INSTRUCTION MANUAL
NFL-1265
Washing Machine Instruction Manual
CONTENTS Page
A NOTE TO YOU
Thank you for buying a NEC appliance.
NEC washers are easy to use, save time, and help you manage your home better.
This manual contains valuable information about how to operate and maintain your washer property and safely.
Please read it carefully.
󱇲Economic wash system
Using artificial intelligence, the washer uses minimum energy and
water by selecting optimal water lever and washing time.
󱇲Low noise system
The washer minimizes the washing and spinning noises by sensing
the amount of laundry.
󱇲Child-Lock
The Child-Lock system has been used to prevent children from
pressing any button to change the program during operation.
PARTS AND FEATURES.................................................................................................................2
WASHER SAFETY...........................................................................................................................3
INSTALLATION INSTRUCTIONS....................................................................................................4
INLET HOSE CONNECTION...........................................................................................................5
ELECTRICAL REQUIREMENTS .....................................................................................................6
OPERATING YOUR WASHER........................................................................................................7
THE FUNCTIONS OF THE CONTROL PANEL...............................................................................9
WASHING PROCEDURE AND PROGRAM SELECTION.............................................................10
MAINTENANCE .............................................................................................................................19
HOW TO CLEAN THE FILTER......................................................................................................20
REMOVING STAINS......................................................................................................................21
TROUBLE SHOOTING ..................................................................................................................22
SPECIFICATION............................................................................................................................23

2
PARTS AND FEATURES
The parts and features of your washer to read are illustrated on this page.
Become familiar with all parts and features before using your washer.
Accessories
NOTE
The drawings in the book may vary from your washer model.
They are designed to show the different features of all models covered by this book,
Your model may not include all features.
Hose drain Inlet hose Spanner Manual Cap holder(3EA)
ADJUSTABLE LEG
CONTROL PANEL
DOOR
DETERGENT CASE
INLET HOSE
LOWER COVER
POWER CORD
HOSE DRAIN

3
Save these instructions
Your safety is important to us.
To reduce the risk of fire, electrical shock, or injury when using your washer adhere to the following
basic precautions.
Understanding your responsibilities
• Do not use chlorine bleach and ammonia or acid(such as vinegar or rust remover) in the same
wash. Hazardous fumes can form.
• Unplug power supply cord before attempting to service your washer.
• Do not wash fiberglass material.
Small particles can stick to fabrics washed in following loads and cause skin irritation.
• Do not spray water on the control panel of the washer.
It could cause fire or an electric shock.
• In case of the dual valve model, if you connect only cold water inlet valve, while water temperature
is selected as hot or warm, there can be water leakage from unconnected water inlet valve.
• This appliance must be grounded.
To avoid electrical shock, use a metal pipe for the ground connection.
• This appliance is not intended for use by young children or infirm persons unless they have been
adequately supervised by a responsible person to ensure that they can use the appliance safely.
• Young children should be supervised to ensure that they do not play with the appliance
• When selecting high temperature washing (60 or 95 degree), do not touch the glass door, as it will
be hot.
• If this appliance is supplied from a cord extension set or electrical portable outlet device, the cord
extension set or electrical portable outlet device must be positioned so that it is not subject to
splashing or ingress of moisture.
• Flammable fluids (dry-cleaning solvents,
kerosene, gasoline, etc.) should not be used or
stored in or near your washer.
Do not add flammable fluids to your wash
water.These substances give off vapors that
can create a fire hazard or explosion.
• After starting a cycle, do not reach into the
washer until all motions stop.
• Do not tamper with the controls.
• If the supply cord is damaged, it must be
replaced by the manufacturer, or its service
agent or a similarly qualified person in order to
avoid a hazard.
Please ...
• Have only a qualified person install, repair,
or replace parts on washer.
• Maintain washer properly.
• Protect washer from the weather and keep
it where the temperature will not fall below
freezing.
• Do not install the washer at a place of
extremely high humidity. It could cause an
electric shock or a short circuit.
• Connect washer to the correct outlet, electrical
supply, water supply, and drain supply.
• Ensure laundry room has a drain to ensure
water will drain away if washer should
malfunction.
• Use only detergent specific for front loader use.
WASHER SAFETY
Read all instructions before using your washer

