Newhank MP103 USB User manual

MP103 USB MP103USB
USERMANUAL
MP103 USB

MP103 USB
2
MP103USB
3
Introduction
Thank you for buying this NewHank product. Please read through these operating instructions
so you will know how to operate your model properly.
After you have finished reading the instructions, ut them away in a safe place for future
reference.
Box Content
CD Player
IEC power cord
Remote control
RCA Cable
Ground rules for installation
Make sure all items listed in the BOX CONTENTS section are included in the box.
Place mixer in an appropriate position for operation.
Make sure all devices are turned off and all faders and gain knobs are set to “zero.”
Connect the stereo outputs to power amplifier(s), tape decks, and/or other audio sources.
Plug all devices into AC power.
Switch everything on in the following order:
1. Audio input sources (i.e. turntables, CD players, etc.)
2. Mixer
3. Last, any amplifiers or output devices
When turning off, always reverse this operation by:
1. Turning off amplifiers
2. Mixer
3. Last, any input devices
Introduction 3
Frontpanel features 4-5
Backpanel function description 6
Safety 7

MP103 USB
4
MP103USB
5
Front panel features
1. Power : Push this button to turn power on and off, the button lights red when the power is
on.
2. Eject : Push this button to load or eject the disc, the disc will not eject during playback.
Stop playback before pushing the eject button.
3. Cue : Pushing this button will set the current search point as a new Cue point. (Cue)
4. Play/Pause : Push once to start playback, once again to pause playback, and once more to
resume playback.
5. Rewind button: Push this button to rewind the search.
6. Fast forward button: Push this button to fast forward the search.
7. Skip (Track Select) : Turn this knob to select a track, by pushing this knob down while
turning, the tracks will change by 10 tracks at a time.
8.
Remote Sensor: Infrared remote control receiver unit.
9.
Disc/USB : Push this button to switch between CD input or a USB device.
10. Repeat : Use this button to repeat the selected track (repeat1) or to repeat all the tracks of
the cd (repeat all).
11.
S./C. (Single and Continuous mode) : Toggles between Single and Continuous mode.
Single mode: Playback will stop when a track ends.
Continuous mode : When a tracks ends, the next track will play automatically and the CD
itself will stop when the last track has played.
12. Time : Push this button to toggle between elapsed time, remaining time or total remaining
time.
Elapsed time: Showing the elapsed time of the current playing track.
Remaining time: Showing the remaining time of the current playing track.
Total remaining time: Showing how much time is remaining of the whole CD.
13. Loop In : Push this button to set a start loop point during playback, when no loop point is
set the loop button is flashing.
14. Loop Out : Push this button for setting the end of the loop point and releasing the loop
action. To finish loop mode push this button again.
15. Reloop : Used for repeating the last saved loop, To finish loop mode push this button again.
16. Pitch button: Activates or deactivates the pitch slider by turning the pitch led on or off.
17. Pitch bend - : While pushing Pitch Bend - the play speed decreases, when releasing this
button playing speed returns to the previous speed.
18. Pitch bend + : While pushing Pitch Bend + the play speed increases, when releasing this
button playing speed returns to the previous speed.
19. Pitch : Use this knob to increase or decrease the speed of the track, the pitch range hold
+/_ 12 %
20. USB Master: Connect your USB storing device to this device to allow the MP102 USB to
read and playback your music files. Via the USB master input only MP3 files can be read.
21. Large LCD display : Indicates all the functions, as they are occurring, with the CD.

MP103 USB
6
MP103USB
7
Backpanel function description
1. IEC Power plug connector : Plug your supplied power cord in here.
2. Balanced right XLR output: Connect these balanced output to a amplifier or active speaker.
3. Balanced left XLR output: Connect these balanced output to a amplifier or active speaker.
4. Balanced output level adjustment knob: By adjusting this knob the volume of the right XLR
channel will increase or decrease.
5. Balanced output level adjustment knob: By adjusting this knob the volume of the right XLR
channel will increase or decrease.
6. RCA out : Connect these unbalanced output to a mixer, amplifier or active
speaker.
7. 6.3 Headphone output: Connect your 6.3 headphone to these output.
8. Headphone volume control: Adjusts the level of the headphone output.
Safety
This equipment is not waterproof.
To prevent a fire or shock hazard, do not place any container filled with liquid near this
equipment (such as a vase or flower pot) or expose it to dripping, splashing, rain or moisture.
To prevent a fire hazard, do not place any naked flame sources (such as a lighted candle) on the
equipment.
To prevent the risk of electrical shock, don’t remove cover or back. No user serviceable parts
inside. Refer servicing to qualified service personnel only.
