NEC P350W Series User manual

Portable Projector
P420X/P350X/P350W
User’s Manual
Model No.
NP-P420X, NP-P350X, NP-P350W

3rd edition, January 2011
• Macintosh,MacOSXandPowerBookaretrademarksofAppleInc.registeredintheU.S.andothercountries.
• Microsoft,Windows,WindowsVista,InternetExplorer,.NETFrameworkandPowerPointareeitheraregistered
trademarkortrademarkofMicrosoftCorporationintheUnitedStatesand/orothercountries.
• MicroSaverisaregisteredtrademarkofKensingtonComputerProductsGroup,adivisionofACCOBrands.
• VirtualRemoteToolusesWinI2C/DDClibrary,©NicomsoftLtd.
• HDMI,theHDMILogoandHigh-DenitionMultimediaInterfacearetrademarksorregisteredtrademarksofHDMI
LicensingLLC.
• TrademarkPJLinkisatrademarkappliedfortrademarkrightsinJapan,theUnitedStatesofAmericaandother
countriesandareas.
• Wi-Fi®,Wi-FiAlliance®,andWi-FiProtectedAccess(WPA,WPA2)®areregisteredtrademarksoftheWi-FiAlli-
ance.
• Blu-rayisatrademarkofBlu-rayDiscAssociation
• Crestron,CrestronControl,andCrestronRoomViewaretrademarksorregisteredtrademarksofCrestronElectron-
ics,Inc.
• Otherproductandcompanynamesmentionedinthisuser’smanualmaybethetrademarksorregisteredtrademarks
oftheirrespectiveholders.
• GPL/LGPLSoftwareLicenses
 TheproductincludessoftwarelicensedunderGNUGeneralPublicLicense(GPL),GNULesserGeneralPublic
License(LGPL),andothers.
 Formoreinformationoneachsoftware,see“readme.pdf”insidethe“aboutGPL&LGPL”folderonthesuppliedCD-
ROM.
NOTES
(1)Thecontentsofthisuser’smanualmaynotbereprintedinpartorwholewithoutpermission.
(2)Thecontentsofthisuser’smanualaresubjecttochangewithoutnotice.
(3)Greatcarehasbeentakeninthepreparationofthisuser’smanual;however,shouldyounoticeanyquestionable
points,errorsoromissions,pleasecontactus.
(4)Notwithstandingarticle(3),NECwillnotberesponsibleforanyclaimsonlossofprotorothermattersdeemed
toresultfromusingtheProjector.

i
Important Information
Safety Cautions
Precautions
PleasereadthismanualcarefullybeforeusingyourNECprojectorandkeepthemanualhandyforfuturereference.
CAUTION
Toturnoffmainpower,besuretoremovetheplugfrompoweroutlet.
Thepoweroutletsocketshouldbeinstalledasneartotheequipmentaspossible,andshouldbeeasily
accessible.
CAUTION
TOPREVENTSHOCK,DONOTOPENTHECABINET.
THEREAREHIGH-VOLTAGECOMPONENTSINSIDE.
REFERSERVICINGTOQUALIFIEDSERVICEPERSONNEL.
Thissymbolwarnstheuserthatuninsulatedvoltagewithintheunitmaybesufcienttocauseelectrical
shock.Therefore,itisdangeroustomakeanykindofcontactwithanypartinsideoftheunit.
Thissymbolalertstheuserthatimportantinformationconcerningtheoperationandmaintenanceofthis
unithasbeenprovided.
Theinformationshouldbereadcarefullytoavoidproblems.
WARNING: TOPREVENTFIREORSHOCK,DONOTEXPOSETHISUNITTORAINORMOISTURE.
DONOTUSETHISUNIT’SPLUGWITHANEXTENSIONCORDORINANOUTLETUNLESSALLTHEPRONGS
CANBEFULLYINSERTED.
DOC Compliance Notice (for Canada only)
ThisClass B digitalapparatusmeets allrequirementsofthe Canadian Interference-CausingEquipmentRegula-
tions.
Machine Noise Information Regulation - 3. GPSGV,
Thehighestsoundpressurelevelislessthan70dB(A)inaccordancewithENISO7779.
CAUTION
Avoiddisplayingstationaryimagesforaprolongedperiodoftime.
DoingsocanresultintheseimagesbeingtemporarilysustainedonthesurfaceoftheLCDpanel.
Ifthisshouldhappen,continuetouseyourprojector.Thestaticbackgroundfrompreviousimageswill
disappear.
Disposing of your used product
EU-widelegislationasimplementedineachMemberStaterequiresthatusedelectricalandelectronic
productscarryingthemark(left)mustbedisposedofseparatelyfromnormalhouseholdwaste.Thisin-
cludesprojectorsandtheirelectricalaccessoriesorlamps.Whenyoudisposeofsuchproducts,please
followtheguidanceofyourlocalauthorityand/orasktheshopwhereyoupurchasedtheproduct.
Aftercollectingtheusedproducts,theyarereusedandrecycledinaproperway.Thiseffortwillhelpus
reducethewastesaswellasthenegativeimpactsuchasmercurycontainedinalamptothehuman
healthandtheenvironmentattheminimumlevel.
ThemarkontheelectricalandelectronicproductsonlyappliestothecurrentEuropeanUnionMember
States.

