NESTLE ReadyRefresh Lumina User manual

lumina™
bottom-load dispenser
User Guide
© 2018 Nestlé Waters North America, Inc. Please read the manual carefully before operatin your water dispenser. Retain it for future reference.
Version 001
BYC458
Scan with QR code reader
to watch how-to videos
for chanin the bottle and
AquaEase water cartride.
For customer service inquiries, please contact
the Nestlé® Waters North America customer
service center at 1-800-274-5282.
Visit ReadyRefresh.com to order additional
bottled water, AquaEase™ water cartrides,
cups, and more.

LUMINA BOTTOMLOAD DISPENSER USER GUIDE  
Contents
. Safety Precautions 
. Features 
. lumina™ Bottom-Load Dispenser 
. AquaEase™ Replaceable Water Cartride 
. Setup & Installation 
. Dispenser Placement 
. AquaEase™ Water Cartride Installation 
. Water Bottle Installation 
. Power 
. Primin System 
. Activatin Hot Water 
. Dispenser Care 
. Bottle Chane 
. AquaEase™ Water Cartride Chane 
. Troubleshootin 
. Water Is Leakin 
. No Water Is Dispensin/Poor Flow Rate 
. Dispense Flow Is Choppy Or Contains Air 
. Cold Water Is Not Cold 
. Hot Water Is Not Hot 
. Dispenser Is Noisy 
. Red Notification LED
Is Not Functionin Properly 
. Technical Information 
. Customer Service 

LUMINA BOTTOMLOAD DISPENSER USER GUIDE  
. Safety Precautions
CAUTION
This unit dispenses water at temperatures that can
cause severe burns; avoid direct contact with hot
water. Keep children and pets away from unit while
dispensin. Never allow children to dispense hot
water without full supervision.
• For indoor use only.
• For use in USA and Canadian markets
only (110V).
• Unit must be installed on a level/flat surface.
• Keep unit in dry place away from direct sunliht.
• Do not place unit in an enclosed space
or cabinet.
• The unit must be at least 4 inches from any wall.
• The unit must be connected to a rounded wall
outlet at all times. Use of an extension cord does
not comply and will void warranty.
• Do not lean the cooler more than 45 derees
durin handlin. If the cooler is temporarily laid
on its side, allow it to stand upriht for 24 hours
before powerin on.
• To protect from shock, do not submerse cord,
plu or any part of the machine in water.
• Never allow children to dispense hot water
without proper and direct supervision. Unplu
unit to prevent unsupervised use by children.
To reduce risk of user injury or damae to the
equipment, the user must read this manual in full
prior to installation. Failure to follow the instructions
in this manual may result in injury.
The followin precautions must be followed in order to safely use the unit:

LUMINA BOTTOMLOAD DISPENSER USER GUIDE  
. AquaEase™ Replaceable Water Cartride
Upper Cartride
1. Cold Water Dispense Tube
2. Foam Rin
3. Cold Water Reservoir
4. Rubber Outlet
5. Upper Cartride Tube
Lower Cartride
6. Lower Cartride Cap
7. Clampin Lever
8. Dip Tube
9. Storae Tab
10. Air Supply Inlet
11. Slots
12. Red Hyiene Cap
13. Tabs
The innovative AquaEase™ Water Cartride helps keep your water dispenser clean by replacin all internal
cold-water contact parts. It is recommended to chane the AquaEase™ Water Cartride every three months
to ensure a clean dispensin source for your water.
Side viewCap view
12
4
3
5
1
13
6
8
7
9 1110
. Features
2.1 lumina™ Bottom-Load Dispenser
1. Cup Dispenser
2. Unit Lid
3. Replacement Indicator
4. Hot Water Lever
5. Child Safety Lock
6. Cold Water Lever
7. Dispense Nozzle
8. Removable Cup Stand
9. Hot Water Switch
10. Air Connector
11. Lower Cartride Storae Slot
12. Cabinet Door
1
5
4
3
7
9
8
12
11
10
6
2
2

