Unparalleled display performance for color-
critical applications. Featuring standard and
ultra-wide color gamuts, the 24” NEC MultiSync
LCD2490WUXi2, 26” LCD2690WUXI2and
30” LCD3090WQXi deliver an entirely new
perspective to your desktop and allow you to
view photographs and graphics in optimum color.
These displays include the SpectraViewII Color
Calibration Solution, which combines award-
winning NEC LCD monitor technology with a color
measurement sensor and sophisticated software.
The result is a highly accurate, reliable, repeatable
and feature-rich display calibration and profiling
solution.
Color and brightness uniformity were paramount
in the design of these high-performance displays,
making them ideal for graphic arts, desktop
publishing, photography and other color-critical
environments. In addition, with their wide-format
design (16:10 aspect ratio), which provides roughly
the same work area as two smaller-sized displays,
you can simultaneously view/work in multiple
application windows.
SpectraViewII
TM LCD Series
Color calibration solution (24" NEC MultiSync®LCD2490W2-BK-SV, 26” LCD2690W2-BK-SV
and 30” LCD3090W-BK-SV) ideal for color-critical applications
Professional Desktop
• Standard and wide color gamut models (up to 97.5% coverage of AdobeRGB)
• Custom-calibrated colorimeter matched for NEC’s wide color gamut displays as well as standard gamut displays
• Auto Luminance control with X-Light™ Pro backlight/sensor design for consistent brightness and color
• ColorComp™ technology compensates for slight variations in luminance and color uniformity, providing even color across the screen
• IPS active matrix LCD provides superior screen performance, including wide viewing angles, lifelike esh tones and dark black levels
• Supports internal programmable 12-bit lookup tables (LUTs) for calibration
• High resolution allows for more content to be displayed on a single monitor
• Designed for landscape or portrait usage without degradation of performance or the display’s lifecycle
• Digital and analog inputs with true MultiSync support for non-native resolutions

Quick and easy measurements. The SpectraViewII system,
available for Mac OS, Windows and Linux*, uses an ultra-sensitive,
custom-calibrated NEC/X-rite iOne Display 2 colorimeter to take
color measurements of the display screen during calibration. The
software analyzes these measurements and sends color adjustment
commands directly to the display monitor. This means that color
adjustments are made in the monitor rather than in the video
graphics adapter, resulting in full use of the number of colors
available on the graphics adapter and a much brighter image
with the maximum possible color gamut. With SpectraViewII, the
video graphics adapter is not used at all to make any gamma or
tone response curve corrections to the display, so the full color
resolution and fidelity of the system is maintained.
12-bit Internal Look Up Tables (LUTs) - Each LCD monitor
supported by SpectraViewII features three internal 12-bit LUTs.
These tables allow precise adjustments to be made to the
display’s tone response curve with minimal reduction to the
number of displayable colors. Since the tone response curve
correction is stored within the display and not on the host
system’s video graphics card LUT, the display can be calibrated
on one machine and then used on another and still maintain
calibration as long as a digital video signal is used.
Display Data Channel Command Interface (DDC/CI) -
SpectraViewII communicates with the monitor using DDC/CI,
which is a two-way communications link between the video
graphics adapter and display monitor using the standard video
signal cable. No extra cables are necessary. All adjustments
to the monitor settings are done automatically using this
communications link.
Multiple calibration sets - Different monitor calibrations can
be easily loaded, allowing quick and easy switching between
different calibration settings without the need to re-calibrate
the display. Each time a calibration set is loaded, the necessary
monitor settings and ICC/ColorSync profiles are automatically
updated.
Calibrated display information - At the end of each monitor
calibration, an information window is displayed, which shows the
results of the calibration and includes a wealth of information
about the display such as the measured color gamut, grayscale
color tracking, Delta-E and luminance values. Additional
information about the display monitor such as the model name,
serial number and the total number of hours that it has been in
use are also displayed.
Calibration status validation - SpectraViewII will query each
calibrated monitor to see if any controls have changed since the
last calibration. If anything has changed, the previous calibrated
state can be restored automatically.
Application flexibility - SpectraViewII provides many features
and options that make it exible enough to be used in a large
variety of applications, including full DICOM support for medical
imaging. The display luminance can be adjusted to either a
specic user-dened value or set to the maximum the display
can achieve. In addition, custom target response curves can be
created in addition to presets such as L* and SMPTE.
