NextBase 380 GWX User manual

User Manual

Table of Contents
02
TABLE OF CONTENTS
INTRODUCTION TO YOUR DASH CAM
USING CCTV IN A COMMERCIAL ENVIRONMENT
PRECAUTIONS / CAUTIONS ON USING THIS PRODUCT
FCC STATEMENT
FCC-SUPPLIER’S DECLARATION OF CONFORMITY
PRODUCT SPECIFICATION
PACKAGE CONTENTS / PRODUCT FEATURES
POWERED GPS MOUNT
FRONT FACING CAMERA - PARTS & CONTROLS
REAR FACING CAMERA - PARTS & CONTROLS
IN VEHICLE INSTALLATION
CONNECTING YOUR DASH CAM TO CAM VIEWER APP
INSTALLING YOUR DASH CAM (FRONT)
POSITIONING YOUR DASH CAM (FRONT)
INSTALLING YOUR DASH CAM (REAR)
FINISHED DASH CAM & REAR CAM SETUP
ANTI-TAMPER SECURITY INSTALLATION
02
03
04
05
06
07
08
09
10
11 - 16
17
18 - 21
22 - 23
24 - 25
26
27 - 28
29 - 30
31
CAM VIEWER APP
- INTRODUCTION
- CONNECT YOUR DEVICE / MAIN SCREEN
- LIVE VIEW AND PIP
- DOWNLOADING RECORDINGS (iOS & ANDROID)
- SHARING RECORDINGS / DASH CAM SETTINGS
- DASH CAM SETTINGS
PC CONNECTION
NEXTBASE SD CARDS
TROUBLESHOOTING
CE MARK INFO. / SOFTWARE LICENSE AGREEMENT
WARRANTY / ONLINE & INTERNATIONAL PURCHASES
32
33
34
35
36
37 - 39
40
41
42 - 43
44
45

Introduction to your Dash Cam
The Nextbase range of Dash Cams have been designed specifically with ease of use in mind, it
is recommended NOT to change the default settings, which have been carefully selected to give the
best performance for day to day use.
Basic operation
The Dash Cam is set to record video, in files 1 minute in length. This means that each
video file is a manageable size should you need to download and send to your insurance company.
Eventually your MicroSD card will fill up with video files but don't worry, the camera automatically
deletes the oldest file to make space for new recordings. This way you never run out of space and
have plenty of driving historical evidence saved.
Typically a 16Gb card will store the last 90 minutes of driving footage.
The Time and Date are automatically set upon the camera from satellite data. They will also update
automatically for Daylight Savings Time, again based on the Country selected.
Automatic Start / Stop Technology.
The Dash Cam senses power supplied to the cigarette lighter socket as soon as the vehicle ignition
is turned on and will start to record automatically.
When the ignition is turned off, the Dash Cam will perform an automatic shutdown process.
1. Tips for capturing best video footage:
1.1 Position the Dash Cam in the centre of the windscreen and ideally behind the rear view mirror
so it is not an obstruction to the driver's field of view.
1.2 osition the Rear Facing Camera towards the top-centre of the rear window, ensuring that it isP
not an obstruction to the driver's field of view.
1.3 Reduce the amount of sky in the picture, by angling the view of the camera towards the road.
Too much sky will make the road appear darker due to the automatic exposure compensation.
1.4 Remove unnecessary items from your dashboard. If objects are placed on your dashboard
these can cause reflections to be seen on the windscreen and these reflections may be
captured during recording.
2. Tips for stable memory card performance:
2.1 Periodically format the memory card. Every 2-3 weeks we recommend that you reformat
the memory card. This will wipe any files from the card and set it up afresh for continued use
with your Dash Cam.
Of course, you should only do this AFTER you've downloaded any files from the card that you
may want to keep, as formatting the card will remove all content.
2.2 Format your memory card using the Dash Cam, this will make sure that the card is structured
specifically for your camera.
2.23 Switch off the Dash Cam before removing or inserting the SD memory card, to prevent the
chance of damage being caused to the memory card or the files stored upon it.
03