ii
Important Information
WARNING TO CALIFORNIA RESIDENTS:
Handlingthecablessuppliedwiththisproductwillexposeyoutolead,achemicalknowntotheStateofCalifornia
tocausebirthdefectsorotherreproductiveharm.WASH HANDS AFTER HANDLING.
RF Interference (for USA only)
WARNING
TheFederalCommunicationsCommissiondoesnotallowanymodicationsorchangestotheunitEXCEPTthose
speciedbyNECDisplaySolutionsofAmerica,Inc.inthismanual.Failuretocomplywiththisgovernmentregu-
lationcouldvoidyourrighttooperatethisequipment.Thisequipmenthasbeentestedandfoundtocomplywith
thelimitsforaClassBdigitaldevice,pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovide
reasonableprotectionagainstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,uses,and
canradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,maycause
harmfulinterferencetoradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurina
particularinstallation.
Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,whichcanbedeterminedby
turningtheequipmentoffandon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthe
followingmeasures:
•Reorientorrelocatethereceivingantenna.
•Increasetheseparationbetweentheequipmentandreceiver.
•Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.
•Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
ForUKonly:InUK,aBSapprovedpowercordwithmouldedplughasaBlack(veAmps)fuseinstalledforusewith
thisequipment.Ifapowercordisnotsuppliedwiththisequipmentpleasecontactyoursupplier.
Important Safeguards
Thesesafetyinstructionsaretoensurethelonglifeofyourprojectorandtopreventreandshock.Pleasereadthem
carefullyandheedallwarnings.
Installation
•Donotplacetheprojectorinthefollowingconditions:
-onanunstablecart,stand,ortable.
-nearwater,baths,ordamprooms.
-indirectsunlight,nearheaters,orheatradiatingappliances.
-inadusty,smokyorsteamyenvironment.
-onasheetofpaperorcloth,rugsorcarpets.
•Ifyouwishtohavetheprojectorinstalledontheceiling:
-Donotattempttoinstalltheprojectoryourself.
-Theprojectormustbeinstalledbyqualiedtechniciansinordertoensureproperoperationandreducetherisk
ofbodilyinjury.
-Inaddition,theceilingmustbestrongenoughtosupporttheprojectorandtheinstallationmustbeinaccordance
withanylocalbuildingcodes.
-Pleaseconsultyourdealerformoreinformation.

iii
Important Information
Fire and Shock Precautions
• Ensurethatthereissufcientventilationandthatventsareunobstructedtopreventthebuild-upofheatinsideyour
projector.Allowatleast4inches(10cm)ofspacebetweenyourprojectorandawall.
• Donottrytotouchtheventilationoutletontheleftfront(whenseenfromthefront)asitcanbecomeheatedwhile
theprojectoristurnedonandimmediatelyaftertheprojectoristurnedoff.Partsoftheprojectormaybecometem-
porarilyheatediftheprojectoristurnedoffwiththePOWERbuttonoriftheACpowersupplyisdisconnectedduring
normalprojectoroperation.
 Usecautionwhenpickinguptheprojector.
• Preventforeignobjectssuchaspaperclipsandbitsofpaperfromfallingintoyourprojector.Donotattempttoretrieve
anyobjectsthatmightfallintoyourprojector.Donotinsertanymetalobjectssuchasawireorscrewdriverintoyour
projector.Ifsomethingshouldfallintoyourprojector,disconnectitimmediatelyandhavetheobjectremovedbya
qualiedservicepersonnel.
• Donotplaceanyobjectsontopoftheprojector.
• Donottouchthepowerplugduringathunderstorm.Doingsocancauseelectricalshockorre.
• Theprojectorisdesignedtooperateonapowersupplyof100-240VAC50/60Hz.Ensurethatyourpowersupply
tsthisrequirementbeforeattemptingtouseyourprojector.
• Donotlookintothelenswhiletheprojectorison.Seriousdamagetoyoureyescouldresult.
• Keepanyitems(magnifyingglassetc.)outofthelightpathoftheprojector.Thelightpathbeingprojectedfromthe
lensisextensive,thereforeanykindofabnormalobjectsthatcanredirectlightcomingoutofthelens,cancause
anunpredictableoutcomesuchasareorinjurytotheeyes.
WARNING
•Donotuseanyotherobjectthantheprojector’sslidinglenscovertocoverthelenswhiletheprojectorison.
 Doingsocancausetheobjecttogetextremelyhot,andpossiblyresultinginareordamageduetotheheat
emittedfromthelightoutput.
Place the projector in a horizontal position
Thetiltangleoftheprojectorshouldnotexceed10degrees,norshouldtheprojectorbeinstalledinanywayother
thanthedesktopandceilingmount,otherwiselamplifecoulddecreasedramatically.
10°

iv
Important Information
• Donotplaceanyobjects,whichareeasilyaffectedbyheat,infrontofaprojectorexhaustvent.
 Doingsocouldleadtotheobjectmeltingorgettingyourhandsburnedfromtheheatthatisemittedfromtheex-
haust.
• Handlethepowercordcarefully.Adamagedorfrayedpowercordcancauseelectricshockorre.
- Donotuseanypowercordotherthantheonesuppliedwiththeprojector.
- Donotbendortugthepowercordexcessively.
- Donotplacethepowercordundertheprojector,oranyheavyobject.
- Donotcoverthepowercordwithothersoftmaterialssuchasrugs.
- Donotheatthepowercord.
- Donothandlethepowerplugwithwethands.
• Turnofftheprojector,unplugthepowercordandhavetheprojectorservicedbyaqualiedservicepersonnelunder
thefollowingconditions:
- Whenthepowercordorplugisdamagedorfrayed.
- Ifliquidhasbeenspilledintotheprojector,orifithasbeenexposedtorainorwater.
- Iftheprojectordoesnotoperatenormallywhenyoufollowtheinstructionsdescribedinthisuser’smanual.
- Iftheprojectorhasbeendroppedorthecabinethasbeendamaged.
- Iftheprojectorexhibitsadistinctchangeinperformance,indicatinganeedforservice.
• Disconnectthepowercordandanyothercablesbeforecarryingtheprojector.
• Turnofftheprojectorandunplugthepowercordbeforecleaningthecabinetorreplacingthelamp.
• Turnofftheprojectorandunplugthepowercordiftheprojectorisnottobeusedforanextendedperiodoftime.
• WhenusingaLANcable(onlymodelswiththeRJ-45LANport):
 Forsafety,donotconnecttotheconnectorforperipheraldevicewiringthatmighthaveexcessivevoltage.
CAUTION
• Donotusethetilt-footforpurposesotherthanoriginallyintended.Misusessuchasgrippingthetilt-footorhang-
ingonthewallcancausedamagetotheprojector.
• Donotsendtheprojectorinthesoftcasebyparceldeliveryserviceorcargoshipment.Theprojectorinsidethe
softcasecouldbedamaged.
• Select[HIGH]inFanmodeifyoucontinuetousetheprojectorforconsecutivedays.(Fromthemenu,select
[SETUP]→[OPTIONS(1)]→[FANMODE]→[HIGH].)
• Donottrytotouchtheventilationoutletontheleftfront(whenseenfromthefront)asitcanbecomeheatedwhile
theprojectoristurnedonandimmediatelyaftertheprojectoristurnedoff.
• DonotturnofftheACpowerfor60secondsafterthelampisturnedonandwhilethePOWERindicatorisblink-
ingblue.Doingsocouldcauseprematurelampfailure.
Remote Control Precautions
• Handletheremotecontrolcarefully.
• Iftheremotecontrolgetswet,wipeitdryimmediately.
• Avoidexcessiveheatandhumidity.
• Donotshort,heat,ortakeapartbatteries.
• Donotthrowbatteriesintore.
• Ifyouwillnotbeusingtheremotecontrolforalongtime,removethebatteries.
• Ensurethatyouhavethebatteries’polarity(+/−)alignedcorrectly.
• Donotusenewandoldbatteriestogether,orusedifferenttypesofbatteriestogether.
• Disposeofusedbatteriesaccordingtoyourlocalregulations.

