Panasonic WVBP110 - MONITOR User manual

Operating
Instructions
CCTV Cameras
WV-BP110AA/V-BP114
Panasonic©
Before alien- p iny l:> connect or operate I" i BrOGUtl.
ylease read Ifese nElru^lionE coTipuicrly

For U.S.A - n
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK). NO USER SER¬
VICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PER¬
SONNEL.
A The lightning flash with arrowhead
symbol, within an equilateral triangle, is
intended to alert the user to the pres¬
ence of uninsulated "dangerous volt¬
age" within the product's enclosure that
may be of sufficient magnitude to con¬
stitute a risk of electric shock to per-
The exclamation point within an equi¬
lateral triangle is intended to alert the
user to the presence of important oper¬
ating and maintenance (servicing)
instructions in the literature accompa¬
nying the appliance.
I Warning:
! This equipment generates and uses radio frequency !
energy and if not installed and used properly, i.e., in j
strict accordance with the instruction manual, may cause |
J harmful interference to radio communications. It has |
! been tested and found to comply with the limits for a !
! Class A computing device pursuant to Subpart J of Part I
I 15 of FCC Rules, which are designed to provide reason- !
| able protection against such interference when operated j
\ in a commercial environment.
i___i
,-For CANADA --,
j This digital apparatus does not exceed the i
j Class A limits for radio noise emissions from digital appa- J
! ratus set out in the Radio Interference Regulations of the !
! Canadian Department of Communications.
The serial number of this product may be found on the
bottom of the unit.
You should note the serial number of this unit in the
space provided and retain this book as a permanent
record of your purchase to aid identification in the event
of theft.
Model No. _ _ _
Serial No.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CONTENTS
PREFACE.2
FEATURES.2
PRECAUTIONS.3
MAJOR OPERATING CONTROLS AND THEIR FUNCTIONS.4
CONNECTIONS. 6
LESES.. v .8
FOCUS OR FLANGE-BACK ADJUSTMENT.9
INSTALLATION OF CAMERA.10
PREVENTION OF BLOOMING AND SMEAR. 10
LENS MAINTENANCE AND CLEANING. 10
SPECIFICATIONS.11
STANDARD ACCESSORY.12
OPTIONAL ACCESSORIES. 12
-1-

PREFACE
FEATURES
Panasonic's WV-BP110 series cameras introduce a
new level of high picture quality through the use of a
1/3 inch interline transfer CCD having 512 horizontal
pixels (picture elements). High performance-to-cost
ratio is achieved through the use of newly developed
Sync IC’s and ability to shoot indoor scenes with a
fixed iris lens by use of Electronic Light Control (ELC)
function.
• Minimum illumination of 0.015 footcandle (0.15 lux)
at F1.4 and Signal-to-noise ratio of 46 dB by
employing a 1/3 inch interline transfer CCD image
sensor with 512 (H) x 492 (V) pixels.
• 380 lines of horizontal resolution
• Ability to shoot indoor scenes with fixed iris lens by
use of Electronic Light Control (ELC) function.

PRECAUTIONS
• Do not attempt to disassemble the camera.
To prevent electric shock, do not remove screws
or cover. There are no user-serviceable parts
inside.
Refer servicing to qualified service personnel.
• Handle the camera with care.
Do not abuse the camera. Avoid striking or shak¬
ing it. The camera could be damaged by improper
handling or storage.
• Do not expose the camera to rain or moisture,
or try to operate it in wet areas.
Do take immediate action if ever the camera do
becomes wet. Turn power off and refer servicing
to qualified service personnel. Moisture can dam¬
age the camera and also create the danger of
electric shock.
• Never face the camera toward the sun.
Whether the camera is in use or not, never face it
toward the sun. Do use caution when operating
the camera in the vicinity of spot lights or other
bright lights and light reflecting objects.
• Do not operate the camera beyond its
temperature, humidity or power source ratings.
Do not use the camera in an extreme environment
where high temperature or high humidity exist.
Use the camera under conditions where tempera¬
tures are within ~22°F - 122°F (-30°C - +50°C),
and humidity is below 90%. The input power
source is 120V AC 60 Hz for WV-BP110 or 24V AC
60 Hz for WV-BP114.
Caution:
To prevent fire or shock hazard, the UL list¬
ed wire VW-1, style 1007 should be used for
the cable for AC 24V Input Terminal.
- 3 -

