GREY CUBE SHELF VESSEL
852763
Assembly instructions
Actual product size
H90 x W100 x D18cm
With: Assembly instructions
Missing or damaged parts
IMPORTANT- RETAIN FOR FUTURE REFERENCE CALL: 0333 777 8999
Produced in China for Next Retail Ltd.
852763-2014-V1
Need Help?

GREY CUBE SHELF VESSEL
852763
Assembly instructions
Warnings The appliance must be positioned so that the plug is
We suggest you retain these instructions for future reference. accessible. If you choose to chase the wire into the wall or
cosmetic reasons and or to install the fire using a fuse spur
Unwrap all packaging materials and place the components connection then the manufacturer cannot be held liable for any
on top of the carton box or on a clean floor to prevent it from charges arising from future decorative or re-installation costs
scratching. should the fire require to be exchanged at a future date.
This product should only be used on firm, level ground. This heater should not be used in a dusty environment.
keep small parts out of reach of children.
Warning: in order to avoid over heating do not cover the heater.
Suites are designed to be freestanding and should not be The appliance MUST be earthed.
permanently secured or sealed to the wall. The appliance MUST NOT be situated directly below a fixed
Read all instructions before using this heater. When using socket outlet.
an electrical heating appliance basic precautions should
always be followed to reduce the risk of fire, electric shock, Check the voltage requirement of the fire accords with the
and injury to persons, including the following: local supply voltage.
This heater is hot when in use. To avoid burns, do not let bare If the moulded plug is removed it should be disposed of with
skin touch hot surfaces. Keep combustible materials such as the fuse removed, as there is a risk of electrical shock if
furniture, pillows, bedding, papers, clothes, and curtains at inserted into another socket outlet.
least 1 metre from the front of the heater and keep them
away from the sides and rear. If the power cord needs to be changed, it can be accessed
through the mains access cover. This work should only be
Extreme caution is necessary when any heater is used by or done by a qualified electrician.
near children or invalids and whenever the heater is left
operating and unattended. The guard is to reduce the risk of Do's
fire or injury from burns and no part of it should be We suggest you spend a short time reading through this
permanently removed. It does not give full protection for leaflet before you start.
children or the infirm. When you are ready to start make sure that you have the
Always unplug the heater when not in use. To disconnect right tools, plenty of space and a clean, dry area for assembly.
heater, turn controls to off, then remove the plug from the
socket. Check the pack and make sure you have all the parts listed.
Connect to properly earthed sockets only. The earth should During assembly children should be kept away from the
comply with current IEE regulations. product due to possible risk of injury.
Use this heater only as described in this manual. Any other
Due to the size of this product we recommend that it is
use not recommended by the manufacturer may cause fire, assembled in the room intended for use.
electric shock, or injury to persons. Ensure that this product is fully assembled as illustrated
Avoid the use of an extension power cord because this may before use.
overheat and become a fire hazard. If an extension cord must
be used it should be a 13A extension cord. Check all screws or bolts are tightened and inspect regularly.
Produced in China for Next Retail Ltd.
852763-2014-V1
BEFORE YOU START

GREY CUBE SHELF VESSEL
852763
Assembly instructions
To clean wipe with a sponge and warm soapy water. Do not To prevent a possible fire, do not block air intakes or exhaust
use solvent based cleaners or detergents as they can bleach in any manner. Do not use above soft surfaces,like a bed,
or damage the product. where openings may become blocked.
Dont's Do not insert or allow foreign objects to enter any ventilation
Do not drag or pull your furniture. or exhaust opening as this may cause an electric shock or
fire,or damage the heater.
Do not tighten screws unit fully assembled. Number of people required to assemble
Do not overtighten screws or bolts. Two people are required to assemble this item.
Do not sit or stand on the product. Times to assemble
Do not use this product if parts are missing, damaged or
worn. 1 hour
Do not use this heater in bathrooms, laundry areas and Tools required
similar indoor locations (e.g. shower or a swimming pool).
Never locate heater where it may fall into a bathtub or other
water container.
Do not run the power cord under carpeting. Do not cover the Missing parts
power cord with throw rugs, runners, or other like. Arrange If you are missing any fixtures and fittings for your product
the power cord away from traffic area and where it will not be please contact our customer service team on 0333 777 8999
tripped over. and they will be happy to arrange for a replacement to be sent
to you free of charge.
Do not use this heater outdoors. Home service technicians
Do not operate a heater with a damaged power cord or plug If you have a fault with your product please contact our
or after a heater malfunctions, has been dropped or damaged customer service team on 0333 777 8999. If you have had the
in any manner. Return heater to authorised service facility for product for 28 days or less you may be offered a replacement.
examination, electrical or mechanical adjustment, or repair. refund or for a fully trained home sevice technician to visit your
home to assess the fault and repair the product where
Do not leave babies and young children unsupervised near possible. If you have had the product for more than 28 days we
this fire (even when switched off). Because of the size of the will send an independant home service technician to review
coals/pebbles there is a risk of choking if a piece is
and repair the product where possible and recommend
swallowed. further action.
Never use scourers, abrasives or chemical cleaners. You can write to us at
Home Customer services
Do not use the heater in areas where gasoline, paint, or Next Retail Ltd
flammable liquids are used or stored. Desford Road
Leicester
Do not use this heater in series with any device which would LE19 4AT
switch the heater on automatically, since a fire riskexists
when the heater is accidentally covered or displaced. To view our full furniture range please visit www.next.co.uk
Produced in China for Next Retail Ltd.
852763-2014-V1