When using the NEXTBASE 380GWX in a commercial vehicle you must ensure that you comply with
any applicable legislation set out by the Government in your location. The following guide is written
for usage of the product in the UK.
UK requirements include but are not limited to the Data Protection Act, the CCTV Code of Practice
and the Surveillance Camera Code of Practice.
A simple CCTV Compliance Checklist is included upon the Software Disk included with the NEXTBASE
380GWX. Additional supporting documents are also included to help Data Controllers comply with
applicable legislation. Example Policy and Procedure documents are also supplied (in editable Word
document format) so that you can amend them to suit your business.
CCTV Compliance Checklist Steps
1. The CCTV Code of Practice states that there should be a pressing need for a camera to be
installed in your vehicle as using cameras can be privacy intrusive. You should ensure that you
have identified a clear need for a camera to be installed (e.g. For the purpose of driver and
passenger safety)
2. You must have a designated Data Controller who will be responsible for ensuring data is
recorded correctly and securely as well as ensuring all Operators are aware of all relevant
policies and procedures regarding the use of The Data Controller must register Dash Cams.
with the Information Commission's Office (ICO). This can be done by visiting www.ico.org.uk.
Data controllers will usually be organisations, but can be individuals, for example self-employed
consultants. Even if an individual is given responsibility for data protection in an organisation,
they will be acting on behalf of the organisation, which will be the data controller.
3. The CCTV Code of practice states that you must let people know when they are in an area
where a surveillance system is in operation.
Supplied with your product are three 'CCTV Window Stickers' (shown below) for this purpose.
To comply with Surveillance Camera Legislation, the above window stickers should be located
on all entrance points to your vehicle.
Using CCTV in a Commercial Environment
4. Using a suitable permanent marker pen please add contact details for CCTV / Data
controller, before applying stickers to your vehicles windows
5. The Data Controller is responsible for ensuring that all Dash Cam operators/drivers are
aware of their responsibilities regarding the data being recorded. Included in the
“NEXTBASE Policy and Procedure Examples” Folder on the Software Disk is an
Operator/Driver Briefing Checklist, to help the Data Controller monitor this.
6. The company should have clear, documented policies regarding all aspects of data being
recorded and stored. These are covered individually later in the checklist.
An example of a CCTV Recording Policy is included in the “NEXTBASE Policy and Procedure
Examples” Folder on the Software Disk.
7. All Operators/Drivers should know where to find company policies and procedures for
using the Dash Cam. This is covered in the Operator/Driver Briefing Checklist.
8. The Data Controller must state how long data is to be stored by the company.
The CCTV Code of Practice states that data should be deleted once it is no longer needed.
An example of a CCTV Data Storage Policy is included in the “NEXTBASE Policy and
Procedure Examples” Folder on the Software Disk.
9. The Data Controller should specify how data is deleted once it is no longer needed. This is
also covered in the CCTV Data Storage Policy example, on the Software Disk.
10. The Data Controller should decide who has access to stored data. This is also covered in the
CCTV Data Storage Policy example on the Software Disk.
11. The Data Controller should decide how the company handles a request for access to data
it has stored. An example of a CCTV Request for Access Policy is included in the “NEXTBASE
Policy and Procedure Examples” Folder on the Software Disk.
Requests for Access can be made by members of the public or from Police forces.
Examples of both Public and Police request forms have been included in the “NEXTBASE Policy
and Procedure Examples” Folder on the Software Disk.
CCTV Compliance Checklist and Example Documents produced using information provided
by The Home Office, Information Commissioner's Office and the Surveillance Camera Commissioner.
Contains public sector information licensed under the Open Government Licence v3.0.
04