MAJOR OPERATING CONTROLS AND THEIR FUNCTIONS

(1 ) Camera Mounting Screw Hole
This threaded hole (1/4” - 20) is used to mount the
camera onto a mounting bracket or tripod.
(2) Flange-backAdjusting Ring
This ring is used to adjust the'back focal length or
picture focus by rotating this ring to counterclock¬
wise.
Caution:
Always set this ring to fully clockwise before
mounting the lens.
(3) Lens (Option)
See page 8 for details on lens selection.
(4) Video Output Connector (VIDEO)
A 1.0 Vp-p/75 ohms composite video signal is pro¬
vided at this connector.
(5) AC Power Cord
(6) A C 24V In Terminal (AC 24V IN)
This terminal accepts 24V AC power source
(19.5V -28V). Be sure to connect grounding lead
to the GND terminal.
Cautions:
1. Connect this to a 24V AC class 2 power sup¬
ply only.
2. To prevent fire or shock hazard, the UL listed
wire VW-1, style 1007 should be used for the
cable for AC 24V Input Terminal.
ELC (Electronic Light Control)
In this mode a continuously variable electronic shutter
is employed to automatically control exposure times in
the CCD Image Sensor, according to the incoming
light level.
With this mode selected, fixed or manual iris lens can
be used instead of an ALC type lens.
Caution:
Under certain unique lighting conditions, the fol¬
lowing may appear:
- 5 -

• Strong smear and/or blooming on high light
objects such as spot lights or windows.
• Noticeable flicker on the picture.
6-
CONNECTIONS
Power Source
• WV-BP110
Connect the AC. Power Cord (5) to a electrical out¬
let of 120V AC 60 Hz.
• WV-BP114
1. A power supply of 24V AC 60 Hz is required.
2. Connect the power cable to the 24V AC In
Terminal (6) on the rear panel of the camera.
Recommended wire gauge sizes for 24V AC line.

Caution:
To prevent fire or shock hazard, the UL listed
wire VW-1, style 1007 should be used for the
cable for AC 24V Input Terminal.
Video Cable
1. It is recommended to use a video monitor whose
resolution is at least equal to the camera's.
2. Terminate the camera output with 75-ohm resistor
at the furthest end of its cable run.
• It is recommended to use 75-ohm coaxial cable.
• Always set the last monitor's termination switch to
75 ohms, and set the termination switches of inter¬
mediate monitors to high impedance (Hi-Z) posi¬
tion.
Monitor Monitor
Table 1
Type of
coaxial cable
RG-59/U
(3C-2V)
RG-6U
(5C-2V)
RG-11/U
(7C-2V)
RG-15/U
(10C-2V)
Recommended
maximum
cable length
(ft)
825
1,650 1,980 2,640
(m)
250
500 600 800
Wiring precautions:
• Do not bend coaxial cable into a curve whose
radius is smaller than 10 times the cables diame¬
ter.
• Never staple the cable-not even with circular sta¬
ples. Mismatching will occur.
• Never crush or pinch the cable.
All of these will change the impedance of the
cable and cause poor picture quality.
♦ The maximum extensible coaxial cable length
between the camera and the monitor is shown in
the table 1. Since cable quality varies among man¬
ufactures, verify video quality before final installa¬
tion if maximum lengths are to be used.
- 7 -

LENSES
1. Selection of Lens
<Manual and Fixed Iris Lenses>
''''' ■ '---^Models
Specifications
WV-LM4R5A
(Wide Angle)
WV-LM6B2
(Wide Angle)
WV-LM12B2
(Standard)
WV-LF4R5C3A
(Wide Angle)
WV-LF9C3A
(Wide Angle)
Image Size
1/2" (6.4 (H) x 4.8 (V) mm)
1/3" (4.8 (H) x 3.6 (V) mm)
Focal Length
4.5 mm
6 mm
12 mm 4.5 mm
9 mm
Maximum
Aperture Ratio
1 : 1.4 1 : 1.4
1 : 1.4 1 : 1.2
1 : 1.2
Angular Field
of View
H
72.6°
[56.9°]
56.8°
[43.5°]
30.4°
[22.8°]
56.4°
29.6°
V
56.7°
[43.61
43.5°
[33.0°]
22.8°
[17.1°]
43.3°
22.2°
Iris
Manual
Manual Manual
Fixed Fixed
Focusing Range
Adjusted by Camera
Mount
CS-mount, 1"-32UN
Filter Size
037.5 mm, P = 0.5
None None
030.5 mm, P = 0.5 030.5 mm, P = 0.5
Dimensions 01-3/4" x 1-5/8"
(044 x 41 mm)
01-11/16" x 1-9/16 1 ’
(a43 x 39 mm)
el-11/16“ x 1-9/16"
(043 x 39 mm)
01-3/8" x 1-7/16"
(034.4 x 36 mm)
01-3/8" x 1-7/16"
(034.4 x 36 mm)
Weights
0.20 lbs. (93g)
0.10 lbs. (45g) 0.08 lbs. (35g)
0.06 lbs. (29g)
0.05 lbs. (23g)
• [ indicates an angle used with the camera WV-BP110 Series.
• Dimensions and weights indicated are approximate.
• Specifications are subject to change without notice.
- 8 -

