Nesco NC-60501 WAVE User manual
Instruction Manual
คู่มือการใช้งาน
INDUCTION COOKER
MODEL : NC-60501 WAVE
2100 W 220-240 V 50/60 Hz
1
A.
B.
D.
F.
2
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
3
-
-
-
-
-
-
4
1.
2.
3.
4.
6.
7.
8.
9.
11.
12.
13.
14.
16.
17.
18.
19.
21.
22.
1.
2.
3.
4.
6
23.
24.
6.
7.
8.
7
8
9
-
-
-
-
11
12
Control Panel of Induction Cooker
Soup Braise
Timer/Pre-set
Keep warm
Boil Deep fry
Pause
fry
ON/STANDBY
Slow re Fierce re
increase
temperature/power
decrease
temperature/power
Hot pot
English
Dear Customer Thank you for choosing a Nesco appliance.The experience,
design, feature and technology of this appliance, as well as the strict quality
controls used during manufacture, will provide full satisfaction for many years.
Air Outlet
Cooker Plate
Cooking Zone
Air Intake
Control Panel
Plug and Cord
A.
B.
C.
D.
E.
F.
13
This appliance is for domestic use only.
This appliance is for indoor use only.
Do not connect the appliance to an outlet to which other appliances are
already connected.
If the surface is cracked, switch off the appliance to avoid the possibility of
electric shock.
If the supply cord is damaged, it must be replaced by the manufacturer or its
service agent or a similar qualied person in order to avoid a hazard.
Do not plug into a socket where several other appliances are plugged in.
Do not modify the parts, or repair this unit, the supply cord must be replaced
by qualied technicians.
Do not use this unit near an open ame or wet places.
Keep out of children’s reach.
Place on a stable, even surface.
Do not carry the hob when the pot or the pan is on it.
Do not heat or overheat the pot empty.
Do not place metallic objects such as knives, forks, spoons, lids, cans and
aluminum foils on the top surface or under the bottom of the stove.
Allow sufcient space around the cooking area (keep a minimum distance of
5 to 10 cm from the unit to walls or other items).
Never use the unit on easily ammable materials (carpet, vinyl).
Do not place paper between the pot or the pan and the unit. The paper may
get burnt.
Do not block air intake or exhaust vent.
Caution! The surface will remain hot for a period of time after use from the
radiant head.
Unit can affect the items having or attracting magnetic elds, such as radios,
televisions, automatic banking cards and cassette tapes.
Do not use the unit on the metallic surface.
Do not disconnect the power cord immediately after cooking, at least 15
seconds is necessary to cool down the unit.
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
The appliance is not intended to be operated by means of an external timer
or separate remote-control system.
Risk of burns! Do not give children the opportunity to drag down hot pots or pans.
Packaging is not a toy! Danger of suffocation! Keep packaging (e.g. foils,
Polyfoam) out of the reach of children. Dispose the packaging environment
friendly and as quickly as possible.
Place the cookware every time in the center of the cooking zone, so that
the bottom of the cookware covers as much of the electromagnetic eld as
possible.
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
14
Before using, please make sure that the power plug is well connects with the
power outlet.
Before placing the pot on the cooker plate, please clean up water stains,
oil spots or any other adherent dirt from the outside surface of the pot and
cooker plate.
Please put the pot to be heated on the central part of the induction cooker.
Do not put an empty pot on the cooker plate to be heated.
After pressing the “ON/STANDBY” key, press the function keys to select the
required mode. The induction cooker enters working mode.
After pressing the “ON/STANDBY” key, if no function key is pressed
for one minute, the induction cooker will switch off automatically.
After pressing the function key, if there is no proper pot on the cooker
plate, the induction cooker will not heat up and the alarm will sound to
indicate that a pot is required. One minute later, it will switch off automatically.
Function Selection: After switching on the appliance, press the corresponding
function key to enter the desired cooking mode.
Please refer to “Functional cooking mode instructions” for the details of the
corresponding heating process for each cooking mode.
Power adjustment: After selecting a mode, if needed, you can press
power key “+” or”-”, or adjust through the sliding-control area.
For some modes, during the heating procedure, the induction cooker
can automatically adjust the power according to the cooking effect.
For certain modes, the power is restricted complying with the cooking effect.
Switch off: When the operating time is over, the induction cooker switches off
automatically.
If switch-off is needed in advance, press the “ON/STANDBY” key to
turn the appliance off.
Pause: The pause function is designed for temporarily stopping heating
during the normal operation process. You can switch to pause status in
any cooking mode.
During operation, when pause is needed, please press the function
key “Pause”. Now, the pause indicator lights up, the display and other
function indicators stay in the previous status. The power indicator
turns off and the induction cooker stops heating.
When the induction cooker is in pause, press the “Pause” key again or select
any cooking mode to quit the pause status and return to the normal heating
process.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
Avoid an overheating of oils and fats. Overheated oil or fat can easily get
ignited. In the case of a small re, switch off all cooking zones (if applicable
deactivate fuses) and quench the ames with a big lid of a pot, dish or wet
dish cloth. Never use water to extinguish this kind of re!
-
After setting pause, the induction cooker stops heating. The default pause
time interval is 10 minutes. After 10 minutes, if the pause mode is not cancelled,
the induction cooker will sound an alarm. The alarm will last for several seconds,
then the induction cooker will switch off automatically.
Adjustment preset: If pre-set is needed, rst press the “Timer/Pre-set”
key. When the pre-set indicator lights up and the number in the display
blinks, press the “+” or “-” key to adjust the preset time.
