2.2 million-pixel and High Sensitivity Full HD 3CCD Camera
NC-H1000Ⅱ
HD Information Camera
Features
Low noise by additional feature CLEAR VIEW
• Improve the S/N by additional function of 'CLEAR VIEW', get more vivid picture than previous
model, NC-H1000. It is suitable for the applications such as using codec compression for transmit.
2.2 million-pixel CCD image quality by shooting
• 2.2 million-pixel CCD, HDTV, high-sensitivity shooting
• Can be used in applications such as surveillance cameras
Automatic mode
• Automatic white balance and auto sensitivity switching that supports 24-hours sentinel surveillance
• Continuous shooting at the site, day and night news broadcast with HD
High-sensitivity shooting mode of the near-infrared photography
• Allows high-sensitivity shooting mode, shooting at night with near-infrared wavelength range.
Digital Zoom
• ×0.1 step adjustment digital zoom. Maximum ×10.0 digital zoom.
*The camera lens is for optional order.
http://www.nec.com/global/prod/nw/broadcast/
NEC Corporation
NC-H1000Ⅱ: HD Information Camera
Specification
Scanning 1080/59.94i
Image Sensor 2/3" 2.2 million-pixel, ITCCD x 3
Effective Pixels 1920 (H) × 1080 (V)
Output Signal HD-SDI x 2, analog (Y/Pb/Pr) for monitor x 1
External Sync BB or TRI-SYNC (0.6Vp-p)
Sensitivity 2000lx/F10
S / N 60dB with Clear View : ON
54dB with Clear View : OFF
Resolution Limit 1000TV lines
Optical Filter 3200K, 3200K+1/8ND, 3200K+1/64ND, IR-pass (with Motor Drive)
Sensitivity Adjustment GAIN 0dB to +42dB, adding pixel OFF/H+/HV+, the maximum accumulation 64FRM
Manual / automatic control
White Balance Auto Tracking / Auto
Digital Zoom ×1.1 to ×10.0 0.1 Step-fold
Power Supply DC +12V (+11V to +16V)
Power Consumption Approx 22W (normal operation)
Dimensions 110 (H) × 96 (W) × 186.5 (D) mm (excluding protrusions)
Weight Approx 1.7kg
Optional accessory
EMB-1000
Audio embedded adaptor
Microphone audio can be embedded by camera platform which mounted on adaptor on the
housing.
OAD-1000 / OBS-1000
Optical transmission adaptor
The optical transmission equipment can be integrated with the tripod.
Cat. No. H01-12070015E
To install, make connections and operate this product, please carefully read and observe instructions,
precautions and recommendations in our instruction manuals.
Safety precautions
！
● The colours in this brochure may differ from those of the actual unit. Designs and specifications of this product is subject to change without prior notice.
© 2012 NEC Corporation. NEC and the NEC logo are registered trademarks of NEC Corporation.
