Morphy Richards MRMWO34 User manual

INSTRUCTION MANUAL
Model: MRMWO34
Read these instructions carefully before
using your microwave oven.
STORE THESE INSTRUCTIONS CAREFULLY
Microwave Oven
www.morphyrichards.com.au

2
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
• Do not attempt to operate this oven with the door open since this can
result in harmful exposure to microwave energy. It is important not to
break or tamper with the safety interlocks.
• Do not place any object between the oven front face and the door
or allow spatter/matter or cleaner residue to accumulate on sealing
surfaces.
• WARNING: If the door or door seals are damaged, the oven must not
be operated until it has been repaired by a competent person.
ADDENDUM
If the apparatus is not maintained in a good state of cleanliness, its surface
could be degraded and affect the lifespan of the apparatus and lead to a
dangerous situation.
SPECIFICATIONS
Model: MRMWO34
Rated Voltage: 240V~50Hz
Rated Input Power (Microwave): 1550W
Rated Output Power (Microwave): 1100W
Oven Capacity: 34L
Turntable Diameter: 315mm
External Dimensions (LxWxH): 519 X 440 X 315mm
Net Weight: Approx 15.5kg

3
WARNING
To reduce the risk of fire, electric shock, injury to persons or exposure
to excessive microwave oven energy when using your appliance, follow
basic precautions, including the following:
• Read and follow the specific: “PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY”.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not
be made by children unless they are older than 8 and supervised.
Children less than 8 years of age shall be kept away unless
continuously supervised.
• Keep the appliance and its cord out of reach of children less than 8
years.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order
to avoid a hazard. (For appliance with type Y attachment)
• WARNING: Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric shock.
• WARNING: It is hazardous for anyone other than an authorised
repairer/technician to carry out any service or repair operation
that involves the removal of a cover which gives protection against
exposure to microwave energy.
• WARNING: Liquids and other foods must not be heated in sealed
containers since they are liable to explode.
IMPORTANT SAFETY INSTRUCTIONS

4
• Do not heat food in plastic or paper containers, due to the possibility of
ignition.
• Only use utensils that are suitable for use in microwave ovens.
• If smoke is emitted, switch off or unplug the appliance and keep the
door closed in order to stifle any flames.
• Microwave heating of beverages can result in delayed eruptive boiling,
therefore care must be taken when handling the container.
• The contents of feeding bottles and baby food jars shall be stirred or
shaken and the temperature checked before consumption, in order to
avoid burns.
• Eggs in their shell and whole hard-boiled eggs should not be heated
in microwave ovens since they may explode, even after microwave
heating has ended.
• The oven should be cleaned regularly and any food deposits removed.
• Failure to maintain the oven in a clean condition could lead to
deterioration of the surface that could adversely affect the life of the
appliance and possibly result in a hazardous situation.
• The appliance must not be installed behind a decorative door in
order to avoid overheating. (This is not applicable for appliances with
decorative door.)
• Only use the temperature probe recommended for this oven. (For ovens
provided with a facility to use a temperature-sensing probe.)
• The microwave oven shall not be placed in a closed cabinet.
• The microwave oven is intended for heating food and beverages.
Drying of food or clothing and heating of warming pads, slippers,
sponges, damp cloth and similar may lead to risk of injury, ignition or
fire.

5
• Metallic containers for food and beverages are not allowed during
microwave cooking.
• The appliance shall not be cleaned with a steam cleaner.
• The appliance is intended to be used freestanding.
• The rear surface of appliances shall be placed against a wall.
• Steam cleaner is not to be used.
• Surface of a storage drawer can get hot.
• Do not use harsh abrasive cleaners or sharp metal scrapers to clean
the oven door glass since they can scratch the surface, which may
result in shattering of the glass.
• WARNING: The appliance and its accessible parts become hot during
use. Care should be taken to avoid touching heating elements. Children
less than 8 years of age shall be kept away unless continuously
supervised.
• During use the appliance becomes hot. Care should be taken to avoid
touching heating elements inside the oven.
• WARNING: Accessible parts may become hot during use. Young
children should be kept away.
• WARNING: Children should only use the oven under adult supervision
due to the temperatures generated.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE

