NexxTech 1519001 User manual

Cat. No.
1519001
Universal Remote
0
CBL
SAT
V
CR
DVD

23
Battery Installation
1. Push down on the tab on the back of the
remote and lift off the cover.
2. Install 2 AAA alkaline batteries (not in-
cluded) into the battery compartment as
indicated by the polarity symbols (+ and -)
marked inside.
3. Replace the cover.
When the remote’s range decreases or it does
not operate properly, replace the batteries. You
have 2 minutes to change the batteries without
losing codes you have programmed. However,
do not press any buttons until batteries are
installed. If buttons are pressed without batter-
ies in the remote, all codes will be lost.
Battery Saver
Your remote automatically times out if the
buttons are pressed more than 30 seconds. This
will save your batteries should your remote get
stuck in a place (for example, between sofa
cushions) where the buttons remain pressed.
TV Volume/Mute Punch-Through
The TV Volume/Mute punch-through feature
lets you control the Volume and Mute function
of your TV in any mode programmed to be a
VCR, DVD, Cable, or SAT device without
changing to TV mode.
TV/VCR Punch-Through
VCR Punch-through is only available in TV
mode and any mode programmed for Cable,
the 6 VCR keys (Play, Pause, Stop, Record, FF
and Rewind) will punch-through to the device
programmed under VCR (in TV mode), or any
mode programmed for Cable.
Setup
Introduction .................................................... 2
Setup ............................................................... 3
Battery Installation..................................... 3
Battery Saver.............................................. 3
TV Volume Punch-Through ....................... 3
TV/VCR Punch-Through ........................... 3
Button Functions ............................................ 4
TV/VCR and TV/DVD Combo units ........ 5
Code Programming ......................................... 6
Direct Code Entry ...................................... 6
Code Search ............................................... 7
Code Identification .................................... 8
Product Operation ........................................... 8
Troubleshooting .............................................. 9
Table of Contents
Introduction
Thank you for buying this Nexxtech 3-in-one
Universal Remote. You can use your remote to
replace a broken or lost remote or combine the
functions of up to three remotes.
This remote control operates the common
features of most (but not all) models and
brands of IR (Infrared) controlled video
equipment. This remote may support functions
that are not available on your device. Some
functions of your particular device (such as
menu functions) may not be controlled by this
remote. In such cases, use the original remote
control for your device.
Please use this manual to become familiar with
your remote, then install batteries and set up
your remote for your particular device and
brand.

45
P(Program) See page 6.
0-9 For channel number or numeric
entries.
Enter To enter channel numbers for some
devices.
Last Goes to last channel viewed.
Rew, Play, FF, Pause, Stop, Rec
VCR transport keys.
TV/VCR and TV/DVD Combo units
For TV/VCR and TV/DVD combo units, you
will need to set up two different buttons to
control both parts of the combo unit. (See
“Direct Code Entry.”) For example, set up a
code under the TV button to control the TV
part of the combo unit AND a separate code
for the VCR or DVD under any other button
you choose.
Button Functions
Note: Some buttons on the remote might have
functions that are labeled differently on the
device you are controlling, depending on the
brand and model of your device. For example,
Last may be called RECALL or Previous
Channel; ENTER may be called DISPLAY.
Also, this remote can only operate features
that exist on your device. For example, your
device must have Previous Channel capability
for the Last button to operate this feature.
The remote powers on in TV mode.
Power To turn selected device on or off.
Menu Press and release Shift then Menu
to display the menu on the TV. The
red LED is on continuously to
indicate the remote is in Menu
mode, VOL UP/DOWN keys oper-
ate as cursor right/left, CH+/- keys
operate as cursor up/down, and
Mute operates as OK. Press Exit key
to exit Menu.
Info Brings up current Channel and
system information.
Guide To view the program guide.
Vol+/- To adjust the volume level.
M(Mute) To mute or restore the volume.
CH+/- To change to next higher (or lower)
channel.
Shift Press and release to access buttons
labeled in blue (red indicator stays
on). Press again to exit Shift mode.
Exit Used to exit or clear on-screen menus.
A-B Operates as TV/Video, TV/VCR,
etc., depending on mode.
Button Functions, cont.