GREY CUBE SHELF VESSEL
852763
Assembly instructions
GETTING TO KNOW YOUR PRODUCT
①
③ ②
Components supplied. Please use this guide if you require replacement parts.
Ref
Dimensions
Visual Qty Ctn
Produced in China for Next Retail Ltd.
852763-2014-V1
1
1
1
1
1
1
90 x100cm
43 x 10.5cm
3 x 5cm
1
2
3

GREY CUBE SHELF VESSEL
852763
Assembly instructions
Fixtures and fittings
supplied (actual size)
Ref
Dimensions
Qty
Fixtures and fittings supplied (not to scale)
Ref
Dimensions
Visual Qty
Produced in China for Next Retail Ltd.
852763-2014-V1
2
14 x 15CM
1
A
B
10 x 1.6CM
mm 10 20 30 40 50 60 70 90 100 110 120 13080

GREY CUBE SHELF VESSEL
852763
Assembly instructions
A X 2 10 x 1.6cm
Produced in China for Next Retail Ltd.
852763-2014-V1
1
2
3
4
NOTE
You can adjust how the light filters
through by slightly adjusting the
positions of the pebbles on the
tray once the unit is switched on.
NOTE
Wall fixings are not included. Please
source suitable wall fixings for your wall
type.
Ensure the area to be drilled is free
from hidden electrical wires and water
or gas pipes !

GREY CUBE SHELF VESSEL
852763
Assembly instructions
Positions
Off
On
On
On
On
Produced in China for Next Retail Ltd.
852763-2014-V1
Heating Appliance Settings
A+B+C
Flame effect and low heat (1KW).
A+B+C+D
Flame effect and high heat (2KW).
A
All functions off
A
Flame effect on.
A+B
Flame effect and cool fan.
5
Switches
Settings
NOTE:
The switches are hidden underneath the canopy as shown.
Switch A is the master power switch for the fireplace, and will switch all
other functions on and off. Switches should be operated in sequence - for
example A, B, C then D to turn all functions on, followed by D, C, B then A
to turn all functions off.

GREY CUBE SHELF VESSEL
852763
Bulb replacement
25 watts max
Produced in China for Next Retail Ltd.
852763-2014-V1
2
1
3
4
WARNING
Before replacing the bulb,
unplug or disconnect fire
from the socket outlet !
WARNING
Bulbs can be very hot, handle with
care. Allow bulbs to cool before
attempting to replace !
Only a G9/25 watts/~240V type
bulb should be used in this product.

GREY CUBE SHELF VESSEL
852763
Troubleshooting
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste. Please recycle
Where facilities exist. Check with your Local Authority or retailer for recycling advice.
YOUR APPLIANCE IS GUARANTEED FOR ONE YEAR FROM THE DATE OF PURCHASE AGAINST ANY
MANUFACTURING DEFECT (BULBS HAVE A LIMITED LIFE-SPAN AND WILL REQUIRE REPLACEMENT
EVENTUALLY. THIS IS NOT REGARDED AS A DEFECT). IF YOU ENCOUNTER A PROBLEM, PLEASE CONTACT
CUSTOMER SERVICES.
RATING INFORMATION
Voltage: ~220V-240V / 50Hz
Heating Elements: 2000W
Lamp: G9 / 25W / ~240V
IMPORTANT:
The wiring in this mains lead is coloured in accordance with the following code:
European Fires (CE approved)
EARTH: GREEN and YELLOW
NEUTRAL: BLUE
LIVE: BROWN
Replacement fuse must conform to British Standards and be rated at 13A.
Produced in China for Next Retail Ltd.
852763-2014-V1
No or poor illumination
of pebble bed
Suggests bulb failure
Locate the failed bulb by removing the pebble bed and
then replace the bulb.
Suggests an electrical supply
problem
No flame effect or fan
operation
Fan heater and flame
effect have stopped
whilst in operation
Suggests the action of the
thermostatic cut out
●Is the appliance plugged in and switched on at the
mains? Are the switches on the fire correctly set?
●Check the fuse in the plug. Replace as necessary.
●Check that the socket functions correctly with other
appliances.
Ensure the air supply and venting are not restricted.
The cut out will automatically reset after being
switched off and on at the mains. Allow 15 minutes to
cool.
Problem
Diagnosis
Correction

,