LUMINA BOTTOMLOAD DISPENSER USER GUIDE  
3.0 Setup & Installation
. AquaEase™ Water Cartride Installation
. Dispenser Placement
1. Press lid release buttons on either side of the lid,
and open the lid.
Find a shaded location for the unit, and place it on a flat surface within 6ft of
a power outlet, at a minimum of 4 inches from any wall.
2. Press and lift tab to release ray bracket
at front of unit.
Install the cup stand by insertin the clips into
the dispensin area wall.
4. Once all components are in place, push firmly
on the handle to fully seal, and press foam rin
down into place, securin the openin of the
cold reservoir.
5. Press down and click the ray bracket closed,
then close the lid.
3. Remove the upper cartride from the packain.
Holdin the handle of the upper water cartride:
AFeed upper cartride tube down the small,
round cavity near the front of the unit
BAlin the dispensin tube to the front
CGently lower the reservoir bottle into the
lare, round openin
DAlin the handle inlet to the steam chamber

LUMINA BOTTOMLOAD DISPENSER USER GUIDE  
3. Remove red hyiene cap from upper cartride
tube, and discard. Ensure side tabs are alined
with the slots of the lower cartride cap.
Push down to lock into place. The upper
cartride tube and red air connector will be
found inside the cabinet.
4. Attach red air connector to inlet on cap.
The connection should be tiht and secure.
5. Slide bottle inside cabinet, ensurin no tubes are
pinched or kinked. Close cabinet door.
3.0 Setup & Installation (continued)
2. Put on supplied loves and remove lower
cartride from packain. Lower dip tube into
new, full bottle and secure cap onto bottle
openin. Press down on clampin lever to lock.
1. Place cup on cup stand. Lift red safety lever,
and simultaneously press and hold the
hot & cold levers for one second, then release.
Primin has started when you see flashin
dispensin liht. After two minutes, the liht will
stop flashin and dispenser is ready for use.
. Primin System
. Power
1. Before powerin on the unit, ensure the hot
water switch is in the OFF position.
2. Plu the unit into a rounded wall outlet. Do not
use an extension cord.
IMPORTANT: The unit must be primed before
activatin the hot water.
1. Turn on the hot water switch located inside
the cabinet.
HOT TANK
SWITCH
. Activatin Hot Water
. Water Bottle Installation
1. Remove entire cap by holdin tab firmly, peelin
halfway around bottle neck and pullin upwards.
HOT TANK
SWITCH

LUMINA BOTTOMLOAD DISPENSER USER GUIDE  
4.0 Dispenser Care
6. Attach red air connector to inlet on cap.
The connection should be tiht and secure.
7. Slide bottle inside cabinet, ensurin no tubes are
pinched or kinked. Close cabinet door.
8. Place cup on cup stand. Lift red safety lever,
and simultaneously press and hold the
hot & cold levers for one second, then release.
Primin has started when you see flashin
dispensin liht. After two minutes, the liht will
stop flashin and dispenser is ready for use.
1. The solid red liht will indicate the bottle is
nearly empty.
2. Brin in a new, full 5-allon bottle of water over
to your dispenser. Remove entire cap by holdin
tab firmly, peelin halfway around bottle neck
and pullin upwards.
3. Remove empty bottle from cabinet and
disconnect red air connector by pullin upwards.
4. Lift up clampin lever to unlock, release cap,
and pull the lower cartride upwards. Let water
drain from tube, then remove from bottle.
5. Lower dip tube into new, full bottle and secure
cap onto bottle openin. Press down on
clampin lever to lock.
. Bottle Chane