6
ELECTRIC SHOCK HAZARD
DANGER
WARNING
ELECTRIC SHOCK HAZARD
Touching some of the internal components can cause serious personal injury or
death. Do not disassemble this appliance.
Improper use of the grounding can
result in electric shock.
Do not plug into an outlet until
appliance is properly installed and
grounded.
This appliance must be grounded. In
the event of an electrical short circuit,
grounding reduces the risk of electric
shock by providing an escape wire for
the electric current.
This appliance is equipped with a
cord having a grounding wire with
a grounding plug. The plug must be
plugged into an outlet that is properly
installed and grounded.
Consult a qualified electrician
or serviceman if the grounding
instructions are not completely
understood or if doubt exists as to
whether the appliance is properly
grounded.
If it is necessary to use an extension
cord, use only a 3-wire.
1. A short power-supply cord is
provided to reduce the risks
resulting from becoming entangled
in or tripping over a longer cord.
2. If a long cord set or extension cord
is used:
• The marked electrical rating of
the cord set or extension cord
should be at least as great as the
electrical rating of the appliance.
• The extension cord must be a
grounding-type 3-wire cord.
• The long cord should be
arranged so that it will not
drape over the counter top or
tabletop where it can be pulled
on by children or tripped over
unintentionally.

7
CLEANING
BE SURE TO UNPLUG THE APPLIANCE FROM THE POWER SUPPLY.
1. Clean the cavity of the oven after using with a slightly damp cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must be cleaned carefully
with a damp cloth when they are dirty.
4. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven
door glass since they can scratch the surface, which may result in shattering of
the glass.
5. Cleaning Tip: For easier cleaning of the cavity walls that the food cooked can
touch: Place half a lemon in a bowl, add 300ml
6. (1/2 pint) water and heat on 100% microwave power for 10 minutes. Wipe the
oven clean using a soft, dry cloth.
UTENSILS CAUTION
PERSONAL INJURY HAZARD
It is hazardous for anyone other than an authorised repairer/technician
to carry out any service or repair operation that involves the removal of a
cover which gives protection against exposure to microwave energy.
See the instructions on “Materials you can use in microwave oven or to be
avoided in microwave oven.” There may be certain non-metallic utensil/container
that are not safe to use for microwaving. If in doubt, you can test the utensil/
container in question following the procedure below.
UTENSILS TEST
1. Fill a microwave-safe container with 1 cup of cold water
(250ml) along with the utensil/container in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil/container is
warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.

8
Utensils Remarks
Browning dish Follow manufacturer’s instructions. The bottom of browning dish must be
at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause
the turntable to break.
Dinnerware Microwave-safe only. Follow manufacturer's instructions.
Do not use cracked or chipped dishes.
Glass jars Always remove lid. Use only to heat food until just warm.
Most glass jars are not heat resistant and may break.
Glassware Heat-resistant oven glassware only. Make sure there is no metallic trim.
Do not use cracked or chipped dishes.
Oven cooking bags Follow manufacturer’s instructions. Do not close with metal tie. Make slits
to allow steam to escape.
Paper plates and
cups
Use for short–term cooking/warming only. Do not leave oven unattended
while cooking.
Paper towels Use to cover food for reheating and absorbing fat. Use with supervision for
a short-term cooking only.
Parchment paper Use as a cover to prevent splattering or a wrap for steaming.
Plastic Microwave-safe only. Follow the manufacturer’s instructions. Should be
labeled "Microwave Safe". Some plastic containers soften, as the food
inside gets hot. "Boiling bags" and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Plastic wrap Microwave-safe only. Use to cover food during cooking to retain moisture.
Do not allow plastic wrap to touch food.
Thermometers Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Wax paper Use as a cover to prevent splattering and retain moisture.
MATERIALS YOU CAN USE IN MICROWAVE OVEN

