NEC NRP-47CR User manual

P/N:48586114E101-R0

INSTRUCTION MANUAL
NRP-47CR

PROJECTION MONITOR
-2-
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to
alert the user to the presence of uninsulated “dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR
MOISTURE.
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

IMPORTANT SAFEGUARDS
-3-
1. Read, Retain and Follow All Instructions
Read all safety and operating instructions before operating the Monitor. Retain the safety and operating
instructions for future reference. Follow all operating and use instructions.
2. Heed Warnings
Adhere to all warnings on the appliance and in the operating instructions.
3. Cleaning
Unplug the Monitor from the wall outlet before cleaning. Do not use liquid, abrasive, or aerosol cleaners.
Cleaners can permanently damage the cabinet and screen. Use a lightly dampened cloth for cleaning.
4. Attachments and Equipment
Never add any attachment and/or equipment without approval of the manufacturer as such additions may
result in the risk of fire, electric shock or other personal injury.
5. Water and Moisture
Do not use the Monitor where contact with or immersion in water is possible. Do not use near bath tubs, wash
bowls, kitchen sinks, laundry tubs, swimming pools, etc.
6. Accessories
Do not place the Monitor on an unstable cart, stand, tripod, or table. The Monitor may fall,
causing serious injury to a child or adult and serious damage to the Monitor. An appliance and
cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces
may cause the appliance and cart combination to overturn.
7. Ventilation
Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the Monitor and
to protect it from overheating. Do not block these openings or allow them to be obstructed by placing the
Monitor on a bed, sofa, rug, or other similar surface. Nor should it be placed over a radiator or heat register. If
the Monitor is to be placed in a rack or bookcase, ensure that there is adequate ventilation and that the
manufacturer’s instructions have been adhered to.
8. Power Source
This Monitor should be operated only from the type of power source indicated on the marking label. If you are
not sure of the type of power supplied to your home, consult your appliance dealer or local power company.
9. Grounding or Polarization
This Monitor is equipped with a polarized alternating current line plug. This plug will fit into the power outlet only
one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If
the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.
10. Power-Cord Protection
Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point
where they exit from the Monitor.
11. Lightning
For added protection for this Monitor during a lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent
damage to the Monitor due to lightning and power-line surges.
Please read the following safeguards for your Monitor and retain for future reference.
Always follow all warnings and instructions marked on the Monitor.

12. Overloading
Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.
13. Object and Liquid Entry
Never push objects of any kind into this Monitor through openings as they may touch dangerous voltage
points or
short-out parts that could result in fire or electric shock. Never spill liquid of any kind on or into the Monitor.
14. Servicing
Do not attempt to service this Monitor yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
15. Damage Requiring Service
Unplug the Monitor from the wall outlet and refer servicing to qualified service personnel under the following
conditions:
(a) When the power-supply cord or plug is damaged.
(b) If liquid has been spilled, or objects have fallen into the Monitor.
(c) If the Monitor has been exposed to rain or water.
(d) If the Monitor does not operate normally by following the operating instructions. Adjust only those
controllers
that are covered by the operating instructions as an improper adjustment of other controllers may result in
damage and will often require extensive work by a qualified technician to restore the Monitor to its normal
operation.
(e) If the Monitor has been dropped or the cabinet has been damaged.
(f) When the Monitor exhibits a distinct change in performance - this indicates a need for service.
16. Replacement Parts
When replacement parts are required, be sure the service technician has used replacement parts specified
by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may
result in fire, electric shock or other hazards.
17. Safety Check
Upon completion of any service or repair to the Monitor, ask the service technician to perform safety checks to
determine that the Monitor is in safe operating condition.
18. Heat
The product should be situated away from heat sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
19. The appliance is not intended for use by young children or infirm persons without supervision.
20. Young children should be supervised to ensure that they do not play with the appliance.
-4-

Warning
-5-
This section must be read carefully and followed by the
user prior to the operation of the product.
The manual states important instructions for the user's own safety, and the proper operation of the product.
In case of an accident, please unplug the unit from the outlet immediately.
Take the plug when unplugging the unit
from the outlet. The cord may cause fire or
electric shock if damaged.
Do not place the product in a lean or
unstable place since it may cause a serious
injury to a person, as well as damage to the
product if it falls.
Ignoring or disregarding the contents of this section and improper
operation of the product may result in the person's death or serious
injury.
Warning
To reduce the risk of electric shock, do not
remove cover or back. No user -serviceable
parts inside. efer to qualified service personnel
for repair.
Do not put any object that contains water -
such as flowerpot - on the unit.
The water may penetrate into the unit, and be
a cause of fire or hazardous electric shock.
Do not put on or use the product near water and
moisture-such as in a bathroom, washbowl, etc.
It may be a cause of fire and electric shock
hazards.
To prevent fire and damages to the product,
unplug the unit from the outlet during lightning
storm, or when it is left unattended and unused
for a long period of time.
Do not let children hang on or climb on the
product since it may be a cause of serious
injury.
Slots and openings in the case are provided for
ventilation to ensure reliable operation of the
product. Never put in any item-such as a coin,
paper, match- through these openings since it
may touch dangerous voltage points that could
result in fire or shock hazard.