After the pre-set is nished, the number on the display will be shown after
blinking for several seconds. The induction cooker starts counting down to
the pre-set time.
When the presetting time is met, the induction cooker will automatically return
to the normal working mode.
Residual heat: When the hot leftover indicator lights up, it shows that the temperature
of the cooking plate is high. Do not touch the plate by your hands to avoid
scalding.
Timer adjustment: If timer operation is not needed the induction
cooker will heat the ingredients for the default time duration (for
the detailed time duration, refer to “Cooking mode instruction”).
If timer is needed, rst press the”Timer/Preset”. When the timer indicator lights
up and the numbers blink on the display, press the key “+” or “-” to adjust the
time duration.
When the adjustment is nished, the number on the display will be shown
after blinking for several seconds. The induction cooker starts counting down.
When the counting down is over, the induction cooker automatically stops
heating and switches off (for soup mode, the automatic keeping warm
function starts).
For particular modes, the timer function does not work. For boiling water, the
timer uses a counting up method.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
Functional cooking mode instruction
The cooking modes of “Hot-pot” individually t to heating requirements,
such as hot-pot and boiling water. In the heating procedure, the
time and power can be adjusted at any time. If the water in the
pot dries up or the temperature is abnormally high, the induction
cooker automatically switches off or starts protection function.
The cooking modes of Deep-fry and Fry t to high temperature
cooking. In the heating procedure, the time and power can be
adjusted at any time. When the temperature of the ingredients
reaches the temperature level provided by the selected mode (the
highest temperature of various modes are different), the induction
cooker will switch to interval heating or stops heating. After the temperature
cools down, the induction cooker restarts heating.
For the cooking modes of Soup and Braise, the induction cooker
can automatically control the power according to the time duration
that has been set and the temperature of the ingredients. Under
these modes, the power can be adjusted within the adjustable
User can select among the different cooking modes according to cooking purpose.
For your convenience, we provide the following instruction.
1.
2.
3.
16
Note: The table above provides the time duration of heating for general modes.
The cooking mode of Slow re with slow stewing ts to the situation that
needs continuous heating with gentle power, When using this mode to
stew soup or boil congee, please rst use the “Hot pot” mode to make
the ingredients boil, and then heat it by using “slow re”. The stewing
time duration can be set according to the feature of original material
or personal taste.
Note: Under this mode, the power cannot be adjusted. If adjustments is
needed, please switch to the other modes, such as “Hot pot”. Then the
power can be adjusted at will.
Boil mode is for boiling water. After the water is boiled, the induction
cooker will switch off automatically.
Note:
1. It is recommended to put water that occupies 30% to 80% of the pot
capacity when boiling water.
2. When boiling water; factors such as uneven pot bottom, scale or
weather conditions could inuence the boiling effect.
Keeping warm cooking mode ts for cooking that needs gentle heat
to maintain warmth. Under this mode, the induction cooker heats the
ingredients with gentle power to maintain a certain temperature inside
the pot.
Note: Under this mode, the power cannot be adjusted.
Fierce re cooking mode is for heating with strong power. When the
temperature of the ingredients reaches the temperature level provided
by the selected mode (the highest temperature of various modes are
different), the induction cooker will switch to interval heating or stops
heating or stops heating. After the temperature cools down, the induction
cooker restarts heating.
The default time duration of heating for each mode is shown in the
following table:
4.
5.
6.
7.
8.
Mode Hotpot
120 60 60 120 30 30
Fry Keep
warm
Soup Braise Deep fry
Default time
duration of
heating (Minute)
17
Please use pot provide with the appliance . Do not use other pots as replacements
to avoid inuencing the performance.
The maximum load for the frying pan is 4 kg. When using it, do not let the
weight of the ingredients exceed this weight to avoid danger.
If other pots are used, please comply with the following conditions:
1. Requirements for pot material: containing iron material.
2. Requirement of pot shape: with even bottom, the diameter is not less than
12 cm. while not more than heating area.
Note: For optimum performance, please use the standard pots provided.
•
•
•
Note: Suitable for iron and stainless steel cooking utensils with diameter 12-22 cm.
Applicable cooking utensils
Iron stock pot
Iron wok
Iron frying pan
Iron milk pot
Iron water kettle
Iron steamer pan
Abnormalities Key checking points and trouble
Self-diagnosis for abnormalitiesshooting
After plugging in the power
cord and pressing the “ON/
STANDBY” key, the indicator
and display do not light up.
•Is the power plug properly connected.
•Is the switch, power outlet, fuse or power cord
damaged.
The “ON/STANDBY” indicator
lights up and the display
works normally, but heating
does not start.
•Is the pot material proper.
•Is the appliance in a “Preset” working status.
Heating suddenly stops
during the process.
•Is the temperature of the oil too high when frying
dishes.
•Is the temperature of the surroundings very high.
•Is the air inlet or air outlet of the induction cooker
blocked.
•Is the default heating time of the induction cooker
over.
•The self-safety protection of the induction cooker
starts, wait for several minutes and connect power to
use it.
18
Table of contents
Languages:
Other Nesco Cooktop manuals
Popular Cooktop manuals by other brands
Gaggenau
Gaggenau VG 233 234 CN instruction manual
Simpson
Simpson CHC944BA User and installation manual
Dacor
Dacor Discovery DYRP48DS use and care manual
Home appliances
Home appliances CI6SE1-4 Zone Installation and operation manual
Viking
Viking Designer DERT3014BS Specifications
Fisher & Paykel
Fisher & Paykel CI122DTB user guide