Precautions
CAUTION:
WEEE: Disposal of Waste Electrical and Electronic Equipment and/or Battery by users
in private households in the European Union.
This symbol on the product or on the packaging indicates that this cannot be
disposed of as household waste. You must dispose of your waste equipment
and/or battery by handing it over to the applicable take-back scheme for the
recycling of electronic equipment and/or batteries. For more information
please contact your local household waste disposal office.
To reduce the risk of electric shock, do not perform any servicing other than that
contained in the instruction manual unless you are qualified to do so.
Have the unit serviced by a qualified service technician if;
The Unit has been exposed to rain or water.
The unit does not seem to operate normally.
The unit exhibits a marked change in performance.
WARNING: Do not expose this product to rain, moisture or water under any circumstances, doing
so may result in the risk of electric shock or fire.
Please read this manual carefully before operation and keep it for future reference. It will be helpful
should you encounter any operational problem.
1. Ensure that the windscreen/rear window is free of dirt or grease before placing mount upon it.
Do not obscure the view of the road ahead or impede the deployment of any airbags in the 2.
event of an accident.
When not in use, please disconnect the car adaptor from both the 12/24Vdc outlet in your vehicle. 3.
4. Only clean the device with a soft dry cloth, for tough dirt, apply some neutral detergent diluted in
5 to 6 parts water to a soft cloth.
Note that alcohol, thinner, benzene etc could cause damage to the paint or coatings.
Avoid making contact with the len as damage be caused. 5. s may
If required clean the glass lens carefully using spectacle lens cleaning fluid on a soft cloth only. 6.
The video recordings made by this are intended for personal use only. 7. Dash Cam
Publication of the recordings on Youtube, the internet or other methods are subject to the 8.
Data Protection Act and the requirements thereof must be adhered to.
If the is to be used within a commercial environment, i.e. truck use, then the CCTV Dash Cam
regulation apply also, in addition to the Data Protection Act regulations. This includes labelling
to identify the use f CCTV is taking place, the omission of Audio recording and informing the o
authorities of who controls the data.relevant
Whilst driving, do not adjust the controls of your device as this is a distraction to driving. 9.
Cautions on using this product
Some Products may contain components that are small enough to be swallowed.
Please keep out of reach of children.
CHOKING
HAZARD:
05
Radio Frequency Band and Power Information
compliance with the following directive 2014/53/EU. The full text of the EU Declaration Of
Conformity is available at the following internet address: https://www.nextbase.com/certifications/
This device meets the EU requirements and the International Commission on
Non-Ionising Radiation Protection (ICNIRP) on the limitation of exposure of the general public to
electromagnetic fields by way of health protection. To comply with the RF exposure requirements,
this equipment must be operated in a minimum of 20 cm separation distance to the user.

FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
• This appliance and its antenna must not be co-located or operated conjunction with any other
antenna or transmitter.
• A minimum separation distance of 20cm must be maintained between the antenna and the
person for this appliance to satisfy the RF exposure requirements.
FCC CAUTION:
Any changes or modifications to the equipment not expressly approved by the party responsible
for compliance could void your authority to operate the equipment.
06

FCC - STATEMENTSUPPLIER'S DECLARATION OF CONFORMITY
SUPPLIER'S DECLARATION OF CONFORMITY
(47 CFR Section 2.906).
We; Tank Design
Hereby, Declare that the essential requirements set out in the 47 CFR Sections 2.906
of FCC, have been fully fulfilled on our product with indication below:
1. Applicant's Info
Company Name: Portable Multimedia Ltd
Mailing Address : Unit 2, Caerphilly Business Park, Van Road, Caerphilly. CF83 3ED. UK
Contact : Graham Lambert
Tel : [phone]
Email Address : [e-mail]
2. Product Info
Product Name : Dash Cam
Model No. : NBDVR380GWX
Brand Name : Nextbase
3. Applied Standard
Standards
E-CFR Title 47 Part 15 Subpart B—Unintentional Radiators: 2017
Report No. TBC*
4. Test Firm Used to Take Measurements:
Name : Waltek Services (Shenzhen) Co., Ltd.
Address : 1/F, Fukangtai Building, West Baima Rd Songgang Street, Baoan District,
Shenzhen, Guangdong, People's Republic of China, 518105
Contact Name : Philo Zhong
Tel : [phone] 802
Email : [email protected]
Designation No. : TBC*
FRN : TBC*
5. FCC Marking
6. Responsibilities and obligations
Strictly follow the FCC rules of 2.906, 2.908, 2.909.
7. Applicant's Authorization
Company Name: Portable Multimedia Ltd
Mailing Address : Unit 2, Caerphilly Business Park, Van Road, Caerphilly. CF83 3ED. UK
Contact Person : Graham Lambert
Signature:
Email Address : [e-mail]
Tel : [phone]
Date : TBC*
8. Responsible party in US.
Company Name: Tank Design
Mailing Address: 158 Sidney Street, Cambridge, MA 02139, United States
Contact Person : Mr Scott Watts
Signature:
Email Address : SW[email protected]
Tel : [phone]
Date : TBC*
* Please visit https://www.nextbase.com/en-gb/help-and-support/dash-cams/
download the latest 380GWX manual
A full list of certicfications can be found at https://www.nextbase.com/certifications/
07