4
Removing transit bolts
1. Before operating the washer, remove the
transit bolts(3 ea) along with the rubber.
• If the bolts are not removed, it may cause
heavy vibration, noise and malfunction.
2. Unscrew the 3 bolts with the spanner
supplied. Keep the 3 bolts and spanner for
future use.
• Whenever the appliance is transported, the
transit bolts must be refitted.
3. Close the holes with the cap holders supplied.
Location of washer
• Check location where the washer will be installed. Make sure you have everything necessary for
correct installation.
• Do not place or store your washer below 0°C (32°F) to avoid any damage from freezing.
• Do not place or store laundry products on top of washer at any time.
• Install washer on an even horizonal floor.
If the washer is installed on an unsuitable floor, it could make
considerable noise, vibrate severely and cause a malfunction. If the
washer is not level, adjust leg up or down for horizontal installation.
• Ventilation openings must not be obstructed by carpeting when the
washer is installed on a carpeted floor.
• Leave space around the washer upon installation
(right and left: 2cm, rear: 10cm)
• In case of built-in installation, the distance between top of the washer
and bottom of upper plate should be at least 3mm.
INSTALLATION INSTRUCTIONS
Laundry
Tub
Washer
approx.
2cm
Drain Hose

5
The washer should be connected to the water mains using new hose sets, old hose sets
should not be reused.
In using only one water tap or in case of only one water inlet valve, connect the inlet hose to
the cold water inlet valve.
Option : Be careful not to confuse hot water inlet and cold water inlet.
For Screw-Shaped Tap
INLET HOSE CONNECTION
1Connect the inlet hose to the water tap by
screwing the connector tightly. 2Connect the inlet hose adapter to the water inlet of a washer and turn it to be fixed.
*Check the packing in the inlet

6
ELECTRICAL REQUIREMENTS
•Electrical earth is required on this washer
•If it does not fit the outlet, have a proper outlet
installed by a qualified electrician.
•Do not earth to a gas pipe.
•Do not change the power supply cord plug.
•Check with a qualified electrician if you are not
sure the washer is properly earthed.
WARNING
Recommended earthing method
Electrical shock hazard : Failure to follow these instructions could result in
death or serious injury.
For your personal safety, this washer must be earthed.
This washer is equipped with a power supply cord ‘A’having a earthing plug ‘B’.
To minimize possible shock hazard, the cord must be plugged into a mating
earthing-type wall receptacle ‘C’. If a mating wall receptacle is not available,
it is the personal responsibility and obligation of the customer to have the
proper earthed wall receptacle installed by a qualified electrician.
C
B
A
Drain system
•Never forget to install drain hose before operating your washer.
•Open the packing box, and there is a drain hose inside the drum.
•Connect the drain hose to the drain outlet at the back side of the washer.
• Top of laundry tub must be at least 60cm high and no higher than 100cm from bottom of washer.
•When installing the drain hose to tub (sink), secure it tightly with a string.
•Proper securing of the drain hose will protect the floor from damage due to water leakage.
•When the drain hose is too long, do not force it back into the washer.
This will cause abnormal noise.
Level adjustment
1If the washer is installed on an
unsuitable floor, it could make
considerable noise, vibrate and
cause a malfunction.

7
OPERATING YOUR WASHER
2Adjust the level of washer using adjustable legs.
•Please check if there is any gap between the
four adjustable legs and the floor.
•Turning adjustable legs by the enclosed
spanner, adjust the level of washer and make
it sure that there is no swaying of washer.
•After the adjustment is finished, turn the fixing
nuts up tightly so that the washer maintains
the adjustment.
3Make it sure that the washer does not sway when you press
down the four corners of the washer's top plate.
adjustable leg
Fixing Nut
NOTE
There should be no swaying of washer and all the
adjustable legs should stick to the floor closely.
To obtain the best washing results, you must operate your washer properly.
This section gives you this important information.
•Close zippers, snaps and hooks to avoid
snagging other items.
Remove pins, buckles and other hard
objects to avoid getting them caught inside
the washer or scratching the washer
interior.
•Empty pockets and pull them inside out.
•Turn down cuffs and turn synthetic knits
inside out to avoid pilling.
•Tie strings and sashes to avoid tangling.
•Treat spots and stains.
(See “Removing stains”on page 21)
Preparing clothes for washing

