Nabco GT-1400 User manual

S82 W18717 Gemini Drive
Muskego, Wisconsin 53150
Phone: [phone]
Fax: [phone]
www.nabcoentrances.com
Technical Support: [phone]
Part #15-9324
Rev. 11/26/14
WARNING
• Turn OFF all power to the Automac Door if a Safety System is not working.
• Instruct the Owner to keep all power turned OFF unl correcve acon can be achieved by a NABCO
trained technician. Failure to follow these pracces may result in serious consequences.
• NEVER leave a Door operang without all Safety detecon systems operaonal.
Model GT 1400
Folding Door System
**With Magnum 4A Control**
Mechanical Installaon Manual
DN 0321

1400 Fold Door System www.NabcoEntrances.com
Part #15-9324 Rev. 11-26-14
i
Table of Contents
Warning Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
General Safety RecommendaƟons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
CHAPTER 1: SCOPE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Secon 1a: To the Installer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-5
Secon 1b: Objecve. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-5
CHAPTER 2: GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Secon 2a: Parts of the Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-6
Secon 2b: Handing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7
Secon 2c: Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7
Secon 2d: Electrical Specificaons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7
Secon 2e: Magnum 4A Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7
Secon 2f: Panic Breakout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7
Secon 2g: Associated Manuals Part Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7
CHAPTER 3: INSTALL THE DOOR FRAME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Secon 3a: Prepare the Rough Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-8
Secon 3b: Remove Dress Plates from Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-8
Secon 3c: Secure Header to Jamb Tubes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-10
Secon 3d: Anchor Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-10
CHAPTER 4: 110 VAC GENERAL WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 414
CHAPTER 5: INSTALL THE FOLDING DOOR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 516
Secon 5a: Install the Boom Pivot (Floor Poron) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-16
Secon 5b: Install the Boom Pivot (Door Poron) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-16
Secon 5c: Secure Spindle Drive Bar to Folding Door. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-17
Secon 5d: Secure Folding Door to Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-17
Secon 5e: Secure Guide Channel to Folding Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-18
Secon 5f: Adjust Folding Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-20

Rev. 11-26-14 Part #15-9324
www.NabcoEntrances.com 1400 Fold Door System
ii
CHAPTER 6: INSTALL THE DOOR PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 621
CHAPTER 7: TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 725

Rev. 11-26-14 Part #15-9324
www.NabcoEntrances.com 1400 Folding Door System
iii
WARNING LABELS
Warning labels are universal and used to alert an individual of potential harm to one’s self or to others. The following
warning labels are listed in a hierarchy order that deines the most potential danger irst, and the least potential
danger last. Please refer to this page in the event that a warning label is displayed within this manual and further
deinition needs to be explained.
Indicates potenally dangerous situaons. Danger is used when there is a hazardous
situaon where there is a high probability of severe injury or death.
It should not be considered for property damage unless personal injury risk
is present.
Indicates a hazardous situaon which has some probability of severe injury.
It should not be considered for property damage unless personal injury risk
is present.
Indicates a hazardous situaon which may result in a minor injury. Cauon
should not be used when there is a possibility of serious injury. Cauon should
not be considered for property damage accidents unless a personal injury risk
is present.
Aenon: A situaon where material could be damaged or the funcon impaired.
Noce: Indicates a statement of company policy as the message relates to the personal safety or
protecon of property. Noce should not be used when there is a hazardous situaon or
personal risk.
Note: Indicates important information that provides further instruction.
DANGER
WARNING
CAUTION