9
Utensils Remarks
Aluminum tray May cause arcing. Transfer food into microwave-safe dish.
Food carton with
metal handle
May cause arcing. Transfer food into microwave-safe dish.
Metal or metal
trimmed utensils
Metal shields the food from microwave energy.
Metal trim may cause arcing.
Metal twist ties May cause arcing and could cause a fire in the oven.
Paper bags May cause a fire in the oven.
Plastic foam Plastic foam may melt or contaminate the liquid inside when exposed to
high temperature.
Wood Wood will dry out when used in the microwave oven and may split or
crack.
MATERIALS TO BE AVOIDED IN MICROWAVE OVEN

10
SETTING UP YOUR OVEN
a. Control panel
b. Turntable shaft
c. Turntable ring assembly
d. Glass tray
e. Observation window
f. Door assembly
g. Safety interlock system
Grill Rack (Can not be used in microwave
function and must be placed on the glass tray)
a. Never place the glass tray upside down.
The glass tray should never be restricted.
b. Both glass tray and turntable ring
assembly must always be used during
cooking.
c. All food and containers of food are
always placed on the glass tray for
cooking.
d. If glass tray or turntable ring assembly
cracks or breaks, contact your nearest
authorized service center.
Hub (underside)
Glass tray
Turntable shaft
Turntable ring assembly
NAMES OF OVEN PARTS AND ACCESSORIES
TURNTABLE INSTALLATION
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
Glass tray
Turntable ring assembly
Instruction Manual
1
1
1

11
Remove all packing material and
accessories. Examine the oven for any
damage such as dents or broken door. Do
not install if oven is damaged.
Cabinet: Remove any protective film found
on the microwave oven cabinet surface.
Do not remove the light brown Mica cover
that is attached to the oven cavity to protect
the magnetron.
1. Select a level surface that provides
enough open space for the intake
and/or outlet vents.
• The minimum installation height
is 85cm.
• The rear surface of appliance
should be placed against a wall.
• Leave a minimum clearance
of 30cm above the oven, a
minimum clearance of 20cm is
required between the oven and
any adjacent walls.
• Do not remove the legs from the
bottom of the oven.
• Blocking the intake and/ or outlet
openings can damage the oven.
• Place the oven as far away
from radios and TV as possible.
Operation of microwave oven
may cause interference to your
radio or TV reception.
2. Plug your oven into a standard
household outlet. Be sure the
voltage and the frequency is the
same as the voltage and the
frequency on the rating label.
WARNING:
Do not install oven over a range
cooktop or other heat-producing
appliance. If installed near or over
a heat source, the oven could be
damaged and the warranty would be
void.
THE ACCESSIBLE
SURFACE MAY BE HOT
DURING OPERATION.
INSTALLATION
COUNTERTOP INSTALLATION

12
OPERATION INSTRUCTION
When the microwave oven is electrified,the oven will display “0:00”, buzzer will ring once.
The input time should be within 0:00--23:59 (24 Hour).
Example: To set 12:12.
1. Press “KITCHEN TIMER /CLOCK” twice, “00:00” will flash and all the “0” will flash.
2. Press the number buttons of “1”, “2”, “1”, “2” in order.
3. Press “KITCHEN TIMER /CLOCK” to finish clock setting. “:” will flash, and the time will light.
Note:
• If the clock is not set, it will not function when powered.
• During the process of clock setting, if you press “STOP/CLEAR” or if no operation in 1 minute,
the oven will go back to the previous status automatically.
Select different microwave power level and set cooking time as you wish. There are five power levels
available for choosing. Keep on pressing “MICROWAVE” to choose the power.
Example: If you want to use 80% microwave power to cook for 10 minutes, you can operate the oven
as the following steps.
1. Press “MICROWAVE” once, “P100” will flash.
2. Press “MICROWAVE” once again to choose 80% power, the oven will display “P80”.
3. Press “START/+30SEC.” to confirm the power.
4. Press the number buttons of “1”, “0”, “0”, “0” in order, the oven will display “10:00”.
5. Press “START/+30SEC.” to start cooking.
Microwave Power Chart
Microwave
Power
High M.High Med. M.Low Low
Display P100 P80 P50 P30 P10
CLOCK SETTING
MICROWAVE COOKING

