UCT-DIFF CAM
NTV-KIT314
Overview
For select uConnect 8.4” vehicles: Allows for aftermarket rear camera to be installed into
vehicle. Converts composite video standard to differential video (Chrysler/Dodge standard).
(NTV-KIT297: UCT-84 Kit required for switching, UCT84 module requires software
adjustment).
Kit Contents
UCT DIFF-CAM
NTV-ASY185

BM
03/25/14
NTV-DOC093
2 | P a g e
Agreement: End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for
misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is
intended for off-road use and passenger entertainment only.
Installation
1. Remove the radio (only) from the dashboard. This usually requires pulling some
panels and a series of screws will hold the radio into the sub-dash.
2. Disconnect all harness from the radio and set the radio aside.
3. Reprogram the UCT84 module, make certain that the ‘Rear view camera’ flag is set
to ‘ON’.
4. Reconnect the UCT84 module into the vehicle.
5. Connect the white plug from the provided DIFF Cam Harness (see figure 1 at the
bottom of this page) to the radio.
6. Connect the camera’s signal RCA to the female RCA labeled ‘R
CAM’.
7. Plug the DIFF Cam R1 board into the 14-pin connector
located on the DIFF Cam harness.
8. Connect the Blue/White wire (combined with Gray/Black
wire) to Output 2 of the UCT84 module (White/Blue, pin 12).
9. If using Output 1 (ACC OUT, White/Red, pin 11) from the UCT-84 to power the
camera, be sure to utilize a relay!
10. Reconnect the remaining plugs to the radio, remount and test for proper operation.
Rear of uConnect radio
Fig 1
Connect DIFF Cam
Harness here

BM
03/25/14
NTV-DOC093
3 | P a g e
Agreement: End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for
misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is
intended for off-road use and passenger entertainment only.
DIFF-CAM Pin Out
UCT DIFF-CAM Diagram
Pin #
Description
Color
3
Ground (-)
Black
6
Reverse Input (combines w/ pin 8)
Gray/Black
8
Reverse Input (combines w/ pin 6)
Blue/White
9
Composite Shield
[shield]
10
Composite Signal
Yellow
12
DIFF (+) to radio
Brown/White
13
DIFF (-) to radio
Brown
Wire side
If using Output 1 (ACC OUT, White/Red, pin 11) from the UCT-84 to power the
camera, be sure to utilize a relay!

BM
03/25/14
NTV-DOC093
4 | P a g e
Agreement: End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for
misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is
intended for off-road use and passenger entertainment only.
DIFF-CAM Operation
Rear view camera is enabled through the module programming before installation. Whenever
the vehicle is placed into reverse, the screen will switch to the attached rear camera.
Forced backup camera is not currently supported. This may be available in a future update. It
will currently only work in reverse.
UCT84 Module (not included) Programming
The UCT84 module is shipped with Video in Motion (VIM) enabled and backup camera
disabled. Any changes to the module’s configuration should be done before installation. The
files needed to change the configuration can be found at
http://www.navtv.com/page/19/downloads.html. Be sure to follow installation instructions of
the software prior to connecting the
module to your computer.
Video in motion; address input in motion:
In the “ON” state, video from the DVD
player will be available while the vehicle is
in motion. Along with navigation input in
motion and Bluetooth control.
If this feature is disabled, all the above
features will work in the factory operation.
Rear view camera: In the “ON” state, the
backup camera port is available. When the
vehicle is placed into reverse the screen
will display the backup camera image
(requires optional camera harness).
The UCT84 ships with Rear view camera ‘OFF’
NTV-ASY166
