Neeco NUTS S Series User manual

•Šaldova 12 •Prague 8 •168 00 •Czech Republic •Europe
User manual for NUTS units S, M, L
NEECO UNIVERSAL TRACKING SYSTEM

•Šaldova 12 •Prague 8 •168 00 •Czech Republic •Europe
NOTICE
This product is not designed for the protection of human health or life.
The use of modules from the S, M or L series is at the owner’s discretion.
M and L series modules contain neodymium magnets for secure fastening.
The modules are designed to transfer data wirelessly. Do not use the modules in places where using this type of equipment is prohibited.
USE
The modules are designed for tracking railway carriages, containers, construction machinery, trailers, caravans, diggers, packages, tractors and other items. They can also
be used as a concealed independent monitoring unit for passenger cars and trucks without connection to the vehicle’s electrical system to avoid warranty breach. The
modules can also be used to monitor your motorcycles. Using correct tracking settings will also help you generate a trip logbook.
WAIVER OF LIABILITY
LEVEL, s.r.o. will not be liable for any damage, financial loss or legal disputes concerning assets or persons arising from correct or incorrect use of the product.
DESCRIPTION
VERSIONS - OVERVIEW
GSM module
Antennas
Battery
L series
2G –3G
Internal GPS & GSM
LiPo 15 600 mAh to 21 600 mAh
M series
2G –3G
Internal GPS & GSM
LiPo 7 800 mAh to 10 800 mAh
S series
2G –2G
Internal GPS & GSM
LiPo 1 500 mAh to 3 400 mAh
OPTIONAL ACCESSORIES
MD 092 000 holder –for L series modules only
MD 092 001 pry bar –for L and M series modules only
SA 092 000 mains charger including a micro USB cable
Optional accessories can be purchased separately.

•Šaldova 12 •Prague 8 •168 00 •Czech Republic •Europe
VERSIONS –DETAILED OVERVIEW OF L SERIES
VERSIONS –DETAILED OVERVIEW OF M SERIES
VERSIONS –DETAILED OVERVIEW OF S SERIES
PRODUCT DESCRIPTION
The modules contain a GPS receiver for detecting position (latitude and longitude), a GSM/GPRS module for transferring the position to a superior system or directly to the
user via SMS, a 3D motion sensor (for detecting movement, vibrations, tilt and impact), a thermometer and a barometer. L and M series modules are equipped with magnets
for fastening the modules to a metal surface or a holder offered as an optional accessory can be used. The operating time per charge depends on the selected operating
mode, ranging from one month to 3.5 years. The operating times of accumulators are also affected by the weather conditions in which the modules operate. Excessively
high or low temperatures increase the self-discharge effect of accumulators.

•Šaldova 12 •Prague 8 •168 00 •Czech Republic •Europe
DESCRIPTION OF FUNCTION AND CONFIGURATION
The information provided below applies if you have a full version of the Trexee service. The functions listed below cannot be used with the Lite version.
The modules operate in a mode selected by you. Module settings are selected at https://nuts.neeco.com in the Settings –Unit settings tab. Each module and the relevant
details can be edited by clicking on the “pencil” icon (registration number, vehicle name, default driver, vehicle icon, travel type). The “plus” button is used to add
new modules to the system. To add a new module, you need to know the HW key of the module, which is found on the label on the rear side of the module, or you can
contact your sales representative to obtain your HW key.
•“Unit configuration” tab
•Here, you can change the unit name, icon for the relevant unit and unit registration number or select a driver.
•To complete your changes, click “Save”.
✓
•“Profile setting” tab (this item is accessible depending on the unit type and setting)
•Here, you configure parameters for sending values.
•You always need to fill in all fields –the current values are listed in the Current profile field in the left bottom section of the screen.
•
•These values can be changed once after 24 hours from the last change.
•The default screen offers 4 choices to ensure that you do not need to input all required settings manually.
•To make configuration easier for you, we have prepared 4 options for module setting to choose from.
•You only need to select the option that matches your needs and you don’t need to go through any additional settings.

•Šaldova 12 •Prague 8 •168 00 •Czech Republic •Europe
✓
•If none of the recommended profiles is suitable for you, you can configure the module according to your specific needs using the advanced
settings. In this case, proceed with caution and familiarise yourselves in detail with each parameter to be changed. This information is available
for each of the parameters when you click on the question mark icon. You can restore the factory settings for the unit at any time by selecting
and sending the “Default unit setting” option.
•Select the “Advanced settings” field.
•The options shown below will be displayed.

•Šaldova 12 •Prague 8 •168 00 •Czech Republic •Europe
You can display explanations for individual fields by clicking the question mark. We always RECOMMEND reading the help section before saving your
settings to find out what each of the fields represents and what you have set.
You can change the settings once after 24 hours from the last change.
What analogue values mean –see below
•If you need to set your unit to trigger the alarm when the unit is removed from the surface (available with Maxi and Standard modules) or you need
to close trips immediately after the end of each trip, please go to the expert settings.
✓
oLOCK –Locking the unit position for detecting its removal and triggering alarm. (Only activate this if you are familiar with this function and
know how to use it.) This function cannot be used with the Mini module.
oRIDES –This function defines precise beginning and end of individual trips. (Only activate this if you are familiar with this function. This
cannot be combined with certain profile types.)
▪Always select RIDES when you want to add fuelling to the system.
oCurrent profile –setting the tracking interval and value monitoring via SMS. Set the units according to the example provided above.
▪Interval for sending positions in motion
▪Interval for sending positions when stationary
▪First position in the interval for analogue value recording
•After you have selected all values, click “Send”
•The system will not let you continue if you forget to set any value or set an incorrect value.
•“Fuel” tab
•This is only estimated information in the case of wireless modules.

