Nautilus Lifeline Marine Rescue GPS User manual

[phone] www.NautilusLifeLine.com [email protected]
Proudly made in Canada
2
1
3
4
Open the dive cap by releasing the latch.
Press the blue button to power on the LifeLine GPS.
It will now begin to search for a GPS lock.
Remove the antenna retainer and manually unfurl the antenna.*
Hold the red button for 5 seconds to begin distress transmission.
The Nautilus LifeLine is an aid to your safety. It is not a life-saving device.
It is not intended to save your life.
QUICK START GUIDE TO ACTIVATE H ELP
* Be cautious when removing antenna retainer. The antenna may spring out rapidly.

[phone] www.NautilusLifeLine.com [email protected]
Proudly made in Canada
Ensure that the O-rings are always
clean and free of contaminants.
Performing a test will reduce the
battery life. Only perform a test once
before each dive trip
This equipment is intended for
emergency use. Do not activate
unless in an emergency situation.
Dive cap should remain sealed
unless in distress situation or when
performing self-test.
DSC functionality may be disabled
in certain countries subject to regu-
lations.
We recommend using Panasonic
CR123 3V (1550 mAh) batteries.
Lower quality batteries may have a
reduced lifespan.
Do not open dive cap underwater.
Be cautious when removing antenna
retainer. The antenna may spring out
rapidly.
In the case of accidental activation,
the user should deactivate the Life-
Line GPS distress signal and notify
the appropriate search and rescue
authorities (e.g., U.S. Coast Guard or
Rescue Coordination Center serving
the geographic region) at the earliest
possible time.
The Nautilus LifeLine is an aid to your safety. It is not a life-saving device.
It is not intended to save your life.
In order to comply with CE RF
exposure guidelines, ensure that the
LifeLine GPS is at least 16cm from
your body when transmitting.
IMPORTANT!

[phone] www.NautilusLifeLine.com [email protected]
Proudly made in Canada
GET TO KNOW LIFELINE GPS
Power Button (On/Off) - Blue
Dive Cap Clasp
Test Button - Yellow
Help Button - Red
Dive Cap
O-ring
Latch
Antenna
Antenna
Retainer
Nautius LifeLine
Marine Rescue GPS
Marine Rescue GPS
Nautilus LifeLine
(Antenna winder)
Proprietary Tool
www.NautilusLifeLine.com
Online Manual

[phone] www.NautilusLifeLine.com [email protected]
Proudly made in Canada
OPERATION
Open the dive cap by releasing the latch
Press the blue button: LifeLine GPS goes to ON standby state and GPS attempts to lock
Pressing the blue button again powers off the LifeLine GPS
• Blue LED flashes slowly while GPS searching
• Blue LED flashes quickly when GPS location determined
Remove the antenna retainer exposing the “H”elp button allowing user to manually
unfurl the antenna.
• User can press red “H”elp button at any time – not necessary to wait
for GPS to find location
Hold the red “H” button for 5 seconds to begin distress transmission
a. Red LED indictor flashing (Blue LED extinguishes)
• Red LED slow flashes if GPS not locked
(same cadence as Blue LED if red button not pressed)
• Red LED quick flashes if GPS locked
(same cadence as Blue LED if red button not pressed)
• Red LED on solid 3s before DSC/AIS transmission
b. White strobe begins – quick double flash every 5s
(to save energy, the white strobe shuts off in bright sun)
* To prevent false alerts the LifeLine GPS will wait 20s before start of first transmission
sequence (Red LED on solid)
2
1
3
4
Batteries should be within
the marked expiry date.
Batteries Not Included
Ensure that your
LifeLine GPS has
two CR123 batteries
installed.
Pull forward only
to remove antenna retainer
Warning:
DO NOT
pull up
How to remove antenna retainer