LUMINA BOTTOMLOAD DISPENSER USER GUIDE  
4.0 Dispenser Care (continued)
5. Lift up clampin lever to unlock, release cap,
and pull the lower cartride upwards.
Let water drain from tube, then remove from
bottle and discard.
6. Press lid release buttons on either side of the lid,
and open the lid.
7. Press and lift tab to release ray bracket
at front of unit.
8. Holdin handle of water cartride, slowly pull
upwards to remove reservoir bottle, tubes and all
connections. Keep reservoir bottle upriht.
. AquaEase™ Water Cartride Chane
By replacin your AquaEase™ Water Cartride every three months (the red indicator liht will flash when
it’s time), you’ll be swappin out all internal cold-water contact parts to ensure a clean dispensin source.
Before installin the new cartride, recycle the empty reservoir bottle and discard the remainin used water
cartride parts.
For additional recyclin options, please call Customer Service at 1-800-274-5282.
1. The flashin red liht will indicate that the
AquaEase water cartride is ready to be
replaced.
Because a new bottle of water is required at this
time, wait until the flashin liht turns to a solid
liht, indicatin that the bottle is empty.
2. Remove empty bottle from cabinet and
disconnect red air connector by pullin upwards.
3. Open your new AquaEase box and locate
the spare, red hyiene cap and have it handy.
4. Disconnect tube from cap by squeezin tabs
and pullin upwards, then place hyiene cap
onto end of tube to ensure no water drips.
9. Remove foam rin. Then, expand and remove
C-shaped bracket from the neck. Separate
bottle from upper cartride (this water can be
consumed). Place empty reservoir bottle in
recyclin bin, and discard remainin parts.

LUMINA BOTTOMLOAD DISPENSER USER GUIDE  
4.0 Dispenser Care (continued)
15. Remove red hyiene cap from upper cartride
tube, and discard. Ensure side tabs are alined
with the slots. Push down to lock into place.
16. Attach red air connector to inlet on cap.
The connection should be tiht and secure.
17. Slide bottle inside cabinet, ensurin no tubes are
pinched or kinked. Close cabinet door. To prime,
see step 3.5.
14. Put on supplied loves and remove lower
cartride from packain. Lower dip tube into
new, full bottle and secure cap onto bottle
openin. Press down on clampin lever to lock.
11. Once all components are in place, push firmly
on the handle to fully seal, and press foam rin
down into place, securin the openin of the
cold reservoir.
12. Press down and click the ray bracket closed,
then close the lid.
10. Remove the upper cartride from the packain.
Holdin the handle of the upper water cartride:
AFeed upper cartride tube down the small,
round cavity near the front of the unit
BAlin the dispensin tube to the front
CGently lower the reservoir bottle into the
lare, round openin
DAlin the handle inlet to the steam chamber
13. Brin in a new, full 5-allon bottle of water over
to your dispenser. Remove entire cap by holdin
tab firmly, peelin halfway around bottle neck
and pullin upwards.