Model Number / Name
Power Requirements
Power Supply
Sensor Resolution
Lens -
Type / Angle / Aperture
Recording Resolution
Card Reader
SD Card
(Recommended Type)
SD Card Recorded file
Capacity
(Dual cameras, based on
default settings)
Recording Format
Unit Dimensions (inc. mount)
Unit Weight (inc. mount)
Cam Viewer (min req.)
Android
iOS
Replay 3 (min req.)
Windows
Mac
NBDVR380GWX
5V / A1.5
12-24Vdc Car Power Cable
(supplied)
Fuse Type: mm 1.5A20 /
Output: 5Vdc
2.12M Pixel
6G / 140° / F1.8
1920 x 1080 @ 30fps
8 - 128GB MicroSD Card
8 - 128GB MicroSD Card,
SDHC / SDXC, U1
for best results use a Nextbase
branded SD Card.
.MOV
W58mm x L98mm x H47mm
115g
V5.1
10.3
Windows7
10.7
Product Specification
Android is a trademark of Google Inc. in the United States and other countries.
Mac is a registered trademarks of Apple Inc. in the United States and other countries.
iOS is a trademark or registered trademark of Cisco in the United States and other countries.
© 2015 Google Inc. All rights reserved. Google Maps™ mapping service is a trademark of Google Inc.
Windows is a registered trademark of Microsoft Corporation in the United States and other countries.
NEXTBASE Replay 3 is a registered trademark of Portable Multimedia LTD in the United Kingdom.
NEXTBASE Cam Viewer is a registered trademark of Portable Multimedia LTD in the United Kingdom.
microSD™ and the microSD logo are trademarks of SD-3C, LLC.
Wi-Fi® is a registered mark of Wi-Fi Alliance Corporation.
Other trademarks and trade names are those of their respective owners.
NBDVR380GWX Rear Camera
Video and Power supplied
through connection to Dash Cam.
Video and Power supplied
through connection to Dash Cam.
2.12M Pixel
6G / 140° / F1.8
1920 x 1080 @ 30fps
N/A, SD Card reader on main unit
N/A, SD Card reader on main unit
.MOV
W49mm x L68mm (+30cm
connector cable) x H37mm
50g
08
8GB MicroSD
16GB MicroSD
32GB MicroSD
64GB MicroSD
128GB MicroSD
=
=
=
=
=
45 minutes
90 minutes
180 minutes
360 minutes
720 minutes