2. Mounting the Lens
When you use the lens other than listed on page 8,
lens mount should be special C-mount (CS-mount T-
32UN) and lens weight should be less than 0.99 lbs
(450g). If not, both the lens and camera should be
secured.
The protrusion of the rear of the lens should be as
shown below.
CS-mount: Less than 1/4" (7 2 mm)
FOCUS OR FLANGE-BACK
ADJUSTMENT
The following adjustment should be made by
qualified service personnel or system installers.
1. Loosen screws on the flange-back adjusting ring
2. Turn the flange-back adjusting ring to the desired
position.
Caution:
Do not turn this ring too much to counterclock¬
wise as this could damage the inner glass
and CCD image sensor.
3. Tighten the screws on the flange-back adjusting
ring.
- 9 -

INSTALLATION OF CAMERA
• Mounting from the top
Remove the mount adaptor from the bottom of the
camera as shown. The hole is the standard photo¬
graphic pan-head screw size (1/4' - 20).
Make sure that two original screws are used when
mounting the mount adaptor; longer type screws
may damage inner components.
PREVENTION OF BLOOMING
AND SMEAR
When the camera is faced toward spot light or other
bright lights and light reflecting objects, smear or
blooming may appear. Therefore, the camera should
be operated carefully in the vicinity of extremely bright
objects to avoid smear or blooming.
LENS MAINTENANCE AND
CLEANING
1. Remove the lens, and inspect the camera CCD
faceplate through the lens mount opening to
assure that the faceplate is free of smudges or
particles of dirt.
2. Clean the CCD faceplate, if necessary, using lens
tissue or a cotton tipped applicator and ethanol.
3. Install the new lens.

SPECIFICATIONS
Pick-up Device:
Scanning Area:
Synchronization:
Scanning System:
Scanning:
Horizontal:
Vertical:
Horizontal Resolution:
Video Output:
Signal-to-Noise Ratio:
Electronic Light Control:
Minimum Illumination:
Lens Mount:
Ambient Operating Temperature:
Power Source:
Power Consumption:
Dimensions (without lens):
Weights (without lens):
512 (H) x 492 (V) pixels. Interline Transfer CCD
4.8 (H) x 3.6 (V) mm (Equivalent to scanning area of 1 /3" pick-up tube)
Line-locked mode
2 : 1 interlace
525 lines/60 fields/30 frames
15.75 kHz
60 Hz
380 lines
1.0 Vp-p composite,75Q/BNC connector
46 dB
Equivalent to continuous variable shutter speed between 1/60 s and
1/80,000 sec.
0.015 footcandle (0.151ux) at FI .4, AGC ON
CS-mount
-22°F - 122°F (-30°C - +50°C)
WV-BP110 120V AC 60 Hz
WV-BP114 24VAC60Hz
WV-BP110 2.3W
WV-BP114 2.3W
2-5/8” (W) x 2-9/8" (H) x 4-5/8" (D)
(67 (W)x 65(H) x 118(D) mm]
WV-BP110 1.3 lbs. (0.61 kg)
WV-BP114 1.0 lbs. (0.45 kg)
Weights and dimensions indicated are approximate.
Specifications are subject to change without notice.
-11-

STANDARD ACCESSORY
OPTIONAL ACCESSORIES
Body Cap
Lenses : WV-LM4R5A, WV-LM6B2, WV-LM12B2
WV-LF4R5C3A, WV-LF9C3A
Panasonic
Broadcast & Television Systems Company
Division of Matsushita Electric Corporation of America _
CLOSED CIRCUIT VIDEO EQUIPMENT DIVISION
Executive Office: One Panasonic Way, Secaucus, New Jersey 07094
Regional Offices:
Northeast: 43 Hartz Way, Secaucus, NJ 07094 [phone]
Southeast: 1854 Shackleford Court, Suite 115, Norcross, CA 30003 [phone]
Midwest: 1707 North Randall Road, Elgin, IL 60123 [phone]
Southwest: 4500 Amon Carter Blvd., Ft. Worth, TX 76155 [phone]
Western: 6550 Katella Ave., Cypress, CA 90630 [phone]
MATSUSHITA ELECTRIC OF CANADA LIMITED
5770 Ambler Drive, Mississauga, Ontario, L4W 2T3 Canada [phone]
PANASONIC SALES COMPANY
DIVISION OF MATSUSHITA ELECTRIC OF PUERTO RICO, INC.
San Gabriel Industrial Park, 65th Infantry, Ave. KM. 9.5 Carolina, Puerto Rico 00630 [phone]
N1193-0
YWV8QA3218AN Printed in Japan
