Nevco 871 Hockey Manual

Basic Operating Procedures
Nevco Model 871Time Clock at Bear Mountain & Juan de Fuca
1. To set time for first period - press ET / TIME / 20 / 00 - period - 1
2. as the referee blows the whistle to begin the period, turn the panel switch on.
3. To enter goals - press HOME S ORE or VISITOR S ORE / 1
4. To enter a penalty - press SET / GUEST PENALTY / 02 / 00 / YES player number -
01
5. To clear a penalty - press HOME PENALTY / PENALTY LEAR / YES
6. To edit a penalty - press HOME PENALTY / PENALTY EDIT / enter edited time,
press YE
7. To edit the time (with clock running) press ET / TIME enter edited time, press YE
8. To edit the score - press SET / HOME S ORE / then enter edited score
9. At the end of the first period - turn the panel switch off after the horn has sounded.
10. To save existing penalties between periods - press PENALTY OFF before you
11. re-start the clock for the three minute break.
12. To set the break time between periods - press SET / TIME / 03 / 00 / YES
13. To stop the shot-clock between periods - press ET / MI C. HOT TIME / BLANK
/YE
14. When horn sounds at the end of the break - turn panel switch off
15. Press PENALTY ON (shot-clock will re-engage automatically)
16. While the referee is setting up the face-off for the second period, set the time for
period two as you did for period one. The clock will ask for the period number - enter
2
17. As the referee blows the whistle to start the period, turn the panel switch on.
DETAILED Operating Procedures
for NEVCO Model 871 Time Clock at Bear Mountain & Juan de Fuca
1. Turn the clock power on. (toggle switch on the side of the clock )
2. Turn the panel switch off. (this on/off plunger switch is on a cord coming from the
left side of the clock and allows the count-down function of the clock to be stopped
and started without interrupting the power supply.
3. The clock will now ask if you want to start where turned off - press no
4. The panel will now read 'Hi, I'm your Nevco MP - 4. I can operate over 500 Nevco
Models, please enter your model code'. Now enter 8-7-1 .
5. The clock will ask if you want to use penalty time-out - press yes. The panel will now
read 0: 00. 03
6. Now set up the time for the first period - press set, press time, press 2-0 press 0-
0, press es. The clock will now read 'period' - press 1
7. Turning the panel switch on as the referee blows the whistle at the opening face-off
will start the clock counting down the first period.

8. Throughout the period, enter goals and penalties as follows:
• To enter a goal, press home score or guest score, (as appropriate) press
1, enter additional goals for each team by pressing 1 as well. The clock will
add one goal to their score each time you do so.
• To edit the score, press set, press home score or guest score, and then
enter the edited score.
• To enter a penalty, press set, press home penalt or guest penalt , enter
the penalty time - (to enter a two minute penalty) - press 0-2 press 0-0 press
es
• As the final step when entering a penalty, the clock will ask you to enter the
player number. Remember that the player number must be entered as two
digits. When the second digit of the pla er number is entered, the clock
begins counting down the penalt , so don't enter the second digit of the
player number until the referee blows the whistle to resume play following the
penalty call.
• To save time and avoid confusion, don't bother trying to enter the actual
jersey number of the offending player (the score-keeper will record it on the
sheet) Just enter the first penalty of the game as 01, the second one as 02,
and so on. Note these numbers on a sheet of paper as you use them so you
don't enter the same number twice in a row. Although the clock will post and
count down two separate penalties for the same team at the same time, if you
enter the same player number two times consecutively, the clock will not
recognize the second penalty.
• To enter two penalties at the same time (offsetting penalties), with the clock
running, press penalt off, then enter both penalties as above. Then, as the
referee blows the whistle to re-start the play following the penalty call, press
penalt on. This will start both penalties counting down at the same time.
• A two-minute penalty must be discontinued (cleared) if a power play goal is
scored against the penalized (short-handed) team. A five-minute penalty must
be cleared if two power-play goals are scored against the short-handed team.
To clear a penalty, press home penalt or visitor penalt , (as appropriate) -
press penalt clear - press es.
• If there are two penalties posted for the same team at the same time, this
procedure will clear the penalty with the least amount of time remaining.
• When clearing a penalty, do not press es until the referee blows the whistle
at the face-off following the power-play goal.
• To edit the time remaining on a penalty, press home penalt or guest
penalt , press penalt edit, enter the edited time, press es.
