occurs
repeatedly, it can be
a refrigerant leakage
issue. Contact the relevant
Customer Care Centre, if
this occurs.

13
PROBLEM POSSIBLE CAUSE SUGGESTED
SOLUTIONS
Poor ice making result. The
ice making process is nor-
mal but the ice produced
is broken, which lasts for
more than 2 hours.
1. Poor heat dissipation.
2. The water temperature is
too high.
3. The ambient temperature
is too high.
4. The ice making system is
abnormal.
1. Leave a 15cm clearance
on all sides of the ice maker
for proper ventilation.
2. Fill the water reservoir
with water ranging between
8°C and 28°C.
3. Operate the ice maker in
an environment with an am-
bient temperature between
10°C and 32°C.
4. Contact the relevant
Customer Care Centre.
MAINTENANCE
TROUBLESHOOTING
TIPS FOR YOUR ICE MAKER
• Opening the lid for long periods can cause a significant
increase of the temperature in the compartments of the
appliance.
• It is normal for the compressor and condenser surface to
reach temperatures between 70°C and 90°C during operation
and surrounding areas may be very hot.
• Due to fast freezing, ice cubes may become opaque. This is
due to air becoming trapped in the water and will not affect the
quality or taste of the ice.
• Do not use with water that is micro biologically unsafe or of
unknown quality. Always use fresh water before starting ice
production either at initial installation or after a long shut-off.

14
MAINTENANCE
If the unit fails to operate efficiently, is broken or other problems
arise, unplug and do not operate.
Ask for advice by calling your local after sales service agent or
the Customer Care Centre on 1300 556 816 (AU) / 0800 666 2824
(NZ).
WARRANTY
Please refer to the warranty card in the box for warranty information.
For any troubleshooting advice, please contact the relative Customer
Care Centre below.
Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd
8 Lakeview Drive, 38 Harris Road, East Tamaki,
Scoresby 3179, Victoria Auckland 2013
Australia New Zealand
Ph: 1300 556 816 Ph: 0800 666 2824

15
NOTES

Glen Dimplex New Zealand Ltd
1 Ron Driver Place
East Tamaki, Auckland
Phone: [phone]
Email: [email protected]
Web: www.morphyrichards.co.nz
© Glen Dimplex Australia. All rights reserved. Material contained in this publication may not be
reproduced in whole or in part, without prior permission in writing of Glen Dimplex Australia.
MRICE17SS_IM_v2
Recycling: Do not dispose of electrical appliances as unsorted municipal waste. Use separate collection
facilities. Contact your local government for information regarding the collection systems available. If
electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the ground
water, polluting the food chain and damaging health and wellbeing.
Expanded Polystyrene Disposal: The websites listed below can assist in the responsible disposal of EPS
(Expanded Polystyrene) packaging products.
Australia: https://recyclingnearyou.com.au/polystyrene and/or http://epsa.org.au
New Zealand: https://greenbusinesshq.com/epsrecycling and/or
https://www.plastics.org.nz/environment/recycling-disposal/eps-recycling
Glen Dimplex Australia Pty Ltd
8 Lakeview Drive
Scoresby VIC 3179
Phone: [phone]
Email: [email protected]
Web: www.morphyrichards.com.au