v
Important Information
Note for US Residents
Thelampinthisproductcontainsmercury.PleasedisposeaccordingtoLocal,StateorFederalLaws.
Lamp Replacement
• Usethespeciedlampforsafetyandperformance.
• Toreplacethelamp,followallinstructionsprovidedonpage147.
• Besuretoreplacethelampandlterwhenthemessage[THE LAMP HAS REACHEDTHE END OF ITS USABLE
LIFE. PLEASE REPLACE THE LAMP AND FILTER.]appears.Ifyoucontinuetousethelampafterthelamphas
reachedtheendofitsusablelife,thelampbulbmayshatter,andpiecesofglassmaybescatteredinthelamp
case.Donottouchthemasthepiecesofglassmaycauseinjury.
 Ifthishappens,contactyourdealerforlampreplacement.
A Lamp Characteristic
Theprojectorhasahigh-pressuremercurylampasalightsource.
Alamphasacharacteristicthatitsbrightnessgraduallydecreaseswithage.Alsorepeatedlyturningthelampon
andoffwillincreasethepossibilityofitslowerbrightness.
CAUTION:
• DONOTTOUCHTHELAMPimmediatelyafterithasbeenused.Itwillbeextremelyhot.Turntheprojectoroff
andthendisconnectthepowercord.Allowatleastonehourforthelamptocoolbeforehandling.
• Whenremovingthelampfromaceiling-mountedprojector,makesurethatnooneisundertheprojector.Glass
fragmentscouldfallifthelamphasbeenburnedout.
About High Altitude mode
• Set[FANMODE]to[HIGHALTITUDE]whenusingtheprojectorataltitudesapproximately5500feet/1600metersor
higher.
 Usingtheprojectorataltitudesapproximately5500feet/1600metersorhigherwithoutsettingto[HIGHALTITUDE]
cancausetheprojectortooverheatandtheprotectorcouldshutdown.Ifthishappens,waitacoupleminutesand
turnontheprojector.
• Usingtheprojectorataltitudeslessthanapproximately5500feet/1600metersandsettingto[HIGHALTITUDE]
cancausethelamptoovercool,causingtheimagetoicker.Switch[FANMODE]to[AUTO].
• Usingtheprojectorataltitudesapproximately5500feet/1600metersorhighercanshortenthelifeofopticalcom-
ponentssuchasthelamp.
About Copyright of original projected pictures:
Pleasenotethatusingthisprojectorforthepurposeofcommercialgainortheattractionofpublicattentioninavenue
suchasacoffeeshoporhotelandemployingcompressionorexpansionofthescreenimagewiththefollowingfunc-
tionsmayraiseconcernabouttheinfringementofcopyrightswhichareprotectedbycopyrightlaw.
[ASPECTRATIO],[KEYSTONE],Magnifyingfeatureandothersimilarfeatures.
Turkish RoHS information relevant for Turkish market
EEE Yönetmeliğine Uygundur.
Thisdeviceisnotintendedforuseinthedirecteldofviewatvisualdisplayworkplaces.Toavoidincommodingreec-
tionsatvisualdisplayworkplacesthisdevicemustnotbeplacedinthedirecteldofview.

vi
Important Information
Information on Wireless LAN:
Insomeareasandcountries,theP420X,P350X,andP350WseriesprojectorscomestandardwiththeUSBWireless
LANUnit.IfyoupurchasetheprojectormodelwithouttheWirelessLANUnit,theoptionalWirelessLANUnitmustbe
installedtousetheprojectorviaawirelessconnection.
Notethatuseinotherthansupportedcountriesandareasmayviolateradiowavelawsofthecountrywhereawire-
lessLANunitisused.UsethewirelessLANUnitaccordingtothecombinationsoftheproductnamesandsupported
countrieslistedonpageviii.
Certificate marks and codes of the NP02LM Series (English)
NP02LM1 Mexico CFTID:RCPNENP10-0740
Brazil
NP02LM2 Argentina CNCID:C-8400
Australia
NewZealand N56
HongKong
HK0011000150
Vietnam
A0557240610AE01A2
FPT Distribution Co, Ltd.
A0557 - 240610
Indonesia
15809/POSTEL/2010
SouthAfrica
India 730/2010/WRLO
Singapore Complies with
IDA Standards
DB00901
UAE
TRA
REGISTERED No:
ER0042849/10
DEALER No:
DA0038690/10
Pakistan
SouthKorea
인증번호:NDS-NP02LM