•Šaldova 12 •Prague 8 •168 00 •Czech Republic •Europe
•You do not need to fill anything in.
•You can also check the last position and unit communication, as well as the current battery status in module settings.
USB AND LED
A micro USB connector and LED signalling charging status is located under a rubber cover on the front side. The USB connector is used for charging M, L and S series modules.
The Trexee L Solar version requires charging with direct solar light. Charging the unit fully takes 65 to 75 hours, depending on the solar activity.
Charging times when using original accessories for charging
•L series –typically 10 to 12 hours
•M series –typically 5 to 7 hours
•S series –typically 2 to 3 hours
LED SIGNALLING
Green LED –power supply, accumulator charging
Flashing
Accumulator charging in progress
Solid light
Accumulator is fully charged, power supply connected
Switched off
Sleep mode
Yellow LED –GSM status
Flashing with 0.5 s interval
Not logged in to GSM, no SIM card
Flashing with 1 s interval
Logged in to GSM
DETECTION OF REMOVAL
After the Maxi or Standard module has been installed on the tracked item (a railway carriage, container, vehicle), module position can be locked. If the module is
subsequently removed from the item, an alarm is triggered. See the LOCK setting above. Notification must be created for obtaining notices to your mobile phone.
See the TREXEE system manual.
RECORD OF ANALOGUE VALUES
The modules allow measuring and recording internal analogue values (temperature, humidity, atmospheric pressure, battery voltage, battery capacity) at a regular
set interval. This interval may be set within the range from 1 to 240 minutes. Measuring or recording analogue values does not wake the GSM or GPS module.
Saved values are sent once the module is fully awakened according to the selected profile.

•Šaldova 12 •Prague 8 •168 00 •Czech Republic •Europe
OPERATION AND INSTALLATION
PUTTING INTO OPERATION
The modules are supplied with configuration for sending the position once every 24 hours and once every 3 minutes when in motion. For more information see Function
description.
SHUT DOWN AND STORAGE
Store the modules in a charged status. Charge the accumulators to at least 50% of their capacity at least every six months. Check the battery status in S series modules every
5 to 6 weeks. Storing the modules in a discharged status may cause irreparable damage to the accumulators due to self-discharge.
CHARGING
The modules are charged via a micro USB connector located under a rubber cover on the front side. The charging status indicated by LED next to the USB connector. Charge
the modules with the charger and cable supplied as accessories. Charging the modules with anything other than original accessories may significantly lengthen the charging
time.
INSTALLATION OF L SERIES MODULE IN HOLDER
CAUTION, the product contains very strong magnets! Place the product on a metal surface or in a holder very carefully to prevent injuring fingers!
Always dismantle the product exclusively with the tool designed for this purpose –the MD 092 001 pry bar. L series modules can be lifted from the metal surface using the
pry bar in the place of locks on the short side of the box.
If an L series module is placed in the MD 092 000 holder, insert the pry bar in one of the openings on the long side of the holder and lift it with the pry bar.
RECOMMENDED INSTALLATION –attach the MD 092 000 holder to the item with at least 4 screws. Use the openings provided on the holder. The holder can also be attached
to the item with a premium quality double-sided tape –we recommend 3M tapes.
PLACEMENT
If possible, place the modules with the front side (with a rubber cover of the USB connector or the USB connector plug) facing free space towards the sky to ensure good
reception of the GPS signal for the GPS antenna inside the module. Positioning modules without free space towards the sky will prolong the time required for obtaining the
valid position and thus shortening the operating time per accumulator charging.
GPS SYSTEM
The system operates with precision of up to 2 m in free space. The precision in built-up areas is lower and the time required for obtaining the position is longer. GPS signal
cannot be received inside buildings or underground spaces. Signal reception may also deteriorate with unsuitable placement. The quality of the signal changes during the
day due to satellite movement and may be affected by adverse weather conditions (heavy rain, snowfall). The signal may also be shadowed by metal items near modules.
SIM INSTALLATION
All modules are supplied by the manufacturer with a SIM card. Removing a SIM card is deemed a breach of warranty. The modules will not function with other SIM cards
than those provided by the manufacturer. A removed SIM card will not function is any other equipment.

•Šaldova 12 •Prague 8 •168 00 •Czech Republic •Europe
TECHNICAL PARAMETERS
GSM
QuadBand
850/900/1800/1900 MHz
SIM
Micro Sim, Plug-in 1,8 V
Communication types
GSM Data, GPRS
GPRS internet connection
Class 12 / static and dynamic IP VPN, UDP protocol /
128bit key encoding
/ FW update, configuration change, current data
reading, event report reading
GNSS
GPS and Glonass
66 satellites
Antennas
GPS a GSM
Internal or external antennas, depending on type
Batteries
Type and capacity
Lilon 15 600 –21 600 mAh charging L
Lilon 7 800 –10 800 mAh charging M
Lilon 1 500 mAh charging S
Consumption
In standby mode
0.2 mAh continuously
GPS position with sending to server
0.4 mAh intermittently
Battery self-discharging
LiIon: 0.6 mAh continuously
USB
USB Micro
Charging
Sensors
Three-axis G sensor
Motion detection / tilt monitoring
Additional sensors
Humidity / temperature / atmospheric pressure
S series module only temperature sensor
Internal memory
Flash 512 Kb
Storage capacity of at least 5000 events / GPS positions
Dimensions
L series module
177 x 85 x 25 mm
M series module
120 x 80 x 24 mm
S series module
50 x 90 x 20 mm
Temperature range
Storage
- 40 °C to 85 °C
Operating temperature
- 25 °C to 65 °C
Protection class
IP65
Waterproof
Weight
Including batteries
0.55 Kg L series
0.25 Kg M series
0.15 Kg S series
