NewTek TriCaster Mini X User manual

NX-001998-0001, Rev.01
Keyboard & Mouse
Removable Power
Cable
Power Supply
TriCaster®Mini X
What’s in the box?
Quick Start Guide
1 Mini DisplayPort to HDMI Adapter &
3 Mini DisplayPort to DisplayPort
Adapters

NX-001998-0001, Rev.01
TriCaster
®
Mini X Connections Set-Up
Back Panel Connections Set-Up
1
2
3
4
5
•Connect the removable power
cord to the power supply
•Connect the power supply
•cable to the power connector
on the unit
•Plug in the removable power
cable to an electrical power
source
•Connect mini DisplayPort to
DisplayPort or HDMI adaptors
•Connect adaptor cables to
HDMI or DisplayPort monitors
and displays
•Connect keyboard and mouse
•If USB extenders are needed
for peripheral devices,
performance can vary and it is
recommended to contact an
authorized NewTek supplier
for advice.
•Connect to network for more
input sources, for output, and
Internet access
•Connect up to four (4)
HDMI cameras sources.
Each input supports video
standard resolutions up to
4Kp30

NX-001998-0001, Rev.01
TriCaster
®
Mini X Connections Set-Up
Front Panel Connections Set-Up
6
7
8
9
10
•Connect microphone
input
•Connect headphone
•Connect line level audio
source
•Connect line level audio
output
•Press to turn on power to
the unit

NX-001998-0001, Rev.01
TriCaster
®
Mini X Registration
1. Serial Number Label
Find the 15-character serial number label on the TC Mini unit
2. Internet Connection
Use one of the Gigabit Ethernet Network Connectors on the unit to make an active Internet
connection.
3. Display, Keyboard & Mouse
Be sure a display, keyboard and mouse are connected to the unit.
4. Power
Press the Power Switch on the unit.
5. End User License Agreement
Once the unit finishes powering up the End User License
Agreement screen appears. Click on I Accept the license
conditions to continue
6. User Information
The User Info screen now appears. Fill out the information
and when complete, click OK
7. TriCaster
®
Registration
The Register TriCaster® screen now appears.
Type in the 15 character serial number and then
click Continue
8. Software Update
After confirmation with the NewTek registration service, the system user interface appears. Before
using the system, please go to https://www.newtek.com/downloads/ to download and install
the latest version of software.
9. Video Tutorials
Clicking on the New Session box is the first step to create a program, but there is a downloadable
video tutorial that will assist in the most common operations and show how an initial program can
be created. https://www.newtek.com/tricaster/mini/videos/