vii
Important Information
English Hereby,NECDisplaySolutions,Ltd.declaresthatthisWirelessLANUnit(Model:NP02LM)
isincompliancewiththeessentialrequirementsandotherrelevantprovisionsofDirective
1999/5/EC.
Finnish NECDisplaySolutions,Ltd.vakuuttaatätenettäWirelessLANUnit(Model:NP02LM)tyyp-
pinenlaiteondirektiivin1999/5/EYoleellistenvaatimustenjasitäkoskeviendirektiivinmuiden
ehtojenmukainen.
German HiermiterklärtNECDisplaySolutions,Ltd.,dasssichdieser/diese/diesesWirelessLANUnit
(Model:NP02LM)inÜbereinstimmungmitdengrundlegendenAnforderungenunddenanderen
relevantenVorschriftenderRichtlinie1999/5/EGbendet”.(BMWi)
HiermiterklärtNECDisplaySolutions,Ltd.dieÜbereinstimmungdesGerätesWirelessLAN
Unit(Model:NP02LM)mitdengrundlegendenAnforderungenunddenanderenrelevanten
FestlegungenderRichtlinie1999/5/EG.(Wien)
French ParlapresenteNECDisplaySolutions,Ltd.declarequel’appareilWirelessLANUnit(Model:
NP02LM)estconformeauxexigencesessentiellesetauxautresdispositionspertinentesde
ladirective1999/5/CE.
Parlapresente,NECDisplaySolutions,Ltd.declareque ceWireless LAN Unit (Model:
NP02LM)estconformeauxexigencesessentiellesetauxautresdispositionsdeladirective
1999/5/CEquiluisontapplicables.
Italian ConlapresenteNECDisplaySolutions,Ltd.dichiarachequestoWirelessLANUnit(Model:
NP02LM)èconformeairequisitiessenzialiedallealtredisposizionipertinentistabilitedalla
direttiva1999/5/CE.
Spanish PormediodelapresenteNECDisplaySolutions,Ltd.declaraqueelWirelessLANUnit(Model:
NP02LM)cumpleconlosrequisitosesencialesycualesquieraotrasdisposicionesaplicables
oexigiblesdelaDirectiva1999/5/CE.
Portuguese NECDisplaySolutions,Ltd.declaraqueesteWirelessLANUnit(Model:NP02LM)estácon-
formecomosrequisitosessenciaiseoutrasdisposiçõesdaDirectiva1999/5/CE.
Swedish HärmedintygarNECDisplaySolutions,Ltd.attdennaWirelessLANUnit(Model:NP02LM)
stårIöverensstämmelsemeddeväsentligaegenskapskravochövrigarelevantabestämmelser
somframgåravdirektiv1999/5/EG.
Dutch HierbijverklaartNECDisplay Solutions,Ltd. dat het toestelWireless LAN Unit (Model:
NP02LM)inovereenstemmingismetdeessentiëleeisenendeandererelevantebepalingen
vanrichtlijn1999/5/EG.
BijdezeverklaartNECDisplaySolutions,Ltd.datdezeWirelessLANUnit(Model:NP02LM)
voldoetaandeessentiëleeisenenaandeoverigerelevantebepalingenvanRichtlijn1999/5/
EC.
Danish Undertegnede NEC DisplaySolutions,Ltd. erklærerherved,at følgendeudstyrWireless
LANUnit(Model:NP02LM)overholderdevæsentligekravogøvrigerelevantekravidirektiv
1999/5/EF.
Greek ΜΕ ΤΗΝ ΠΑΡOΥΣΑ NEC Display Solutions, Ltd. ΔΗΛΩΝΕΙ OΤΙ Wireless LAN Unit (Model:
NP02LM) ΣΥΜΜOΡΦΩΝΕΤΑΙ ΠΡOΣ ΤΙΣ OΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛOΙΠΕΣ ΣXΕΤΙΚΕΣ
ΔΙΑΤΑΞΕΙΣ ΤΗΣ OΔΗΓΙΑΣ 1999/5/ΕΚ.

viii
Important Information
Table of Supported Areas and Countries
Notethatusewithotherthanthecombinationsoftheproductnamesandsupportedcountriesandareaslistedbelow
mayviolateradiowavelawsofthecountrywherethedeviceisused.
ProductName Supportedcountriesandareas
NP02LM1 Brazil/Canada/Colombia/Mexico/Taiwan/UnitedStates
NP02LM2 Argentina/Australia/Austria/Belgium/Bulgaria/Chile/China/Cyprus/Czech/Denmark
/Ecuador/Egypt/Estonia/Finland/France/Germany/Greece/HongKong/Hungary/
Iceland/India/Indonesia/Ireland/Israel/Italy/Japan/Latvia/Liechtenstein/Lithuania/
Luxembourg/Malaysia/Malta/NewZealand/Norway/Oman/Pakistan/Peru/Philippines
/Poland/Portugal/Romania/SaudiArabia/Singapore/Slovak/Slovenia/SouthAfrica/
SouthKorea/Spain/SriLanka/Sweden/Switzerland/Thailand/TheNetherlands/Turkey
/Ukraine/UnitedArabEmirates/UnitedKingdom/Vietnam
NP02LM3 Russia
Cautions
• Cautions on Usage
Warning
• TheWirelessLANUnitisnotmeantforusewithfacilitiesorequipmentinvolvingthesafeguardofhumanlife,
suchasmedicalequipment,nuclearfacilitiesorequipment,aeronauticalorspaceequipment,transportation
facilitiesorequipment,etc.,orwithfacilitiesorequipmentrequiringhighlevelsofreliability.DonotusetheWire-
lessLANUnitinsuchcases.
• DonotusetheWirelessLANUnitnearcardiacpacemakers.
• DonotusetheWirelessLANUnitnearmedicalequipment.Doingsomaycauseelectromagneticinterference
withthemedicalequipment,possibleleadingtodeath.
• DonotdisassembleormodifytheWirelessLANUnitinanyway.Doingsocouldleadtoreorelectricshock.
• DonotusetheWirelessLANUnitinwetormoistplaces,suchasinbathroomsornearhumidiers.Doingso
couldleadtore,electricshockormalfunction.
Caution
Topreventdamageduetostaticelectricity,eliminateanystaticelectricityfromyourbodybeforetouchingtheWire-
lessLANUnit.
• StaticelectricityfromthehumanbodymaydamagetheWirelessLANUnit.BeforetouchingtheWirelessLAN
Unit,touchanaluminumsash,adoorknob,orsomeothermetalobjectaroundyoutoeliminatethestaticelec-
tricity.
Caution
TheradiowavesusedbytheWirelessLANUnitpassthroughthewoodorglassusedinnormalhomes(butnot
throughwindowpaneswithbuilt-inmetallicmesh).
Theradiowavesdonotpassthroughironreinforcingbars,metalorconcrete,however,sotheWirelessLANUnit
cannotbeusedforcommunicatingthroughwallsoroorsmadewiththesematerials.