1400 Folding Door System www.NabcoEntrances.com
Part #15-9324 Rev. 11-26-14
iv
GENERAL SAFETY RECOMMENDATIONS
Do Not install or service this product unless Safety Pracces, Warning Labels, Installaon
Instrucons, and Operang Instrucons, have been read and fully understood. Failure to
so do may result in bodily injury or property damage.
Handle Glass With Care!!! Use cauon when moving and installing the glass panels.
These panels are designed to be assembled with tempered glass. Any sharp objects
that come in contact with glass may cause the glass to shaer. NABCO Entrances is not
responsible for glass that is broken during the installaon of this Unit.
Noce: Read, study and understand the operang instrucons contained in, or referenced in
this manual before operang. If you do not understand the instrucon, ask the installing
qualified technician to teach you how to use the door.
Noce: This manual and the owner’s manual must be given to and retained by the purchasing
facility or end user.
Noce: Advise the purchasing facility or end user to make regular safety checks and all other
dues that may apply.
►If the door appears broken or does not seem to work correctly, it should be immediately
removed from service until repairs can be carried out or a qualiied service technician is
contacted for corrective action.
►It is the responsibility of the purchasing facility or end user to keep warning and
instructional labels and literature legible, intact and with the door. Replacement
labels and literature may be obtained from local NABCO Entrances, Inc. distributors.
If the name of the local distributor is unknown, contact NABCO Entrances, Inc. at
1-877-622-2694 for assistance.
►Do Not take shortcuts.
►Ensure that all safety devices provided by the manufacturer work as intended.
►Ensure that all safety decals are properly displayed on any/all swing doors.
WARNING
CAUTION

1400 Fold Door System www.NabcoEntrances.com
Part #15-9324 Rev. 11-26-14
1-5 Scope
CHAPTER 1: SCOPE
Secon 1a: To the Installer
The purpose of this manual is to familiarize the installer and purchaser with the proper
installation and operation of this system. It is essential that this equipment be properly installed
and operational before the door is used by the public. It is the installer’s responsibility to inspect
the operation of the entrance system to be sure it complies with any applicable standards. In
the United States, ANSI Standard A156.10 covers the GT-1400 Fold Door System. All automatic
equipment complies with UL325 and CAN/CSA-C22.2 No 247-92. Other local standards or
codes may apply. Use them in addition to the ANSI standard. The GT-1400 is listed with the
Underwriters Laboratory and is identiied as such on the label.
Instruct the building owners and operator on the essentials of the operation of the door and this
device. The owner should follow these instructions to determine whether the door is operating
properly and should immediately call for service if there is any malfunction. All installation
changes and adjustments must be made by qualiied, NABCO trained technicians.
Note: As an Option, the GT-1400 Fold door can be certiied to have a Hurricane High Impact Compliant
Version manufactured to meet the High Velosity Hurricane Zone (HVHZ) requirements of the Florida
building codes.
Secon 1b: Objecve
The GT-1400 is designed to be installed within a Rough Opening of a Building. The door
function is controlled by the Magnum Control. This Control offers many features to accommodate
most installation options.
This manual offers step by step instructions.

Rev. 11-26-14 Part #15-9324
www.NabcoEntrances.com 1400 Fold Door System
Geng Started 2-6
CHAPTER 2: GETTING STARTED
GT-1400 Fold Door System is manufactured out of aluminum, and comes with the following:
►Installation Conigurations:
• Installed within Rough Opening of Building
• Door Panel assemblies always fold toward the direction of breakout.
►Mechanical Conigurations:
• Bottom Load: The Access Cover is located at the bottom of the Header.
• Single Fold: (1) Door Leaf assembly that slides to the right or left (FS - FX or FX - FS).
• Bi-Part: (2) Door Leaf assemblies that slide apart from the center (FS -FX - FX - FS).
• FS = Swing Panel
• FX = Slide Panel
►Extrusion Conigurations:
• Slick Jamb Tubes
►Emergency Egress:
• Full Open: Door Panel assembly breaks out for emergency egress.
Secon 2a: Parts of the Header
DN 0828
④⑤
①
③
②⑥
⑦
O
F
F
12 4
3
AUX
PWR
J2
J5
AC IN
SW2
SW1
F1
R2 R3 R4 R5 R6 R7 R8
TDAS TDPG LCHK CLOSESTOPO PEN BCHK
CURRENT
LIMIT
MOTOR
J1
R28
MAGNUM 4A
LED
TRANSFORMER
RELAY RELAY
J4
SIGNAL
INPUT
CAPACITOR
C26
D10
O
F
F
12 4
3
AUX
PWR
J2
J5
AC IN
SW2
SW1
F1
R2 R3 R4 R5 R6 R7 R8
TDAS TDPGL CHKC LOSESTOP OPENB CHK
CURRENT
LIMIT
MOTOR
J1
R28
MAGNUM 4A
LED
TRANSFORMER
RELAY RELAY
J4
SIGNAL
INPUT
CAPACITOR
C26
D10
1. Spindle Drive Bar 3. Push Rod 5. Motor
2. Rod End 4. Operator 6. Auxilary Transformer
7. Magnum Control and Mounting Bracket