Network support (Windows only) - SpectraViewII integrates with
the NEC NaViSet™ Administrator network software (available
separately from your NEC representative) to provide remote
network access and monitoring of display monitors. NaViSet™
Administrator is able to read, display and log the current
calibration settings and status of displays on an existing network
(LAN). This feature is particularly useful for large installations
where central monitoring and asset management is needed.
Monitor locking - Once calibrated, the On Screen Display (OSD®)
controls for the display monitors can be locked to prevent
accidental or unauthorized adjustment, which may invalidate the
calibrated state of the monitor.
Monitor profiling - After calibration, the display is automatically
profiled and highly accurate ICC/ColorSync color profiles
are generated and automatically registered with the color
management system. These profiles use the Bradford
Chromaticity Adaptation matrix.
Colorimeter function - The software features a colorimeter function,
which allows direct measurements to be taken by the color sensor
and the results displayed in a variety of different formats.
SpectraViewII Color Calibration Solution Features and Benefits
www.necdisplay.com
* Limited Linux support for large installations

NEC Display Solutions
500 Park Boulevard, Suite 1100
Itasca, IL 60143
866-NEC-MORE
MultiSync LCD2490W2-BK-SV
24”
0.27mm
94 @ native resolution
320 cd/m2
1000:1
178° Vert., 178° Hor. (89U/89D/89L/89R) @CR>10
Rapid Response™ (8ms G-to-G; 16ms B-to-B)
12-bit internal LUTs, displays 16.7 million colors out
of 68.5 billion color palette
AdobeRGB** - 75.2% / sRGB - 96.7%
AdobeRGB - 75.6% / sRGB - 102%
31.5 - 93.8/118 KHz (Analog/Digital)
50 - 85 Hz
NA
Analog RGB 0.7 Vp-p/75 Ohms
Separate sync: TTL Level (Positive/Negative)
Composite sync: TTL Level (Positive/Negative)
Composite sync on green: (0.3Vp-p negative 0.7Vp-p
positive)
DVI-D, DVI-I & VGA 15-pin D-sub
720 x 400 @ 70-85 Hz
640 x 480 @ 60-85 Hz
800 x 600 @ 56-85 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-85 Hz
1024 x 1280 @ 60 Hz
1152 x 864 @ 70-85 Hz
1152 x 870 @ 75 Hz
1280 x 960 @ 60 Hz
1280 x 1024 @ 60-75 Hz
1400 x 1050 @ 60-75 Hz
1440 x 900 @ 60-85 Hz
1600 x 1200 @ 60 Hz
1920 x 1200 @ 60Hz
720 x 480p @ 60 Hz
720 x 576p @ 50 Hz
1280 x 720p @ 50/60Hz
1920 x 1080p @ 50/60 Hz
1920 x 1200 @ 60Hz
ColorComp - uniformity corrrection, X-Light Pro -
backlight stabilization, AmbiBright - ambient light
sensor, ultra-thin frame (bezel), No Touch Auto Adjust™,
VESA Mount, sRGB, tilt, swivel, height-adjustable stand
(150mm), pivot, quick-release stand, vacation switch
(zero-watt mode), 12-bit LUTs, black level adjustment,
overdrive, ECO Mode™, real-time clock, Analog/Digital
CableComp™, TileMatrix™, TileComp™, SpectraView™
software-enabled
AC 100-120V / AC 220-240V
75W
1W
21.8 x 17 x12 in. / 554.2 x 432.4 x 306mm
21.8 x 14.2 x 4.1in. / 554.2 x 359.8 x 104mm
26 lbs. / 11.8 kg
19.2 lbs. / 8.7 kg
100 x 100mm / 200 x 100mm
5-35° C / 41-95° F
30-80%
3048m / 10,000 ft.
-10-60° C / 14-140° F
10-85%
12,192m / 40,000 ft.
UL/C-UL, UL60601, CE, Gost/PCT, PSB, CCC, TUV GS,
FCC Class B/Canadian DOC, C-tick, MPR II / MPR III, VCCI
(class 2), JIS C 61000-3-2, static electricity guideline, low
emission guideline, TUV-Ergonomie, ISO9241-307, TCO
‘03, TCO ‘6, US Mercury regulations, WEEE, RoHs, SASO,
Energy Star 4.0 Tier 2, GEEA, JEITA VOC Guideline.