8
•Drop items into washer loosely. Items
should move easily through wash water for
best cleaning and wrinkle-free results.
•Load washer properly and select correct
load size setting.
Overloading and selecting a setting too
small for the wash load can :
- Cause poor cleaning
- Increase wrinkling
- Create excessive lint
- Wear out items faster (because of pilling)
•Mix large and small items in each load. Load
evenly to maintain washer balance.
An unbalanced load can make the washer
vibrate during spin.
•Reduce wash time when using a small load
size setting. Load with only a few small
items needs less wash time.
•Use a large load size setting to reduce
wrinkling with permanent press clothes and
some synthetic knits. These items should
have more room to move in the water than
heavy items. (towels, jeans)
Loading
1Detergent case 2Adding fabric softener
•If desired, add measured liquid fabric
softener to the softener inlet.
•Pour liquid fabric softener into the dispenser
using the amount recommended on the
package.
•Do not exceed the maximum fill line.
Overfilling can cause early dispensing of the
fabric softener which could stain clothes.
•Do not open the detergent case when water
is supplied.
•Avoid pouring fabric softener directly on the
clothes.
Adding detergent
•Separate heavily soiled items from lightly soiled ones, even if they would normally be washed
together.
•Separate dark colors from light colors, colorfast items from non-colorfast item.
Sorting
Soil (Heavy, Normal, Light) Separate clothes according to amount of soil.
Color (White, Lights, Darks) Separate white clothes from colored clothes.
Lint (Lint producers, Collectors) Wash lint producers and lint collectors separately.
Main wash Pre wash
Fabric softener
•Please use only the powder detergent for the front
loader washing machine.
•Please use the proper amount of detergent in
conformity with the instruction of the detergent
manufacturer.
•A use of a large amount of detergent more than the
recommended amount can cause many soapsuds and
the overload to the motor. In addition to, this will
deteriorate the washing and rinse performance.

9
Press this switch to turn the power on or off.
Operation and temporary stop is repeated as it is pressed.
When you want to change program in operating;
press the “Start/Hold”button →Select the program that you want to change →press the
“Start/Hold”button again.
You can select the course you want, and each lamp is turned on when that course is selected.
For the more detailed information, please refer to pages 11~18.
It can be used to adjust temperature of water according to types of the load to be washed.
As the button is pressed, temperature of water is selected by
Cold →30˚C →40˚C →60˚C →95˚C
By pressing the spin button, the spin speed can be chosen.
Rinse Hold •
Is selected by pressing the spin button repeatedly. This function leaves clothes
in the machine; suspended in the water after a rinse without entering into spin.
•To proceed through to a drain or spin, after the Rinse Hold function is
completed, use spin button.
Crease Care •If you want to prevent crease, select this button with spin speed.
Rinse+ •Is used to add a rinse, which may assist in removing traces of detergent residue.
•By selecting Rinse+ function, the rinse time and the rinse water are increased.
Pre-Wash •The washer operates one additional wash and spin before the main wash.
•If the laundry is heavily soiled, Pre-Wash course is effective.
•Pre-Wash is available in Cotton and Synthetic programs.
All courses have pre-set washing times, but Time Save decreases it to 10 minutes.
Each time this button is pressed the watch icon is repeated on and off. When it is on, the Time
Save function is set. Time Save is available in Cotton, Eco and Synthetic programs.
It can be used to pre-engage time for wash.
Use this function when you want to protect any accident occurring from handling of washer by a child.
During an operation of washer, press ‘Time Save’and ‘Time Delay’buttons simultaneously.
In Child Lock mode, no button functions except Power button.
In Child Lock mode, press ‘Time Save’and ‘Time Delay’buttons simultaneously like setting Child
Lock and Child Lock is cancelled.
To change to the desired program, while in Child Lock mode;
1. Press both the Time save and Time delay buttons together once again.
2. Press the Start/Hold button.
3. Select the desired program and press the Start/Pause button again.
THE FUNCTIONS OF THE CONTROL PANEL
* The child lock can be set at any time and it is automatically cancelled when operational errors
occur. Also child lock is cancelled when power is off.
Change
the desired
program