67
Programming with Code Search
If your product does not respond after you
have tried all the codes for your brand, or if
your brand is not listed, try searching for your
code by following these steps.
1. Manually turn on the device (TV, VCR,
etc.) to be controlled.
2. Press and hold the P (Program) button until
the red indicator stays on. Release the P
button.
3. Press and release the desired mode button
(TV, VCR, etc.). The red indicator blinks,
then stays lit.
4. Press the Channel Up button repeatedly (up
to 300 times) until the device to be con-
trolled changes channels.
If you accidentally overshoot the desired
code, press the Channel Down button to
backtrack through the library until the
device changes channels. Pressing Channel
Up changes the direction to forward again.
5. Press and release the Enter button to set the
code.
If the device does not have a Channel Up
button, use Play (VCR/DVD) or Power in-
stead. If you go all the way through the code
library without finding the correct code the
indicator blinks a few times then goes off.
The Code Search method above assumes that
you want to store VCR or DVD codes under
the VCR/DVD button, SAT or Cable codes
under SAT/CBL, etc. If you want to store a
SAT code under VCR/DVD, first press the P
(Program) button. Then press VCR/DVD.
Then enter any SAT code from the code list.
Then proceed from step 4 for Code Search
above.
Code Programming
The P (Program) button is used to program the
remote. You can program the remote using the
code for your brand of device from the code
list, or search through the library of codes until
you find a code that works for your device.
You can store any kind of code under any
mode (except TV). For example, you can store
a CD code under the SAT/CBL button, or an
Audio code under the DVD/VCR button, etc.
However, you can only store TV codes under
the TV button.
Direct Code Entry
1. Press and hold the P (Program) button until
the red indicator stays on. Release the P
button.
2. Press and release the desired mode button
(TV, VCR, etc.). The red indicator blinks,
then stays lit.
3. Enter the 3 digit code from the code list.
Note: The red indicator turns off after a
valid code entry and flashes for an invalid
code.
4. With your device on, press Channel Up. If
the device responds, no further setup is
required.
Note: If some buttons on your device do not
operate, try one of the other codes for your
brand.
Code Programming, cont.

89
1. Press and hold the P (Program) button until
the red indicator stays lit. Release the P
(Program) button.
2. Press and release the desired mode button
(TV, VCR, etc.). The red indicator blinks,
then stays lit.
3. Press and release the P (Program) button.
The indicator light blinks off.
4. To find the first digit for the code stored
under the mode key you pressed in step 2,
press each numeric key from 0-9 in turn.
When the indicator blinks off, the number
you pressed is the first digit for the code
you are searching for.
5. Repeat step 4 to find the second and third
digits. (Indicator goes off when third digit is
found).
Operation
1. Press the mode button for the desired
device.
2. Aim the remote at the device.
3. Press POWER to turn on the device.
4. Press other buttons to operate the features
of your device.
Note: The REC button must be pressed twice
to record from your VCR. For some brands of
VCRs, you might need to press the REC
button once, then press it again for three
seconds.
Code Identification
Remote does not operate your device.
• Press the mode button of the device you
want to control.
• Program the remote with a new code.
• Install new batteries. (You might have to
reprogram your remote after installing new
batteries.)
• Remote may not be compatible with your
device.
Remote does not operate some features of
your device.
• Program remote with a new code.
• Remote may not be able to operate all
features of your device or button names
might be different than your device.
Indicator light blinks after you program a
device code.
• Remote did not accept the code.
• Try to program the code again or try a
different code.
Troubleshooting