ix
Important Information
• FCC Compliance
ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:(1)this
devicemaynotcauseharmfulinterferenceand(2)thisdevicemustacceptanyinterferencereceived,including
interferencethatmaycauseundesiredoperation.
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBPersonalComputerandPeripheral,
pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmful
interferenceinaresidentialinstallation.
Thisequipmentgenerates,usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordance
withtheinstructions,maycauseharmfulinterferencetoradiocommunications.
However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescause
harmfulinterferencetoradioortelevisionreception,whichcanbedeterminedbyturningtheequipmentoffandon,
theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowingmeasures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
ThisequipmenthasbeentestedtocomplywiththelimitsforaClassBpersonalcomputerandperiph-eral,pursuantto
SubpartBofPart15ofFCCRules.Onlyperipherals(computerinput/outputdevices,terminals,printers,etc.)certied
(DoC)orveriedtocomplywithClassBlimitsmaybeattachedtothisequipment.Operationwithnon-certied(DoC)
ornon-veriedpersonalcomputerand/orperipheralsislikelytoresultinInterferencetoradioandTVreception.
TheconnectionofaunshieldedequipmentinterfacecabletothisequipmentwillinvalidatetheFCCCerticationof
thisdeviceandmaycauseinterferencelevelswhichExceedthelimitsestablishedbyFCCforequipment.
Youarecautionedthatchangesormodicationsnotexpresslyapprovedbythepartyresponsibleforcompliancecould
voidyourauthoritytooperatetheequipment.
Regulatory Information/Disclaimers
InstallationanduseofthisWirelessLANdevicemustbeinstrictaccordancewiththeinstructionsincludedinthe
userdocumentationprovidedwiththeproduct.Anychangesormodications(includingtheantennas)madetothis
devicethatarenotexpresslyapprovedbythemanufacturermayvoidtheuser’sauthoritytooperatetheequipment.
Themanufacturerisnotresponsibleforanyradioortelevisioninterferencecausedbyunauthorizedmodicationof
thisdevice,orthesubstitutionoftheconnectingcablesandequipmentotherthanmanufacturerspecied.Itisthe
responsibilityoftheusertocorrectanyinterferencecausedbysuchunauthorizedmodication,substitutionorattach-
ment.Manufactureranditsauthorizedresellersordistributorswillassumenoliabilityforanydamageorviolationof
governmentregulationsarisingfromfailingtocomplywiththeseguidelines.
IEEE802.11bor802.11goperationofthisproductintheU.S.A.isrmware-limitedtochannels1through11.
CAUTION
ThisequipmentcomplieswithFCCRFradiationexposurelimitssetforthforanuncontrolledenvironment.Thisdevice
anditsantennamustnotbeco-locatedoroperatinginconjunctionwithanyotherantennaortransmitter.
TocomplywithFCCRFexposurecompliancerequirements,theantennausedforthistransmittermustbeinstalled
toprovideaseparationdistanceofatleast7.87"/20cmfromallpersonsandmustnotbeco-locatedoroperatingin
conjunctionwithanyotherantennaortransmitter.
ThisClassBdigitalapparatuscomplieswithCanadianRSS-210.
CetappareilnumeriquedelaClasseBestconformealanormeCNR-210duCanada.
Industry Canada Statement
ThisdevicecomplieswithRSS-210oftheIndustryCanadaRules.Operationissubjecttothefollowingtwocondi-
tions:
1)thisdevicemaynotcauseinterferenceand
2)thisdevicemustacceptanyinterference,includinginterferencethatmaycauseundesiredoperationofthedevice

x
Important Information
Regulatory Statement:
OperationofthisdeviceissubjectedtothefollowingNationalregulationsandmaybeprohibitedtouseifcertain
restrictionshouldbeapplied.
France:
Outdooruselimitedto10mWe.i.r.p.withintheband2454–2483.5MHz.DerogationinFrenchoverseasdepartments
ofGuyaneandLaReunion:outdoorusenotallowedinband2400-2420MHz.
• Cautions on security when using wireless LAN products
WithawirelessLAN,radiowavesareusedinsteadofLANcablesfortheexchangeofdatabetweenthewireless
accesspoints(computers,etc.),offeringtheadvantagethatLANconnectionscanbemadefreelywithintherange
oftheradiowaves.
Ontheotherhand,theradiowavesreachallpointswithinthisrange,regardlessofwallsorotherobstacles,possibly
resultingintheproblemsdescribedbelowifthepropersecuritymeasuresarenottaken.
• Contents of transmissions may be intercepted
Maliciousthirdpartiesmaypurposelyintercepttheradiowavesandstealinformationcontainedinthetransmissions,
includingsuchpersonalinformationasIDnumbers,passwords,creditcardnumbers,e-mailmessages,etc.
• Improper intrusions
Maliciousthirdpartiesmaywithoutpermissionaccessthepersonalorcompanynetworkandstealpersonalor
condentialinformation,pretendtobesomeoneelseandleakincorrectinformation,rewriteinformationthathas
beenintercepted,introducecomputervirusesorotherwisedamagedataorthesystem,etc.
WirelessLANcardsandwirelessaccesspointsgenerallyincludesecuritymeasuresfordealingwiththeseproblems.
Makingthepropersecuritysettingsbeforeusingtheproductscanreducetheriskofsuchproblemsarising.
Werecommendthatyoufullyunderstandtheproblemsthatcanarisewhenusingtheproductswithoutmakingthe
securitysettings,thenthatyoumakethesecuritysettingsbasedonyourowndecisionandatyourowndiscretion.