1400 Fold Door System www.NabcoEntrances.com
Part #15-9324 Rev. 11-26-14
2-7 Geng Started
Secon 2b: Handing
Figure 2-1 Handing
DN 0833
EXTERIOR
BREAKOUT SIDE
INTERIOR
Le Hand Right Hand
Secon 2c: Wiring
For wiring details please refer to “Wiring and Adjustment Magnum 4A”; P/N 15-10682.
Secon 2d: Electrical Specificaons
Note: Electrical conduit should be pulled through the frame before mounting the Folding door.
Electricity Description
Power Input 120 (±10%) AC 50-60Hz, 5 Amps per Operator
Available current for accessories 24 VAC .5 Amps from Magnum Control
24 VAC 1 Amp from Auxiliary Transformer
Disconnect power to the junction box prior to making any electrical connections.
Failure to do so may result in serious personal or fatal injury. When uncertain
whether power supply is disconnected, always verify using a voltmeter.
Notice: Wiring must meet all local, state, federal or other governing agency codes.
Secon 2e: Magnum 4A Control
The Magnum 4A Control is programmed to open/close the Fold door according to how the door
will be used in terms of Handing, Speed, and Time Delay. Please refer to “Wiring and Adjustment
Magnum 4-4A”; P/N 15-10682 for details.
Secon 2f: Panic Breakout
Note: Adjustments are not required for GT-1400 Panic Breakout to work.
When the Folding door is broken out, (2) Magnetic Reed Switches CLOSE the circuit to activate the
Continuous Safety feature and disable the Operator. It should only take 50 pounds of force on the
Strike end of any Folding door for Breakout to occur.
Secon 2g: Associated Manuals Part Numbers
Note: Associated Manuals can be downloaded from the NABCO web site at: www.nabcoentrances.com.
►Swing Door Wiring and Adjustment Magnum 4A Control; P/N 15-10682
DANGER

Rev. 11-26-14 Part #15-9324
www.NabcoEntrances.com 1400 Fold Door System
Install Frame 3-8
CHAPTER 3: INSTALL THE DOOR FRAME
Secon 3a: Prepare the Rough Opening
Note: Make allowances for tile or other existing materials that may change the loor height.
1. Ensure the Rough Opening is the correct size. Please see Figure 2-2.
The width of the Rough Opening should equal:
• Package Width + 1/4 inch on each side
The height of the Rough Opening should equal:
• Package height + 1/4 inch on each side
Figure 3-1 Rough Opening
R.O. WIDTH
R.O.
HEIGHT
90.0° 90.0°
1/4” 1/4”
1/4”
FINISHED FLOOR
DN 0081
Secon 3b: Remove Dress Plates from Header
1. Remove Header from Carton.
2. Position Header so the Magnetic Latches are on the loor. Please see Figure 3-2.
a. Protect Header from scratches.
3. Go to the Guide Channel located on the same side the Rocker Switch is installed on the
Dress Plate.
Do not let go of the Guide Channel it will spring back to its original location and can
result in personal injury or damage.
4. Swing out the Guide Channel 90 degrees away from the Magnetic Latch.
a. Manually hold the Guide Channel while taking off the Dress Plate and Lock Plates.
DANGER