Package Contents Product Features
Please check the contents of your NEXTBASE product.
Product appearance may differ slightly to that shown above.
Thank you for purchasing this Nextbase Dash Cam, in this section we will outline some of the
features available with this Dash Cam.
Designed in the UK the 380GWX is discreet and fits neatly at the top of the windscreen to record
the road ahead in FULL 1080p HD to ensure that you capture every detail such as road signs and
number plates. The Nextbase 380GWX Dash Cam has been made specifically for the commercial
and fleet market, protecting both business and your drivers. The 380GWX has also been designed
to be compatible with a Rear Facing Camera, to cover your view of the road behind you, as well as
the road ahead.
By having a unique lens with 90 degree vertical adjustment the Nextbase 380GWX is the only
Dash Cam really suited to commercial cars, vans and trucks with flat windscreens.
With any Dash Cam a key concern of any fleet manager is making sure that the device is running
at all times. On the side of the Nextbase 380GWX are special security covers, protecting the user
controls to make sure the device is working.
The SD card, power connector and On/Off button can all be locked away with security to ensure
that the camera is running at all times and there is no chance of the SD card being tampered with.
1. Corporate responsibility – protect your employees and drivers on the road.
2. Prove that your driver wasn't to blame in the event of an incident.
3. In the event of an accident – Dash Cam footage can significantly reduce insurance claim time
to get your fleet vehicles back on the road sooner.
4. Protect your brand reputation – by having a Dash Cam Drivers tend to be more cautious, on
average 33% safer than without a Dash Cam*
*telematics scores with and without Dash Cam fitted
For Help and Support please call 02920 866 429
Dash Cam, Mount, &
Rear Facing Camera Module
Car Power Cable
USB Cable
Security Pack
Quick Start Guide
Window Stickers
Manual, CCTV, & Software Disk
Your Dash Cam and Rear
Camera can record both
the road and the road
behind you
Charge your Dash Cam in you
vehicle using the Car Power Cable.
Connect your Dash Cam to your PC.
Use the additional security
attachments to prevent
tampering with the Dash Cam.
Quickly get your Dash Cam set up and
running using the Quick Start Guide.
Stickers for CCTV usage and
to warn other road users that
your vehicle is protected.
Everything you need to get you
started with your Dash Cam.
09

Made in China
For use with 90 connector
5VDC-IN
For use with
straight
connector
5VDC-IN
NBDVR380GWMNT
4
Locking Pins
These pins will locate and then allow the camera to be attached to the mount.
DC-IN Sockets
There are two sockets available, one for use with the supplied 90° car adaptor, the other
for use with the Nextbase Hardwire Kit (sold separately) which uses a straight connector.
Please contact your Nextbase retailer to purchase the Nextbase Hardwire Kit.
Cable Lock
The cable lock secures the car adaptor or hardwire kit cable to the mount.
Cable Lock Anti-Tamper Screw
Location of the anti-tamper screw, that can be used to secure the cable lock to the mount.
Adhesive Pad
Once the backing tape has been removed this adhesive pad will securely adhere the mount to
your windscreen.
Note:
- Before removing the red backing tape from the adhesive pad make sure you have determined
the optimum position for the Dash Cam (see page 26) and that the windscreen is free of dust
and/or dirt.
- A spare adhesive pad has been provided, in case you wish to change the mounts location.
1
1
5
2
3
4
Powered GPS Mount
Please see below to identify the parts of the supplied GPS mount.
2
3
5
10

Front Facing Camera - Parts and Controls
Please see below to identify the parts and controls of your Dash Cam.
Left side:
1
5
2
3
4
Side Cover
There are two types of side cover supplied:
Standard covers:
These are fitted when the Dash Cam as standard and are used during normal operation.
Remember to replace the side cover before use.
Locking covers:
Included within the Security Pack are two locking covers, these can be secured to the Dash
Cam using the supplied anti-tamper screws. This allows the owner of the vehicle to prevent
un-authorised access to or operation of the Dash Cam.
Anti-Tamper Screw Insert
Insert thread for the anti-tamper screw.
Reset Button
In the unlikely event the Dash Cam becomes unresponsive, press the RESET button to
restart the Dash Cam.
Power & Start / Stop Recording Button
Long press (2 seconds) power On/Off the Dash Cam.
Short press to start / stop recording.
Camera to Mount Locking Screw
The camera can be secured to the mount to prevent un-authorised removal, see pages
41 - 42 for further details.
Microphone
Integral microphone for audio recording, this can be turned off via the Cam Viewer App.
6
T gugv
1
2
3 4 5 6
11