xi
Important Information
Specifications
(1) Specifications common to the NP02LM series
OperatingVoltage 5V(powersuppliedfromtheprojector)
MAXAmps 460mA
WirelessStandard IEEE802.11b/IEEE802.11g/IEEE802.11n
ModulationMethod CCK/DQPSK/DBPSK/OFDM/DS-SS
LEDDisplay
(Green)
Duringcommunication:blinking
Standby:slowblinking
Nooperation:lightoff
Interface USB2.0(connectedtoUSBwirelessLANportontheprojector)
Dimensions Width:1.1"/28mm
Height:0.43"/11mm
Length: 3.03"/81mm(includingthecap)
Weight 0.049lbs/22g(includingthecap)
Environmental
Considerations
OperationalTemperatures:
41°to104°F/5°to40°C,20%to80%humidity
(non-condensing)
StorageTemperatures:
14°to122°F(-10°to50°C),20%to80%humidity
(non-condensing)
(2) Compliant standards according to model
NP02LM1
IEEE802.11b CenterFrequencyRange/
Operatingchannels
2412to2462MHz
1to11channels
Transmissionmethod DS-SSmethod(directdispersionspectrumdispersion
method)
DataRates 11/5.5/2/1Mbps
IEEE802.11g CenterFrequencyRange/
Operatingchannels
2412to2462MHz
1to11channels
Transmissionmethod OFDMmethod(OrthogonalFrequencyDivisionMultiplex-
ingmethod)
DataRates 54/48/36/24/18/12/9/6Mbps
IEEE802.11n CenterFrequencyRange/
Operatingchannels
2412to2462MHz
1to11channels
Transmissionmethod OFDMmethod(OrthogonalFrequencyDivisionMultiplex-
ingmethod)/
MIMOmethod(Multiple-Input
Multiple-Outputmethod)
DataRates* Whendualchannelcommunicationisdisabled
130/117/104/78/52/39/26/19.5/13Mbps
Whendualchannelcommunicationisenabled
300/270/243/216/162/108/81/54/40.5/27/13.5Mbps

xii
Important Information
NP02LM2
IEEE802.11b CenterFrequencyRange/
Operatingchannels
2412to2472MHz
1to13channels
Transmissionmethod DS-SSmethod(directdispersionspectrumdispersion
method)
DataRates 11/5.5/2/1Mbps
IEEE802.11g CenterFrequencyRange/
Operatingchannels
2412to2472MHz
1to13channels
Transmissionmethod OFDMmethod(OrthogonalFrequencyDivisionMultiplex-
ingmethod)
DataRates 54/48/36/24/18/12/9/6Mbps
IEEE802.11n CenterFrequencyRange/
Operatingchannels
2412to2472MHz
1to13channels
Transmissionmethod OFDMmethod(OrthogonalFrequencyDivisionMultiplex-
ingmethod)/
MIMOmethod(Multiple-Input
Multiple-Outputmethod)
DataRates* Whendualchannelcommunicationisdisabled
130/117/104/78/52/39/26/19.5/13Mbps
Whendualchannelcommunicationisenabled
300/270/243/216/162/108/81/54/40.5/27/13.5Mbps
NP02LM3
IEEE802.11b CenterFrequencyRange/
Operatingchannels
2412to2472MHz
1to13channels
Transmissionmethod DS-SSmethod(directdispersionspectrumdispersion
method)
DataRates 11/5.5/2/1Mbps
IEEE802.11g CenterFrequencyRange/
Operatingchannels
2412to2472MHz
1to13channels
Transmissionmethod OFDMmethod(OrthogonalFrequencyDivisionMultiplex-
ingmethod)
DataRates 54/48/36/24/18/12/9/6Mbps
IEEE802.11n CenterFrequencyRange/
Operatingchannels
Notavailable
Transmissionmethod Notavailable
DataRates Notavailable
* Dualchannelcommunicationwillbeautomaticallyswitchedbetween"enabled"and"disabled"accordingtothe
usageenvironment.
注意
依據 低功率電波輻射性電機管理辦法
第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或
變更原設計之特性及功能。
第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善
至無干擾時方得繼續使用。前項合法通信，指依電信規定作業之無線電信。低功率射頻電機須忍受合法通信或工
業、科學及醫療用電波輻射性電機設備之干擾。

xiii
Table of Contents
Important Information............................................................................................i
1. Introduction.......................................................................................................... 1
1What’sintheBox?......................................................................................................... 1
IntroductiontotheProjector .......................................................................................... 2
CongratulationsonYourPurchaseoftheProjector ................................................. 2
Featuresyou’llenjoy: ............................................................................................... 2
Aboutthisuser’smanual.......................................................................................... 3
PartNamesoftheProjector .......................................................................................... 4
Front/Top.................................................................................................................. 4
Rear ......................................................................................................................... 5
TopFeatures ............................................................................................................ 6
TerminalPanelFeatures .......................................................................................... 7
PartNamesoftheRemoteControl ............................................................................... 8
BatteryInstallation ................................................................................................... 9
RemoteControlPrecautions.................................................................................... 9
OperatingRangeforWirelessRemoteControl........................................................ 9
OperatingEnvironmentforSoftwareIncludedonCD-ROM ........................................ 10
OperatingEnvironment.......................................................................................... 11
2. Projecting an Image (Basic Operation) .............................................. 12
1FlowofProjectinganImage........................................................................................ 12
ConnectingYourComputer/ConnectingthePowerCord............................................. 13
TurningontheProjector .............................................................................................. 14
NoteonStartupscreen(MenuLanguageSelectscreen)...................................... 15
SelectingaSource ...................................................................................................... 16
Selectingthecomputerorvideosource................................................................. 16
AdjustingthePictureSizeandPosition....................................................................... 17
Adjustingtheverticalpositionofaprojectedimage(Lensshift)............................ 18
Focus ..................................................................................................................... 19
Zoom...................................................................................................................... 20
AdjusttheTiltFoot ................................................................................................. 21
CorrectingKeystoneDistortionManually .................................................................... 22
Adjustingwithbuttonsonthecabinet .................................................................... 22
Adjustingwiththeremotecontrol........................................................................... 23
OptimizingComputerSignalAutomatically ................................................................. 24
AdjustingtheImageUsingAutoAdjust.................................................................. 24
TurningUporDownVolume ........................................................................................ 24
TurningofftheProjector .............................................................................................. 25
AfterUse...................................................................................................................... 26
3. Convenient Features..................................................................................... 27
1TurningofftheImageandSound ................................................................................ 27
FreezingaPicture ....................................................................................................... 27
EnlargingaPicture ...................................................................................................... 27
ChangingEcoMode/CheckingEnergy-SavingEffectUsingEcoMode[ECO
MODE] ................................................................................................................... 28