1400 Fold Door System www.NabcoEntrances.com
Part #15-9324 Rev. 11-26-14
3-9 Install Frame
Figure 3-2 Swing Out Channel Guides 90 Degrees
DN 0837
Guide Channel
Swing
Out 90
Magnec Latches
Dress Plate
Rocker Switch
5. Remove #10-24 x 3/4 inch screws used to secure the Dress Plate. Please see Figure 3-3.
a. Save screws for reinstallation.
6. Carefully lower the Dress Plate until the Rocker Switch wiring is exposed.
7. Disconnect the Switch from the switch harness.
8. Remove the Dress Plate and Lock Plates.
a. Save hardware for reinstallation.
9. Manually return the Guide Channel so that it butts up against the Magnetic Latch.
10. Go to the other Guide Channel. Repeat steps 4 and 5 and 8 and 9.
Figure 3-3 Remove Dress Plates from Header
DN 0834
#10-24 x 3/4” Screw
Lock Plate
Dress Plate
(w/Rocker Switch)
Boom of Header
Rocker Switch Harness
ON
HOLD-OPEN
OFFOFF
Dress Plate

Rev. 11-26-14 Part #15-9324
www.NabcoEntrances.com 1400 Fold Door System
Install Frame 3-10
Secon 3c: Secure Header to Jamb Tubes
1. Remove (4) 1/4-20 x 3/4 inch bolts and (4) 1/4 inch star washers that were pre-screwed
inside rivnuts located on each Jamb tube.
a. Save hardware for reinstallation.
2. Position Jamb tubes on either side of Header so the Weathering faces up, towards the Exterior
side of building (opposite of Magnetic Latches). Please see Figure 3-4.
3. Orientate the Frame so the open end at the bottom of each Jamb Tube is facing the Exterior
side of the building.
Figure 3-4 Orientate Frame to Exterior Side of Building
DN 0830
Magnec Latches
Boom of Jamb Tube
(towards Exterior opening)
EXTERIOR
Door Opening
Weathering must face up
(towards Exterior opening)
4. Use a 7/16 inch Socket on a 6 inch extension to secure the Header to each Jamb Tube with (4)
1/4-20 x 3/4 inch bolts and (4) star washers that were saved. Please see Figure 3-5.
a. Do not overtighten Bolts.
Figure 3-5 Secure Header to Jamb Tubes
DN 0327
1/4-20 x 1” Bolt
1/4 “ Star Washer
Jamb Tube
Header
Secon 3d: Anchor Placement
Anchors are not provided by NABCO.
Anchors must be appropriate for the type of structure being fastened to.
Ensure anchor heads to not come in contact with edges of glass to prevent breakage.
Note: It is recommended to countersink holes as required to lush the surface.
Note: It is recommended to drill tap threads for 1/4 inch anchors in a steel or aluminum structure.
Note: If anchor points in structure are known, the aluminum door framing can be predrilled prior to

1400 Fold Door System www.NabcoEntrances.com
Part #15-9324 Rev. 11-26-14
3-11 Install Frame
installing into the opening.
Note: Do not overtighten anchors to prevent deforming Jamb tubes.
3.c.a: Secure Jamb Tubes to Rough Opening
Figure 3-6 Anchor Placement
DN 0832
36” max
48” max
48” max
Y Y Y
Y Y Y
5. Lift to position assembled Frame into the rough opening.
a. Ensure the Panic Catch magnets are toward the Interior side of Building.
b. Ensure the Weathering Strips are toward the Exterior side of Building.
6. Plumb Jamb tubes in both planes to ensure the rough opening allows a 1/4 inch clearance.
Please see Figure 3-7.
a. Shim back of Jamb as required.
7. Plumb the Header at the top to ensure the rough opening allows a 1/4 inch clearance.
a. Shim top of Header or Transom Horizontal as required.
Figure 3-7 Shim and Plumb Frame
1/4” Shim and plumb
for proper clearance
DN0831
Jamb Tube
Header
1/4” Shim and plumb
for proper clearance
8. Secure Jamb Tubes to Rough Opening accordingly. Please see Figure 3-8.
Standard Fold Door
• Use 1/4 inch diameter anchors with a minimum of 3 per Jamb tube, maximum is
48 inches on center. Drill 1/4 inch diameter holes in the face of Jamb Tube and then
countersink each hole. Please see Figure 3-6.
Hurricane Fold Door
• Screw in anchors to secure the Frame (per manufacturer’s certiication document(s).
Figure 3-8 Secure Jamb Tubes to Rough Opening
DN 0658
SLICK JAMB
1/4” Anchor 1/4” Anchor Hole(s)

