Dear customer,
Thank you very much for purchasing the NCSNavi ”Bluetooth GPS Receiver”. This user
guide is for R120 Bluetooth GPS Receiver. Please read through this guide carefully
before installation so you can use this product quickly and safely.
Moreover, it is suggested that you check the accessories that come along with the
product before installation; retain this user guide and warranty card after installation for
future reference.
★ Safety Instructions ─Please read carefully before use.
The design and make of the product meet the strictest quality and safety standards;
however, users should take note of the followings:
1. Read through the instructions ─You should read through all safety and
operation instructions before operating R120.
2. Retain the instructions ─Safety and operation instruction documents should
be retained for contingent use.
3. Notice the warnings ─All warnings marked on the operation instruction should
be kept in mind.
4. Follow the instructions ─All operation and use instructions should be followed.
5. Water and moisture ─Never use the product near water, such as bath tubs,
pools, kitchen sinks, washing machines, damp basements or swimming pools.
6. Crutch ─The product must set upon manufacture’s recommended crutches
only.
7. Ventilation ─The product should be stored in a well ventilated area.
●Hidden installation on a bookshelf or cellar is not allowed because it will
obstruct airflow from the ventilator.
8. Heat ─The product should be set far away from heating devices, like heaters,
radiators, ovens, or other heating appliances.
9. Power ─The product must use power only as described in the user guide or
marked on the product.
10.Protect power cables ─The wiring of power cables should not obstruct people
from walking or clip on other objects. Make sure the outlet is suitable for the
power cable and the plug.
11.Clean ─The product should be cleaned according to the manufacturer’s
instruction.
12.Liquid ─No liquid should be spilled into the sealed cabinet through the
openings.
13.Damages that require repair ─The product should be repaired by qualified
personnel when:
● The power cable or plug is damaged; or
● The object falls down or liquid flows into the cabinet; or
● it is caught in the rain; or
● it can not operate normally or shows apparent changes in performance; or
● it falls on the ground or the sealed part is damaged.
14.Repair ─In addition to the parts described in this user guide, users must not try
to repair the product themselves. All repairs should be performed by qualified
personnel.

NCSNAVI R120 BLUETOOTH GPS RECEIVER USER MANUAL
4
1. Overview
(Fig.1)
NCSNavi R120 Bluetooth GPS Receiver (Fig. 1) is a total solution GPS receiver with
Bluetooth and built-in rechargeable battery for high sensitivity to tracking signal. R120
design is based on MediaTek Inc.(MTK) GPS solution-MT3318 low power architecture.
R120 Bluetooth GPS Receiver transmits satellite information on to the PDA, mobile
phone or Notebook by its Bluetooth interfaces.
R120 meets the requirement of field application, such as car navigation, mapping,
agriculture surveying and security use under clear view of sky. R120 contacts to other
device through Bluetooth interface, and built-in rechargeable Li-ion battery to save
satellite information such as the status of satellite signal, the previous available location,
date and time.
With the advanced technology, R120 can track up to 51 satellites simultaneously,
re-acquires satellite signals in 0.1 microsecond and updates position data per second.

NCSNAVI R120 BLUETOOTH GPS RECEIVER USER MANUAL
5
2. Packing List
Thank you for purchasing the R120 Bluetooth GPS Receiver. Before you start, make
sure that the following items are included in your package. If any of these items are
missing, please contact your original local NCSNavi dealer or distributor.
R120 Bluetooth GPS Receiver 1 Set
Car Cigarette adapter 1 Set
Mini USB cable 1 Set
User guide and Driver CD 1 Pc
R120 Quick Start Guide 1 Pc
Warranty card 1 Pc
