Newco LCD-1 Installation guide

LCD-1 By NEWCO Enterprises
Installation
And
Programming Guide

“LCD-1” Liquid Coffee Dispenser
NEWCO Enterprises Phone: [phone] Fax: [phone].09
2 of 29
PN: 121314
Section 1 – Installation Instructions
Section 2 – Set-Up Programming Instructions
Section 3 – Service Level Programming Instructions
Section 1
Installation Instructions:
Place Machine on a Level Countertop Surface
Connect ¼ Inch Flare water Supply to the Water Inlet
located on lower Left Rear of the Machine.
(
(N NE EW WC CO O r re ec co om mm me en nd ds s c co op pp pe er r t tu ub bi in ng g f fo or r u us se e a as s w wa at te er r s su up pp pl ly y t to o a al ll l o of f o ou ur r
b
br re ew wi in ng g e eq qu ui ip pm me en nt t) )
Turn water Supply On
Plug or wire brewer to the appropriate voltage circuit as
indicated on the serial tag.
Locate power switch on the lower left rear of the machine
and turn machine power on.
Machine will begin to fill.
If machine has not filled to probe level within 2 minutes it will enter an error
mode. Error code E-4 will appear on the display screen. To reset the error
and resume filling turn power switch off and then on.
When water in tank reaches probe level, heating cycle will
begin.
You are now ready to proceed to Set-Up Programming.

“LCD-1” Liquid Coffee Dispenser
NEWCO Enterprises Phone: [phone] Fax: [phone].09
3 of 29
PN: 121314
Section 2
Set-Up Programming Instructions:
Open machine cabinet door and locate the 3-switch control
panel w/lighted display screen. Three dashed lines will
appear on the display screen, as shown in figure 1.
Step 1. Enter a Programming Mode
Press and hold the center switch labeled “Enter”. After five
seconds, the display will change to “Flu” as shown in Figure
2 (See instructions for Flushing on page 22). Continue to
hold in the switch and the temperature will appear, (Release
the switch when temp. appears on the display.) as shown in
figure 2A.
Fig. 1
Fig. 2A
Fig. 2
FLu
170

“LCD-1” Liquid Coffee Dispenser
NEWCO Enterprises Phone: [phone] Fax: [phone].09
4 of 29
PN: 121314
Step 2. Adjust Temperature
The machine features an adjustable temperature range of
170-190F. Use the + or – switch to scroll to the desired
temperature setting, as shown in figure 3.
Press the “Enter” switch to save and proceed to the next
programming option. Either the word “YES” or the word “NO”
will appear on the display screen. Proceed to Step 3.
Step 3. Enable/Disable BIB Tracking
This machine features the option to track the liquid output of
the BIB and then alert the operator when the BIB is empty.
(Display will flash and buzzer will beep if enabled.)
To Enable BIB Tracking, use the + or – switch to scroll until
the display reads YES. To disable BIB Tracking, use the + or
– switch to scroll until the display reads NO, as shown in
figures 4 & 5. When you have made your selection, press
Fig. 3
Fig. 3A
no
170

“LCD-1” Liquid Coffee Dispenser
NEWCO Enterprises Phone: [phone] Fax: [phone].09
5 of 29
PN: 121314
“ Enter” to save and proceed to the next programming
option. On or Off will appear on the display screen, as shown
in figure 6. Proceed to Step 4.
Step 4. Enable/Disable Alarm
This machine features a buzzer alarm that will sound to
notify the operator when one of the following three things
has occurred:
 BIB Tracking has detected an empty BIB (See step 4)
 A machine malfunction has been detected
 The machine has completed a sanitization cycle
This feature offers the option to disable the buzzer alarm.
To enable the alarm, use the + or – switch to scroll until the
display reads ON.
To disable the alarm use the + or – switch to scroll until the
display reads OFF. See figure 7. When you have made your
selection, press “Enter” to save and proceed to the next
programming option. SEL will appear on the display screen.
See figure 8.
Fig 4
Fig 5
Fig. 7
Fig 6
Fig. 8
yES
no
on
OFF
SEL

“LCD-1” Liquid Coffee Dispenser
NEWCO Enterprises Phone: [phone] Fax: [phone].09
6 of 29
PN: 121314
Step 5. Program Selector Switches
This machine features a 4-selector switch control panel. The
center switch on the control panel is reserved for Hot Water
Dispense. The remaining 3 switches can be programmed to
deliver different strength drinks or different sized drinks-see
Figure 9, Page 7.
Program selection product:
To program a selector switch to create a drink using the
product on the right, enter the pump speed from Ratio Chart
in to the Pump.
Ratio Chart
Ratio
Pump Speed
Setting
45:1
11
40:1
13
35:1
16
30:1
20
25:1
25
These ratio’s are based upon a one ounce per second
dispense rate.