J-Moss, Windows XP, DEN-TORI
4 years parts and labor, including backlight /
2-day Advanced Exchange service
M - F (7am - 7pm CST)
MultiSync LCD3090W-BK-SV
29.8”
0.251mm
102 @ native resolution
350 cd/m2
1000:1
178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10
Rapid Response™ (6ms G-to-G; 12ms B-to-B)
12-bit internal LUTs, displays 16.7 million colors out
of 68.5 billion color palette
AdobeRGB** - 97.5% / sRGB - 100%
AdobeRGB - 106.6% / sRGB - 143.9%
24 - 93.8 KHz (Analog/Digital)
24 - 85 Hz
25.2 - 268.5 MHz (DualLink)
Analog RGB 0.7 Vp-p/75 Ohms
Separate sync: TTL Level (Positive/Negative)
Composite sync: TTL Level (Positive/Negative)
Composite sync on green: (0.3Vp-p negative 0.7Vp-p
positive)
DVI-D (HDCP), DVI-I
640 x 400 @ 70-85 Hz***
720 x 400 @ 70-85 Hz
640 x 480 @ 60-85 Hz
800 x 600 @ 56-85 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-85 Hz
1152 x 864 @ 70-85 Hz
1152 x 870 @ 75 Hz
1280 x 960 @ 60 Hz
1280 x 1024 @ 60-85 Hz
1400 x 1050 @ 60-75 Hz
1440 x 900 @ 60-85 Hz
1600 x 1200 @ 60-75 Hz****
1680 x 1050 @ 60-75 Hz****
1920 x 1200 @ 60 Hz
1920 x 1440 @ 30-60Hz****
2560 x 1600 @ 30-60 Hz****
2560 x 1600 @ 60 Hz landscape / 1600 x 2560 @ 60
Hz portrait
Ultra-thin frame (bezel), No Touch Auto Adjust™,
NaViSet™ software, tilt, VESA Mount, sRGB, tilt, swivel,
height-adjustable stand (190mm), pivot, quick-release
stand, vacation switch, 12-bit LUTs, black level
adjustment, AmbiBright, ColorComp, overdrive, ECO
Mode™, real-time clock, X-Light Pro, Analog/Digital
CableComp™, TileMatrix™, TileComp™, GammaComp™
MD software, standalone calibration, SpectraView™
software-enabled, Windows Vista™ Premium-certied
AC 100-120V / AC 220-240V
150W
2W
27.1 x 18.8-26.3 x 13.5 in./ 687.3 x 478.6-668.6 x 342.8mm
23.2 x 15.1 x 4.1 in./ 589.8 x 383.4 x 104mm
40.7 lbs. / 18.5 kg
31.9 lbs. / 14.5 kg
100 x 100mm and 200 x 100mm
5-35° C / 41-95° F
30-80%
3048m / 10,000 ft.
-10-60° C / 14-140° F
10-85%
12,192m / 40,000 ft.
UL/C-UL, UL60601, CE, Gost/PCT, PSB, CCC, TUV GS,
FCC Class B/Canadian DOC, C-tick, MPR II / MPR III,
VCCI (class 2), JIS C 61000-3-2, static electricity guide-
line, low emission guideline, TUV-Ergonomie, ISO9241-
307, TCO ‘03, TCO ‘6, US Mercury regulations, WEEE,
RoHs, SASO, Energy Star 4.0 Tier 2, GEEA, JEITA VOC
Guideline. J-Moss, Windows XP, DEN-TORI
4 years parts and labor, including backlight /
2-day Advanced Exchange service
M - F (7am - 7pm CST)
MultiSync LCD2690W2-BK-SV
25.5"
0.287mm
89 @ native resolution
320 cd/m2
1000:1
178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10
Rapid Response™ (8ms G-to-G; 16ms B-to-B)
12-bit internal LUTs, 16.7 million colors out of 68.5
billion color palette
AdobeRGB** - 97.3% / sRGB - 100%
AdobeRGB - 106.5% / sRGB - 143.6%
31.5 - 93.8/119.2 KHz (Analog/Digital)
51 - 85 Hz
NA
Analog RGB 0.7 Vp-p/75 Ohms
Separate sync: TTL Level (Positive/Negative)
Composite sync: TTL Level (Positive/Negative)
Composite sync on green: (0.3Vp-p negative 0.7Vp-p
positive)
DVI-D, DVI-I & VGA 15-pin D-sub
720 x 400 @ 70-85 Hz
640 x 480 @ 60-85 Hz
800 x 600 @ 56-85 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-85 Hz
1024 x 1280 @ 60 Hz
1152 x 864 @ 70-85 Hz
1152 x 870 @ 75 Hz
1280 x 960 @ 60 Hz
1280 x 1024 @ 60-75 Hz
1400 x 1050 @ 60-75 Hz
1440 x 900 @ 60-85 Hz
1600 x 1200 @ 60 Hz
1920 x 1200 @ 60Hz
720 x 480p @ 60 Hz
720 x 576p @ 50 Hz