Caution
-6-
Please keep the user's manual in a safe place for future reference.
This section must be read carefully and followed by the user when installing and transporting the product.
Do not put volatile substance-such as
benzene, naphtha- near the product since it
may cause a change in the product's color.
Do not put magnetic related substance, or
telephone near the product since it may
cause distortion of the image
Do not expose the product in a dusty or
moisturized place since it may be a cause of
malfunctioning.
Place the Monitor far away from the view
since it may cause damage in your eyesight. efer servicing to qualified service personnel for cleaning at least once a year
since dust inside the Monitor set may be a
result or fire and malfunctioning of the
product.
The product should be situated away from
any heat source-such as radiators, heat
registers, stoves, or other products that
produce heat.
Do not put on any heavy item on the power
cord since it may result in fire or hazardous
electric shock if the cord is damaged.
Do not cover the top of the Monitor set.
Ventilation will be prevented, and it may be
a cause of fire if the product is internally
overheated.
Unplug the power from the outlet and all the related
connections from the unit to prevent electric shock. At least
two people must work together to move the Monitor set when
transporting to prevent the Monitor from falling, and
consequently, any serious injury or damage.
Do not touch the power cord with
moisturized or watery hands when plugging
to or unplugging from the outlet since it may
be a cause of electric shock.
Ignoring or disregarding the contents of this section and
improper operation of the product may result in the
person's death or serious injury.
Caution
5~7
(Magnification)
Do not spill water or drop the remote
controller since it may be a cause of
malfunctioning.

This product has advantages as follows.
-7-
Make Sure of Auxiliary Parts.
Large Screen
You can enjoy favorite broadcasting by using a
large screen with the size of 47” bases on
projection technology.
Use under the wheels
to avoid the movement.
Various Screen
You can watch various sizes of screen such as 16:9, 4:3, Panorama, Zoom.
4:3 Zoom1 Zoom2Panorama
OPTIONAL ADJUSTMENT OF SOUND
You can adjust sound per frequency like Audio since the equalizer is built-in.
CONNECTION OF VARIOUS DEVICES
You can watch many kinds of media in a large screen through connection of DVD or DTV, etc.
Adoption Dolby Virtual
You can enjoy dynamic and stereo sound
as in a theater.
16:9
The unit can fall over if PULLED or PUSHED,
especially if persons climb onto or hang off it.
Accidents may occur.
Method of installation for safety.
If you require to secure the unit, please
using the fixing clamp supplied.
Fixing can be done by suitable straps.
Before moving, please ensure that the
securing straps are not attached.
Clamp
Screw
Information of setting up Monitor
INSTRUCTION MANUAL
NRP-47CR

Table of Contents
-8-
Installation and Maintenance
Video Connection 9
Audio Connection 9
Camcorder & Video Game Connection 10
DVD Connection 11
Digital Satellite Receiver Connection 12
Cable TV Broadcasting Connection 12
Name of Each Part 13
Basic Guide
Method To Use Basic Menu 16
To Watch Monitor 17
Selection of Input Signal 19
Application Guide
Screen Adjustment 22
Selection of PIP 26
Sound Adjust 29
Adjustment of Static Convergence 35
Selection of Language 37
Troubleshooting 38
Product Specifications 39
Service Centres 40

Video Connection
-9-
You may connect S-Video input to enjoy a clearer and brighter picture images. You can choose and
make the connection with any one of Video 1,2, or 3 inputs.
When making connection to other equipment, please ensure you turn the main switch OFF to prevent
any damage to the equipment.
Connection is not necessary in Mono mode.
Connect either S-Video or Video input to the unit. When both are connected, the output display will be
in S-Video.
Connecting with an External Source
Audio Connection
-You may minimize the volume of the Monitor set, and listen to the sound.
-The default status of “Dolby Virtual” is in “Line out: Internal”.
Standard Audio Connection
When making connection to other equipment, please ensure you turn the main switch OFF to prevent
any damage to the equipment.

Camcorder & Video Game Connection
-10-
-Use the input jack provided at the side panel of the Monitor set
-Use the same connection method for Video game.
When making connection to other equipment, please ensure you turn the main switch OFF to prevent
any damage to the equipment.
Watching the Camcorder Recording on Monitor
When making connection to other equipment, please ensure you turn the main switch OFF to prevent
any damage to the equipment.
-Connect the camcorder and video as follows.
-Turn the camcorder's video output switch on, and play the recorded material.
-Press the "VIDEO" button, and select Video 1.
-Select A/V INPUT for the Video Input, and start recording.
Playing a Recorded Material and Recording a Video simultaneously
Video game

DVD Connection
-11-
-480i, 576i or 576p input signal is possible for DVD input.
-DVD screen output is composed of three separate primary color jack(Y/Cb/Cr), resulting in a higher image quality.
-Y/Cb/Cr, may also be noted as Y/PB/PR or Y/Pb/Pr in different DVD players.
-The DVD player’s audio output must be connected to the DVD audio input socket at the back of the Monitor set.
DVD
When making connection to other equipment, please ensure you turn the main switch OFF to prevent
any damage to the equipment.