4
Front Facing Camera - Parts and Controls (contd.)
Please see below to identify the parts and controls of your Dash Cam.
Right side:
1
5
2
3
4
Side Cover
Removable side cover, remember to replace the side cover before use.
Anti-Tamper Screw Insert
Insert thread for the anti-tamper screw.
USB Socket
Connect the supplied USB data cable here to connect the Dash Cam to a computer.
Note:
During normal use the car power cable is connected to the mount, not directly to
this socket.
SD Card Slot
Insert the MicroSD card here, taking care that the gold contacts are facing towards the mount.
Camera to Mount Locking Screw
The camera can be secured to the mount to prevent un-authorised removal,
see pages 31 for further details.
1
1
5 3
12

Front Facing Camera - Parts and Controls (contd.)
Please see below to identify the parts and controls of your Dash Cam.
Top side:
3
4
2
1
1LED Indicators
The functions of the three LED indicators are described in the below table.
Note:
- The blue LED will only function when there is a NEXTBASE 380 Battery Pack installed,
this is sold separately.
Please contact your NEXTBASE retailer to purchase the NBDVR380BAT.
- This Dash Cam uses Negative Temperature Coefficient (NTC) technology to protect
the battery. This will shut down battery charging should the Dash Cam’s internal
temperature exceed 70 degrees.
Protect Mass Storage Mode Card Format/Bad Card Protected
Wi-Fi Wi-Fi On/Update Mode Card Format/Bad Card Device Connected
LED Colour Function
Battery
Power
GPS
Battery
Power
GPS
Low Battery Warning
Updating FW
Formatting SD Card
Battery Charging
Power On
GPS Locked
Slow Flash Fast Flash Solid
-
Recording
Searching for GPS Lock
13

Wi-Fi Button & Indicator
Press and hold the Wi-Fi button for 2 seconds to turn on the Dash Cam's Wi-Fi function.
Once turned on, the button will flash slowly blue in colour, awaiting a connection from a
smartphone / tablet etc.
Once a device has been successfully connected the button will become solid blue. If no
connection is established within 2 minutes, then the Wi-Fi function turns off automatically and
the blue flashing light will extinguish.
See pages 32 - 39 for details on how to connect your mobile device to the Dash Cam and
how to use the Cam Viewer App.
Note:
- The Protect button can also be used to format the SD card, when recording is stopped.
Press and hold the Protect button for 6 seconds, the yellow LED will flash quickly during
the SD card formatting process.
Speaker
Used for the two types of ‘notification’ sounds.
Sounds:
There are two sounds, these are used to identify when recording starts and stops.
1. Start recording
A three-tone beep sound (ascending) will be heard when recording starts.
2. Stop recording
A three-tone beep sound (descending) will be heard when recording stops.
Announcements:
There are two spoken announcements, these are used to identify there is a SD card
issue that needs attention before recording can start.
i. Please insert Class 10 SD card
This is heard when there is either no SD card inserted, the inserted SD card is not of
the Class 10 type or the SD card is defective and cannot be successfully formatted.
ii. Card error, format SD card
The inserted card has previously been formatted to an incompatible standard for use
with the Dash Cam, this is usually resolved by simply re-formatting the SD card within
the Dash Cam.
See page 38 for details on how format the SD card.
Note:
- Should formatting the SD card not resolve the issue, please try another quality
branded SD card, making sure that is a Class 10 (48MB/s minimum) type.
- T he Sounds and Announcements can be turned On / Off from the Cam Viewer
Protect Button & Indicator
Press the protect button whilst recording to protect the current file, the button will illuminate,
red in colour indicating the file is protected.
Depending on at which point during the current recording the file is protected, the camera
will also save the previous or subsequent recordings, as follows:-
If the protection takes place during the first 3rd of the recording, the previous recording will
also be protected.
If the protection takes place during the final 3rd of a recording, the next recording will also be
protected.
Note:
- The protect button is also used when connecting the camera to a computer using the
USB cable. Press and hold the protect button when connecting the camera to a computer
and the Dash Cam will power on in Update Mode.
2
3
4
Front Facing Camera - Parts and Controls (contd.)
14

