N Brown Group WT 477 Operating instructions

Assembly Intructions - Please keep for future reference Cat No. WT 477
No. People Assembly time
15 - 20
Minutes
Important - Please read these intructions fully before starting assembly
If you need help or have damaged or missing parts, cal the JDW customer helpline: 0871 231 200
MONTPELLIER WOODEN BENCH

Safety and Care Advice
Important - Please read these instructions fully before starting assembly
• Check you have all the
components and tools
listed on the next pages.
• Remove all ttings from the
plastic bags and seperate
them into their groups.
• Keep children and animals
away from the work area,
small parts could choke if
swallowed.
• Make sure you have
enough space to lay out
the parts before starting.
• Do not stand or put weight
on the product, this could
cause damage.
• Assemble the item as close
to its nal position (in the
same room) as possible.
• Assemble on a soft, level
surface to avoid damaging
the unit or your oor.
• We do not recommend the
use of power
drills/drivers
for inserting
screws as this
could damage
the unit. Only use hand
screwdrivers.
Care and Maintenance
• Please clean using cloth
with glass cleaner, do not
use bleach or abrasive
cleaners.
• From time to time check
that there are no loose
screws on this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal
centre.
If you need help or have damaged or missing parts, call the JDW
customer helpline: 0871 231 2000
If you are unhappy with the product and wish to return it,
please follow the retailer’s returns procedure.
Warning
Important - In order to help prevent overturning, this product must be used with the wall anti-tip
strap/device provided.
• To help prevent product toppling over please follow the below steps:
• Use the anti-tip strap/device provided.
• Do not allow children to climp or hang on the furniture.
• Do not place heavy items on top of the furniture, unless the furniture has been designated for
this purpose.
Please note that only the anti-tip strap/devices and screw are provided, you will need to provide
wall plugs and screws applicable for your wall type.

0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190
Components- Panels
Please check that you have all the components listed below before constructing your item.
Part No Qty Description
ALeg frame 2
B
C
Components- Fixings
Please check that you have all the components listed below before constructing your item.
Part No Qty Description
Bolt M8x50 4
F4
4
1
1
Tools Required
Allen key
Ruler - Use this to measure your screws (mm)
Screew M7x90
Insert nut
Seat frame
G
Back rest
D2
Support bar
E
1
Screew 4x35
H
2Allen key
I

ASSEMBLY INSTRUCTION
A
STEP 2
* Place the part (D) down as shown
C
B
B
C
E
F
E
F
F
E
F
E
STEP 1
Assemble part (A), (B), (C), at the same time
* Line up part (E) and place into the hole
* Tighten and secure with part (F)
D

ASSEMBLY INSTRUCTION
* Product is fully assembled
CARE AND CLEANING
1. TO CLEAN, WIPE WITH DAMP CLOTH. DO NOT USE BLEACH, ACID SOLVENTS OR ABRASIVE CLEANERS
OR FRAME PARTS.
2. DURING VARYING WEATHER CONDITIONS AND WINTER PERIOD, WE STRONGLY RECOMMEND THAT
IT CAN BE. STORED IN A DRY AREA
3. IN THE EVENT OF BARE METAL SHOWING DUE TO SCRATCH, IT IS PREFERRED TO TREAT WITH A
RUST REPELLING VARNISH OR SIMILAR.
4. PERIODICALLY CHECK AND ENSURE THAT ALL THE SCREWS ARE COMPLETELY TIGHTEN.
5. A MATCHING FURNITURE COVER IS STRONGLY RECOMMENDED TO EXTEND THE USAGE LIFE-SPAN.
