NISBETS ESSENTIALS DA536 User manual

Chest Freezer
Instruction manual
Model • Modèle • Modell • Modello • Modelo • Malli:
DA536
NL Diepvrieskist
Handleiding
7IT Congelatore a pozzetto
Manuale di istruzioni
22
FR
Congélateur coffre
Mode d'emploi
12 ES Arcón congelador
Manual de instrucciones
27
DE Gefriertruhe
Bedienungsanleitung
17 PT Arca frigorífica
Manual de instruções
32
DA536_ML_A5_v3_20210826.indb 1DA536_ML_A5_v3_20210826.indb 1 2021/8/26 13:142021/8/26 13:14

2
UK
Safety instructions
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out
installation and any repairs if required. Do not remove any
components on this product.
• Consult Local and National Standards to comply with the
following:
- Health and Safety at Work Legislation
- BS EN Codes of Practice
- Fire Precautions
- IEE Wiring Regulations
- Building Regulations
• DO NOT use jet/pressure washers to clean the appliance.
• DO NOT use the appliance outside.
• DO NOT use this appliance to store medical supplies.
• DO NOT allow oil or fat to come into contact with the plastic
components or door seal. Clean immediately if contact
occurs.
• Always carry, store and handle the appliance in a vertical
position and move by holding the base of the appliance.
• Always switch off and disconnect the power supply to the
unit before cleaning.
• Keep all packaging away from children. Dispose of the
packaging in accordance to the regulations of local authorities.
• If the power cord is damaged, it must be replaced by a
Nisbets Essentials agent or a recommended qualified
technician in order to avoid a hazard.
• Children shall not play with the appliance.
DA536_ML_A5_v3_20210826.indb 2DA536_ML_A5_v3_20210826.indb 2 2021/8/26 13:142021/8/26 13:14

3
UK
• Cleaning and user maintenance shall not be made by
children without supervision.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
• Nisbets Essentials recommend that this appliance should
be periodically tested (at least annually) by a Competent
Person. Testing should include, but not be limited to: Visual
Inspection, Polarity Test, Earth Continuity, Insulation
Continuity and Functional Testing.
• Nisbets Essentials recommend that this product is
connected to a circuit protected by an appropriate RCD
(Residual Current Device).
Warning: Risk of fire / flammable materials
• Do not store explosive substances such as aerosol cans with
a flammable propellant in this appliance.
Warning: Keep all ventilation openings clear of obstruction.
Unit should not be boxed in without adequate ventilation.
• Warning: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
• Warning: Do not damage the refrigerant circuit.
• Warning: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are the
type recommended by the manufacturer.
Introduction
Please take a few moments to carefully read through this manual. Correct maintenance and operation of this
machine will provide the best possible performance from your Nisbets Essentials product.
DA536_ML_A5_v3_20210826.indb 3DA536_ML_A5_v3_20210826.indb 3 2021/8/26 13:142021/8/26 13:14

4
UK
Pack Contents
The following is included:
• Nisbets Essentials Chest Freezer
• Instruction manual
Nisbets Essentials prides itself on quality and service,
ensuring that at the time of packaging the contents
are supplied fully functional and free of damage.
Should you find any damage as a result of transit,
please contact your Nisbets Essentials dealer
immediately.
Installation
Note: If the unit has not been stored
or moved in an upright position, let
it stand upright for approximately 12
hours before operation. If in doubt
allow to stand.
1. Remove the appliance from the packaging and
the protective film from all surfaces.
2. To optimize performance and longevity, ensure
a minimum clearance of 2.5cm is maintained
between the unit and walls and other objects,
with a minimum 5cm clearance on the top.
NEVER LOCATE NEXT TO A HEAT SOURCE.
WARNING: When positioning the
appliance, ensure the supply cord is
not trapped or damaged.
WARNING: Do not locate multiple
portable socket-outlets or portable
power supplies at the rear of the
appliance.
Operation
Control Panel
Power indicator light
Run indicator light
Thermostat
Turn On
1. Close the lid of the appliance.
2. Connect the appliance to a mains power supply.
The POWER indicator light starts to illuminate.
3. Set the thermostat to the desired temperature
to turn the appliance on. The thermostat is
graded from 1(-12°C) to 7(-24°C).
Note: Avoid turning on and off too
frequently. After turned off, wait an
interval of 5 minutes before turning
it on again.
Storing Food
To get the best results from your appliance, follow
these instructions:
• Let hot food cool to room temperature before
placing in the appliance. Overloading the
appliance will force the compressor to run longer.
Foods that freeze too slowly may lose quality or
may even spoil.
• Wrap or cover food where possible. Ensure to
wipe containers dry before placing them in the
appliance. This cuts down on frost build-up
inside the appliance.
• Appliance storage compartment should not be
lined with aluminium foil, wax paper or paper
towelling. Liners interfere with cold air circulation
thus make the appliance less efficient.
• Organize and label food to reduce door openings
and extended searches. Remove as many items
as possible at one time and close the door as
soon as possible.
To avoid contamination of food, please respect the
following instructions:
• Opening the door for long periods can cause a
significant increase of the temperature in the
compartments of the appliance.
• If the refrigerating appliance is left empty for
long periods, switch it off. Then defrost and clean
it thoroughly. Let it dry well and leave the door
open to prevent mould developing within the
appliance.
• Clean regularly surfaces that can come in contact
with food and accessible drainage systems.
• Store raw meat and fish in suitable containers in
the refrigerator, so that they are not in contact
with or drip onto other food.
• Note: Please store different food according
to the compartments or targeted storage
temperature of your purchased items.
DA536_ML_A5_v3_20210826.indb 4DA536_ML_A5_v3_20210826.indb 4 2021/8/26 13:142021/8/26 13:14

5
UK
Cleaning, Care & Maintenance
• Always switch off and disconnect the power supply before cleaning.
• Clean the interior of the appliance as often as possible.
• Do not use abrasive cleaning agents. These can leave harmful residues.
• Clean the door seal with warm water only.
• Always wipe dry after cleaning.
Manual defrost
Nisbets Essentials recommend defrosting the appliance when any frost build up inside the freezer reaches
5mm thick.
1. Turn the freezer off and disconnect it from the power supply.
2. Remove food and shelving basket.
3. Put a water container underneath the drain hole at the left lower part of the front. Then unscrew the 2
drain hole covers (one inside the compartment; the other on the front housing).
4. Let the inside frost melt naturally. Wipe off any residue water.
5. When defrost done, put back the drain hole covers.
Troubleshooting
If your Nisbets Essentials appliance develops a fault, please check the following table before making a call to
the Helpline or your Nisbets Essentials dealer.
Fault Probable Cause Solution
The appliance is not
working
The unit is not switched on Check the unit is plugged in correctly and
switched on
Plug or lead is damaged Call Nisbets Essentials agent or qualified
Technician
Fuse in the plug has blown Replace the fuse
Power supply Check power supply
The appliance
turns on, but the
temperature is too
high/low
Too much ice on the evaporator Defrost the appliance
Condenser blocked with dust Clean the Condenser
Lid not shut properly Check lid is shut and seals are not damaged
Appliance is located near a heat source
or air flow to the condenser is being
interrupted
Move the freezer to a more suitable location
Ambient temperature is too high Increase ventilation or move appliance to a
cooler position
Appliance is overloaded Reduce the amount of food stored in the
appliance
The appliance is
unusually loud
Loose nut/screw Check and tighten all nuts and screws
The appliance has not been installed in
a level or stable position
Check installation position and change if
necessary
Difficult to open the
lid
Vacuum created by pressure
differences
Allow 20-30 seconds for pressure to
equalise