Digital Satellite Receiver Connection
(DIGITAL SET TOP BOX)
-12-
Cable TV Broadcasting Connection
The signal input of 1080i and 576p are available in this product.
You may use a general A/V jack for its connection.
Digital Satellite Receiver
Watching cable television is only possible after you have subscribed to the local broadcasting company and
installed a cable receiver. You may make the connection to any of the Video input 1, 2, & 3.
External Input Connection Source
Watching High Definition Digital Broadcasting
When making connection to other equipment, please ensure you turn the main switch OFF to prevent
any damage to the equipment.
When making connection to other equipment, please ensure you turn the main switch OFF to prevent
any damage to the equipment.

Name of Each Part
-13-
Buttons on the Monitor set have the same function as those of the remote controller.
Front Panel Button
If you turn the Monitor set off by pressing the main power button at this panel, it is as
unplugging the power cord from the outlet since this will prevent all operation of both the
Monitor set and the remote controller. Unless you are not using the unit for a long period of
time, have the main power on this panel turned on at all times.
Remote controller signal receiver
The screen contains the remote controller signal receiving window; thus, point the remote
controller towards the screen when using it.
Stand by / Timer Lamp
Stand by lamp is green color if power turns on and red color if power turns off.
Timer lamp turns on in Off/On reservation.
Front Panel

-14-
Side Panel
It is convenient to use the input jacks
provided at the side panel when connecting
to the camcorder or video game.
Back Panel
Side and Rear Panel

-15-
Parts of the remote controller

Method To Use Basic Menu
-16-
- Basic menu appears on the screen if pressing the menu button of the remote control.
- There are 5 items of Picture, Sound, Function, PIP and Special in the basic menu.
- Each item has sub-items under it. If the desired item is selected, the relevant sub-items are displayed upward.
SOUND
FUNCTION
PIP
SPECIAL
Adjusts Brightness, Contrast, Sharpeness and Color(PAL & NTSC),
Tint(NTSC Only).
Adjusts Balance and Equalizer.
Adjusts Timer, Language and Picture NR.
Adjusts PIP
Adjusts Center, Convergence, Dolby Virtual, Component
Press the “Menu” button.
•The main menu appears if
pressing the Menu button.
Press the “◀VOL▶” button.
•You may setup according to the
directions on the screen after
selecting the desired item and
pressing the “◀VOL▶”button.
•If the setup is completed, exit
from the menu by pressing the
“Menu”button.
Basic Menu

To Watch Monitor
-17-
- Buttons with same name in the main body performs same function.
VIDEO COMPONENT POWER
MENU
RECALL
DOLBY
VIRTUAL SOUND
MODE
SCREEN
SIZE
MUTE
PIP POSITION
PIP VIDEO STILL
SWAP
SCREEN
MODE
SLEEP
VOL VOL
Press the “Main Power”button of the
main body.
•The buttons of the remote control and the
main body operate only when pressing the
“Main Power”button of the main body.
The remote control and the main body do not
operate if turning the “Main Power”button of
the main body off.
To suddenly turn sound off
1. Press the ‘Mute’button.
2. No sound is heard if ‘Mute’is displayed on
the screen.
3. Sound is heard again if pressing the ‘Mute’
button once again.
For example, please use this button when
telephone rings or when guest comes while
watching Monitor.
To Watch Monitor

-18-
Press the “Main Power” button.
•Press the “Main Power”button of the
main body.
•The stand by lamp turns on in red
color.
•Press the “Power”button of the main
body or the “Power”button of the
remote control.
•The stand by lamp turns on in “green”
color and the Monitor turns on.
Adjust volume.
•Sound reduces if pressing the ◀
VOL button.
•Sound increases if pressing the
VOL▶button.
Press the “Power” button for turning the Monitor off.
•Monitor turns off and the
stand by lamp changes to
red color.
Vol 9

Press the “VIDEO” button.
•Screen changes as follows whenever pressing the
“VIDEO”button.
Video 1
Video 2
Video 3
Video 3
- See 9p for connection method of Monitor and “Video”.
Notices:
Cautions in menu setup
•Menu disappears if not operating any button for 10 seconds from the menu.
•Don’t connect video signal and S-video signal to the video input terminal
(1,2,3) at the same time. If connecting both signals at the same time, the S-
video operates.
•You can watch only when this input terminal must be connected to the
composite video (generally video) signal.
•If sound signal is of mono method, connect it to the L-terminal of the sound
input terminal.
Selection of Input Signal
-19-
When watching video, Camcorder, Cable Monitor