Rev. 11-26-14 Part #15-9324
www.NabcoEntrances.com 1400 Fold Door System
Install Frame 3-12
3.c.b: Secure Header to Rough Opening
Verify that each Motor is connected to the Magnum 4A Control before inserting Pin
or 1/8" Allen Wrench into Lovejoy Coupling Access Hole via the Access Hole on the
Magnum 4A Control. Failure to do so will allow the Fold Doors to slam shut without
motor breaking in the event the Pin or 1/8" Allen Wrench falls out.
Do not let go of the Guide Channel if a Pin or 1/8" Allen Wrench has not been inserted
into the Lovejoy Coupling Access Hole, it will spring back to its original location and
can result in personal injury or damage.
1. Ensure the Motor is connected to the Magnum 4A Control.
2. Swing the Guide Channel out and away from the Magnetic Latch. Please see Figure 3-9.
a. It will be necessary to manually hold the Guide Channel in the 90 degree position until
the Pin or 1/8 inch Allen Wrench is inserted into the Lovejoy Coupling Access Hole.
Figure 3-9 Swing out Channel Guides
DN 0838
Guide Channel
(open towards Exterior)
Swing Out 90
EXTERIOR
1/4" Anchor
3. Insert a Pin or 1/8 inch Allen Wrench into the access hole located on the Magnum Control
mounting bracket which leads to the Lovejoy Coupling access hole in the Operator. Please see
Figure 3-10.
Do not allow the Pin or 1/8 inch Allen Wrench to drop out of the Access Hole at any
time during installation. The Guide Channel will spring back to its original location
and can result in personal injury or damage.
Figure 3-10 Insert Pin or 1/8 inch Allen Wrench
O
F
F
1 2 4
3
AUX
AUX
PWR
PWR
J2
J2
J5
J5
AC IN
AC IN
SW2
SW2
SW1
SW1
F1
F1
R2
R2
R3
R3
R4
R4
R5
R5
R6
R6
R7
R7
R8
R8
TDAS
TDAS
TDPG
TDPG
LCHK
LCHK
CLOSE
CLOSE
STOP
STOP
OPEN
OPEN
BCHK
BCHK
CURRENT
CURRENT
LIMIT
LIMIT
MOTOR
MOTOR
J1
J1
R28
R28
MAGNUM 4A
MAGNUM 4A
LED
LED
TRANSFORMER
TRANSFORMER
RELAY
RELAY
RELAY
RELAY
J4
J4
SIGNAL
SIGNAL
INPUT
INPUT
CAPACITOR
CAPACITOR
C26
C26
D10
D10
O
F
F
1 2 4
3
AUX
AUX
PWR
PWR
J2
J2
J5
J5
AC IN
AC IN
SW2
SW2
SW1
SW1
F1
F1
R2
R2
R3
R3
R4
R4
R5
R5
R6
R6
R7
R7
R8
R8
TDAS
TDAS
TDPG
TDPG
LCHK
LCHK
CLOSE
CLOSE
STOP
STOP
OPEN
OPEN
BCHK
BCHK
CURRENT
CURRENT
LIMIT
LIMIT
MOTOR
MOTOR
J1
J1
R28
R28
MAGNUM 4A
MAGNUM 4A
LED
LED
TRANSFORMER
TRANSFORMER
RELAY
RELAY
RELAY
RELAY
J4
J4
SIGNAL
SIGNAL
INPUT
INPUT
CAPACITOR
CAPACITOR
C26
C26
D10
D10
AUX
F1
PWR
J2
AC IN
MAGNUM 4A
TRANSFORMER
RELAY RELAY
J4
J5
MOTOR
J1
R2 R3 R4 R5 R6 R7 R8
O
F
F
12 4
3
SW2
SW1
TDAS TDPG LCHK CLOSESTOP OPEN BCHK
CURRENT
LIMIT
R28
LED
SIGNAL
INPUT
CAPACITOR
C26
D10
AUX
F1
PWR
J2
AC IN
MAGNUM 4A
TRANSFORMER
RELAY RELAY
J4
J5
MOTOR
J1
R2 R3 R4 R5 R6 R7 R8
O
F
F
12 4
3
SW2
SW1
TDAS TDPG LCHK CLOSESTOP OPEN BCHK
CURRENT
LIMIT
R28
LED
SIGNAL
INPUT
CAPACITOR
C26
D10
Magnum 4A Control
Operator
Insert Pin or Allen Wrench
Lovejoy Access
Coupling Hole
Magnum 4A
Access Hole
DN 0839
DANGER
DANGER
DANGER