Product: 380GWX
Model: NBDVR380GWX
FCC ID: 2AOT9-NBDVR380GWX
Made in China
Note:
To format the SD Card
using the camera, press
and hold the Protect
button for 6 seconds.
The yellow LED will flicker
during formatting.
Front Facing Camera - Parts and Controls (contd.)
Please see below to identify the parts and controls of your Dash Cam.
Bottom:
1
Mount to Camera Fixing Points
The mount locking pins locate here when attaching the camera to the mount.
Battery Compartment
For use with the battery pack (sold separately), required if using the Parking Mode function
on a 'switched' live power source, i.e. a 12Vdc outlet that only provides power when the
vehicles ignition is turned on.
Please contact your Nextbase retailer to purchase the battery, part number NBDVR380BAT.
2
2
1
15

Front Facing Camera - Parts and Controls (contd.)
Please see below to identify the parts and controls of your Dash Cam.
Front and Rear view:
1Front Facing Camera Lens
Wide angle 140° field of view.
Rear Cam connection point
The USB-C connection point for the Rear Camera is located underneath the dust cover.
2
1
2
16

1Rear Facing Camera Lens
Wide angle 140° field of view.
Rear Cam Cable Connection Cable
30 cm Rear Camera Connection Cable. Attach the 6.5m cable to connect the Rear Facing
Camera to the Front Facing Camera.
LED Indicator
The LED will turn on to indicate that the file is protected.
Adhesive pad
Once the backing tape has been removed this adhesive pad will securely adhere the mount
to your windscreen.
Note:
- Before removing the red backing tape from the adhesive pad make sure you have
determined the optimum position for the Dash Cam (see page 26) and that the rear window
is free of dust and/or dirt.
2
Rear Facing Camera - Parts and Controls
Please see below to identify the parts and controls of your Dash Cam.
Left and Right view:
Top and Bottom view:
12
3
4
3
4
17

In Vehicle Installation
1 Remove Side Cover
Using the finger nail slot, remove the right hand side cover, under which the SD card
slot is located.
2 Insert micro SD Card
Insert the MicroSD card here, taking care that the gold contacts are facing towards the
bottom of the Dash Cam.
3 Replace Side Cover
Click the side cover back in to place, with the curved edge engaging firstly.
1
2
3
18

In Vehicle Installation (contd.)
4 Remove Camera From Mount
Slide the mount towards the camera lens to disengage the mount.
5 Remove Cable Lock
The cable lock is in the corner of the mount and can be twisted away from the mount
itself and then disengaged completely from the mount.
6 Connect Power
Connect the supplied Car Power cable in to the Mini USB socket marked ‘For use with 90
connector’.
Note:
- The Nextbase hardwire kit connector will utilize the mini USB socket marked ‘For use
with straight connector’.
- Once the Car Power is connected to the Dash Cam mount, do NOT connect it to the
12-24Vdc power supply in your vehicle until the Rear Facing Camera has also been
connected. ALWAYS make sure your Dash Cam is powered OFF before connecting or
dis-connecting the Rear Facing Camera.
4
5
6
19

In Vehicle Installation (contd.)
7 Refit Cable Lock
The cable lock can now be refitted by firstly inserting the tang fully and then rotating the cable
lock until it engages fully around the power cable and then clicks in to place in the mount.
The cable clamp can be secured to the mount to prevent un-authorised removal, see pages
31 for further details.
8 Refit Camera to Mount
Offer the mount to the camera to engage the locking pins and then slide the mount away
from the camera lens to engage the mount connections fully.
7
8
9
9 Attach the Rear Cam Connector Cable to the Dash Cam
Plug the USB-C end of the 6.5m connector cable into the port at the rear of the Dash Cam.
20