xiv
Table of Contents
CheckingEnergy-SavingEffect[CARBONMETER] ............................................. 29
PreventingtheUnauthorizedUseoftheProjector[SECURITY] ................................. 30
OperatingYourComputer’sMouseFunctionsfromtheProjector’sRemoteControl
viatheUSBCable(RemoteMouseFunction)....................................................... 33
ProjectingYourComputer’sScreenImagefromtheProjectorviatheUSBCable
(USBDisplay) ........................................................................................................ 34
ControllingtheProjectorbyUsinganHTTPBrowser ................................................. 36
ProjectingYourComputer’sScreenImagefromtheProjectorviaaNetwork
[NETWORKPROJECTOR].................................................................................... 43
UsingtheProjectortoOperateYourComputerviaaNetwork[REMOTE
DESKTOP]............................................................................................................. 47
4. Using the Viewer ............................................................................................. 52
❶WhatyoucandowiththeViewer................................................................................. 52
❷Preparingpresentationmaterials ................................................................................ 55
❸ProjectingimagesstoredinaUSBmemorydevice .................................................... 56
StartingtheViewer................................................................................................. 56
ExitingtheViewer .................................................................................................. 59
NamesandfunctionsofViewerscreen.................................................................. 60
Vieweroptionsettings............................................................................................ 65
❹Projectingdatafromsharedfolder .............................................................................. 68
Connectingtheprojectortothesharedfolder ....................................................... 68
Disconnectingthesharedfolderfromtheprojector ............................................... 71
❺Projectingdatafrommediaserver............................................................................... 72
Settingup“MediaSharing”inWindowsMediaPlayer 11 ...................................... 72
Settingup“MediaSharing”inWindowsMediaPlayer12 ...................................... 74
Connectingtheprojectortothemediaserver........................................................ 75
Disconnectingtheprojectorfromthemediaserver ............................................... 76
❻Restrictionsondisplayingles .................................................................................... 77
SomerestrictionsonPowerPointles.................................................................... 77
SomerestrictionsonPDFles .............................................................................. 77
5. Using On-Screen Menu................................................................................ 78
1UsingtheMenus.......................................................................................................... 78
MenuElements............................................................................................................ 79
ListofMenuItems ....................................................................................................... 80
MenuDescriptions&Functions[SOURCE] ................................................................ 82
COMPUTER1and2 ............................................................................................. 82
HDMI...................................................................................................................... 82
VIDEO.................................................................................................................... 82
S-VIDEO ................................................................................................................ 82
VIEWER................................................................................................................. 82
NETWORK............................................................................................................. 82
USBDISPLAY........................................................................................................ 82
MenuDescriptions&Functions[ADJUST].................................................................. 83
[PICTURE] ............................................................................................................. 83
[IMAGEOPTIONS] ................................................................................................ 86
[AUDIO].................................................................................................................. 90

xv
Table of Contents
MenuDescriptions&Functions[SETUP].................................................................... 91
[GENERAL]............................................................................................................ 91
[MENU] .................................................................................................................. 93
[INSTALLATION] .................................................................................................... 95
[OPTIONS(1)] ........................................................................................................ 97
[OPTIONS(2)] ........................................................................................................ 99
MenuDescriptions&Functions[INFO.] .................................................................... 101
[USAGETIME] ..................................................................................................... 101
[SOURCE]............................................................................................................ 102
[WIREDLAN]....................................................................................................... 102
[WIRELESSLAN] ................................................................................................ 102
[VERSION(1)] ...................................................................................................... 103
[VERSION(2)] ...................................................................................................... 103
[OTHERS] ............................................................................................................ 103
MenuDescriptions&Functions[RESET].................................................................. 104
ReturningtoFactoryDefault[RESET]................................................................. 104
❾ApplicationMenu....................................................................................................... 105
IMAGEEXPRESSUTILITY ................................................................................. 105
DESKTOPCONTROLUTILITY........................................................................... 105
NETWORKPROJECTOR.................................................................................... 106
REMOTEDESKTOPCONNECTION .................................................................. 106
NETWORKSETTINGS........................................................................................ 107
TOOLS................................................................................................................. 123
6. Installation and Connections ................................................................. 128
1SettingUptheScreenandtheProjector................................................................... 128
SelectingaLocation............................................................................................. 128
ThrowDistanceandScreenSize......................................................................... 130
MakingConnections.................................................................................................. 132
ConnectingYourComputer .................................................................................. 132
ConnectinganExternalMonitor .......................................................................... 134
ConnectingYourDVDPlayerorOtherAVEquipment.......................................... 135
ConnectingComponentInput .............................................................................. 136
ConnectingHDMIInput........................................................................................ 137
ConnectingtoaWiredLAN ................................................................................. 138
ConnectingtoaWirelessLAN(NP02LMseries) ................................................. 139
AttachingtheOptionalCableCover(NP01CV) ................................................... 142
7. Maintenance .................................................................................................... 143
1CleaningtheFilters.................................................................................................... 143
CleaningtheLens...................................................................................................... 146
CleaningtheCabinet................................................................................................. 146
ReplacingtheLampandtheFilters........................................................................... 147
8. User Supportware......................................................................................... 152
InstallingSoftwareProgram ...................................................................................... 152
InstallationforWindowssoftware......................................................................... 152
InstallationforMacintoshsoftware....................................................................... 154
UsingtheComputerCable(VGA)toOperatetheProjector(VirtualRemoteTool) ... 155