10
1. COTTON IS AUTOMATICALLY SELECTED UPON POWER ON
•Press the Power button to start.
•Press the Start/Hold button
•Initial condition
- Program : Cotton
- Wash : main wash
- Rinse : 3 times
- Spin : 800 rpm
- Water temperature : 40˚C
WASHING PROCEDURE AND PROGRAM SELECTION
2. MANUAL SELECTING
•Press the Power button to start
•Select the conditions which you want to use by turning the program dial and pressing each button.
•Press the Start/Hold button.
3. RESERVED WASHING
•Reservation can be made from 2 hours to 12 hours.
example) To make reservation to complete washing in 8 hours.
- Procedure to press the button.
* Each pressing of the button advances time delay by one hour.
•Now the reservation is made.
•If you want to check the selected program, press the “Start/Hold”button again.
•Preparing washing before starting “Time Delay”;
- Turn on the water tap
- Load laundry and close the door
- Place the detergent and fabric softener in the detergent case.
•To cancel the time delay, press the Power button.
•Depending on the program selection, this reserved washing time will vary. In some program selection,
this reserved washing will not be available.
ajust to "8"
select the
program
or manual

11
4. FUNCTION
•Recommended programs according to the laundry type
•Pre Wash : If the clothes are heavily soiled, “Pre Wash”program is recommended. Pre
Wash is available in Cotton and Synthetic programs.
•Rinse+ : Used to introduce an additional rinse, which may assist in removing traces of detergent residue.
•Eco : By selecting Eco function, the water temperature is lowered and washing time is increased.
So you can economize your consumption of heating energy.
Fabirc
Type
First check if clothes are machine
washable.(white cotton, linen
towel and sheets..)
Colorfast garments
(shirts, night dresses, pajamas..)
and lightly soiled white cottons
(underwear..)
60˚C
(95˚C)
Pre Wash
Rinse+
Crease Care Rating
40˚C
(60˚C, 30˚C)
Pre Wash
Rinse+
Crease Care Rating
Laundry type is the same as
Cotton. 60˚CRinse+ Crease Care Rating
Proper
Temp. Option Maximum Load
Program
Cotton
Eco
Polyamide, Acrylic, Polyester 40˚C
(60˚C, 30˚C)
Pre Wash
Rinse+
Crease Care
Less than
1.5kg
Synthetic
Delicate laundry easily
damaged
(silk, curtains..) Cold Rinse+
Crease Care Less than 1.0kg
Delicate
Machine washable woolens
with pure new wool only. Cold Rinse+ Crease Care Less than 1.0kg
Wool
“Hand wash”marked delicate
and wool laundry Cold (30˚C) Rinse+ Crease Care Less than 1.0kg
Hand Wash
Colored clothes which
are lightly soiled fast. 30˚C (Cold, 40˚C) Rinse+ Crease Care Less than 1.0kg
Quick

12
* COTTON PROGRAM
Note
•If you want to change the setting during operation, press the Start/Hold button to hold the operation and
press the button you want.
•‘30’, ‘40’, ‘60’and ‘95’˚C washing temperatures are selectable with Cotton program.
•‘Prewash’, ‘Rinse+’, and ‘Crease Care’wash options are selectable with Cotton program.
•cotton 40°C and 60°C (1000 or 1200 rpm): program setting for test in accordance or in conformity with
AS/NZS 2040 and IEC 60 456.
Caution!
•If you select washing temperature ‘95’˚C, some cold water is supplied before the drain of main wash. This
is to protect the user from the hazard of burn injury by lowering the temperature of hot wash water instead
of directly draining it. Therefore this is not a malfuction.
(Be careful with the draining water, since it can be still hot although the temperature is lowered.)
Put the laundry in to the drum. Put detergent and softener into the detergent case.
Then close the door.
• Put detergent into the main wash and prewash compartments in the detergent case.
Softener should be below the ‘MAX’level.
• Put detergent into the pre wash compartment only if you want to add prewash.
• When you want to use bleach, put it into the main wash compartment with detergent.
1
Press the Power button.
• The LED shows only ‘---’and all Program Lights turn on.
2
Select the ‘Cotton’program using program selection dial.
•
If you press Start/Hold button after power button without selecting program, the
‘Cotton’program is selected as default program.
• Washing temperature ‘40’˚C, spin ‘800’rpm and rinse ‘3’times are selected
automatically.
• If you want to change washing temperature, the spin velocity or add wash options
(Rinse+, Crease Care), press each button.
3
Press Start/Hold button.
•
The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
4