1400 Fold Door System www.NabcoEntrances.com
Part #15-9324 Rev. 11-26-14
3-13 Install Frame
4. With both Guide Channels locked into the 90 degree open position, secure Header to the
rough opening:
Standard Fold Door
• Use 1/4 inch diameter anchors with a maximum 48 inches on center. First anchor
maximum is 36 inches from each end of the Header. Secure with appropriate
Fasteners.
Hurricane Fold Door
• Screw in anchors to secure the Frame (per manufacturer’s certiication document(s).

Rev. 11-26-14 Part #15-9324
www.NabcoEntrances.com 1400 Fold Door System
Connect Incoming Wiring 4-14
CHAPTER 4: 110 VAC GENERAL WIRING
The Magnum 4A Control Bracket has (3) 7/8 inch Holes that can be used to secure a Cable Clamp
or Conduit. Please see Figure 4-1.
Figure 4-1 Magnum 4A Control Bracket
DN 0841
7/8" Hole
7/8" Hole
Do not place finger or uninsulated tools inside electrical control box. Touching
wires or other parts inside enclosure may cause electrical shock, serious injury
or death.
1. Disconnect Power at Fused disconnect. Verify with voltmeter.
2. Route wiring away from moving parts and other low voltage wiring.
Note: Wire clamps are factory installed installed the Header to secure power wires as they come from the
end of the Header.
4.a.a: Main Power Connecons - Single Fold
④
Hot
Ground
DN 0840
Green
Neutral
Black
White White
Black
Black
Black
①
②
③
⑤⑥
AUX
F1
PWR
J2
AC IN
MAGNUM 4A
TRANSFORMER
RELAY RELAY
J4
J5
MOTOR
J1
R2 R3 R4 R5 R6 R7 R8
O
F
F
12 4
3
SW2
SW1
TDAS TDPG LCHKCLOSESTOP OPEN BCHK
CURRENT
LIMIT
R28
LED
SIGNAL
INPUT
CAPACITOR
C26
D10
1. Magnum 4A Control Bracket 3. Power Switch 5. Motor Thermal Switch
2. Magnum 4A Control 4. Ground Screw 6. Transformer
DANGER

1400 Fold Door System www.NabcoEntrances.com
Part #15-9324 Rev. 11-26-14
4-15 Connect Incoming Wiring
4.a.b: Main Power Connecons - Bi-Fold - 2 Controls
AUX
F1
PWR
J2
AC IN
MAGNUM 4A
TRANSFORMER
RELAY RELAY
J4
J5
MOTOR
J1
R2 R3 R4 R5 R6 R7 R8
O
F
F
12 4
3
SW2
SW1
TDAS TDPG LCHK CLOSESTOP OPEN BCHK
CURRENT
LIMIT
R28
LED
SIGNAL
INPUT
CAPACITOR
C26
D10
AUX
F1
PWR
J2
AC IN
MAGNUM 4A
TRANSFORMER
RELAY RELAY
J4
J5
MOTOR
J1
R2 R3 R4 R5 R6 R7 R8
O
F
F
12 4
3
SW2
SW1
TDAST DPG LCHK CLOSESTOPO PENB CHK
CURRENT
LIMIT
R28
LED
SIGNAL
INPUT
CAPACITOR
C26
D10
DN 0843
④
Hot
Ground Green
Neutral
Black
White White
Black
Black
Black
①
②
③
⑤
⑥
Black
White
Black
1. Magnum 4A Control Bracket 3. Power Switch 5. Motor Thermal Switch
2. Magnum 4A Control 4. Ground Screw 6. Transformer