13
KITCHEN TIMER
MELT
1. Press “KITCHEN TIMER/CLOCK” once, LED will display 00:00.
2. Press the number buttons and enter the correct time. (the maximum cooking time is 99 minutes
and 99 seconds)
3. Press “START/+30SEC.” to confirm setting.
4. When the kitchen time is reached, the buzzer will ring 5 times. Then turn back to waiting state. If
the clock is set (24-hour system), LED will display the current time.
Note: The kitchen timer is different from 24-hour system, Kitchen Timer is a timer.
1. Press the “MELT.” button once, “A-02” will flash.
2. Press “START/+30SEC.” button to confirm the setting.
3. Press the number button of “1” or “2” to select the melt menu. And press the same number button
repeatedly to select the weight of food.
4. Press the “START/+30SEC” button to start cooking.
Reheat Chart
Menu Weight Display
1
MELT
CHOCOLATE
50g 50g
75g 75g
100g 100g
150g 150g
175g 175g
200g 200g
250g 250g
2
MELT
BUTTER
50g 50g
75g 75g
100g 100g
150g 150g
175g 175g
200g 200g
250g 250g

14
1. Press “DEFROST.” once, the oven will display “D-01”.
2. Press “START/+30SEC.” button to confirm the setting.
3. Input the figure of the time of cooking.
(The maximum cooking time is 99 minutes and 99 seconds.)
4. Press “START/+30SEC.” button to start defrosting.
DEFROST BY TIME
DEFROST BY WEIGHT
1. Press “DEFROST.” pad twice, the oven will display “D-02”.
2. Press “START/+30SEC.” button to confirm the setting.
3. Input the figure of the weight of food.
(The input figure of the weight should be within 100--2000g)
4. Press “START/+30SEC.” button to start defrosting.
MEMORY
1. Press “MEMORY.” button one to three times to set memory “1”, memory “2” or
memory “3” program, and the oven will display “1”, “2” or “3”.
2. Set one or two stages to program you want.
(Reheat or Auto menu cannot be set as memory program).
Example:
• Press “MICROWAVE.” once to choose 100% microwave power;
• Press number buttons “1”, “0”, “0”, “0” in order to adjust the cooking time;
3. Press “MEMORY” button to save the memory program chosen, or press
“START/+30SEC.” to start cooking and save the program automatically.
4. Next time when you want to cook with the memory program which has been set,
you just only need to press “MEMORY.” button to choose the program wanted and
then press “START/+30SEC.” to start cooking.
Note: If the electricity is cut off, the procedure that has been saved will be canceled.

15
Example : Cooking vegetable of 300g:
1. Press “AUTO MENU.” button once, “A-01 will flash”
2. Press “START/+ 30SEC.” to confirm the menu
3. Press “1/VEGETABLE.” repeatedly till the “300” display.
4. Press “START/+ 30SEC.” to start cooking.
The numeral pads 0—9 are matching with ten different options respectively;
Pad Cook Pad Cook Pad Cook Pad Cook
1 VEGETABLE 4 PA S TA 7 BEVERAGE 0 PIZZA
2 FISH 5 P O TATO 8 POPCORN
3 MEAT 6 SOUP 9 MUFFIN
AUTO MENU COOKING

16
Menu Weight Press Times Display
VEGETABLE
200g Once 200
300g Twice 300
400g 3 times 400
FISH
250g Once 250
350g Twice 350
450g 3 times 450
MEAT
250g Once 250
350g Twice 350
450g 3 times 450
PA S TA
50g (with cold water 450g) Once 50
100g (with cold water 800g) Twice 100
P OTAT O
1 (approximately 230g) Once 1
2 Twice 2
3 3 times 3
SOUP
200ml Once 200
400ml Twice 400
600ml 3 times 600
BEVERAGE
1 cup (approximately 240ml) Once 1
2 cups Twice 2
3 cups 3 times 3
POPCORN 100g Once 100
MUFFIN
1 Once 1
2 Twice 2
3 3 times 3
PIZZA
200g Once 200
400g Twice 400
AUTO MENU CHART