13
* ECO PROGRAM
Note
•If you want to change the setting during operation, press the Start/Hold button to hold the operation and
press the button you want.
•Only ‘60’˚C washing temperature is selectable with Eco program.
•Only ‘Rinse+’and ‘Crease Care’of all wash options are selectable with Eco program.
Put the laundry in the drum. Put detergent and softener into the detergent case.
Then close the door.
•
Put detergent into the main wash and prewash compartments in the detergent
case. Softener should be below the ‘MAX’level.
• When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
• The LED shows only ‘---’and all Program Lights turn on.
1
2
Select the ‘Eco’program using program selection dial.
• Washing temperature ‘60’˚C, spin ‘800’rpm and rinse ‘3’times are selected
automatically.
•
If you want to change the spin velocity or add wash options (Rinse+, Crease Care),
press each button.
3
Press Start/Hold button.
• The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
4

14
* SYNTHETIC PROGRAM
Note
•If you want to change the setting during operation, press the Start/Hold button to hold the operation and
press the button you want.
•Only ‘30’, ‘40’and ‘60’˚C washing temperatures are selectable with Synthetic program.
•‘Prewash’, ‘Rinse+’, and ‘Crease Care’wash options are selectable with Synthetic program.
•The appropriate amount of laundry for Synthetic program is below 1.5kg.
Put the laundry in the drum. Put detergent and softener into the detergent case. Then
close the door.
• Put detergent into the main wash and prewash compartments in the detergent
case. Softener should be below the ‘MAX’level.
• Put detergent into the pre wash compartment only if you want to add prewash.
• When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
• The LED shows only ‘---’and all Program Lights turn on.
1
2
Select the ‘Synthetic’program using program selection dial.
• Washing temperature ‘40’˚C, spin ‘800’rpm and rinse ‘3’times are selected
automatically.
•
If you want to change washing temperature, the spin velocity or add wash options
(Prewash, Rinse+, Crease Care), press each button.
3
Press Start/Hold button.
• The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
4

15
* DELICATE PROGRAM
Note
•If you want to change the setting during operation, press the Start/Hold button to hold the operation and
press the button you want.
•Only ‘cold’of washing temperature is selectable with Delicate program.
•‘1000’rpm of spin velocity is NOT selectable with Delicate program.
•Only ‘Rinse+’and ‘Crease Care’wash options are selectable with Delicate program.
•The appropriate amount of laundry for Delicate program is below 1.0kg.
Put the laundry in the drum. Put detergent and softener into the detergent case.
Then close the door.
•
Put detergent into the main wash compartments in the detergent case.
Softener should be below the ‘MAX’level.
• When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
• The LED shows only ‘---’and all Program Lights turn on.
1
2
Select the ‘Delicate’program using program selection dial.
• Washing temperature ‘Cold’, spin ‘400’rpm and rinse ‘2’times are selected
automatically.
•
If you want to change the spin velocity or add wash options (Rinse+, Crease Care),
press each button.
3
Press Start/Hold button.
•
The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
4

16
* WOOL PROGRAM
Note
•If you want to change the setting during operation, press the Start/Hold button to hold the operation and
press the button you want.
•Only ‘Cold’washing temperature is selectable with Wool program.
•‘1000’rpm of spin velocity is NOT selectable with Hand program in order to protect damage to clothes.
•Only ‘Rinse+’and ‘Crease Care’wash options are selectable with Wool program.
•The appropriate amount of laundry for Wool program is below 1.0kg.
•Use only special detergent for wool.
(Since special neutral detergent for wool creates a lot of bubbles, use appropriate amount).
Put the laundry in the drum. Put detergent and softener into the detergent case. Then
close the door.
• Put detergent into the main wash compartments in the detergent case.
Softener should be below the ‘MAX’level.
•
When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
• The LED shows only ‘---’and all Program Lights turn on.
1
2
Select the ‘Wool’program using program selection dial.
• Washing temperature ‘Cold’, spin ‘400’rpm and rinse ‘2’times are selected
automatically.
• If you want to change the spin velocity or add wash options (Rinse+, Crease Care),
press each button.
3
Press Start/Hold button.
• The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
4

17
* HAND WASH
Note
•If you want to change the setting during operation, press the Start/Hold button to hold the operation and
press the button you want.
•Only ‘Cold’and ‘30’˚C washing temperatures are selectable with Hand Wash program.
•‘1000’rpm of spin velocity is NOT selectable with Hand program.
•Only ‘Rinse+’and ‘Crease Care’wash options are selectable with Hand Wash program.
•Use Hand Wash program for the laundry that is marked ‘Hand wash’in the care label.
Put the laundry in the drum. Put detergent and softener into the detergent case. Then
close the door.
• Put detergent into the main wash compartments in the detergent case.
Softener should be below the ‘MAX’level.
•
When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
• The LED shows only ‘---’and all Program Lights turn on.
1
2
Select the ‘Hand Wash’program using program selection dial.
• Washing temperature ‘Cold’, spin ‘400’rpm and rinse ‘3’times are selected
automatically.
•
If you want to change the washing temperature, spin velocity or add wash options
(Rinse+, Crease Care), press each button.
3
Press Start/Hold button.
•
The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
4