Rev. 11-26-14 Part #15-9324
www.NabcoEntrances.com 1400 Fold Door System
Install the Folding Door 5-16
CHAPTER 5: INSTALL THE FOLDING DOOR
Secon 5a: Install the Boom Pivot (Floor Poron)
1. Obtain the Bottom Pivot Parts Box (P/N 22-9643) provided by NABCO.
a. (2) 1/4 - 20 round head screws provided by the Pivot Manufacturer are not required.
2. Obtain the Bottom Pivot (Floor Portion) from the Parts Box.
3. Insert the Bottom Pivot into Notch located at the bottom of Jamb tube. Please see Figure 5-1.
4. Temporarily secure Bottom Pivot to Jamb tube with (1) 1/4-20 x 7/8 inch Flat Head screw.
Figure 5-1 Temporarily Secure Bottom Bracket to Jamb Tube
DN 0835
1/4-20 x 7/8”
Flat Head Screw
Pivot Jamb Tube
5. Using the Bottom Pivot as a template, drill down through (2) screw holes with a 1/4 inch
Masonry drill bit at least 1-1/2 inches into the loor.
6. Remove the Bottom Pivot Floor Portion.
7. Insert (1) 1 inch Anchor into each drilled hole. Please see Figure 5-2.
8. Replace Bottom Pivot. Align screw holes with Anchors.
9. Secure Bottom Pivot to Jamb tube with (1) 1/4-20 x 7/8 inch Flat Head screw.
10. Obtain the Pivot Base Bracket from the Parts Box.
11. With the open end pointing to Jamb Tube, align screw holes with the Bottom Pivot.
a. If deemed necessary, the Pivot Plate can be adjusted by sliding it in either direction.
12. Secure the Pivot Base Bracket to the Bottom Pivot and to the loor by inserting
(1) #14 x 1-1/2 inch Flat Head screw into each Anchor.
13. Screw the Pivot Bearing onto the Thread Post.
Figure 5-2 Secure Bottom Pivot Assembly to Floor and Jamb Tube
DN 0836
#16 Blue Anchor #14 x 1-1/2” Phillips
Pan Head Screw
Boom Pivot
Floor
Pivot Base Bracket
Pivot Bearing
Thread Post
Secon 5b: Install the Boom Pivot (Door Poron)
1. Obtain the Folding Door provided by NABCO.
2. Lay the Folding Door on a lat surface.
a. Protect Folding Door from scratches.

1400 Fold Door System www.NabcoEntrances.com
Part #15-9324 Rev. 11-26-14
5-17 Install the Folding Door
3. Go to the Bottom Rail. Locate (2) pre-drilled holes inside Web. Please see Figure 5-3.
4. Lay the Bottom Pivot (Door Portion) onto the Spacer. Align screw holes to the Web.
5. Secure the Bottom Pivot to the Spacer and to the Web within the Bottom Rail with (2)
1/4 - 20 x 1-1/4” Hex Screws.
DN 0330
1/4” Star Washer
Spacer for Boom Pivot
Web
1/4-20 x 1/4” Hex Screw
Pivot Sle
Boom Pivot
Figure 5-3 Install Bottom Pivot Door Portion Assembly into Web
Secon 5c: Secure Spindle Drive Bar to Folding Door
Note: The Drive Bar is installed to the Channel Guide at the NABCO Factory for shipping purposes only and
must be removed from the Channel Guide before the Folding Door can be installed.
1. Ensure the Pin or 1/8 inch Allen Wrench is still inserted into the Lovejoy Coupling Access
Hole. If not, please follow instructions listed in Section 3d; Steps 3 thru 4.
2. Go to the Spindle Drive Bar. Remove the Hex Bolt and Nut. Please see Figure 5-4.
a. Please refer to the Shipping Sticker located on the Spindle Drive Bar.
3. Release the Spindle Drive Bar from the Guide Channel.
a. The Spindle Drive Bar can be pushed up into the Header or down into the Top Web of the
Folding door, but will remain at a 90 degree angle.
b. The Guide Channel can now freely swing closed or open.
4. Swing the Guide Channel up against the Magnetic Latch.
Figure 5-4 Release Spindle Drive Bar from Guide Channel
DN 0844
Nut
Guide Channel
Spindle Drive Bar
Bolt
Spindle Drive Bar - 90 Out
(Lowered down from Header)
Guide Channel
90
Secon 5d: Secure Folding Door to Frame
1. With the Folding Door still on a lat surface, go to the Pivot End of the Top Web.
2. Remove (4) 1/4-20 x 3/4 inch Hex Head Screws and (4) 1/4 inch Star Washers from
Riv-nuts located inside the Web. Save hardware for reinstallation. Please see Figure 5-5.