“LCD-1” Liquid Coffee Dispenser
NEWCO Enterprises Phone: [phone] Fax: [phone].09
7 of 29
PN: 121314
To Program a selector switch:
1. On the 4-selector switch control panel, press the switch
that you want to program. The display will change to
identify the switch that you have chosen. (b01 thru b03
are the switch identifiers.) See figures 9 & 10.
NOTE: The center button is for hot water only and cannot
be used for programming.
Button #
Pump
Speed
Portion
Control
Button 6
18
0:00
(OFF)
Button 5
20
0:00
(OFF)
Button 4
22
0:00
(OFF)
Fig 9
Fig 10
BUTTON 6 (b1)
BUTTON 5 (b2)
BUTTON 4 (b3)
b:01
Buttons
1, 2 &3
are not
programmed
by
Factory
3
2
1
Factory Default Settings

“LCD-1” Liquid Coffee Dispenser
NEWCO Enterprises Phone: [phone] Fax: [phone].09
8 of 29
PN: 121314
2. Press Enter. The number “1” and the current speed for
BIB pump will appear in the display. As shown in
figure 11.
3. Using the + or – button to scroll, set Pump speed for
the desired ratio using Ratio Chart on page 6 as a
guide as shown in figure 12.
4. Press “Enter” to save and proceed with the set-up
program. A time value (min: sec) will appear in the
display. If the switch that you are programming has
1:12
Fig 11
Fig 12
1:25
01

“LCD-1” Liquid Coffee Dispenser
NEWCO Enterprises Phone: [phone] Fax: [phone].09
9 of 29
PN: 121314
been set in a portion control mode, the value will
represent the current dispense time for the switch. If the
switch is in a continuous flow (push and hold) mode,
the time value will be 0:00 Shown in figure 13.
5. Press “Enter” to save and proceed to the next set-up
programming option. SEL will appear on the display.
6. Continue with switch programming by repeating steps 1
thru 5.
7. When switch programming is completed, continue to
press and release the “Enter” button until the display
returns to 3 dashed lines. The machine will be in a
normal operating mode.
8.
Fig 13
0:00

“LCD-1” Liquid Coffee Dispenser
NEWCO Enterprises Phone: [phone] Fax: [phone].09
10 of 29
PN: 121314
Procedure: Set Portion Control
To program a switch for portioned controls dispense time
must start at “0:00" to do this:
1. Place the desired cup under the dispense head.
2. Press and hold the “Enter” switch.
3. Press and hold the selector switch that you want to
program.
4. After two seconds release the “Enter” switch.
5. When the cup (or carafe) is filled to the desired level,
release the selector switch.
6. The switch is now programmed to automatically fill to
that level.
Procedure: Return Switch to Continuous Flow Mode
1. Enter program mode by pressing and holding the
“Enter” switch for five seconds.
2. Press and release the “Enter” switch until SEL appears
on the display.
3. Press the selector switch that you want to return to
continuous flow mode. (The switch identifier will appear
on the display.)

“LCD-1” Liquid Coffee Dispenser
NEWCO Enterprises Phone: [phone] Fax: [phone].09
11 of 29
PN: 121314
4. Press and release the settings button 3 times. (The
selector switch timer will appear on the display.)
5. Using the + and – switches, scroll until the selector
switch timer reads 0:00
6. Press and release the “Enter” switch until 3 dashed
lines appears on the display.
The switch is now in a continuous flow (push and hold)
mode.
Procedure: Disable a Selector Switch
1. Push and hold the “Enter” switch for 8 seconds to enter
a programming mode. The current temperature setting
will appear on the display. (Refer to: Page 3 Section 2
Step 1.)
2. Press and release the “Enter” switch repeatedly until
SEL appears in the display.
3. Press the selector switch that you have chosen to
disable.
4. Press and release the “Enter” switch. Pump speed will
appear in the display.
5. Using the + or – button to scroll, set Pump speed to
0.00
6. Press and release the “Enter” switch until thee dashed
lines appear in the display. The switch is disabled.