xvi
Table of Contents
ProjectingYourComputer’sScreenImagefromtheProjectoroveraLAN(Image
ExpressUtilityLite) .............................................................................................. 160
ProjectinganImagefromanAngle(GeometricCorrectionToolinImageExpress
UtilityLite) ............................................................................................................ 163
WhatyoucandowithGCT.................................................................................. 163
ProjectinganImagefromanAngle(GCT)........................................................... 163
ProjectingImagesorVideosfromtheProjectoroveraLAN(ImageExpressUtility
2.0)....................................................................................................................... 165
WhatyoucandowithImageExpressUtility2.0.................................................. 165
ConnectingtheprojectortoaLAN....................................................................... 166
BasicOperationofImageExpressUtility2.0....................................................... 167
UsingtheProjectortoOperateYourComputeroveraLAN(DesktopControlUtility
1.0)....................................................................................................................... 176
WhatyoucandowithDesktopControlUtility1.0................................................ 176
ConnectingtheprojectortoaLAN....................................................................... 176
Usingtheprojectortooperateyourcomputer’sdesktopscreen.......................... 177
ControllingtheProjectoroveraLAN(PCControlUtilityPro4)................................. 185
ConvertingPowerPointlestoSlides(ViewerPPTConverter3.0)........................... 186
ProjectingYourMac’sScreenImagefromtheProjectoroveraLAN(Image
ExpressUtility2forMac) ..................................................................................... 188
WhatyoucandowithImageExpressUtility2..................................................... 188
Operatingenvironment ........................................................................................ 188
ConnectingtheprojectortoaLAN....................................................................... 188
UsingImageExpressUtility2.............................................................................. 189
9. Appendix............................................................................................................. 192
1Troubleshooting ......................................................................................................... 192
IndicatorMessages.............................................................................................. 192
CommonProblems&Solutions........................................................................... 193
Ifthereisnopicture,orthepictureisnotdisplayedcorrectly............................... 194
Specications ............................................................................................................ 195
CabinetDimensions .................................................................................................. 197
PinAssignmentsofD-SubCOMPUTERInputConnector ........................................ 198
CompatibleInputSignalList...................................................................................... 199
PCControlCodesandCableConnection................................................................. 200
TroubleshootingCheckList........................................................................................ 201
TravelCareGuide....................................................................................................... 203

1
Projector
1. Introduction
1What’s in the Box?
Makesureyourboxcontainseverythinglisted.Ifanypiecesaremissing,contactyourdealer.
Pleasesavetheoriginalboxandpackingmaterialsifyoueverneedtoshipyourprojector.
Power cord
(US: 7N080236)
(EU: 7N080022)
Computer cable (VGA)
(7N520073)
NEC Projector CD-ROM
User’s manual (PDF) and the utility
software
(7N951553)
For North America only
Registrationcard
Limitedwarranty
For customers in Europe:
YouwillndourcurrentvalidGuar-
anteePolicyonourWebSite:
www.nec-display-solutions.com
Insome areas andcountries, the projector comes
standardwiththeUSBWirelessLANUnit.Ifyoupur-
chasetheprojectormodelwithouttheWirelessLAN
Unit,theoptionalWirelessLANUnitmustbeinstalled
tousetheprojectorviaawirelessconnection.
• ImportantInfomation(ForNorthAmerica:
7N8N1261) (For Other countries than North
America: 7N8N1261 and 7N8N1272)
• QuickSetupGuide(ForNorthAmerica:
7N8N1281) (For Other countries than North
America: 7N8N1281 and 7N8N1291)
Remote control
(7N900922)
Batteries (AAA × 2)
Unlessotherwisedescribedintheuser’smanual,thedrawingsfortheprojectorcabinetshowexamplesoftheP420X.

2
1. Introduction
Introduction to the Projector
Thissectionintroducesyoutoyournewprojectoranddescribesthefeaturesandcontrols.
Congratulations on Your Purchase of the Projector
Thisprojectorisoneoftheverybestprojectorsavailabletoday.Theprojectorenablesyoutoprojectpreciseimages
upto300inchesacross(measureddiagonally)fromyourPCorMacintoshcomputer(desktopornotebook),VCR,
DVDplayer,ordocumentcamera.
Youcanusetheprojectoronatabletoporcart,youcanusetheprojectortoprojectimagesfrombehindthescreen,
andtheprojectorcanbepermanentlymountedonaceiling*1.Theremotecontrolcanbeusedwirelessly.
*1 Donotattempttomounttheprojectoronaceilingyourself.
 Theprojectormustbeinstalledbyqualiedtechniciansinordertoensureproperoperationandreducetherisk
ofbodilyinjury.
 Inaddition,theceilingmustbestrongenoughtosupporttheprojectorandtheinstallationmustbeinaccordance
withanylocalbuildingcodes.Pleaseconsultyourdealerformoreinformation.
Features you’ll enjoy:
• Quick start (3 seconds*1), Quick Power Off (0 seconds), Direct Power Off
 3seconds*1afterturningonthepower,theprojectorisreadytodisplayPCorvideoimages.
 Theprojectorcanbeputawayimmediatelyaftertheprojectorispowereddown.Nocooldownperiodisrequired
aftertheprojectoristurnedofffromtheremotecontrolorcabinetcontrolpanel.
 Theprojectorhasafeaturecalled“DirectPowerOff”.Thisfeatureallowstheprojectortobeturnedoff(evenwhen
projectinganimage)byusingtheMainPowerSwitchordisconnectingtheACpowersupply.
 ToturnofftheACpowersupplywhentheprojectorispoweredon,useapowerstripequippedwithaswitchand
abreaker.
 *1Thequickstarttimeisonlywhen[STANDBYMODE]issetto[NORMAL]intheon-screenmessage.
• 0.2 W (100-130 V AC)/0.4 W (200-240 V AC) in standby condition with energy saving technology
 Selecting[POWER-SAVING]for[STANDBYMODE]fromthemenucanputtheprojectorinpower-savingmode
thatconsumesonly0.2W(100-130VAC)/0.4W(200-240VAC).
• Carbon Meter
 Thisfeaturewillshowenergy-savingeffectintermsofCO2emissionreduction(kg)whentheprojector’s[ECO
MODE]issetto[AUTOECO]or[ECO1].
 TheamountofCO2emissionreductionwillbedisplayedintheconrmationmessageatthetimeofpower-offand
intheINFOoftheon-screenmenu.
• Lamp life up to 5000 hours (P350X)/3500 hours (P420X/P350W) without cleaning the lters regularly
 UsinginEcoModeallowsyoutoprolongtheprojector’slamplifeupto5000hours(upto4000hoursinNORMAL
Mode(ECOModeOFF)).
 ForP420XandP350W:
 UsinginEcoModeallowsyoutoprolongtheprojector’slamplifeupto3500hours(upto3000hoursinNORMAL
Mode(ECOModeOFF))
 Thetwo-layer,largeltersrequirenoregularcleaning.Filterreplacementisrequredonlywhenlampreplacement
isdone.
• Vertical lens shift mechanism offers installation exibility
 Manuallensshiftthatcanbeadjustedbyturningdialsonthetopoftheprojector.
• HDMI input port provides digital signal
 TheHDMIinputprovidesHDCPcompatibledigitalsignals.TheHDMIinputalsosupportsaudiosignal.