17
1. When the oven is in the waiting states, press “START/+30SEC.” button to start with full microwave
power for 30 seconds (the maximum setting is 99 minutes and 99 seconds).
2. When the oven is in the waiting state, press the number buttons to set the cooking time and then
press “START/+30SEC.” button to start cooking with full microwave power.
Note: This can NOT be set as one stage of the multi-stage cooking.
MULTI STAGE COOKING
SPEEDY MICROWAVE COOKING
Two stages of cooking can be maximumly set. If one of the stages is defrosting, it should be put in the
first stage automatically. The buzzer will ring once after each stage and the next stage will begin.
Example: If you want to cook the food with 100% microwave power for 10 minutes+ 80% microwave
power for 15 minutes. Do it as following:
1. Press “MICROWAVE.” once to choose 100% microwave power;
2. Press “START/+30SEC.” button to confirm the setting.
3. Press number buttons “1”,”0”,”0”,”0” in order to adjust the cooking time;
4. Press “MICROWAVE.” once, “P100” will flash.
5. Press “POWER.” repeatedly to adjust the microwave power till oven displays “P80”.
6. Press “START/+30SEC.” button to confirm the setting.
7. Press number buttons “1”,”5”,”0”,”0” in order to adjust the cooking time;
8. Press “START/+30SEC.” to start cooking.
NOTE: Kitchen Timer, Auto Menu, Speedy Cooking or Preheating cannot be set as one
of the multi-stage.

18
1. Press “REHEAT.” pad , the “H-01” will flash and “AUTO.” indicator will light.
(Press the “REHEAT.” pad several times to select the cooking program you want.)
2. Press “START/+30SEC.” button to confirm.
3. Press the “REHEAT.” pad several times to select the weight of the cooking food.
4. Press “START/+30SEC.” button to start cooking.
Menu Weight Display
H-01
(AUTO REHEAT)
150g 150
250g 250
350g 350
450g 450
600g 600
H-02
(DINNER PLATE)
250g 250
350g 350
450g 450
600g 600
REHEAT
REHEAT CHART

19
1. In waiting state, the oven will display clock and “ : ” will flash.
2. In function setting state, the oven will display the related setting.
3. In the operation and suspending state, the oven will display the residual cooking time.
4. During microwave, grill, combination or convection cooking, 30 seconds can be added by pressing
“START/+30SEC.” button.
INQUIRING FUNCTION
SPECIFICATION
LOCK-OUT FUNCTION FOR CHILDREN
1. In cooking state, press “COMBI.”, “MICROWAVE.”, or “CONVEC.”, and the current power will be
displayed for 3 seconds.
2. In cooking state, press “CLOCK/KITCHEN TIMER.” to inquire the time. The time will flash for 3
seconds.
LOCK:
In waiting state, press “STOP/CLEAR” , there will be a long “beep”.
3 seconds later, there will be 2 short beeps. And a button indicator will light.
The oven will display “ ” or current time.
LOCK QUITTING:
In locked state, press “STOP/CLEAR” , there will be a long “beep”.
3 seconds later, there will be 2 short beeps. And a button indicator will go out. The oven will
display “0:00” or current time.

Glen Dimplex Australia Pty Ltd
1340 Ferntree Gully Road
Scoresby VIC 3179
Phone: [phone]
Email: [email protected]
Web: www.morphyrichards.com.au
Normal
Microwave oven
interfering TV reception
Radio and TV reception may be interfered with when microwave
oven is operating. It is similar to the interference of small electrical
appliances, like a mixer, vacuum cleaner, and electric fan. It is
normal.
Dim oven light In low power microwave cooking, oven light may become dim. It is
normal.
Steam accumulating on
door, hot air out of vents
In cooking, food can release steam. Most escape from vents, but
some may accumulate on cool place like oven door. It is normal.
Oven started accidentally
with no food in
Do not run the unit without any food inside.
Trouble Possible Cause Remedy
Oven cannot be started 1. Power cord not
plugged in tightly
Unplug. Then plug in again
after 10 seconds
2. Fuse blowing or circuit
breaker works
Replace fuse or reset circuit
(repaired by professional
personnel of our company)
3. Trouble with outlet Test outlet with other
appliances
Oven does not heat 4. Door not closed well Close door
TROUBLE SHOOTING