“LCD-1” Liquid Coffee Dispenser
NEWCO Enterprises Phone: [phone] Fax: [phone].09
12 of 29
PN: 121314
Section 3
Service Level Programming Functions:
Sanitizing Instructions
Press the + switch to enter sanitize mode. SAN will appear in
the display. (As shown in figure 14)
Remove the product BIBs from the machine and connect a
BIB of sanitizing solution to the PUMP BIB connector.
Place an empty decanter or other vessel under the dispense
area of the machine.
Press the “San” (+) switch on the display panel to begin
sanitizing.
When sanitizing cycle ends (2.5 minutes total: pump 45 sec.,
dwell 90 sec., & water 15 sec.), the buzzer alarm will sound
3 times if enabled during the “Set-Up Programming”.
Disconnect the BIB of sanitizing solution from the Pump BIB
connector.
SAn
Fig. 14

“LCD-1” Liquid Coffee Dispenser
NEWCO Enterprises Phone: [phone] Fax: [phone].09
13 of 29
PN: 121314
When sanitizing cycle ends, remove the sanitizing solution
and replace the coffee BIB product. The machine will
automatically advance to the Prime Pumps mode.
To Prime: Press and hold the “Start” (+) switch until a steady
stream of product flows from the dispense area into the
vessel.
Press and release the “Enter” Switch until 3 dashed lines
appear in the display.
Discard the contents of the decanter or vessel.
Prime Pump Feature:
This feature allows you to enter directly into a Prime Pump
mode without sanitizing.
Press the - switch to enter the Prime Pump mode.
Follow the same Prime Pump procedures from Sanitizing
Instructions.
BIB Counter Auto-Reset Feature:
If enabled during the “Set-Up Programming” of the machine
a buzzer alarm will sound once per second to indicate that
the product BIB is empty.
Entering into a Prime Pump mode turns off the alarm.
BIB tracking is automatically reset when the pump is primed.

“LCD-1” Liquid Coffee Dispenser
NEWCO Enterprises Phone: [phone] Fax: [phone].09
14 of 29
PN: 121314
Product Installation Procedures:
 Open the cutout on the product box and position the
BIB fitment into the slotted area as shown in figure 1.
Fig. 1
Fig. 2

“LCD-1” Liquid Coffee Dispenser
NEWCO Enterprises Phone: [phone] Fax: [phone].09
15 of 29
PN: 121314
 Remove the plastic insert from the BIB fitment as
shown in figure 2.
 Using finger and thumb only to prevent over-tightening,
thread the BIB connector on to the BIB fitment until
seated as shown in figure 3.
Fig. 3
Fig. 4

“LCD-1” Liquid Coffee Dispenser
NEWCO Enterprises Phone: [phone] Fax: [phone].09
16 of 29
PN: 121314
 Place the product in the storage compartment as shown
in figure 4.
 Position the tubing as shown in figure 5
Fig. 5

“LCD-1” Liquid Coffee Dispenser
NEWCO Enterprises Phone: [phone] Fax: [phone].09
17 of 29
PN: 121314
Cleaning & Sanitizing Instructions:
 Remove product from storage area and disconnect BIB
connectors as shown in figures 1 & 2.
Fig. 2
Fig. 1

“LCD-1” Liquid Coffee Dispenser
NEWCO Enterprises Phone: [phone] Fax: [phone].09
18 of 29
PN: 121314
 Place an empty container in the dispense area of the
machine as shown in figure 3.
Fig. 3

“LCD-1” Liquid Coffee Dispenser
NEWCO Enterprises Phone: [phone] Fax: [phone].09
19 of 29
PN: 121314
 Connect the sanitizing solution adaptor (PN 120513) to
the BIB connector for Pump and connect sanitizing BIB
(PN 120509) as shown in figures 4 & 5.
Fig. 4
Fig. 5

“LCD-1” Liquid Coffee Dispenser
NEWCO Enterprises Phone: [phone] Fax: [phone].09
20 of 29
PN: 121314
 Press the Start button to enter sanitizing mode as
shown in figure 6.
Press the Start button again to
begin sanitizing. Sanitization
cycle will run for 2-1/2 minutes &
hot water will be delivered to rinse
the mixing chamber.
Buzzer alarm will sound 3 beeps
when cycle is complete.
Fig. 6
SAn