LUMINA BOTTOMLOAD DISPENSER USER GUIDE  
5.0 Troubleshootin
. Water Is Leakin
. Ensure that the cup stand is dry. If not,
remove tray and drain residual water.
. Ensure ray bracket is closed fully and secured
in place. (See section 3.2, step 5)
. Ensure upper cartride and foam rin
are properly alined and fully sealed.
(See section 3.2, step 4)
. Ensure the upper to lower cartride connector
is assembled correctly and fully seated.
(See section 3.3, step 3)
. Ensure that the rubber dispense tubes are sittin
properly inside the nozzle and bein pinched by
the ray bracket. If any debris is observed, wipe
the area with a clean cloth to remove.
. If the AquaEase™ cartride was recently
chaned, water may have spilled durin handlin
of the old cartride. Condensation from the
cold reservoir may also accumulate durin the
chane. Monitor the cooler for  hours to see if
the leak stops.
. If the issue cannot be identified, unplu unit,
remove water bottle and call customer support
for assistance.
. No Water Is Dispensin/
Poor Flow Rate
. Ensure there is water in the water bottle.
If not, replace. (See section 4.1)
. Ensure the unit has power.
(See section 3.4, step 2)
. If dispensin hot water, ensure child safety lever
on the hot dispenser is lifted to disenae.
. Cold Water Is Not Cold
. It takes up to one hour after setup to chill
the water.
. Ensure the unit has power.
. Ensure the unit is at least  inches from
any wall.
. If more than . liters ( fl. ounces) of cold
water was consecutively dispensed, the majority
of the cold reservoir was depleted. Allow the
dispenser  minutes of non-use to fully chill
the water.
. If dispenser was recently tilted more than
 derees, unplu dispenser for  hours
before powerin on.
. Hot Water Is Not Hot
. It takes up to  minutes after setup to heat
the water.
. Ensure the unit has power.
. Ensure the hot tank switch is turned on.
(See section 3.6)
. If more than liter ( fl. ounces) of hot water
was consecutively dispensed, the majority of the
hot reservoir was depleted. Allow the dispenser
 minutes of non-use to fully heat the water.
. Dispenser Is Noisy
. Ensure the unit is level and not on an
uneven surface.
. Ensure that the front door and top lid are
properly closed. Partial closures may produce
rattlin noises.
. Ensure the lower cartride is fully seated
and sealed. (See section 4.1, step 5)
. Ensure the clampin lever is locked in the
down position. (See section 4.1, step 5)
. Ensure the air connector is tihtly connected.
(See section 4.1, step 6)
. While dispensin, ensure the lever is pressed
all the way down to enae the air pump and
dispense LED liht. The air pump must turn
on with every dispense to maintain system
pressure and dispense water.
. Ensure the dispenser was primed after
the bottle and AquaEase™ water cartride were
installed. If the dispenser was depressurized
for any reason, it will need to be re-primed.
(See section 3.5)
. Dispense Flow
Is Choppy Or Contains Air
. After a bottle chane or AquaEase™ water
cartride chane, air bubbles may be present in
the first few dispenses. This is normal.
. Ensure the upper to lower cartride connector
is assembled correctly and fully seated.
(See section 3.3, step 3)
. Ensure upper cartride is properly alined
and fully sealed. (See section 3.2, step 3)
. Ensure that the rubber dispense tubes are sittin
properly inside the nozzle and bein pinched by
the ray bracket. If any debris is observed, wipe
the area with a clean cloth to remove.
. If the dispense stream still contains air after
several cups are dispensed, the AquaEase™
water cartride may be damaed. Call customer
support for assistance.
. Ensure that the plastic cups are properly
positioned inside the cup dispenser
(if applicable).
. Durin primin, the dispense LED will flash
and the air pump will run continuously for
 minutes. As air is pured from the system,
you may hear whistlin in addition to the
runnin pump. This is normal.
. Red Notification LED
Is Not Functionin Properly
. In order for the LED to function properly, a new
-allon bottle must be used for every bottle
chane and cartride chane. If a partially filled
bottle was used, the LED will reain functionality
on the next new/full bottle chane.
. The Bottle Chane Indicator liht is dependent
on customer usae. Small variations on when
the liht illuminates is normal.
. If the cooler is left unpowered for extended
periods of time, the notification timers may
reset themselves. The notification LED will
return to its proper function on the next bottle
or cartride chane.

LUMINA BOTTOMLOAD DISPENSER USER GUIDE  
6.0 Technical Information
Refrieration System
Refrierant can be harmful to the environment if released.
Never attempt to modify or repair the refrieration system.
Refrierant Type: Ra
Chare: 
Refrieration Pressure: Hih Side: . MPa ( PSIG)
Low Side: .MPa ( PSIG).
Water Flow
The flow rate from the water outlets on the dispenser is approximately
. allons per minute ( L/min).
Ambient Operatin Conditions
The unit is certified by UL for indoor use only. The unit is rated
IP, and therefore, is not protected aainst the entry of water.
The acceptable operatin temperature is -°F.
Dispensin Method
The unit utilizes an air pump to dispense water under positive
pressure. Never attempt to modify the air pump, its tubin, or any
of the unit’s internal components.

LUMINA BOTTOMLOAD DISPENSER USER GUIDE  
7.0 Customer Service
For any customer service inquiries, please contact
the Nestlé® Waters North America customer service
center at 1-800-274-5282.
