NIME audiodesign Elite Two User manual
OWNER’S MANUAL
High-end loudspeaker
Model: Elite Two
OWNER’S MANUAL
Dear Music Lover,
Thank you for your decision to purchase one of NIME audiodesign loudspeaker model and thank
you for entering our family. No matter which model you choose your audiophile senses will be satisfied
with the highest quality music reproduction and unique design that will fit any contemporary interior.
The light motive of the brand was and until this moment remains “Luxury of sound” which allows
a small insight into the glamour and magnificence of sound reproduction. By mixing contemporary
design, the most quality components and materials with the timeless, inviolable Italian style we have
enriched the audiophile community with unique models that meets the highest market requirements.
The roots of the brand are grown in Italy, in Viareggio known as a place where luxury expression
reaches its maximum and where the impact of exclusive yachts construction left the imprint on NIME
speakers handcrafting.
A beauty in every sense always guided our team. Understanding that the real beauty is in details,
we invested all possible efforts not to become “one of the many” with classic and monotonous designs.
The mission and main goal was to stand out, to be unique, to overachieve and amaze you.
OWNER’S MANUAL
SET-UP
The initial set-up of a Nime audio loudspeaker is relatively easy. Please take your
time reading the guidelines and more detailed instructions on the following pages of
this manual after completing the rest four steps as listed below.
1.
Unpacking.
Carefully remove the loudspeaker from the packaging and position it
with its underside on the floor. Remove the white cloth cover around the
loudspeaker. We suggest that you keep the box and white cloth for future use.
2.
Positioning.
Place the loudspeaker facing the listening area at its desired
position in the room. Remove the foam plugs from the rear bass re ex port (if
provided with your loudspeaker model).
3.
Connecting.
While the amplifier is switched off, connect each loudspeaker to the
amplifier with the speaker cable. Turn the volume level all the way down and power
the amplifieron.
4. Listening. The loudspeaker is now ready to play. Optimal performance will only
be realized after careful positioning and running- in the speakers as described over
the course of the following pages. In order to achieve the full speaker capacity follow the
operetion mode between 8-12 weeks. Feel free to contact our Customer Service department with
any further questions or for additional assistanc
OWNER’S MANUAL
HIGH SOUND PRESSURE LEVELS CAUTION
Listening to high sound pressure levels over a longer period of time may harm your
hearing. To avoid auditory effect do not listen to high sound levels over a longer
period of time.
Children should be supervised to ensure that they do not play with the
appliance.
Do not use abrasive cloths or sponges for cleaning or other cleaning products,
before checking compatibility with the speakers.
Don’t obstruct the passage in the various environments; take care to lay the cables in cable ducts.
The place of destination must also ensure a horizontal and stable position.
Do not leave the speakers exposed to a heat source or in a high-temperature location, such as in
the sun or near a heat source. High temperatures can damage the electronic circuitry and
compromise the quality of sound reproduction.
Do not leave the speakers in dusty or dirty locations as it may damage components.
Do not leave the speakers in cold areas. Returning to normal temperature can cause
condensation inside the unit.
Do not operate the units outside of the following temperature range: from -4° to 131°F (from-20°
to 55°C)
Avoid wetting and exposing to steam.
Do not open the cabinets of the speakers for any reason the speaker. Tampering of any
component will void the warranty, and may result in generation of potentially hazardous
electromagnetic fields
OWNER’S MANUAL
PRODUCT DESCRIPTION
In order to be among the best on the market, innovators have to ensure that another must follow
every big achievement.
Elite Two is a result of detailed technical planning and designing based on Elite One. Elite Two is
a 2-way, closed case speaker that represents a real fusion of form and musicality by Nime Audio design.
Uncompromised design and assembly quality became our trademark. Elegant and functional
thick, steel reinforcements are supporting and cushioning the interior where the drivers are based. Much
attention was dedicated to every single detail in order to deliver uncompromised quality to our valuable
partners and faithful audiophiles.
Elite two is a result of deep passion and a faultless work, a synthesis that expresses beauty.
Once you try Elite TWO speakers and feel the essence of the music flowing trough its channels you will
understand the full meaning of the phrase “Made in Italy”.
OWNER’S MANUAL
TECHNICAL SPECIFICATION
EnclosureTypeWoofer
Close box
Tweeter
3 cm CeramicDome
MinimumAmplifierPower
20 Watts perchannel
Frequency Response
34 Hz –20 kHz +/- 3 dB
Enclosure Dimensions (H x W x D)
1180 x 500 x 700mm
Weight
40 Kg each
Woofer
22 cm Ceramic Cone Woofer
Nominal Impedance 8 ohm
Sensitivity
90 dB
Glossy white, Lacquered black, Matt black, Satin steel,
Personalized lacquering
Available finishingof thespeakers
OWNER’S MANUAL
POSITIONING
Loudspeaker placement
The starting point for any setup will be to create a triangle
between each loudspeaker and the listening seat. Each side of the
triangle should have about the same distance. From this starting
point the best possible sound staging and sound balance can be
found.
Distance between loudspeakers
Setting the distance between the speakers is a trade-off
between a wide sound and a precise center image. The farther
apart the speakers (with the same listening position) the wider the
sound stage, however the center image weakens. Achieve the best
possible balance for your listening taste.
Distance between loudspeaker and the rear wall
The distance to the rear wall should be at least 0.5 meters. The rear wall reacts the low frequency
sound into the room making the sound more bass-heavy with more slam and changes the tonal balance of
the sound. The nearer the rear wall the more bass. But this will also color the sound and make the room
impose the sound even further in the bass region. Move the speakers back and forth to achieve the right
OWNER’S MANUAL
tonal balance (with the listening seat at the same position). Moving the speaker further into the room also
improves the depth of the soundstage. Achieve the right trade-off between the tonal balance and the
depth of thesoundstage.
Position of the listening point
The distance between the speakers and the listening position, also called the sweet spot, should
be at least 7 ft (2 –2.5 meters) for the sound from the woofers, midranges and tweet- ers to integrate. Be
careful not to have the listening position right next to a wall. In the best listening position everything
snaps into focus, the soundstage is precise and spacious and the tonal balance is just right. Move the
listening position back and forth to achieve this.
OWNER’S MANUAL
CONNECTING THE SPEAKERS
Before connecting the loudspeakers to your amplifier, switch off the amplifier completely.
Step 1: Connect a two-pole loudspeaker cable to the binding posts of the LEFT speaker, located
at rear of the Cabinet. Connect one cable lead to the red (+) post, and the other cables lead to the white (–)
post. Connect a two-pole loudspeaker cable to the binding posts of the RIGHT speaker, located at rear of
the Cabinet. Connect one cable lead to the red (+) post, and the other cables lead to the white (–) post.
Step 2: With your amplifier switched off, connect the other end of the left loudspeaker cable to
the left left loudspeaker outputs of the amplifier. Take care to ensure the correct polarity: Chose the red
(+) output and white or black (-) output according to the loudspeaker binding posts.
Ensure that the positive and negative cables (+/-) do not make contact with each other.
Otherwise your amplifier or loudspeakers may be damaged. Ensure that the connectors
have a clean contact area and that the contact is tight., loudspeaker cables that will suit
both your electronics and the NIME loudspeakers. Tighten the posts and check the
contact regularly to make sure that it hasn’t loosened over time.