10 11
ORBYX ELECTRONICS WARRANTY
ORBYX Electronics warrants that this product will be free from
defects in materials and workmanship for a period of ninety (90) days
from the date of purchase. Within this period, simply take the product
and your proof of purchase to any ORBYX Electronics store or dealer
and the product will be repaired without charge for parts and labour.
ORBYX Electronics reserves the right to charge for transportation.
Any product which has been subject to misuse or accidental damage is
excluded from this warranty. This warranty is only applicable to a
product purchased through ORBYX Electronics’ company owned
stores and dealers and to a product that is presented for repair in a
country where ORBYX Electronics offers the product for sale. While
this warranty does not confer any legal rights other than those set out
above, you may have additional statutory rights which will vary under
the laws of the various countries, states, province and other govern-
mental entities in which ORBYX Electronics operates. This warranty
is subject to all statutory rights you may have in the country of
purchase.
GARANTIE ORBYX ELECTRONICS
ORBYX Electronics garantit ce produit contre tout vice de matière ou
de fabrication pour une période de quatre-vingt-dix (90) jours à
compter de la date d’achat. Au cours de cette période, vous n’avez
qu’a retourner le produit, accompagné d’une preuve d’achat, à tout
magasin ou detaillant ORBYX Electronics où il sera réparé sans frais
pour les pièces et la main-d’oeuvre. ORBYX Electronics se réserve le
droit d’imputer des frais de transport. La garantie ne s’applique pas
aux produits endommagés suite à un mauvais usage ou à un accident.
La garantie s’applique qu’a un produit acheté dans un magasin de la
compagnie ORBYX Electronics ou chez un détaillant ORBYX
Electronics et à un produit qui est vendu dans le pays où l’on fait la
demande de réparation au titre de la garantie. Bien que cette garantie
n’accorde aucun droit particulier autre que ceux susmentionnés, il se
peut que vous puissez jouir d’autres droits qui varient selon le pays,
l’état, la province ou l’entité gouvernementale où ORBYX Electronics
exerce ses affaires. Cette garantie se conforme à tous les droits légaux
que vous pourriez avoir dans le pays d’achat.
Distributed exclusively in the U.S. by:
Orbyx Electronics, LLC
501 South Cheryl Lane,
Walnut, CA 91789.
Imported in Canada for/Importé au Canada pour:
Orbyx Electronics,
Concord, Canada, L4K 4M3.
For parts, service, and general inquiries please call:
1-866-363-3059.
Pour pièces, service et demandes générales, s’il vous plaît, appelez: 1-
866-363-3059.
Limited Warranty/Garantie Limiteé U.S.A & Canada
© 2004 ORBYX Electronics. All Rights Reserved.
Limited Warranty - Canada
Who is Providing This Warranty?
• Orbyx Electronics, LLC (“Orbyx), as the distributor of this
Nexxtech product (your “Product”).
What Does This Warranty Cover?
• This warranty covers defects in materials or workmanship in your
Product under normal use and conditions.
What is the Period of Coverage?
• This warranty covers your Product for 90 days from the original
purchase date.
Who Is Covered?
• This warranty covers the original consumer purchaser. Coverage
terminates if you sell or otherwise transfer your Product.
What Will We Do To Correct Problems?
• We will repair your Product or replace your Product with a new or
reconditioned equivalent product, at our option.
How Do You Get Service?
• Call Orbyx TOLL FREE at 1-866-363-3059 for instructions for
obtaining warranty service from Orbyx’s authorized service
providers.
• Or, return your Product directly to the retail store from which you
purchased the Product.
• When you obtain service for your Product, you must provide a
purchase receipt (or other proof of the original purchase date) and a
description of the defect(s).
What Does This Warranty Not Cover?
• This warranty DOES NOT COVER:
• damage due to misuse, abuse, alteration, unauthorized repair, or
accident (such as improper electrical current);
• damage due to “acts of God” (such as lightning) or other contingen-
cies beyond our control;
• cosmetic damage;
• externally generated static, signal reception or antenna problems not
caused by your Product; or batteries.
• This warranty also DOES NOT COVER, and in no case will we be
liable for, any incidental damages (such as transportation costs to
and from an authorized service provider, or loss of time) or
consequential damages (such as costs of repairing or replacing other
property which is damaged, including tapes, discs, speakers not
included with your Product or other accessories, or external
electrical systems) resulting from the use of your Product. Some
states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion may not
apply to you.
• Defacing the serial number, or using your Product for commercial or
institutional purposes, voids this warranty.
Are There Other Warranties?
• There are no express warranties other than those expressed herein.
Neither the sales personnel nor any other person is authorized to
make any other warranties or to extend the duration of any
warranties.
• ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED
WARRANTY OF MERCHANTABILITY (AN UNWRITTEN
WARRANTY THAT A PRODUCT IS FIT FOR ORDINARY USE),
ARE LIMITED TO 90 DAYS. Some states do not allow limitations
on how long an implied warranty lasts, so the above limitation may
not apply to you.
How Does State Law Apply?
• This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state.
Limited Warranty - USA

Distributed exclusively in the U.S. by:
Orbyx Electronics, LLC
501 South Cheryl Lane,
Walnut, CA 91789.
Imported in Canada for/Importé au Canada pour:
Orbyx Electronics,
Concord, Canada, L4K 4M3.
Cat. No.
1519001
Universal Remote