Rev. 11-26-14 Part #15-9324
www.NabcoEntrances.com 1400 Fold Door System
Install the Folding Door 5-18
Figure 5-5 Remove Screws and Star Washers
DN 0845
1/4” Star Washer
1/4-20 x 2”
Phillips Head Screw
Web
3. Lift the Folding Door from the lat surface. Please see Figure 5-6.
a. Keep Door Panels loosely folded.
4. Tilt the Folding Door to slide the Spindle Drive Bar into the Pivot end of Top Web.
a. The Spindle Drive Bar can be pushed up inside the Header to allow clearance.
5. Upright the Folding Door to slide the Bottom Pivot onto the Pivot Bearing located inside the
Bottom Rail.
6. Go back to the Top Web. Lower the Spindle Drive Bar until it butts up against the Web.
7. Secure the Spindle Drive Bar to the Web with (4) 1/4-20 x 3/4 inch Hex Head Screws and (4)
1/4 inch Star Washers that were saved for reinstallation.
a. Do not tighten down bolts at this time.
b. Bolts need to be loose enough to allow the Folding Door to be adjusted.
c. It may be necessary to adjust the preload of the Folding Door at a later time.
Figure 5-6 Install Folding Door
DN 0848
Spindle
Drive Bar
Pivot
Bearing
Spindle
Drive Bar
1/4” Star Washer
1/4-20 x 2”
Phillips Head Screw
Secon 5e: Secure Guide Channel to Folding Door
1. Manually hold open the Folding door while removing the Pin or 1/8 inch Allen Wrench from
the Lovejoy Coupling Access Hole.

1400 Fold Door System www.NabcoEntrances.com
Part #15-9324 Rev. 11-26-14
5-19 Install the Folding Door
a. Allow the Folding door to close without slamming closed.
2. Swing out and then lift the Guide Channel so it is directly on top of the Guide Roller located
inside the Top Web at the Strike end. Drop the Guide Channel onto the Guide Roller.
3. Ensure gap at the top of Door Panel is parallel to the Header and the gap at the top of Doors
are parallel to each other.
Figure 5-7 Drop the Guide Channel onto the Guide Roller
DN 0851
Guide Channel
Guide Roller
4. Ensure gap between the Strike Door and Strike Jamb Tube are parallel to each other and gap
between Bi-Fold Doors are parallel to each other. Please see Figure 5-8.
5. It is important for all gaps to be parallel to each other. Move the Strike end of each Door Panel
up or down until it is square within the door Frame.
6. Tighten down the (4) 1/4-20 x 3/4 inch Hex Head screws and (4) 1/4 inch Star Washers.
Figure 5-8 Square Fold Door Panels
DN 0323 BIFOLD DOOR SINGLE FOLD DOOR
Gap
Gap
Gap
Gap Gap
7. Push on the Bar located in the middle of (2) Door Panels to manually fold open the Door.
Please see Figure 5-9.
8. Go to the Spindle Drive Bar located inside the Top Web, at the Pivot end.
9. Obtain (1) Split Plastic Bushing that was provided by NABCO.
10. Push the Split Plastic Bushing around the Spindle between the Guide Channel and Spindle
Drive Bar.