18
* QUICK 30
Note
•If you want to change the setting during operation, press the Start/Hold button to hold the operation and
press the button you want.
•Only ‘Cold’, ‘30’˚C and ‘40’˚C washing temperatures are selectable with Quick 30 program.
•Only ‘Rinse+’and ‘Crease Care’wash options are selectable with Quick 30 program.
Put the laundry in the drum. Put detergent and softener into the detergent case.
Then close the door.
• Put detergent into the main wash compartments in the detergent case.
Softener should be below the ‘MAX’level.
• When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
•
The LED shows only ‘---’and all Program Lights turn on.
1
2
Select the ‘Quick’program using program selection dial.
• Washing temperature ‘30’˚C, spin ‘800’rpm and rinse ‘2’times are selected
automatically.
• If you want to change the washing temperature, spin velocity or add wash options
(Rinse+, Crease Care), press each button.
3
Press Start/Hold button.
•
The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
4

19
MAINTENANCE
Proper care of your washer can extend its life. This section explains how to care for your washer
properly and safely.
Cleaning your washer
Winter storage or moving care
Install and store your washer where it will not freeze. Because some water may stay in the
hoses, freezing can damage your washer.
If you store or move your washer during freezing weather, winterize it.
Non-use or vacation care
Operate your washer only when you are at home.
If you are on vacation or don’t use your washer for an extended period of time, you should:
•Unplug the power supply cord or turn off eletrical power to the washer.
•Turn off the water supplier to the washer.
This helps avoid accidental flooding (due to a water pressure surge) while you are away.
Wipe up detergent, bleach, and other spills with
a soft, damp cloth or sponge as they occur.
Occasionally wipe the outside of the washer to
keep its looking like new.
Clean interior with 250ml of chlorine bleach
mixed with 500ml of detergent.
Run washer through a complete cycle.
Repeat this process if necessary.
Exterior Interior
•Turn off water faucet.
•Disconnect and drain water inlet hoses.
•Run washer on a drain and spin setting (see
page 10) for 1 minute.
•Unplug the power supply cord.
•Flush water pipes and hoses.
•Reconnect water inlet hoses.
•Turn on water faucet.
•Reconnect power supply cord.
To winterize washer To use washer again
Do not put sharp or metal objects in your washer as they
can get caught or damage the finish. Check all pockets for
pins, clips, money, bolts, etc.
Do not lay these objects on your washer after emptying
pockets.

20
HOW TO CLEAN THE FILTER
Cleaning the water inlet filter
•Clean the filter when water leaks from the water inlet.
Cleaning the drain filter
•This drain filter is used to screen the foreign stuffs such as threads, coins, pins, buttons etc..
•If the drain filter is not cleaned at proper time(every 10 times of use), drain problem might
happen.
CAUTION : Be careful when draining if the water is hot.
Cleaning the detergent case
*After a while detergent and fabric softeners leave a deposit in the case;
- It should be cleaned from time to time with a jet of running water.
- If necessary it can be removed completely from the machine by pressing the softener catch
downwards and by pulling it out.
- To facilitate cleaning, the upper part of the fabric softener compartment can be removed.
*Detergent can also accumulate inside the recess which should be
cleaned occasionally with a brush.
*Once you have finished cleaning, replace the case and run a rinse
cycle without laundry.
1Pull the power
plug out before
cleaning it.
2Turn off the water
supply to the
washer and
separate the inlet
hose.
3Pull the inlet filter
out. 4Remove the dirt from the inlet filter
with a brush.
1. Open the lower cover(1) by
using a coin. Remove the cap
hose(2) to pull out the hose.
2. Unplug the cap hose(2), allowing
the water to flow out. At this time
use a vessel to prevent water
flowing on to the floor. When water
does not flow any more, turn the
pump filter(3) open to the left.
3. Remove any foreign material
from the pump filter(3). After
cleaning, turn the pump filter
clockwise and insert the cap
hose(2) to the original place.
Close the lower cover.
1
100
23
2
3