[phone] www.NautilusLifeLine.com [email protected]
Proudly made in Canada
MMSI
2
1
3
4
5
Each LifeLine GPS comes pre-programmed with an MID number. This number
serves as your identification and will be transmitted along with your distress call.
The number can be found on the back label of your LifeLine GPS.
If your vessel (or the vessel you are traveling with) has a DSC enabled VHF radio, it
is recommended to program the vessel MMSI number into your LifeLine GPS. This
allows your LifeLine GPS to send a DSC position report directly to the vessel VHF
radio by holding down the yellow button for 5 seconds.
Note: Not required for use of the red Help button
USER MID
VESSEL MMSI CONFIGURATION
MMSI PROGRAMMING (Android)
Download and install Nautilus LifeLine GPS MMSI Programming App from
Google Play or Apple iTunes
Start the App and enter Own Ship’s MMSI, Group MMSI, and if desired, AIS
Only or DSC Only
Lay LifeLine GPS face down with Label pointing up
Aim your mobile phone’s flashlight at LifeLine GPS and press PROGRAM.
Your mobile phone’s flashlight will flicker. Try not to move the phone during
the programming sequence.
LifeLine GPS flashes the white strobe LED twice when successfully
programmed and returns to IDLE state. If no valid programming sequence
received after 60s, LifeLine GPS returns to IDLE state.
REGION CONFIGURATION (COMING SOON)
MMSI PROGRAMMING (iOS) – Coming Soon

Press and hold LifeLine GPS Test Button for 5s till ORANGE indicator on Solid
Releasing TEST button the ORANGE indicator will flash with the same rate as BLUE indicator
• Slow flashing indicates no acquired position
• Fast flashing indicates acquired position
Test sequence begins after LifeLine GPS has acquired position.
Approximately 20s after acquiring position the ORANGE Indicator will stop flashing (on solid)
and LifeLine GPS will transmit a low power Routine Own Ship Position Report. This message
will only be received by close proximity Marine VHF radios.
Low Battery indicated by alternate sequencing of ORANGE – RED indicators. Replace
batteries before next use.
Good Battery indicated by LifeLine GPS returning to IDLE.
2
1
3
4
5
6
Note: Test should be done at a temperature between 10-30 degrees Celsius.
TEST SEQUENCE
[phone] www.NautilusLifeLine.com [email protected]
Proudly made in Canada
MAINTENANCE
Check the O-ring carefully for dust or contaminants before submerging the unit.
Applying a very sparing application of lubricant to the piston o-ring can be beneficial.

[phone] www.NautilusLifeLine.com [email protected]
Proudly made in Canada
REWINDING ANTENNA
To rewind the antenna, after use of the LifeLine GPS, use the tool provided in the box. Pass
the end of the antenna through the slot of the rewinding tool. Insert the tool into the open
space of the top cap. Continuously turn the tool clockwise to fully spool the antenna back
into place. Remove the tool and replace the antenna retainer.
(Need to install with proper
orientation +, - symbols)
How to install batteries
Unscrew two screws
on top cap Insert two batteries Put screws back
The batteries should be replaced per the battery
vendor's expiry date as printed on the batteries
and recorded on the back label or after TEST
mode battery change notice (alternating RED and
Yellow LEDs). Replacing the batteries requires a
Philips #1 head screw driver and a clean, non lint
surface. We recommend using Panasonic
CR123A 3V batteries. Lower quality batteries may
have a reduced lifespan.
BATTERY INFORMATION

SPECIFICATIONS
AIS Transmit Power: 1 Watt
AIS Frequency: 161.975 and 162.025 MHz
DSC Transmit Power: 0.5 Watt
DSC Frequency: 156.525 MHz
Messages: Individual Distress Relay, Distress Alert
Environmental Temperature Range: -20°C ~ +55°C
Waterproof Depth: 425 feet (130 meter) sea water
Dimensions: 2.9 x 3.8 x 1.5 inch (75 x 97 x 39mm)
Weight: 4.6 oz (131g) with batteries
This radio device is designed to only provide an effective
alerting and locating capability in close proximity to a
vessel. This radio beacon is NOT an EPIRB.
Proudly made in Canada
WARNING：The FCC / The Industry Canada regulations provide that changes or modications not expressly
approved by the party responsible for compliance could void the user’s authority to operate the equipment.