1280 x 720p @ 50/60Hz
1920 x 1080p @ 50/60 Hz
1920 x 1200 @ 60Hz
ColorComp - uniformity corrrection, X-Light Pro - back-
light stabilization, AmbiBright - ambient light sensor,
ultra-thin frame (bezel), No Touch Auto Adjust™, VESA
Mount, sRGB, tilt, swivel, height-adjustable stand
(150mm), pivot, quick-release stand, vacation switch
(zero-watt mode), 12-bit LUTs, black level adjustment,
overdrive, ECO Mode™, real-time clock, Analog/Digital
CableComp™, TileMatrix™, TileComp™, SpectraView™
software-enabled
AC 100-120V / AC 220-240V
111W
1W
23.2 x 17.5 x 12 in. / 589.8 x 444.2 x 306mm
23.2 x 15.1 x 4.1in. / 589.8 x 383.4 x 104mm
27.7 lbs./12.6 kg
20.2 lbs./9.2 kg
100 x 100mm
5-35° C / 41-95° F
30-80%
3048m / 10,000 ft.
-10-60° C / 14-140° F
10-85%
12,192m / 40,000 ft.
UL/C-UL, UL60601, CE, Gost/PCT, PSB, CCC, TUV GS,
FCC Class B/Canadian DOC, C-tick, MPR II / MPR III,
VCCI (class 2), JIS C 61000-3-2, static electricity guideline,
low emission guideline, TUV-Ergonomie, ISO9241-307,
TCO ‘03, TCO ‘6, US Mercury regulations, WEEE, RoHs,
SASO, Energy Star 4.0 Tier 2, GEEA, JEITA VOC Guideline.
J-Moss, Windows XP, DEN-TORI
4 years parts and labor, including backlight /
2-day Advanced Exchange service
M - F (7am - 7pm CST)
MultiSync and OSD are registered trademarks, and ColorComp, NaViSet,
SpectraViewII and X-Light Pro are trademarks of NEC Display Solutions. All
other brand or product names are trademarks or registered trademarks of their
respective holders. Product specications subject to change. 5/09 ver. 2.
©2009 NEC Display Solutions of America, Inc. All rights reserved.
Model
Display
Viewable Size Image
Pixel Pitch
Pixels Per Inch
Brightness (typical)
Contrast Ratio (typical)
Viewing Angle (typical)
Response Time (typical)
Panel Bit Depth
Color Gamut*
Coverage
Size
Synchronization Range
Horizontal
Vertical
Video Bandwidth
Input Signal
Video
Sync
Inputs
Resolutions Supported
(Analog/Digital)
Native Resolution
Additional Features
Voltage Rating
Power Consumption (typical)
On
Power Savings Mode
Net Dimensions (WxHxD)
with stand
without stand
Net Weight
with stand
without stand
VESA Hole Configuration Specifications
Environmental Conditions
Operating Temperature
Operating Humidity
Operating Altitude
Storage Temperature
Storage Humidity
Storage Altitude
Safety Standards
Limited Warranty
Technical Support
SpectraViewII Software Requirements
Apple Mac OS X 10.2.8 or higher/Microsoft Windows 2000, XP, XP x64, Server 2003 or Vista 32 bit.
Linux version of SpectraViewII is available for customers with large installations of NEC monitors.
At least one available USB port for GretagMacbeth color sensor.
Visit www.necdisplay.com for the latest requirements.
* Color gamut size and coverage calculated as 2-D gamut area in CIE 1931 xy colorspace. Size is the total relative display
gamut area and includes any colors outside the reference gamut. Coverage is the relative display gamut area contained
inside the reference gamut. NTSC values provided for comparison purposes - modern broadcast video uses SMPTE-C, ITU-R
BT, 709-5/sRGB or EBU primatries.
** AdobeRGB is a standard dened by Adobe Systems Incorporated.
*** 640 x 400 available with DIGITAL input only only
**** 30 Hz refresh rate available with ANALOG input only
720 x 480p @ 60 Hz
720 x 576p @ 50 Hz
1280 x 720p @ 50-60 Hz
1920 x 1080p @ 50-60 Hz
