NETTROTTER Ecco freeze User manual

Via Zanella, 21 20851 - Lissone (MB) [phone] [e-mail]
FREEZE
Quick start guide
Temperature and Humidity
Parameter Meter Wireless IoT
www.nettrotter.io

Index
1. Ecco Freeze battery connection 3
2. Device positioning 4
3. Settings 5
3.1. Mobile App 7
3.1.1. Download the application 7
3.1.2. Register the device 7
3.1.3. Associate device 7
3.1.4. Add other devices 8
3.2. Web app 8
FREEZE

3
FREEZE
The Ecco Freeze (master) solution with Minion (beacon) uses two devices for the detection of tempera-
ture and humidity parameters, and provides for the installation of the beacon inside the cold chamber for
the detection of temperature and humidity parameters.
Freeze Minion
1. Ecco Freeze battery connection
1. Open device 2. Connect the battery
Fig. 2Fig. 1

4
FREEZE
2. Device positioning
The Minion (beacon) should be placed near the
entrance of the cold room, on the roof of the cold
room in the center of the door, or on one of the ver-
tical sides of the door frame 10-15 cm from it .
The Minion transmits this information that the
Freeze device will read in real time and then trans-
mit to the central monitoring system.
To ensure the correct functioning of the solution
and correct positioning outside the cold room, we
use a signal detector that makes use of the BLE
Scanner application (downloadable in the App Sto-
re or Google Play) by placing it outside the cold
room with the Identication code for the Minion.
In addition to the Minion device code (for example
003BBB9), the application also reports the signal’s
power level (eg Fig. 3: -65). The further you move
away from the cold store, the more the power value
decreases. It is advisable to keep this value above
-70 (eg -70, -68, -60 ...).
Fig. 3
Therefore, the ideal place to install the Freeze must respect these two conditions:
1. Visible Minion code in the application
2. Signal level above -70
As an additional verication of the correct connection between Freeze (master) and Minion (beacon), the
Freeze is equipped with an internal button (Fig. 4).
Once the Freeze is positioned with the above criteria, open the device and press the button indicated in
Fig. 4, within 20 ”, the green LED on the master lights, indicating the start of the test.
Fig. 4
0039139F

5
FREEZE
1. If within the next 20 ”there is a sequence of 5 consecutive ashes, then it means that the two
devices are in mutual coverage.
2. If, on the other hand, there is only a continuous illumination of the green LED, it means that the
two devices have not been connected.
In case 2, it is necessary to reposition the master in a position that guarantees less attenuation and grea-
ter power of the input signal to the master (-60, -50).
Wait 60 ”and then repeat the operation with the button request.
Place Ecco Freeze at least the same height as the Minion or higher
COLD CHAMBER
ACCESS DOOR
Minion
Wall
Freeze
COLD CHAMBER
VIEW FROM ABOVE
Minion on the
ceiling of the
chamber
ACCESS DOOR
Freeze

6
FREEZE
3. Settings
To view the data, you can congure the device at:
3.1. Mobile app
3.2. Web app
Warning:
In the case of abnormally functioning cells that generate a large amount of liquid condensate, pending
repair / normalization of the operation, it is necessary to protect the Minion of the Ecco Freeze with the
bag inside the package (Fig. 5) . With a strip of about 3 cm of double-sided adhesive, before placing the
sensor inside the cold room, lock the sensor inside the bag (Fig. 6).
Fig. 6Fig. 5
Back wall
Freeze’s largest
reception area
View from
above Freeze

7
FREEZE
3.1. Mobile App
3.1.1. Download the application
From the App Store or Google Play, download the Ealloora application:
Install the Ealloora application and receive the temperature and humidity measurement of the envi-
ronment you want to monitor on your mobile phone. If the predened thresholds are exceeded, you will
receive a notication in the application.
3.1.2. Register the device
• On the home screen of the application, click Registration.
• Fill in the required information.
• Click Conrm Registration.
• If you already have an Ealloora account, enter your email and password and click Sign in.
3.1.3. Associate device
• Device associated with the Serial Number:
• Enter the serial number written on the label on the back of the device.
• Give your device a name.
• Click on combine.

8
FREEZE
The device is correctly associated.
In case of problems, contact customer service:
www.marketpinegrove.com/customer-service
3.1.4. Add other devices
• In the future, to quickly associate other Ealloora devices, from the home page, click on +
• Add the devices you want by following the same procedure.
3.2. Web app
To make use of the web app, consult your distributor at www.pinegrove.io

9
FREEZE

12.2-2020
FREEZE is an exclusive solution of Nettrotter Srl
Via Zanella 21, 20851 Lissone (MB), Italy
Made in Italy
